StairsLV LTD

Kondisi: baik (bekas), de-DE Fjdjv A Ta Depfx Am Sjph

Kondisi: baru, Tahun pembuatan: 2025, Dimensions (L/W/H) 4630x3005x2334 mm Weight 12,160 kg Total power requirement 135.6 kW Sanding Line SANDOMAT SFR-R-P1300+SUR-R1300 Fjdpsv A Hftefx Am Seph - Working width: 1300 mm - Min. workpiece length: 465 mm - Min./max. pass-through height: 3-100 mm - Total power: 71.8 kW - Feed speed, stepless: 4-28 m/min - Motor power, first sanding unit: 30 kW - Motor power, second sanding unit: 22 kW - Motor power, third sanding unit: 15 kW - Feed motor: 3.7 kW - Height adjustment motor: 0.55 kW - Dust extraction brush motor: 0.55 kW - Hardness of first sanding roller: 80 Sh - Hardness of second sanding roller: 50 Sh - Third sanding roller: pad-type - Diameter of first sanding roller: Ø 255 mm - Diameter of second sanding roller: Ø 255 mm - Third sanding roller: pad-type - Sanding belt speed, first belt: 21 m/s - Sanding belt speed, second belt: 14.5 m/s - Sanding belt speed, third belt: 11 m/s - Sanding belt dimensions: 1320 × 2000 mm - Compressed air connection: 6 bar - Air consumption: 17 m³/h - Extraction capacity: 9,200 m³/h - Voltage: 400 V / 50 Hz - Dimensions L=2100, W=3005, H=2334 mm - Weight: 6,390 kg SANDOMAT SUR-R1300 Technical data: - Working width: 1300 mm - Min. workpiece length: 390 mm - Min./max. pass-through height: 10-100 mm - Total power: 63.8 kW - Feed speed, stepless: 5-32 m/min - Motor power, first sanding unit: 37 kW - Motor power, second sanding unit: 22 kW - Feed motor: 3.7 kW - Height adjustment motor: 0.55 kW - Dust extraction brush motor: 0.55 kW - Hardness of first sanding roller: 80 Sh - Hardness of second sanding roller: 70 Sh - Diameter of first sanding roller: Ø 255 mm - Diameter of second sanding roller: Ø 255 mm - Sanding belt speed, first belt: 21 m/s - Sanding belt speed, second belt: 18 m/s - Sanding belt dimensions: 1320 × 2400 mm - Compressed air connection: 6 bar - Air consumption: 17 m³/h - Extraction capacity: 9,500 m³/h - Voltage: 400 V / 50 Hz - Dimensions L=2530, W=2170, H=2290 mm - Weight: 5,770 kg

Kondisi: bekas, Tahun pembuatan: 2000, Working width: .- mm Fodpfjvwfl Ujx Am Soph Equipped with 1 sanding unit consisting of: - Combination unit with electronic pad for lacquer sanding - Lacquer sanding - Dust brush - Roller table at infeed, 270 mm - Electronic program control for 50 programs Machine overhauled with brand new feed belt Valves and pressure regulators replaced Machine fully adjusted, Test sanding performed Used Manufacturer: Bütfering Model: Classic 111 C Year of manufacture: 2000 Machine no.: 63608 Working width: 1100 mm Passage height: 160 mm CE type tested GS wood dust certified Belt dimensions: 1120 mm x 1900 mm Feed speed: 4 + 8 m/min. 1 combination unit 3.7/7.5+15 kW, 3 belt speeds with automatic positioning via control Steel roller Diameter: 130 mm Belt speed: approx. 4.5 + 9 + 18 m/s Electronic segmented pad Segment spacing: 50 mm for lacquer sanding, workpiece controlled Location: 97447 Gerolzhofen, free loaded, unpacked Delivery in current condition as inspected, without guarantee or warranty.
