Alp Grafischer Maschinenhandel

Kondisi: bekas, Tahun pembuatan: 2019, Fungsionalitas: berfungsi sepenuhnya,

Kondisi: bekas, CNC mesin bubut otomatis MURATEC MW120 Ncedeydfuaepfx Agljl

Kondisi: baru, Tahun pembuatan: 2025, kapasitas angkut: 4.000 kg, tinggi angkat: 17.550 mm, panjang total: 7.350 mm, Max. lifting capacity: 4,000 kg Max. lifting height: 17.55 m Max. outreach: 13.08 m Breakout force with bucket: 7,766 daN Upward tilt angle: 16° Downward tilt angle: 110° Turning radius (over tires): 3.94 m Lifting: 16 s Lowering: 12 s Telescoping out: 16 s Telescoping in: 13 s Tilting in: 4 s Tilting out: 4 s Engine standard: Stage V Number of cylinders / cylinder capacity: 4 - 3,621 cm³ Rated engine output – power: 100 Hp / 75 kW Max. torque / engine speed: 410 Nm @ 1600 rpm Traction force: 7,850 daN Transmission type: Torque converter Number of gears (forward / reverse): 4 / 4 Travel speed (laden): 25 km/h Max. travel speed: 24.90 km/h Max. travel speed (may vary depending on applicable regulations): 24.90 km/h Parking brake: Automatic parking brake Service brake: Oil-immersed multi-disc brakes on front and rear axles Hydraulic pump type: Gear pump Hydraulic flow rate / hydraulic pressure: 167 l/min – 270 bar Engine oil capacity: 10 l Ncsdpfx Ageydfrxslsl Hydraulic oil capacity: 135 l Fuel tank capacity: 140 l Noise level in operator’s cab (LpA): 79 dB External noise level (LwA): 106 dB Hand/arm vibration: < 2.50 m/s² Steering wheels (front / rear): 2 / 2 Drive wheels (front / rear): 2 / 2 Cab certification: ROPS / FOPS Level 2 Controls: JSM

Kondisi: bekas, Tahun pembuatan: 2025, panjang total: 20.590 mm, - Maximum working height: 43.15 m - Maximum platform height: 41.15 m - Maximum lateral outreach: 27.43 m - Outreach below ground level: 6.00 m - Lifting capacity – unrestricted: 300 kg - Lifting capacity – restricted: 454 kg - Max. persons on platform (restricted/unrestricted outreach): 3/2 - Platform swing range: 160° - Basket arm length: 5.48 / 9.14 m - Vertical basket arm swing range: 130° - Upper structure swing range: 360° - Lateral overhang (axles retracted): 1.14 m - Lateral overhang (axles extended): 1.70 m - Travel speed – stowed: 4.3 km/h - Travel speed – raised: 0.65 km/h - Gradeability – stowed(2): 35% - Tilt sensor activation (longitudinal/lateral axis): 4.5° / 4.5° Ncedpfx Agoydfrrsljl - Turning radius – inside/outside (axles retracted): 8.03 m / 9.96 m - Turning radius – inside/outside (axles extended): 2.90 m / 6.17 m - Tires: 445D50/710 - Drive type: Diesel - Hydraulic tank capacity: 227 L - Fuel tank capacity: 151 L - Noise/sound pressure level (ground): 91 dBA - Noise/sound pressure level (platform): 75 dBA - Vibrations: < 2.5 m/s² - Tire contact pressure: 896 kPa

Kondisi: bekas, panjang total: 4.490 mm, Tahun pembuatan: 2013, kapasitas angkut: 5.500 kg, Crane Ormig 5.5tmE Drive: Electric Ncedpfx Agoydfrlolel Year of manufacture: 2013 Lifting capacity (kg): 5,500

Kondisi: bekas, Tahun pembuatan: 2007, de_HU Ncodpfx Ageydfq Ijlsl

Kondisi: bekas, Tahun pembuatan: 2008, de-01 Ncedpfx Aeydfqzogljl

Kondisi: bekas, Tahun pembuatan: 2003, tokmányátmérő-250-mm Ncjdpoydfpkjfx Agljl

Kondisi: bekas, Tahun pembuatan: 2000, 0001 Ncjdpfx Aeydfpdogljl

Kondisi: sangat baik (bekas), Wheel diameter – max. 300 / 400 mm Wheel width 76 mm Module – max. 6 Module – min. 0.5 Control unit BWO CNC 921 Stroke position adjustment 94 mm/stroke Stroke 82 mm Stroke rate 75 – 1000 strokes/min Number of teeth 5 – 200 Ncedpfxoydfn Te Aglsl Cutter arbor mount SK 45 Table diameter 400 mm Total power requirement 50 kW Machine weight approx. 7.5 t Space requirement approx. 5.0 x 3.8 x 3.4 m Machine in very good condition!

Kondisi: bekas, Raddurchmesser - max. 1000 mm Radbreite 160 mm Modul - max. 7 Modul - min. 0,5 Abstand Tisch - UK Stößel 230 mm Hubzahl 31 - 175 Hub/min Nsdpfxeydfn He Aglecl Werkzeugaufnahme MK 4 Gesamtleistungsbedarf 6 kW Maschinengewicht ca. 5,2 t

Kondisi: bekas, spindeldrehzahlen-18-1280-u-min Nsdpfoydfnysx Aglecl

Kondisi: bekas, Tahun pembuatan: 1999, de Ncodpsydfntofx Aglol

Kondisi: bekas, Tahun pembuatan: 2006, Table length 3000 mm Table width 1500 mm Laser power in watts 4000 Equipment: - Enclosed machine frame with integrated laser unit - Laser unit: CO2 laser TFL 3200 high-frequency unit, maintenance-free turbo radial fan, mirror telescope - Automatic pallet changer - Longitudinal conveyor belt for small parts / waste - Drives: Maintenance-free three-phase servo motors - Additional high-dynamic Xp-axis - Quick-change device for cutting head - Laser cutting head with 5" lens and laser cutting head with 7.5" lens - Programmable cutting gas pressure control - APC capacitive height regulation and process control - Automatic focus position adjustment AutoLas Plus - Laser power control - Positioning laser diode - HI-LAS high-pressure cutting - Fast processing with SprintLAS - ContourLAS for creating smaller holes - PMS plasma sensor system - Automatic sheet edge detection - Programmable power cycles - Compressed air cutting - PCS Process Control System - Microweld Nsdpfjydfngjx Aglocl - Spray unit for safe thick sheet processing - Shut-off automatic - Work area lighting - Sinumerik 840D control: Open PC-based control system, easy operation, online help, integrated e-shop, diagnostic function, maintenance logbook, technology data, teleservice - Workshop programming ToPs 100 lite - Safety: Multi-beam light barriers, fully encapsulated and ventilated beam guidance, monitoring system, multi-chamber extraction and compact dust collector, protective enclosure

Kondisi: bekas, Tahun pembuatan: 1999, X-axis travel: 5,850 mm Y-axis travel: 1,200 mm Z-axis travel: 2,000 mm Control: HEIDENHAIN TNC 430 D Table size: 6,120 x 1,000 mm Table load capacity: 20,000 kg Internal coolant supply: 20 bar Chip conveyor included HEIDENHAIN HR-410 handwheel Tool changer: 60 stations/tools Spindle taper: ISO 50 Motor power: 30 kW Working feed rate: 5,000 mm/min Rapid traverse: 12,000 mm/min Spindle speed: 20–3,000 rpm Ncedpfx Agoydfmiolsl Total power requirement: 41 kW Machine weight approx. 31 t

Kondisi: bekas, Tahun pembuatan: 1999, Travel X-axis: 3,400 mm Travel Y-axis: 1,250 mm Travel Z-axis: 2,000 mm Nodpfx Ajydfmceglscl Control: TNC-430 PA Table size: 4,700 x 1,200 mm Vertical travel: 500 mm Tool holder: ISO 50 Milling head - swiveling 0.001º/0.001º Main motor: 37 kW Chip conveyor included Handwheel HR-410 Tool changer with 60 positions Automatic milling head 45º Machine weight approx. 35 t - Automatic 45º head - Automatic 45º head 0.001º/0.001º - 45º head max. speed 3,000 rpm - 45º head tool holder ISO-50 - Twist head infinitely variable - Front bearing diameter: 150 mm - Station pick up AITEK for 45º and twist head - RENISHAW MP 16+SP2/1

Kondisi: bekas, Tahun pembuatan: 2000, x-travel 1000 mm y-travel 1000 mm z-travel 950 mm Control system: FANUC Pro-3 Feedrate X/Y/Z axes: 1 - 50,000 mm/min Rapid traverse X/Y/Z: 50.00 m/min Tool holder: HSK-A 100 Spindle speed: 20 - 12,000 rpm Spindle motor: 25 / 30 kW Milling spindle torque: 420 Nm Spindle diameter at front bearing: 110 mm B axis: 360 x 0.001° Pallet size: 2x 800 x 800 mm Max. table load: 1,800 kg Workpiece size: 1,000 x 950 mm Max. workpiece height: 1,000 mm Tool magazine with 188 stations Max. tool length: 475 mm Tool diameter: 320 mm Nodpfx Ajydflxeglscl Max. tool weight: 20.00 kg Total power requirement: 65.00 kW Machine weight approx. 30.00 t Space requirements approx. 8.00 x 5.30 x H3.50 m Horizontal machining center with FANUC Professional 3 control system, NC rotary table, electronic handwheel, chip conveyor, KNOLL VRF450/2300 coolant filter, through-spindle coolant, 188-position tool magazine. Spindle replaced in 2023. The machine can be inspected under power.

Kondisi: bekas, Tahun pembuatan: 2003, x-travel 1,600 mm y-travel 1,250 mm z-travel 1,000 mm Pallet size 1,000 x 1,250 mm Control system: SIN840D Drive power (40% duty cycle) 38.00 kW Spindle speed - stepless 20 - 10,000 rpm Drive power (100% duty cycle) 25.00 kW Torque at 40% / 100% duty cycle 288 / 187 Nm Tool holder SK50 Feed rate X/Y/Z axis 20 - 15,000 mm/min Rapid traverse X/Y/Z 60.00 m/min B-axis -150° / +80° x 0.001° B-axis feed rate 3,600° / min C-axis 360 x 0.001° C-axis rapid traverse 1 - 3,600 rpm Table load capacity 3,000 kg Tool magazine with 240 stations Tool diameter 110 mm Tool diameter with 2 adjacent empty pockets 250 mm Max. tool length 650 mm Max. tool weight 15.00 kg Total power requirement 75.00 kW Machine weight approx. 55.00 t Required floor space approx. 12.50 x 8.00 x 4.20 m 5-axis machining center with SIEMENS Sinumerik 840D control Electronic handwheel Operation mode 4 240-position tool magazine 4-station pallet storage system Measuring probe TS641 BLUM laser Ncodpeydflrofx Aglol Coolant system Through-spindle coolant supply Chip conveyor Coolant chiller

Kondisi: bekas, Tahun pembuatan: 2005, Swing diameter: 640 mm Turning length: 1,185 mm Control: SINUMERIK 840D Max. workpiece diameter: 640 mm Distance between spindle heads: 1,500 mm Nsdsydfllopfx Aglecl Slide I: X1 / Y1 / Z1 / B Travel X-axis: 550 mm Travel Y-axis: 180 mm Travel Z-axis: 1,185 mm B-axis: 240° Feed rate X-axis: 0 – 40,000 mm/min Feed rate Y-axis: 1 – 24,000 mm/min Feed rate Z-axis: 1 – 70,000 mm/min Feed rate B-axis: 1 – 20 rpm Rapid traverse X/Y/Z: 40 / 24 / 70 m/min Feed force X/Y/Z S6: 7.00/11.00/7.50 kN Tool holder: HSK 63 Milling spindle speed: 10 – 12,000 rpm Drive power 100% duty cycle: 13.20 kW Drive power 40% duty cycle: 22.00 kW Milling spindle torque: 60 / 100 Nm Number of tools in magazine: 46 Max. tool length: 350 / 200 mm Tool diameter: 80 mm Tool diameter with 2 free slots: 120 mm Max. tool weight: 6 / 10 kg Slide II: X2 / Z2 Travel X-axis: 180 mm Travel Z-axis: 1,050 mm Feed rate X-axis: 1 – 24,000 mm/min Feed rate Z-axis: 1 – 36,000 mm/min Rapid traverse X + Z axes: 24 / 36 m/min Feed force Z / X S6: 11.00 / 9.00 kN Turret (multi-station): 12 positions Tool holder DIN 69880 Ø40 Driven tool stations: 12 Driven tool speed: 1 – 4,000 rpm Drive power 100% duty cycle: 10.70 kW Torque S1: 32 Nm Slide III Z3 mm Travel Z-axis: 1,150 mm Feed rate Z-axis: 1 – 36,000 mm/min Rapid traverse Z-axis: 36.00 m/min Feed force Z-axis S6: 13.00 Nm Main spindle ISM90 Main spindle speed: 10 – 4,000 rpm Drive power 100% duty cycle: 36.00 kW Drive power 40% duty cycle: 45.00 kW Torque at 40% / 100% duty cycle: 800 / 630 Nm Spindle bore: 80 mm Counter spindle speed: 10 – 5,000 rpm Drive power 100% duty cycle: 21.00 kW Drive power 40% duty cycle: 28.00 kW Torque at 40% / 100% duty cycle: 320 / 240 Nm Spindle bore: 80 mm Total power requirement: 70.00 kW Machine weight approx.: 20.00 t Space requirements approx.: 8.50 x 4.50 x H3.10 m Machine features: SIEMENS SINUMERIK 840D control, main and counter spindle, chip conveyor, oil mist separator, DMG Automation WH10top. Main spindle ISM90: Hollow clamping device, C axis, 3-jaw power chuck SMW-AUTOBLOK KNCS-NB-315-91 Counter spindle ISM76: Partial hollow clamping device, C axis, 3-jaw power chuck SMW-AUTOBLOK KNCS-NB-315-91 Workpiece transfer device with integrated conveyor belt, automatic safety cover, differential pressure clamping. With pump skid for coolant: - Pump 1: 17 l/min at 80 bar - Pump 2: 20 l/min at 8 bar - Pump 3: 40 l/min at 20 bar Without coolant system, previously connected to central system. Accessories: Hainbuch collet chuck incl. collets Ø30, 45, 50, 55, 60, 65, 72, 82, 85, 90 1 piece workpiece gripper for turret

Kondisi: siap digunakan (bekas), Fungsionalitas: berfungsi sepenuhnya, tipe perpindahan gigi: hidrostatik, jenis bahan bakar: diesel, ukuran ban: 20.5R25, kondisi ban: 70 persen, jumlah tempat duduk: 1, volume sekop: 2,6 m³, Tahun pembuatan: 2016, jam operasional: 4.855 h, Perlengkapan: kabin, lampu depan tambahan, penggerak semua roda,

Kondisi: baru, berat kosong: 7.300 kg, berat muatan maksimum: 26.700 kg, berat keseluruhan: 34.000 kg, konfigurasi gandar: 3 gandar, panjang ruang muatan: 8.000 mm, lebar ruang muat: 2.550 mm, suspensi: udara, ukuran ban: 235 / 75 R 17,5, warna: lain, tipe perpindahan gigi: lain, ukuran ban depan: 235 / 75 R 17,5, ukuran ban belakang: 235 / 75 R 17,5, kabin pengemudi: lain, kelas emisi: tidak ada, bahan bakar: biodiesel, Perlengkapan: ABS, rem angin bertekanan,

Kondisi: bekas, berat kosong: 3.600 kg, berat muatan maksimum: 12.400 kg, berat keseluruhan: 16.000 kg, konfigurasi gandar: 2 gandar, pendaftaran pertama: 04/2015, panjang ruang muatan: 4.480 mm, lebar ruang muat: 2.150 mm, tinggi ruang muatan: 1.200 mm, suspensi: baja, ukuran ban: 445/45R19.5, warna: oranye, jarak tempuh: 1.001 km, tipe perpindahan gigi: lain, kabin pengemudi: lain,

Kondisi: bekas, jarak tempuh: 144.000 km, daya: 170 kW (231,14 hp), pendaftaran pertama: 05/2014, jenis bahan bakar: diesel, berat kosong: 5.985 kg, berat muatan maksimum: 7.515 kg, berat keseluruhan: 13.500 kg, ukuran ban: 265/70 R 19,5, konfigurasi gandar: 4x2, jarak roda: 3.260 mm, inspeksi berikutnya (TÜV): 07/2026, warna: hitam, kabin pengemudi: kabin harian, tipe perpindahan gigi: mekanis, kelas emisi: Euro 6, suspensi: baja, jumlah tempat duduk: 3, tinggi total: 63.350 mm, panjang ruang muatan: 4.200 mm, lebar ruang muat: 2.350 mm, tinggi ruang muatan: 500 mm, Perlengkapan: ABS, kabin, kemudi berkuasa, kunci diferensial,

Kondisi: bekas, jarak tempuh: 220.500 km, daya: 331 kW (450,03 hp), pendaftaran pertama: 06/2016, jenis bahan bakar: diesel, berat kosong: 14.840 kg, berat muatan maksimum: 17.160 kg, berat keseluruhan: 32.000 kg, konfigurasi gandar: 8x4, rem: pengereman mesin, warna: putih, kabin pengemudi: kabin harian, tipe perpindahan gigi: otomatis, kelas emisi: Euro 6, suspensi: baja, jumlah tempat duduk: 2, panjang ruang muatan: 5.800 mm, lebar ruang muat: 2.380 mm, tinggi ruang muatan: 1.000 mm, Perlengkapan: ABS, kabin, kebisingan rendah, kemudi berkuasa, kendali jelajah, komputer bawaan, kontrol traksi, kunci diferensial, kunci sentral, lampu depan tambahan, lampu kabut, pemanas jok, pendingin udara,

Kondisi: bekas, jarak tempuh: 321.620 km, daya: 375 kW (509,86 hp), pendaftaran pertama: 01/2015, jenis bahan bakar: diesel, berat kosong: 13.569 kg, berat muatan maksimum: 12.431 kg, berat keseluruhan: 26.000 kg, konfigurasi gandar: 6x6, jarak roda: 3.600 mm, inspeksi berikutnya (TÜV): 05/2026, rem: pengereman mesin, warna: putih, kabin pengemudi: kabin harian, tipe perpindahan gigi: otomatis, kelas emisi: Euro 6, suspensi: baja, jumlah tempat duduk: 2, panjang ruang muatan: 4.900 mm, lebar ruang muat: 2.380 mm, tinggi ruang muatan: 800 mm, Perlengkapan: ABS, kabin, kebisingan rendah, kendali jelajah, kontrol traksi, kopling trailer, kunci diferensial, kunci sentral, lampu depan tambahan, lampu kabut, pemanas jok, pendingin udara, penggerak semua roda,
