Karl Karletshofer GmbH

Kondisi: siap digunakan (bekas), Gergaji otomatis sesuai foto, preferensi untuk ekspor. Dijual tanpa garansi dan tanpa penjaminan, sebagai donor suku cadang. Video dapat dikirim melalui WhatsApp. Gijdpfxjyrxyxj Ah Rjp

Kondisi: baik (bekas), Tahun pembuatan: 1989, nomor mesin/kendaraan: 0172, 25286 Technical Specifications: - Saw blade dimensions 400 x 35 x 2.0 mm - Cutting capacity - 90° - Round: approx. 252 mm - Flat: approx. 250 x 160 mm - Square: approx. 210 x 210 mm - 45° Giodpfxow Ei Tde Ah Rsp - Round: approx. 160 mm - Flat: approx. 150 x 150 mm - Automatic material feed - Max. vise opening width: 265 mm - Miter-adjustable vise - Coolant system - Drive 400 V / 0.65 / 1.6 kW - Space requirement: approx. W 1400 x H 950 x D 1700 mm - Weight: approx. 600 kg

Kondisi: bekas, Tahun pembuatan: 2009, KASTOflex F Circular Saw in good condition, complete with documentation. Available for demonstration in Kaunas. Gsdpfx Aewfd Icjh Reip Specification Model: KASTOflex F Year: 2009 Weight: 2,700 kg Power: 13 kW Dimensions: Length 4800 x Height 2225 x Width 2580 mm Automatic feed and discharge Offcut conveyor Mitre cutting Material clamping CNC controller Cutting capacity at 90° (round/square/flat): 150 mm / 140 x 140 mm / 200 x 100 mm Cutting capacity at 45° (round/square/flat): 145 mm / 120 x 120 mm / 160 x 80 mm Cutting capacity at 60° (round/square/flat): 115 mm / 100 x 100 mm / 120 x 60 mm Blade diameter (Ø 350 mm opt.) Ø 400 to 450 mm If you have any further questions, we will be happy to assist you.

Kondisi: bekas, Tahun pembuatan: 1996, Detail Teknis: Godpfx Aevpt Eysh Roip Berat mesin sekitar: 1750 kg Motor gergaji: 2,2 kW Kebutuhan daya total: 5 kW Kecepatan potong: 17 - 90 m/menit Diameter potong: 320 mm Area potong maks.: 320 x 320 mm Panjang pisau gergaji pita: 4.930 x 34 x 1,1 mm Panjang pengumpanan: maks 9x 600 mm Kebutuhan ruang sekitar: 2,6 x 2,4 x 1,40 m Mesin gergaji pita otomatis, pemotongan lurus, diameter potong min. 10 mm, panjang potong min. 6 mm, panjang sisa minimum 15 mm (otomatis 80 mm), berat material maks. 400 kg/m, tangki pendingin 60 l, kapasitas pompa 16 l/menit, tekanan penjepit dapat diatur 20-60 bar, konveyor serpihan 2.400 x 950 mm, meja rol 2.200 x 950 mm, 5 pcs. pisau gergaji pita cadangan 4.930 x 34 x 1,1 mm, manual pengoperasian.

Kondisi: sangat baik (bekas), For sale: heavy-duty metal-cutting band saw in very good condition. Gsdpfx Ahju Udrie Reip

Kondisi: bekas, Tahun pembuatan: 1988, Maximum round cut: 370 mm Piece counter: yes Godpfxjupmwrs Ah Rsip Double stroke possible

Kondisi: bekas, Tahun pembuatan: 2005, Cutting diameter: 220 mm Saw blade length: 425 mm Maximum cut length: 2,500 mm Total power requirement: 0.95 kW Machine weight: approx. 219 kg Space requirement: approx. [missing data] KLAEGER Bandsawing Machine Type PLUS 220, year of manufacture 2005 Cutting range: approx. 300 mm With sophisticated 2,500 mm material length stop and roller conveyors to the front and rear Saw blade length: 425 mm Gsdet Hxayspfx Ah Rjip Hydraulic feed: 16-32 m/min Vise adjustable for mitre cuts Coolant system, elevated version

Kondisi: hampir baru (bekas), Tahun pembuatan: 2004, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 051888, Used automatic circular saw Brand: Pedrazzoli Model: SB 350/45 AP Serial number: 051888 Year: 2004 Head rotation mechanism for angled cuts up to 45° to the left with locking lever. Removable pneumatic anti-burr vice. Pneumatic cylinder for feed movement, with speed adjustment brake. Transmission with dual adjustable-pulley system for variable speed from 15 to 90 m/s. Tilting head mounted on adjustable self-lubricating bushings. Feed stroke of 600 mm, controlled by pneumatic cylinder. Repeatable up to a maximum of 9 strokes for a total travel of 5400 mm. Maximum feeder vice opening: 160 mm. Programmable piece counter. Minimum final cut waste: 160 mm. Feeder speed control valve. Ammeter. Reverse function. Emergency stop button and lockable switch on control panel. Blade lubrication and cooling system with electric pump. Coolant tank with removable pump for easy cleaning. Fully enclosed guard designed for quick blade replacement. Blade diameter: Ø 350 mm. Cutting capacity: Round tubes 0°: 102 mm 45° right: 102 mm Square tubes 0°: 85 mm 45° right: 90 mm Giodjrfw Ikepfx Ah Rop Rectangular tubes 0°: 158 x 85 mm 45° right: 120 x 85 mm Specifications: Three-phase, 380V Dimensions: 1300 x 1350 x 1600 mm Working height: 950 mm Weight: 420 kg

Kondisi: bekas, Tahun pembuatan: 1987, Hydraulic bandsaw, metal saw, reciprocating saw KASTO Unfortunately, the type plate is missing, the specifications are based on a comparable saw. Type: PSB WBS 210 / 230 Year of manufacture: 1980s Cutting capacity - round: Ø 250 mm Cutting capacity - square: 225 x 225 mm Cutting capacity - rectangular: 260 x 100 mm Cutting speed: 11 - 13 - 17 - 22 - 26 - 34 m/min Saw blade length: 400 mm Motor power: 1.4 and 1.8 kW, pole-switchable Power supply: 380 Volt, 50 Hz - Only for 90° cuts, no mitre adjustment - Saw motor with 2 speeds and 3 V-belt steps Gijdpeq R Riiefx Ah Rjp - Hydraulic saw frame feed - Hydraulic cutting pressure adjustment via throttle valve - Rapid lowering of the saw frame - Manually height-adjustable material support table with mm scale via handwheel - Manual material clamping - Coolant system integrated in machine base Required space (L x W x H): 1500 x 700 x 1550 mm Weight: approx. 590 kg

Kondisi: bekas, max. diameter: 400 Bandsaw from KASTO Model OB 1731 Videos: Gedeih N Shspfx Ah Reip ?feature=share ?feature=share

Tahun pembuatan: 2002, Kondisi: diremaj di bengkel (bekas), Beam cutting, drilling, and marking line CIRCULAR SAW Brand: KALTENBACH Model: HDM 1431 / T13 / SP-CNC Year: 2002 Serial No.: 122,400 Weight without accessories: 10,980kg - Circular saw with downward cutting motion. - Saw unit with gear system, drive system, and saw blade mounted on a heavy-duty, wear-resistant rotary bearing. - Heavy-duty saw gear with helical, hardened, and ground gearing operating in an oil bath. - Hydraulic saw blade feed, adjustable according to cutting chart, with very rapid return stroke. - Hydraulic horizontal clamping device. Rear clamping jaw with long-stroke clamping cylinder and automatic return stroke limitation. - Vertical clamping block with self-adjusting pressure plate. - Mitre cutting device for adjusting the angle from 45° left to 35° right. - Material sensor for automatic switch from rapid to working feed. - Hydraulically liftable feed roller for optimal material transport across the saw table. - Economical lubrication system with micro-dosing unit, particularly suitable for cutting profiles. - Chip collector installed on the machine frame. Specifications: - Saw blade housing: 100x4x30x250mm - Saw blade diameter: 1,430mm - Cutting width: 9.5mm - Cutting speed: 10 to 20m/min - Saw feed rate: 0-400mm/min - Rapid return speed: 2,000mm/min - Total power: 25KW Giedpfxohzbips Ah Rop - Working height: 640mm Cutting Capacities: 90º Cuts - Angle steel: 250mm - U steel: 400mm - Double-T beam: 600mm - Wide flange beams: 1,008x302mm - Special wide flange beams: 1,000x450mm Mitre Cuts: IPBv beam - 75º: 1,008x302mm - 60º: 910x302mm - 45º: 716x304mm - 40º: 716x304mm - 35º: 478x307mm IPBs beam - 75º: 1,008x402mm - 45º: 524x357mm IPE beam - 45º: 600x220mm DRILLING UNIT Brand: Kaltenbach Model: KDX 1215 Serial No.: 122,401 Working Capacities: - Angle steel (min - max): 80x65x10mm - 250x250x28mm - U steel (min - max): 80x45mm - 400x110mm - Double-T beam (min - max): 80x46mm - 600x220mm - Wide flange beam (min - max): 100x100mm - 1,008x302mm - Extra wide flange beam: 1,200x500mm Drilling units: 3 - Vertical (Y axis): 1 unit - Horizontal (Z and W axes): 2 units Drilling diameter: 8 - 40mm RPM: 150 - 1100 Rapid feed - Rapid return: 3,850mm/min - 8,000mm/min Drilling spindle feed: 0-500mm/min Rapid spindle positioning: 15,000mm/min Automatic tool changer: 5 tools per drilling unit. 3x5 units = 15 total tools Total power: 45KW MARKING UNIT FEED SYSTEM: - 26 meters infeed with beam feeder + 6 side arms for parallel beam feed to roller conveyors - 30 meters with roller conveyors for outfeed + 6 side arms - 4 side arms for small parts - The majority of rollers are powered - The total length required for infeed to outfeed is approximately 60 linear meters. *Please request machine installation layout drawings.

Kondisi: bekas, Tahun pembuatan: 1977, Cutting diameter: 250 mm Saw blade length: 450 mm Cutting speed: 50/70/100/135 strokes/min Dimensions (L x W x H): 2.6 x 1.8 x 1.1 m Total power requirement: 3.8 kW Machine weight approx.: 1.2 t - Fully automatic band saw machine Gjdpfx Ahscxxw Ue Rsip
