SC PRESSTRADE Romania SRL

Kondisi: baik (bekas), Tahun pembuatan: 2002, 10442 Iedpfx Ajxmd Shsdqjih

Kondisi: baik (bekas), Kondisi: bekas Nomor stok: 968859 Kondisi: Baik Diameter maksimum: 100 mm (4") Panjang maksimum: 100 mm (4") Jumlah gigi: 6-400 Pitch maksimum pada baja: 15 D.P. 12 putaran meja Dikalibrasi secara geometris antara 200 hingga 2.400 rpm Iisdoxlabispfx Adqoh Sistem pemakanan: Pemotongan horizontal atau plunging Motor utama: 1,5 HP Motor pompa pendingin: 0,1 HP Motor sistem hidrolik: 0,1 HP Dimensi: 1120x1120x1680 mm Berat mesin: 500 kg

Kondisi: baik (bekas), Mikron Gear Hobbing Machine Type 132-02 (M23) – Now available at our facility in Ireland: a Mikron Gear Hobbing Machine Type 132-02 (M23) in very good condition. This Swiss-made precision machine is ideal for small gear production, toolrooms, and manufacturers seeking reliable, high-precision gear cutting capabilities. Mikron is renowned for its robust construction and long-lasting performance in gear hobbing applications, making it an excellent solution for cutting spur gears, helical gears, and splines with consistent accuracy. Condition Used Stock number 968859 Status Good Maximum diameter 100 mm (4") Isdpfx Asxlabcedqjih Maximum length 100 mm (4") Number of teeth 6–400 Maximum pitch in steel 15 D.P. 12 table rotations Geometrically calibrated between 200 and 2,400 rpm Feed Horizontal or plunge cutting Main motor 1.5 HP Coolant pump motor 0.1 HP Hydraulic system motor 0.1 HP Dimensions 1120 x 1120 x 1680 mm Machine weight 500 kg

Kondisi: sangat baik (bekas), Mesin pembuat roda gigi LIEBHERR LC 282 CNC Spesifikasi Produsen: LIEBHERR Model: LC 282 CNC Kondisi: Bekas Nomor stok: Factory Diameter maks: 280 mm Putaran hob: 1200 rpm Modul: 7 Diameter meja: 250 mm Putaran meja: 100/200 min Jarak min-maks antara benda kerja dan hob: 30 - 300 mm Kemiringan kepala: 45° Diameter maks hob: 160 mm Iedpfsxgpqcsx Adqoih Berat mesin: 12.000 kg

Kondisi: bekas, Tahun pembuatan: 1999, Technical details: Maximum wheel diameter: 280 mm Maximum module: 7 Machine weight approx.: 13 t Table speed range: 100 rpm Table diameter: 250 mm Minimum number of teeth: 4 Cutter speeds: 1500 rpm Maximum cutter diameter: 160 mm Maximum cutter length: 230 mm Iodpfx Aoxc Ugbjdqjih Well-maintained gear hobbing machine Available from: 01/08/2024

Kondisi: bekas, Tahun pembuatan: 2001, Technical details: Iisdpfxjxc Ic Nj Adqsh Maximum wheel diameter: 280 mm Maximum module: 7 Approximate machine weight: 13 t

Kondisi: bekas, Tahun pembuatan: 2004, Technical details: Maximum wheel diameter: 200 mm Wheel width: 60 mm Maximum module: 7 Machine weight approx.: 15 t Table diameter: 180 mm Table speed range: 100 rpm Cutter speeds: 750 rpm Iijdpfx Adexc E H Sjqjh Well-maintained gear hobbing machine without feeder/automation Available from: 24.08.2024

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2001, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 1719, diameter roda: 280 mm, RINCIAN TEKNIS Diameter roda maks.: 280 mm Modul maks.: 7 RINCIAN MESIN Berat mesin: 13 t Tegangan operasi: 400 V Iiedsw T R Aujpfx Adqoh Tegangan kontrol: 24 V DC

Kondisi: siap digunakan (bekas), Tahun pembuatan: 1999, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 1130, diameter meja: 250 mm, diameter roda: 280 mm, kecepatan spindel (maks.): 1.500 rpm, DETAIL TEKNIS Diameter roda - maks.: 280 mm Modul - maks.: 7 Rentang kecepatan putar meja: 100 rpm Diameter meja: 250 mm Jarak antar sumbu: 15 - 285 mm Jalur aksial: maks. 350 mm Kepala Frais Daya penggerak: 16 kW Jumlah gigi - min.: 4 Kecepatan putar cutter: 1.500 rpm Diameter cutter terbesar: 160 mm Panjang cutter maks.: 230 mm Perjalanan tangensial: 200 mm Kecepatan tangensial: 3.000 mm/menit Sudut putar: ± 45° DETAIL MESIN Iijdpjw T R Ahefx Adqsh Berat mesin kira-kira: 13.000 kg Tegangan suplai: 400 V Frekuensi jaringan: 50 Hz Daya terpasang: 35 kVA

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2000, Fungsionalitas: berfungsi sepenuhnya, diameter roda gigi: 180 mm, jarak gerak sumbu Z: 300 mm, panjang poros: 640 mm, RINCIAN TEKNIS Diameter roda - maks.: 180 mm Modul - maks.: 4 Gerak sumbu axial (sumbu Z): 300 mm Panjang poros - maks.: 490-640 mm Perjalanan Y: 33 - 193 mm RINCIAN MESIN Iodpfsw T R Abjx Adqoih Kebutuhan daya total: 14 kW Berat mesin: 8 t Penghitung benda kerja: 886.067 buah

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2005, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 1443, diameter meja: 180 mm, diameter roda gigi: 200 mm, panjang spindle milling: 230 mm, kecepatan spindel (maks.): 750 rpm, sudut putar sumbu A (min.): -45 °, sudut putar sumbu A (maks.): 45 °, TECHNICAL DETAILS Max. workpiece diameter: 200 mm Table diameter: 180 mm Max. table rotational speed: 100 rpm Centre distance: 15 - 400 mm Machine Base Max. axial travel: 600 mm Milling Head Swivel Device Milling head swivel angle: ± 45 degrees Milling Head Drive power: 27 kW Max. module: 7 mm Max. cutter speed: 750 rpm Max. cutter diameter: 160 mm Max. cutter length: 230 mm Max. tangential travel: 200 mm Max. tangential speed: 3,000 mm/min Counter-holder Ijdow T Ry Tepfx Adqsih Max. counter-holder travel: 540 mm Max. rapid traverse of counter-holder: 15,000 mm/min Max. counter-holder arm force: 13 kN MACHINE DETAILS Total weight approx.: 15,000 kg Ambient temperature: 15 - 38 °C Operating voltage (tolerance +/- 10%): 400 V Operating frequency (tolerance +/- 2%): 50 Hz Control voltage: 24 V DC Hydraulics Hydraulic oil: HLP 46 Max. operating pressure: 70 bar Pump delivery rate: 24 l/min Hydraulic tank capacity approx.: 7 l Max. average noise level: 82 dB(A)

Kondisi: bekas, Tahun pembuatan: 2003, Technical Details: Maximum wheel diameter: 80 mm Maximum module: 3 Total power requirement: 25–35 kW Machine weight approx.: 10 t Workpiece weight: 15 kg Maximum workpiece length: -50 to +450 mm Table diameter: 145 mm Iijdpfx Aewwlunjdqeh Cutter diameter: 90 mm Maximum cutter length: 220 mm Cutter spindle speed: 1,000 rpm

Kondisi: bekas, Tahun pembuatan: 2000, Fungsionalitas: berfungsi sepenuhnya, diameter meja: 132 mm, diameter roda: 130 mm, kecepatan spindel (maks.): 3.500 rpm, diameter alat: 80 mm, sudut putar sumbu A (min.): -40 °, sudut putar sumbu A (maks.): 40 °, Vertically-oriented Gear Hobbing Machine - SAMPUTENSILI S130 CNC Modul Well-maintained vertical CNC gear hobbing machine suitable for shafts and gear wheels with tailstock Also suitable for hard hobbing (ideal for steering pinions) TECHNICAL DETAILS Control type: CNC Control system: Sinumerik 840C Max. gear diameter: 130 mm Max. module: 3 Total power requirement: 15 kW Machine weight: approx. 6 t Space requirements: approx. 2.3 m x 2.5 m x 2.17 m Rapid traverse (radial, axial): 10,000 mm/min Rapid traverse (tangential): 7,500 mm/min Max. gear diameter: 130 mm Max. module: 3 mm Tangential slide travel: 200 mm Radial slide travel: 10/100 mm Axial slide travel: 300/200 mm Milling head speed: 250–3,500 rpm Milling head swivel range: up to ±40° Tool diameter: 80 mm Max. tool length: 240 mm Table speed: 5–1,000 rpm Milling spindle drive: 15 kW Feed range: 0.1–2,000 mm/min Table diameter: 132 mm MACHINE DETAILS Control: Sinumerik 840C Connected load: 40 kVA Iodpfxewmb Nye Adqoih Motor power: 15 kW Weight: 6 t Dimensions: 2,300 x 2,500 x 2,170 mm EQUIPMENT - Hydraulic workpiece clamping - Automatic loading system - Magnetic chip conveyor

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2003, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 0315, berat benda kerja (maks.): 15 kg, diameter roda: 80 mm, panjang penggilingan: 220 mm, panjang benda kerja (maks.): 450 mm, TECHNICAL DETAILS Max. workpiece diameter: 80 mm Workpiece weight: 15 kg Workpiece length: 50 mm – 450 mm Machining Max. module for steel: 3 mm Max. milling slide travel: 250 mm Max. shifting travel: 180 mm Table diameter: 145 mm Table speed: 150 rpm Milling head swivel range: ±45 degrees Centre distance cutter – workpiece: 10 mm – 200 mm Milling unit Cutter diameter: 90 mm Cutter length: max. 220 mm Cutter speeds: 1,000 rpm Spindle drive power: 15 / 23 kW Table drive power: 5.8 / 19.0 kW MACHINE DETAILS Machine weight with counter stand: 10,000 kg Total connected load: 25–35 kVA Iisdpfx Adowmbnpeqeh

Kondisi: diremaj di bengkel (bekas), Tahun pembuatan: 1991, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 27604, panjang umpan sumbu Y: 170 mm, panjang umpan sumbu Z: 200 mm, diameter meja: 160 mm, kecepatan spindel (maks.): 600 rpm, TECHNICAL DETAILS X-axis: 150 mm Y-axis: 170 mm Z-axis: 200 mm Swivel angle: -150/30° Milling unit Max. hob diameter: 130 mm Max. hob length (shank-type cutter): 220 mm Max. module: 3 Cutter length: max. 220 mm Cutter speeds: stepless up to 600 rpm Cutter arbor diameter: 32 mm Table Table diameter: 160 mm Table bore diameter: 63 mm Control & Retrofit Control system: SINUMERIK 840 D SIEMENS Retrofit: Sinumerik 840 D / Windows XP Pro in 2010 MACHINE DETAILS Total power requirement: approx. 20 kW Iodpfx Aev Rdwiodqoih Machine weight: approx. 10,500 kg Required space: approx. 6.8 x 3.7 x 2.85 m

Kondisi: bekas, Tahun pembuatan: 2002, Fungsionalitas: berfungsi sepenuhnya, diameter roda: 130 mm, tinggi benda kerja (maks.): 170 mm, TECHNICAL DETAILS Control system: Sinumerik 840D Iiodpfx Aev I Tmuedqeh Head circular diameter: 80 mm Toothed length: 170 mm Overall length of hob cutter: 245 mm Collet chuck diameter: 32 mm Tool spindle speed: 300 - 3000 rpm Gear diameter: max. 130 mm Gear width: 170 mm Module: 0.5 - 3 Slide travel radial / tangential / axial: 200 / 170 / 250 mm Milling head swivel angle: ± 45° Workpiece tables: Ø 168.14 mm Bore: 65.532 mm Table speed: 0 - 1000 rpm Table bore: 65.532 mm Feed rate X/Z: 1 - 6000 mm/min Rapid traverse X,Z / Y: 6 / 5 m/min MACHINE DETAILS Total power requirement: 48 kVA Operating voltage: 3 x 400 V, 50 Hz Machine weight: approx. 9 t Space requirements: approx. 7.64 x 3.14 x 3.25 m

Kondisi: siap digunakan (bekas), Max. wheel diameter: 150 mm Wheel width 1: 200 mm Module – max.: 4 Module – min.: 1 Control: Sinumerik 840 D Table diameter: 140 mm Axial adjustment – max.: 200 mm Cutter arbor: ISO 40 Max. cutter diameter: 130 mm Max. cutter length: 220 mm Cutter speeds – stepless: 300 – 1200 rpm Cutter slide traverse – max.: 170 mm Milling head – swiveling: + / – 45° Feed rate: 1 – 1500 mm/min Rapid traverse speed: 3000 m/min Max. workpiece diameter in magazine: 150 mm Total power requirement: 50 kW Machine weight approx.: 8.5 t Space requirement approx.: 4.7 x 3.6 x 2.6 m Iisdpfx Adevzhg Noqjh Used CNC Gear Hobbing Machine, Manufacturer: Pfauter, Year of manufacture: 1992, completely overhauled in 2013 by SerWeMa (specialist company), equipped with Siemens Sinumerik 840 D control and workpiece magazine. This is a pre-owned machine; therefore, we sell under exclusion of any warranty.

Kondisi: baru, Eifco gear hobbing machines product range Isdju Egdlspfx Adqsih
