MORI SEIKI NHX 5000

MORI SEIKI NHX 5000

Kondisi: baik (bekas), Fungsionalitas: berfungsi sepenuhnya, Perlengkapan: dokumentasi / manual, konveyor serpihan, Zu verkaufen: Gebrautes Mori Seiki NHX5000 Horizontal-Bearbeitungszentrum in ausgezeichnetem Zustand. Modell: NHX-5000/40 Ledpfx Ajuf S Rzoc Hshk Baujahr: 2012 Die Maschine ist nach vorheriger Absprache vor Ort verfügbar. Lieferbedingung: EXW Székesfehérvár. Auf Wunsch unterstützen wir Sie beim Abbau und Wiederaufbau der Maschine.

Kondisi: baik (bekas), Tahun pembuatan: 2005, Machine as per photos Condition: Very good, apart from a defective slot in the tool magazine. Lodpfx Aevf D Anec Hjhk Tool holders included.

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2012, jam operasional: 45.656 h, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: AX4E -NAOS 12-160, jarak pergerakan sumbu X: 730 mm, jarak lintasan sumbu Y: 730 mm, jarak gerak sumbu Z: 880 mm, beban meja: 500 kg, kecepatan spindel (maks.): 12.000 rpm, TECHNICAL DETAILS Travel X-axis: 730 mm Travel Y-axis: 730 mm Travel Z-axis: 880 mm Maximum spindle speed: 12,000 rpm Spindle drive power: 15 / 11 kW Maximum torque: 102 Nm Tool holder: SK 40 Distance spindle center to table: 80 - 800 mm Distance spindle nose to table center: 70 - 950 mm Number of pallets: 2 Pallet size: 500 x 500 mm Maximum workpiece weight: 500 kg Maximum workpiece diameter: 800 mm Maximum workpiece height: 1,100 mm Pallet change time: 9.5 s Indexing time: 1.49 s Ljdpfx Acsx I Amio Hehk Number of tool stations: 60 Maximum tool diameter: 70 mm Maximum tool diameter with free adjacent slot: 170 mm Maximum tool length: 550 mm Tool-to-tool change time: 0.9 s Rapid traverse: 60 m/min Maximum feed rate: 60,000 mm/min Jog feed rate: 0 - 5,000 mm/min MACHINE DETAILS Total power requirement: 34 kVA Dimensions & Weight Space required: approx. 5,500 x 3,000 x 2,800 mm Machine weight: approx. 11.1 t Operating hours: 45,656 h EQUIPMENT Chip conveyor Coolant system Internal coolant supply IF Knoll Tool changer B axis Pallet changer Oil mist separator Magazine tool breakage control Thread milling Note: Proof of spindle replacement in 2019 is enclosed.

Kondisi: bekas, Tahun pembuatan: 2014, de-to-hu-v1 Lsdsxtbmiopfx Ac Hehk

Kondisi: bekas, Putar di atas penopang 400 mm Ljdpfx Aexg Nd Asc Hohk Putar di atas kereta 350 mm Jarak antara centers 610 mm Gerakan panjang maksimum 560 mm Gerakan lintang maksimum 40+120 mm Kecepatan spindle 40-4000 rpm Diameter lubang spindle 52 mm Revolver dengan 12 stasiun Kontrol: Fanuc 6T Dilengkapi dengan: Lihat foto

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2017, jam operasional: 15.208 h, jarak pergerakan sumbu X: 730 mm, jarak lintasan sumbu Y: 730 mm, jarak gerak sumbu Z: 880 mm, berat keseluruhan: 12.000 kg, kecepatan spindel (maks.): 15.000 rpm, daya motor spindle: 21.000 W, jumlah sumbu: 4, This 4-axis DMG MORI NHX 5000 machining center was manufactured in 2017. It features a maximum spindle speed of 15,000 rpm and travel ranges of 730 mm in both the X and Y axes, with a Z-axis travel of 880 mm. The machine is equipped with a robust pallet size of 500 x 500 mm and has a tool capacity of 40 tools. If you are looking for high-quality machining capabilities, consider the DMG MORI NHX 5000 horizontal machining center we are offering for sale. Please contact us for further details. • Spindle torque: 111 Nm (continuous 85 Nm) • Tool holder: BT40 • Tool magazine capacity: 40 tools (optional magazine for 60 tools) • Rapid traverse (X/Y/Z): 60 m/min • Acceleration (X/Y/Z): 1G • Pallet size: 500 x 500 mm • Number of pallets: 2 • Automatic rotary pallet changer: 2 stations • NC table B-axis: direct drive, indexing 0.001°, max. speed 100 rpm • Maximum pallet load: standard 500 kg (optional 700 kg) • Direct measuring system; linear scale standard • Control unit: CELOS Siemens 840D sl with 21.5" ERGOline multi-touch display • Electronic handwheel: Siemens • Coolant through spindle preparation up to 70 bar • Renishaw probe OMP60 • Tool breakage detection system • Machine status signal light • Water-glycol spindle cooling • Application tuning cycle (ATC) • Machine bed: 3-point support • Power connection: L1 L2 L3 N PE • Connected load: 46 kVA • Max. input current: 67 A • Protection: 125 A • Short-circuit current: 1.25 kA • Max. supply voltage: 4.0 kV • Supply voltage: 400 V ±10 % • Frequency: 50 Hz • Control voltage: AC 230 V / DC 24 V • Operating hours: 27,715 h • Spindle hours: 15,208 h Additional equipment • Knoll KF110/700 Lhodpfx Acoyt Hwze Hjk • Knoll flow monitor • High-pressure coolant system • 2x clamping towers (250 x 250 x 650 mm) TRIAG incl. accessories • 95x tool holders HSK63 (various clamping devices) Technical Specification Taper size: BT 40

Kondisi: bekas, PUSAT BUBUT "MORI SEIKI" MOD. ZL 200SMC Dengan turret ganda bermotor & sub-spindle CNC MSC-501 Panjang pembubutan mm 452 Lsdpfsxwxwtjx Ac Hjhk Diameter maksimum pembubutan mm 388 Diameter maksimum di atas alas mm 510 Jarak antar senter mm 751 Mount spindle A2-6 Kecepatan spindle 4.000 rpm Daya motor spindle 11 kW Jumlah alat 12

Kondisi: diremajakan ulang (bekas), Tahun pembuatan: 2003, Fungsionalitas: berfungsi sepenuhnya, diameter putar di atas sled silang: 510 mm, panjang pembubutan: 752 mm, diameter pembubutan: 390 mm, kecepatan spindel (maks.): 4.000 rpm, gerak cepat sumbu X: 18.000 m/menit, pergeseran cepat sumbu Y: 24.000 m/menit, pergerakan cepat sumbu Z: 24.000 m/menit, kecepatan pemakanan sumbu X: 18.000 m/menit, laju pemakanan sumbu Z: 24.000 m/menit, MORI SEIKI ZL-2035MC CNC Lathe – Technical Specifications The MORI SEIKI ZL-2035MC is a high-precision CNC lathe, ideal for advanced multi-axis turning operations, equipped with twin spindles and powered turrets. Manufactured in December 2002, it is engineered to deliver productivity and accuracy in complex machining. General Features Brand: MORI SEIKI Model: ZL-2035MC Category: CNC Lathe Year of manufacture: 12/2002 CNC Control: MORI SEIKI MSG-501 Machine weight: 5,900 kg Machine Dimensions: Length: 4,350 mm Width: 2,400 mm Height: 2,200 mm Machining Capacity Max swing over bed: Ø 680 mm Max swing over carriage: Ø 510 mm Distance between centers: 752 mm Max turning diameter: Spindle No.1: Ø 390 mm Spindle No.2: Ø 294 mm Max turning length: 520 mm Bar capacity: Ø 65 mm (Ø 51 mm on No.2) Axis Travels X-Axis: No.1: 235 mm No.2: 175 mm Z-Axis: No.1: 520 mm No.2: 490 mm B-Axis: 505 mm Main Spindle Speed: 40 – 4,000 rpm Spindle nose: JIS A2-6 Chuck diameter: Ø 210 mm Minimum programmable C-axis increment: 0.001° Motor power (continuous/30 min): 11 / 7.5 kW Sub-Spindle Speed: 40 – 4,000 rpm Spindle nose: JIS A2-5 Chuck diameter: Ø 160 mm Minimum programmable C-axis increment: 0.001° Motor power (continuous/30 min): 7.5 / 5.5 kW Tool Turrets Turret No.1 Number of stations: 12 Driven stations: Yes Driven tool speed: 4,000 rpm Turning/boring tool size: 25x25 mm / Ø 32 mm Lhodpfx Aoxd Td Uec Hjk Turret No.2 Number of stations: 8 Driven stations: Yes Driven tool speed: 3,000 rpm Turning/boring tool size: 25x25 mm / Ø 32 mm Feed Rates Rapid traverse X-axis: 18,000 mm/min Rapid traverse Z-axis: 24,000 mm/min Rapid traverse B-axis: 24,000 mm/min Manual feed X / Z / B axes: 0 – 1,260 mm/min Included Accessories 5 driven toolholders and various fixed toolholders Chip conveyor Transformer Part ejector arm Coolant tank with pumps Manuals, electrical diagrams, and CE Declaration

Kondisi: bekas, Tahun pembuatan: 2007, de2hu-it-lt-001 Lhsdsw Rrb Hspfx Ac Hok

Kondisi: bekas, Tahun pembuatan: 1961, de2c1c73 Lhedpfx Aewwl I Isc Hok
