Mesin bor radial

TOS / MAS VO 50

Kondisi: bekas, Tahun pembuatan: 2004, Technical details: X travel: 600 mm Y travel: 400 mm Z travel: 400 mm Spindle speed: 63 – 3,150 rpm Stepless feed: 12–3,000 / 6–1,500 (Z) mm/min Quill stroke: 100 mm Swiveling head +/-: 90° Spindle taper ISO: SK 40 Clamping surface: 630 x 400 mm Total power requirement: 8 kW Machine weight approx.: 2.2 t Space requirement approx.: 2 x 1.9 x 1.95 m Giodpfx Ask Hdu Djhusr Universal milling machine with traverse control, mechanical handwheels, rotatable tilting table ±45°, hydraulic tool clamping, partial enclosure, coolant tank, manual

Tahun pembuatan: 2002, Kondisi: diremaj di bengkel (bekas), Beam cutting, drilling, and marking line CIRCULAR SAW Brand: KALTENBACH Model: HDM 1431 / T13 / SP-CNC Year: 2002 Serial No.: 122,400 Weight without accessories: 10,980kg - Circular saw with downward cutting motion. - Saw unit with gear system, drive system, and saw blade mounted on a heavy-duty, wear-resistant rotary bearing. - Heavy-duty saw gear with helical, hardened, and ground gearing operating in an oil bath. - Hydraulic saw blade feed, adjustable according to cutting chart, with very rapid return stroke. - Hydraulic horizontal clamping device. Rear clamping jaw with long-stroke clamping cylinder and automatic return stroke limitation. - Vertical clamping block with self-adjusting pressure plate. - Mitre cutting device for adjusting the angle from 45° left to 35° right. - Material sensor for automatic switch from rapid to working feed. - Hydraulically liftable feed roller for optimal material transport across the saw table. - Economical lubrication system with micro-dosing unit, particularly suitable for cutting profiles. - Chip collector installed on the machine frame. Specifications: - Saw blade housing: 100x4x30x250mm - Saw blade diameter: 1,430mm - Cutting width: 9.5mm - Cutting speed: 10 to 20m/min - Saw feed rate: 0-400mm/min - Rapid return speed: 2,000mm/min - Total power: 25KW - Working height: 640mm Cutting Capacities: 90º Cuts - Angle steel: 250mm - U steel: 400mm - Double-T beam: 600mm - Wide flange beams: 1,008x302mm - Special wide flange beams: 1,000x450mm Mitre Cuts: IPBv beam - 75º: 1,008x302mm - 60º: 910x302mm - 45º: 716x304mm - 40º: 716x304mm Godjhzbipjpfx Ahusir - 35º: 478x307mm IPBs beam - 75º: 1,008x402mm - 45º: 524x357mm IPE beam - 45º: 600x220mm DRILLING UNIT Brand: Kaltenbach Model: KDX 1215 Serial No.: 122,401 Working Capacities: - Angle steel (min - max): 80x65x10mm - 250x250x28mm - U steel (min - max): 80x45mm - 400x110mm - Double-T beam (min - max): 80x46mm - 600x220mm - Wide flange beam (min - max): 100x100mm - 1,008x302mm - Extra wide flange beam: 1,200x500mm Drilling units: 3 - Vertical (Y axis): 1 unit - Horizontal (Z and W axes): 2 units Drilling diameter: 8 - 40mm RPM: 150 - 1100 Rapid feed - Rapid return: 3,850mm/min - 8,000mm/min Drilling spindle feed: 0-500mm/min Rapid spindle positioning: 15,000mm/min Automatic tool changer: 5 tools per drilling unit. 3x5 units = 15 total tools Total power: 45KW MARKING UNIT FEED SYSTEM: - 26 meters infeed with beam feeder + 6 side arms for parallel beam feed to roller conveyors - 30 meters with roller conveyors for outfeed + 6 side arms - 4 side arms for small parts - The majority of rollers are powered - The total length required for infeed to outfeed is approximately 60 linear meters. *Please request machine installation layout drawings.

Kondisi: bekas, Hydraulic Guillotine Shear STEINER Type HTS 30/20 R Machine No. 315 Year of Manufacture: 1982 Cutting length: 3050 mm Cutting thickness: 20 mm Backgauge: 800 mm, CNC-controlled Gsdpfx Ajd Hxx Aehujir Motor power: approx. 30 kW Power supply: 400 Volt, 50 Hz - Backgauge with ELGO positioning control - Backgauge adjustment via ball screw spindles - SICK safety light curtain at the front for operator protection - 3 material support arms with ball rollers - Electric foot switch - Spare blade - Oil cooler with air heat exchanger - Very robust machine in extremely solid design Footprint of base machine (L x W x H): 4650 x 2610 x 3200 mm Weight of base machine: 27,000 kg Transport dimensions (base machine): 4650 x 2610 x 3200 mm Transport dimensions (additional): 3500 x 2450 x 1400 mm Total weight: 27,000 kg Good condition Machine can be inspected in storage at 37235 Hessisch Lichtenau, trial cuts possible. Currently, the hold-downs are being resealed, so a corresponding price adjustment will take place in the next few days.

Tahun pembuatan: 2007, Kondisi: siap digunakan (bekas), jarak pergerakan sumbu X: 3.500 mm, jarak lintasan sumbu Y: 1.200 mm, jarak gerak sumbu Z: 1.500 mm, jumlah sumbu: 5, TOS Varnsdorf WHN130 5-sumbu ini diproduksi pada tahun 2007. Ini adalah mesin bor dan frais horizontal dengan ukuran meja 1800 × 1800 mm dan diameter spindle 130 mm. Mesin ini dilengkapi dengan meja putar dan dikendalikan oleh sistem NCT-104. Pertimbangkan untuk membeli mesin bor TOS Varnsdorf WHN130 ini. Silakan hubungi kami untuk informasi lebih lanjut. • Sistem kontrol: NCT-104 • Meja: berputar, 1800 × 1800 mm Gisdpfox Imtaox Ahujr • W (penjorok spindle): 570 mm • Diameter spindle: 130 mm

Kondisi: siap digunakan (bekas), Lathe, manufacturer Takisawa, model TAL 510, equipped with chuck, quick-change tool post, and live center. Gijdpfjvyuuqex Ahujr

Kondisi: baik (bekas), schleifmaschine-001 Gedpfexcblqsx Ahusir

Kondisi: baik (bekas), Tahun pembuatan: 1979, Model engineering milling machine, universal model milling machine, milling machine, universal milling machine, tool milling machine, drilling and milling machine, model engineering mill - Manufacturer: Zimmermann, Universal Milling Machine Type FZ 1 with extensive accessories - Rotatable cross table: 490 x 400 mm - Travel (X/Y/Z): 320/385/430 mm - Spindle mount: SK30 - Drive: 1.1 kW - Speeds: 560 to 14,000 rpm, 8 steps - Accessories: included, see photos - Dimensions: 1000/680/H1970 mm - Weight: 477 kg Godpfx Ahenzpx Reueir

Tahun pembuatan: 1984, Kondisi: bekas, nomor mesin/kendaraan: 25 948, Outreach: 485 or 1050 mm Roller diameter: 500 mm Passage height: 380 mm Table size: worktable 780 x 800 mm Saw band length: over 2 wheels 3920 - 4050 mm Max. saw blade width: 20 mm Band speed: 15 - 940 m/min Drive motor: 380 V, 4 kW Godpfx Ahob N Eh Heusir Space requirement: 950 x 2130 x 2100 mm Weight: 1740 kg

Kondisi: baik (bekas), Tahun pembuatan: 1988, panjang penggilingan: 1.000 mm, lebar penggilingan: 550 mm, tinggi penggerindaan: 400 mm, diameter roda gerinda: 400 mm, lebar roda gerinda: 100 mm, Manufacturer: ELB-SCHLIFF Model: SWBE 010 ND Year of manufacture: 12/1988 Delivery time: immediate Gedpfju Rqynsx Ahusir Electro-permanent magnetic chuck SAV 1000 x 400 mm Fine pole pitch 45-5 mm Electronic straight dresser with compensation Vertical digital readout Mounting with grinding wheel max. 400 x 100 x 127 mm Spindle motor 7.5 kW, 1435 rpm Taper wedges Coolant system with universal paper band filter Complete documentation

Kondisi: baik (bekas), Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 804, panjang rol: 2.550 mm, lebar kerja: 2.500 mm, ketebalan lembaran (maks.): 16 mm, ketebalan pelat baja (maks.): 16 mm, berat keseluruhan: 12.500 kg, 3-roll plate bending machine 2500 x 16 mm, hydraulic Manufacturer: KUMLA Model: PV 7 H Serial No.: 804, overhauled in 1987 The machine features a very robust construction and has only been used in single-shift operation. Giodpfx Aevxbm Rjhuor Max. bending length: 2500 mm Max. sheet thickness: 16 mm Cone bending device Top roll diameter: 324 mm Bottom roll diameter: 305 mm Hydraulic roll adjustment Dimensions: L x W x H = 5000 x 1600 x 1900 mm Working height: 1000 mm Additionally, a stair platform can be purchased to go with the machine.
