Pusat permesinan vertikal CNC

TRENS MC 100 VA

Kondisi: bekas, Tahun pembuatan: 2020, Technical Details: X-axis travel: 1530 mm y-axis travel: 530 mm z-axis travel: 465 mm Pendulum operation right, fixed table X = 925 mm Pendulum operation left, 2-axis table X = 780 mm Control: Heidenhain TNC 640 Tool magazine: 122 SK 40 holders Spindle speeds - infinitely variable: 12,000 rpm Kdjdpfx Aoyqyfgefiek Spindle torque: 120 Nm Drive power: 22 kW Fixed table dimensions: 920 x 540 mm Table load capacity (fixed table): 2000 kg Maximum workpiece size on fixed table: 900 x 500 x 400 mm Diameter of integrated 2-axis rotary table: 650 mm Rotary table load capacity: 500 kg B-axis swivel angle: -90°/+110° Workpiece size, rotary table: 600 x 500 x 400 mm Workpiece dimensions over both tables: 1500 x 500 x 400 mm Internal coolant supply: 70 bar Machine weight approx.: 10.5 t Space requirement approx.: 3.65 x 2.53 x 2.81 m Accessories: Removable handwheel HR 510 FS Rotoclear viewing window Automatic shut-off at program end Workpiece measurement with Blum TC 52 probe Coolant gun at workstation The Spinner U5 1530 5-axis machine with Heidenhain TNC 640 control is nearly as-new, in excellent condition. 122 SK 40 toolholders are included. A special Gressel vise for 5-axis machining on the rotary table is also included. The B and C axes feature hydraulic brakes for increased rigidity during static machining. All linear and rotary axes are equipped with direct measuring systems. "Advanced Function Set 1" Option 8: - Swiveling of the machining plane via coordinate transformation - Cycles for cylindrical surface interpolation (Cycles 27, 28, 29, and 39) - Transferring an X-Y programmed contour onto the cylindrical surface - Automatic calculation of feedrate in mm/min of a rotary axis depending on the tool's distance from the rotary axis center (M116) - 3-axis circular machining in tilted machining plane (spatial circle) "Active Chatter Control" Option 145: Increases chip removal rate

Kondisi: seperti baru (mesin pameran), Tahun pembuatan: 2023, Control: Heidenhain TNC 640 Kdjdpfxot Dizvo Afijk Working area Travel X: 1,020 mm Travel Y: 520 mm Travel Z: 610 mm Clamping surface (L x W): 1,160 x 520 mm Table load: 750 kg Spindle Speed: 15,000 rpm direct drive Tool holder: SK40 (BigPlus) DIN69872 General Tool changer: 30 positions (double gripper) Machine bed: High-strength Meehanite cast iron Repeatability: 0.008 mm Chip management: Chip conveyor incl. chip flushing in the work area Coolant management: Internal coolant supply (ICS 30 bar) Cooling air: Programmable external cooling Temperature management: Automatic spindle cooler Jogging support: Electronic handwheel Part and work area cleaning: Rinse and compressed air gun Coolant cleaning: Oil skimmer Network connection: Ethernet interface

Kondisi: hampir baru (bekas), Tahun pembuatan: 2024, jam operasional: 100 h, jarak pergerakan sumbu X: 660 mm, jarak lintasan sumbu Y: 406 mm, jarak gerak sumbu Z: 508 mm, 001 Ksdpfoyh Nz Aox Afiedk

Kondisi: sangat baik (bekas), various steady rests Kdjdpjd E Tb Eofx Afiok

Kondisi: baru, Tahun pembuatan: 2021, Fungsionalitas: berfungsi sepenuhnya, Mesin seperti baru, hanya 600 jam operasi! HEIDENHAIN 640 Meja 1300x700 Sumbu X, Y, Z: X=1220 Y=710 Z=630 Putaran spindle 60–10000 Penukar alat 24 posisi. Kedpowx Nkcefx Afiodk Dimensi mesin 3200 x 3900 x 2490 mm Berat mesin 9500 KG

Kondisi: baru, Tahun pembuatan: 2025, Fungsionalitas: berfungsi sepenuhnya, jarak pergerakan sumbu X: 1.000 mm, jarak lintasan sumbu Y: 600 mm, jarak gerak sumbu Z: 600 mm, gerak cepat sumbu X: 36 m/menit, pergeseran cepat sumbu Y: 36 m/menit, pergerakan cepat sumbu Z: 36 m/menit, kecepatan pemakanan sumbu X: 15 m/menit, laju pemakanan gandar Y: 15 m/menit, laju pemakanan sumbu Z: 15 m/menit, tinggi total: 2.700 mm, panjang total: 2.800 mm, lebar total: 3.550 mm, lebar meja: 600 mm, panjang meja: 1.200 mm, beban meja: 800 kg, berat keseluruhan: 7.500 kg, kecepatan spindel (maks.): 8.000 rpm, hidung spindel: SK40, Perlengkapan: dokumentasi / manual, kecepatan rotasi dapat diubah tanpa batas, konveyor serpihan, V10 Vertical precision machining center with cross-table design Machine Specification: Control: FANUC 0i-MF Travel: Kedpfxjvtz Dxe Afiodk X-axis travel: 1,000 mm Y-axis travel: 600 mm Z-axis travel: 600 mm Spindle nose to table surface: 150 - 750 mm Precision: Positioning accuracy: 0.008/0.006/0.006 mm (X/Y/Z) Repeatability: 0.005/0.004/0.004 mm (X/Y/Z) Table: Table size: 1,200 x 600 mm Max. load: 800 kg T-slot (table): 5x18x100 mm Spindle: Drive type: Belt drive Max. speed: 8,000 rpm Power: 7.5/11 kW Tool holder: SK40 Drawbar: MAS P40T-I (45°) Feed Rates: Rapid traverse (X/Y/Z): 36/36/36 m/min Cutting feed rate: 15/15/15 m/min Tool magazine: Capacity: 24 stations Type: SK40 Max. tool diameter: 80 mm Max. tool diameter (adjacent free): 150 mm Max. tool length: 300 mm Max. tool weight: 8 kg Indexing (tool to tool): 2.5 secs Power supply: 30 kVA Machine weight: 6.5 t Dimensions (LxWxH): 2800 x 3550 x 2650 mm Standard configuration: • Control: Mitsubishi M80VB • 8,000 rpm belt-driven spindle • 24-position automatic tool changer • Pneumatic and hydraulic lubrication system • Coolant system • Internal coolant tank with chip conveyor • Full enclosure • Air gun • 3-color signal tower • Standard accessories • Chip cart • CE compliant Options: • SIEMENS 828D • FANUC 0i • 10,000 rpm belt-driven spindle • 12,000 rpm direct drive spindle • Spindle oil chiller • NC rotary table, 4th axis • Tool measurement system • Tool magazine safety cover • Water gun • Oil skimmer • Chip conveyor with chip cart • Oil mist extraction (preparation) • Alternative coolant tank for aluminum chips • Air conditioning for electrical cabinet • Glass scales (not available for V6)

Kondisi: sangat baik (bekas), Tahun pembuatan: 2016, Fungsionalitas: berfungsi sepenuhnya, jarak pergerakan sumbu X: 800 mm, jarak lintasan sumbu Y: 450 mm, jarak gerak sumbu Z: 510 mm, gerak cepat sumbu X: 40 m/menit, pergeseran cepat sumbu Y: 40 m/menit, pergerakan cepat sumbu Z: 40 m/menit, produsen pengendali: HEIDENHAIN, model controller: HEIDENHAIN TNC-620, tinggi total: 2.500 mm, panjang total: 3.600 mm, lebar total: 2.500 mm, lebar meja: 1.000 mm, panjang meja: 450 mm, beban meja: 600 kg, berat keseluruhan: 5.000 kg, kecepatan spindel (min.): 80 rpm, kecepatan spindel (maks.): 12.000 rpm, pasokan pendingin: 20 batang, hidung spindel: ISO 40, jumlah spindel: 1, jumlah slot dalam magazin alat: 30, panjang alat: 300 mm, diameter alat: 80 mm, berat alat: 8 g, tegangan masuk: 380 V, Perlengkapan: dokumentasi / manual, kecepatan rotasi dapat diubah tanpa batas, konveyor serpihan, USATO vertical machining center "DOOSAN DNM 4500" with Heidenhain TNC-620 CNC control Kdsdpfsw D Dy Nox Afiok

Kondisi: baik (bekas), Tahun pembuatan: 2013, 1 Kdsdpfx Aev Nhw Rsfisk

Kondisi: sangat baik (bekas), Tahun pembuatan: 2021, jam operasional: 2.500 h, Fungsionalitas: berfungsi sepenuhnya, jarak pergerakan sumbu X: 1.060 mm, jarak lintasan sumbu Y: 600 mm, jarak gerak sumbu Z: 600 mm, model controller: Heidenhain ITNC640, kecepatan spindel (maks.): 10.000 rpm, Kami menawarkan Posmill CE1000 dalam kondisi baik dengan sekitar 2.500 jam spindle dengan opsi berikut: Heidenhain linear scale pada sumbu X, Y, dan Z Kontrol Heidenhain TNC 640 Spindel bertekanan udara Spindel 10.000 RPM ISO40 Pengganti alat otomatis 40 alat (ATC) Belt filter dengan pendingin internal 20 bar Hexagon touch probe Hexagon tool probe Konveyor chip Kompensasi panas spindle pada sumbu Z Spesifikasi teknis: Kdsdpfoyindaex Afiek Perjalanan sumbu X: 1060 mm Perjalanan sumbu Y: 600 mm Perjalanan sumbu Z: 600 mm Mesin dalam toleransi baru dan protokol geometri tersedia.

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2021, jam operasional: 2.500 h, jarak pergerakan sumbu X: 1.270 mm, jarak lintasan sumbu Y: 660 mm, jarak gerak sumbu Z: 610 mm, produsen pengendali: HURCO, model controller: WINMAX, tinggi total: 3.240 mm, beban meja: 2.000 kg, berat keseluruhan: 7.950 kg, kecepatan spindel (maks.): 12.000 rpm, berat alat: 7.000 g, jumlah sumbu: 3, This 3-axis Hurco VMX50i was manufactured in 2021. It is equipped with a robust SK40 spindle reaching speeds of up to 12,000 rpm and offers a large table area of 1500 x 660 mm, capable of supporting workpieces up to 2,000 kg. With X/Y/Z travels of 1270/660/610 mm and rapid traverse rates of 32/32/24 m/min, this machine is ideally suited for dynamic machining operations. Includes an automatic tool changer with 30/40 positions. Please contact us for further details regarding this machine. • Spindle nose to table: 101–711 mm • Table working area (W x D): 1500 x 660 mm • Table T-slots (DIN 650): 6 x 18 x 100 mm Kdjdpfx Asx D E Acjfisk • Automatic tool changer (ATC) positions: 30/40 • Machine condition: Powered on and operational • Total machine hours: 6,700 Additional equipment: • Chip conveyor • Mist extractor • External coolant tank with filtration for internal tool cooling • Including workpiece and tool probes • Programming extensions for DWG/DXF Dimensions: Machine depth: 5059 mm
