Teknologi pemberian makan

VA SBZ-2

Kondisi: bekas, Tahun pembuatan: 1980, nomor mesin/kendaraan: A-07/471A, Maximum sheet width: 130 mm Straightening roller diameter: 40 mm Number of straightening rollers: 5 Feeding rollers: 2+2 Minimum sheet thickness: 0.4 mm Maximum sheet thickness: 3.5 mm Weight: 0.4 t Space requirement approx.: 0.6 x 0.65 x 1.15 m Psdpfocxxx Rsx Ab Ijgw Strip straightening machine with integrated infinitely variable VARI drive, reversible (forward and reverse operation), mode selector switch for manual and automatic operation, entry roller basket, analog display for roll position indication, roll position adjustment via handwheels, automatic loop control, in very good condition.

Tahun pembuatan: 1987, Kondisi: bekas, Strip width 150 mm Coil weight 80 kg Coil outside diameter 650 mm Mandrel height 1000 mm Expansion range 230 - 445 mm Total power requirement kW Machine weight approx. t Psdefn Aqljpfx Ab Ijgw Space requirement approx. m motor-driven decoiler

Tahun pembuatan: 2017, jam operasional: 30 h, Kondisi: seperti baru (mesin pameran), Maximum band thickness: 4 mm Band width: 300 mm Pgodpfsb Nbglox Ab Isw Repeatability: +/- 0.05 mm NC drive with compact control unit Feed force: 3000 N (300 kg) Maximum band pressing force: 1.2 t

Kondisi: baik (bekas), Tahun pembuatan: 1999, Lg 33922 Decoiler-Straightener Combination SOPREM BRH 7-200-80U-1250 BAP Psdehuwacjpfx Ab Iegw Strip width max. 200 mm Coil weight max. 1,250 kg Expansion range approx. 380 to 430 mm Coil outside diameter max. 1,300 mm Strip thickness approx. 0.8 to 3 mm Working direction from right to left

Tahun pembuatan: 2023, Kondisi: baru, Control system with motor for all legacy NC feeds. Replacement for Alba, Schleicher, Dreher, PA, etc. Torque range: 6–90 Nm. Complete price starting from €3,900 for Alba stepper motors, from €5,900 for servo drives. Can be installed by any qualified electrician. Podpfx Abocn Du Ij Iogw

Tahun pembuatan: 2016, Kondisi: siap digunakan (bekas), The Coiltech Decoiler Straightener Feeder System is a compact feeding solution designed for press applications. Strip width: 600 mm, material thickness: up to 6.5 mm, straightening rollers: 7 x 115 mm, decoiler capacity: 6,000 kg, inner coil diameter (min-max): 470–520 mm. Connected load: 7.5 kW, supplied with documentation. Pgodji El Ucspfx Ab Ijw

Kondisi: bekas, Material width 250 mm Material thickness 2 – 4 mm Pjdpfx Abogbl Aaj Ijgw Number of straightening rollers 7 Entry height 1250 mm Feed-in angle adjustable, positive 25° Feed-in angle adjustable, negative 30° Total power requirement 3 kW Machine weight approx. 800 kg Space requirement approx. ... m The straightening machine has been disassembled, inspected, and subsequently repainted.

Kondisi: sangat baik (bekas), RNA vibratory feeder with 900 mm diameter, spiral conveyor / ct1339a In good condition, for sale with ESR3000 controller. Manufacturer: RNA Model: SRC-N 630-1 L Vibration frequency: 50 Hz / 3000 rpm Voltage: 220 V Power: 5.4 [unit unclear, likely kVA or kW] Diameter: 900 mm A = Discharge height: 167 mm B = Track width: 50 mm D = Bowl diameter: 980 mm H = Bowl height: 250 mm Pgedpoh Iy Ttofx Ab Iow S = Track pitch: 81 mm

Kondisi: diremajakan ulang (bekas), Tahun pembuatan: 2025, Drive: Servo motor Maximum strip width: 300 mm Strip thickness: 0.5 – 4.0 mm Maximum cross-section: 1,200 mm² Feed length: 0 – 9,999.9 mm Accuracy: +/- 0.05 mm Pedjr H Dwiepfx Ab Isgw Roller diameter: 80 mm The feed rollers are hardened and ground. The upper roller is lifted for strip insertion via pneumatic cylinders and valve. The pressure of the upper roller is pneumatically applied by short-stroke cylinders. The upper roller is torsion-resistant mounted to prevent unilateral roller pressure. Off-center strip transport is permissible. A run-in roller basket, an adjustable strip side guide, and an end-of-strip monitoring at the infeed side are included in the standard configuration. Protective covers on feed rollers and drive components. Intermediate ventilation can be switched on or off.

Kondisi: baru, nomor mesin/kendaraan: SH O2 27-40-18.2, berat kosong: 615 kg, berat muatan maksimum: 2.085 kg, berat keseluruhan: 2.700 kg, konfigurasi gandar: 2 gandar, panjang ruang muatan: 4.010 mm, lebar ruang muat: 1.830 mm, tinggi ruang muatan: 345 mm,
