Mesin pembengkok cincin

AKYAPAK APK 30

Kondisi: sangat baik (bekas), Tahun pembuatan: 2008, The machine is in excellent condition, having performed only 123,000 operations. Lsdpom Ak R Usfx Ac Hehc CNC-controlled automatic system, designed for processing welded frames. Independent drive and control system. Multiple use of the same cycle time Operates in conjunction with a welding and cleaning line Does not require additional floor space in the workshop After adaptation, it can operate in a sash production line. All operations are performed during the cooling phase: - Water drainage - Ventilation, grooves - Ventilation, drilling in colored profiles - Mullion connector drilling in the frame - Hinge hole drilling in the frame (x6) The center is equipped with its own system for transporting frames from the welder to the cleaner. SPS and NC controls. User-friendly visualization.

Kondisi: baik (bekas), Tahun pembuatan: 2003, Manufacturer: KUKA Model: KR 210 L 180 Year of manufacture: 2003 Maximum load capacity: 150 kg Lhodpfx Acoh Dw Dqe Hsc

Kondisi: baik (bekas), Tahun pembuatan: 1984, 24126 Motorized Solid Bar Twisting Machine + Ring and Arch Bending Machine Technical Specifications: - Bending process motorized, with automatic or manual operation - Bending capacity for square steel (ST 37) up to approx. 30 mm - Bending capacity for flat steel (ST 37) up to approx. 30 x 8 mm - Adjustable bending length between twisting units up to approx. 1200 mm - Minimum twisting length: 10 x material thickness (long side) - Preselection for bending time and twisting length - Right and left-hand rotation - Tailstock - Arch and ring bending attachment GRB 66 with various roller sets - Bending performance: - Flat steel 60 x 10 mm (vertical): min. radius 700 mm Ljdpfxjr Ik N De Ac Hehc - Flat steel 70 x 12 mm (flat): min. radius 500 mm - Round pipe 1 ½” x 2: min. radius 800 mm - Square tube 40 x 40 x 3: min. radius 1500 mm - Angle 45 x 6: min. radius 600 mm - Round pipe roller sets: steel 1 ¼”, plastic 1 ½” - Standard roller set - Space requirement: approx. W 1850 x H 1300 x D 700 mm - Drive: 400 V / 2.2 kW - Weight: approx. 250 kg

Kondisi: baik (bekas), Fungsionalitas: berfungsi sepenuhnya, Tahun pembuatan: 2012, nomor mesin/kendaraan: 778 F 319, de-01 Lhjdpfemx Rrlsx Ac Hec

Kondisi: bekas, Tahun pembuatan: 1986, Sheet thickness 6.0 mm Pressure 18 t Shearing angle - upper blade 90° Blade length 225 x 225 mm Operating voltage 380 V Total power requirement 5.5 kW Machine weight approx. 650 kg Lhjdog Ip Efopfx Ac Hjc Required space approx. 1.10 x 0.80 x 1.05 m - Adjustable angle stops

Kondisi: bekas, Tahun pembuatan: 1999, x-travel 2000 mm y-travel 800 mm z-travel 850 mm Control HEIDENHAIN TNC 360 Lhsdpfsv H Ertsx Ac Hec Total power requirement / kW Machine weight approx. / t Space requirement approx. / m

Tahun pembuatan: 2010, Kondisi: sangat baik (bekas), Kammer innen 2000 x 1250 x 1250 mm Innenvolumen 2344 Liter Bis zu 400 °C (Leistung 33 kW) Vorheizen / Trocknen für manuelle, zyklische und CNC-Bearbeitung bis hin zur interaktiven Konturbearbeitung Abgedeckte Führungsbahnen (DGP) für hohe Langzeitpräzision Direktantrieb vom Motor zur Hauptspindel für laufruhigen Betrieb Ledpfxsuqkwfs Ac Hehc Ölumlaufschmiereinheit mit Filterung zur Schmierung des Präzisionshauptspindellagers Kombinierte Steuereinheit für wirtschaftlich vorteilhafte Programmierung und Maschinenbetrieb sowie optimalen Zugang zum Arbeitsbereich Länge: 2500 mm Breite: 2015 mm Höhe: 2900 mm Gewicht: 4000 kg

Kondisi: baru, Tahun pembuatan: 2024, kapasitas angkut: 300 kg, Protec KT 300 H Welding Turntable, 170/400 Special Version Horizontal load capacity: 300 kg, tilted: 150 kg Power supply: 220 V, 50 Hz Table diameter: 450 mm Hollow shaft diameter: 170 mm Lsdorypmgjpfx Ac Hshc Table height: 500 mm Welding current transmission: 400 A Quick-release chuck diameter 300 mm, surcharge: €550 Quick-release chuck diameter 400 mm, surcharge: €750 Crank gear motor, stepless adjustment 0 – 90° Stepless speed control: 0.01 to approx. 5 rpm Including foot remote control Digital display with welding time limitation (optional)

Kondisi: bekas, Tahun pembuatan: 1999, Technical Details: Drilling capacity in steel (diameter): 32 mm Throat depth: 293 mm Drilling stroke: 120 mm Drilling capacity in cast iron: Ø 38 mm Spindle taper: MK 3 Ljdpfxova Hmrs Ac Hehc Spindle overhang: 293 mm Spindle speed: 160 – 2250 rpm Feed: 0.10 – 0.20 mm/rev, manual and automatic Max. distance spindle/table: 55 - 642 mm Table clamping surface: 300 x 300 mm Drill table adjustment: yes Column diameter: 115 mm Distance spindle center to base plate: 1207 mm Total power requirement: 1.9 kW Approx. machine weight: 280 kg Approx. machine dimensions (LxWxH): 0.7 x 1.0 x 1.9 m Pillar drilling machine with stepless speed adjustment and automatic feed. Tapping function with direction switch. Equipment: RÖHM drill chuck 3 - 16 mm, operation via left/right foot switch. Very well-maintained, excellent used condition!

Kondisi: bekas, Combined profile steel shear and punching machine GEKA type HYD 80 / Hydracrop 80/A Mach. no. 9566 Year of manufacture approx. 2000 Punching force 80 tons Throat depth 300 mm Punching up to Ø 40 mm in 14 mm sheet Flat bar shear 450 x 15 mm Angle steel shear 130 x 130 x 13 mm Square shear 45 x 45 mm Round bar shear Ø 45 mm Rectangular notcher up to 12 mm Motor power 5.5 kW Electrical connection 400 Volt, 50 Hz - Back gauge with electric stroke release 500 mm - Work table with back gauge at punching station 550 x 380 mm - Working height at punching station 1100 mm - Work table with back gauge at rectangular notcher 550 x 400 mm Lodsrz Tutopfx Ac Hjhc - Working height rectangular notcher 930 mm - approx. 21 various punching tools - Operating instructions - Original paintwork, not repainted Required space L x W x H 1800 x 1150 x 1950 mm Weight 1.7 tons Very good condition
