Pusat pemesinan umpan cepat

BIESSE COMIL INSIDER KT 2

Kondisi: baik (bekas), Tahun pembuatan: 1982, Fungsionalitas: berfungsi sepenuhnya, jenis arus masuk: tiga fasa, MCS Jigger high-temperature 143ºC. Type: COMBY-JIGGER JP70. Year of manufacture: 1982. Completely refurbished in 2002. Pressure: 3 kg/cm² Capacity: 9,170 l Fpjdpfxofqmx Ts Abhjc Roll width: 2,000 mm Fabric diameter: 1,100 mm Roller diameter: 324 mm Additives tank.

Tahun pembuatan: 1992, Kondisi: bekas, Plate heat exchanger for milk processing Fpjdpfx Aboh Eulgohsc

Kondisi: bekas, nomor mesin/kendaraan: 008011, Area kerja sumbu X: 6200 mm Area kerja sumbu Y: 1935 mm Meja kerja: Dengan tumpuan konsol vakum Daya spindle utama: 10.5 kW Jumlah sumbu yang dikontrol: 4 sumbu Fpsdpfx Aowu Af Ejbhoc Jumlah spindle bor: 40 Jumlah tempat alat: 22

Kondisi: bekas, Tahun pembuatan: 2008, · Working area X-Y-Z: 3,660 x 1,550 x 130 mm · Travel length X-Y: 4,200 x 2,000 mm Aggregate and Accessories Description (Basic) The machine base structure is a monolithic design made from thick-walled steel. It is reinforced with welded triangular plates throughout the entire machine bed, providing extreme stability. The use of a triangle shape with a broad base for all load-bearing elements is the key to ensuring long-term precision and stability. The machine layout allows the operator to achieve an optimal workflow with minimal space requirements. This foundation provides a balanced, secure base for the processing unit with excellent load distribution. The mobile portal-type aggregate carrier is constructed as a solid monoblock. It is positioned in the X-axis along ground prismatic guides via recirculating ball carriages. The working aggregate is mounted to this portal carrier on ground prismatic guides and recirculating ball carriages. Axis Movement: Y and Z axes are driven by precision-ground recirculating ball screws of the highest accuracy class. The X-axis drive is a backlash-free, preloaded precision rack-and-pinion system. This ensures even load distribution during positioning, which is crucial for balanced movements even in complex operations. Axis movements are realized by brushless AC servo motors. These provide outstanding positioning speeds with very short ramp times. Additionally, all motors feature fully integrated measurement systems, making this drivetrain entirely maintenance-free. · Rapid traverse in X: 40 m/min · Rapid traverse in Y: 60 m/min · Rapid traverse in Z: 22.5 m/min Vacuum System (Basic) · Vacuum pump: 100 cbm/h · Power: 2.5 kW · Max. vacuum (connection): 0.9 bar Control / Electrical Cabinet · Office PC or industrial PC (see options) · Basic NC control: ESA-GV KVARA 6.0 · Cable remote control with main functions ELECTRICAL/ELECTRONIC CNC CONTROL Universal is equipped with a powerful NC control system. The integrated office PC provides an unmatched level of familiarity to the NC system: the software operates on Windows XP, allowing fast and simple programming—even for inexperienced users. The system is open and allows connections to a CD-ROM drive, audio card, barcode reader, modem, printer, scanner systems, etc. Installation of any network systems or commercially available CAD programs is also possible. To save space, the electrical cabinet is mounted beneath the machine table, while the operator uses a separately mobile, wheeled console that can be freely positioned. PROGRAMMING SYSTEM XILOG Software features: - Import of DXF files - Import of ASCII files - Operator interface available in native language (I - GB - F - D - E) - Linear and circular interpolation in three axes, linear in space, helical on selected plane - Assisted programming - Calculator for direct transfer of computed data - Graphical and syntax aids for drilling and milling operations - Parametric programming for repeating panel machining on different p Fsdsvvi Nzspfx Abhepc

Kondisi: baru, DM1100 2C – Edge Rounding Machine for Laser, Plasma, and Punched Parts. NEW DESIGN – UNDER POWER FOR INSPECTION – IMMEDIATELY AVAILABLE FROM STOCK The DM1100 2C rounds both the upper and lower edges of metal parts, starting from a minimum size of 150 mm up to a length of 1100 mm, all IN A SINGLE PASS. The first station processes the parts from below using two counter-rotating cross belts, while the second station processes the parts from above also using two counter-rotating cross belts. Thanks to these cross belts, both internal and external edges of the parts are rounded. Sharp edges on steel, stainless steel, and aluminum parts—produced by laser, punch presses, or shearing processes—are removed effectively. Simultaneous processing of both sides of laser-cut or punched metal parts saves time and reduces production costs. Fpjdpfjd Ev Upsx Abhec Another key advantage of the DM1100 2C is its capability to process small parts from 50 mm onwards. By folding up a table, the rotation direction of the upper conveyor belt is automatically reversed, and the gap of the first processing station is bridged, so that parts go directly into the second station. This means small parts sized from 50 mm up to 150 mm can then be processed on one side only. An additional positive feature of this machine is its ability to round parts with protective surface film without damaging the film. Simple, tool-free cross belt change. Programmed automatic positioning of the upper and lower belts for optimal accessibility and reduced changeover times. Effortless operation via integrated touchscreen. This machine is, of course, also available with a return conveyor system. Technical Data: Working capacity (Ø mm): 1100x50 Number of cross belt stations: 2 Cross belt speed (m/s): 2–8 Feed speed (m/s): 0.6–3.2 Cross belt motor (kW): (4x) 3 Feed motor (kW): (3x) 0.18 Total power (kW): 13.1 Power consumption (A): 30 Extraction connection per head (Ø mm): 150 Dimensions (mm): 2560x1980x2150 Weight (kg): 2210

Kondisi: bekas, Tahun pembuatan: 2003, x-travel: 930 mm y-travel: 400 mm z-travel: 406 mm Spindle speed: 9–6,750 rpm Table size: 1,370 x 254 mm Quill stroke: 127 mm Quill feed: (3) 0.04; 0.08; 0.15 mm/rev Drilling capacity in steel: 32 mm Feed range: 19–890 mm/min (x-axis) Spindle taper: SK 40 Column overhang: 200–680 mm Total power requirement: 4 kVA Machine weight (approx.): 1.15 t Required space (approx.): 1.5 x 1.45 x 2.2 m Product Information – "Multifunctional Milling Machine Optimill MF 4 Vario – Tool Milling Machine with Variable Spindle Speed" The Optimill MF 4 Vario is a multifunctional drilling and milling machine designed for professional applications. It features a continuously variable electronic drive with frequency inverter "Made in Germany" and a digital 3-axis position display DPA 21. Heavy-duty, massive construction made from high-quality Meehanite cast iron. High concentricity accuracy thanks to tapered roller bearings, less than 0.01 mm measured at the quill. Automatic quill feed. Clockwise/counterclockwise rotation for thread cutting. X and Y axes with adjustable dovetail guideways. Coolant system. Y-axis features a flat guideway and a large travel of 400 mm. Motorized table height adjustment (Z-axis) with rapid traverse. Equipment details: - Frequency inverter, quality made in EU - Drilling/milling head - Tiltable ±45° - Overhang 200–680 mm - Stepless speed control, especially wide speed range - Drill depth stop, adjustable with millimeter scale, front readable - Protective screen, height-adjustable, generously sized - Cross table, heavy-duty, generously sized, precision-machined surface - Motorized table height adjustment (Z-axis), adjustable end stops - OPTI control panel with integrated control desk - Integrated digital position display DPA 21 with rpm indicator - X-axis motorized table feed, stepless speed regulation, rapid traverse, right/left-hand rotation Technical Data: Length (product): 1,500 mm Width/Depth (product): 1,450 mm Height (product): 2,200 mm Weight (net): 1,150 kg Total connected load: 4 kW Electrical voltage: 400 V Phase(s): 3 Ph Mains frequency: 50 Hz Max. cutter head size: 100 mm Max. end mill size: 20 mm Vertical spindle overhang: 200–680 mm Vertical spindle spindle mount: ISO 40 DIN 2080 Vertical spindle speed range: 8 ranges, electronically adjustable Horizontal milling table length: 1,370 mm Horizontal milling table width: 254 mm Distance vertical spindle–horizontal table min.: 40 mm Distance vertical spindle–horizontal table max.: 446 mm Horizontal table T-slot size: 16 mm Number of T-slots: 3 T-slot spacing: 63 mm Max. table load: 275 kg Vertical spindle main drive motor: 3 kW Coolant pump drive motor: 100 W Manual X-axis travel: 930 mm Manual Y-axis travel: 400 mm Manual Z-axis travel: 406 mm Automatic X-axis travel: 850 mm Automatic Z-axis travel: 350 mm Drilling capacity in steel (S235JR): 32 mm Continuous drilling capacity in steel (S235JR): 28 mm Fpedpjt U Rm Iefx Abhec Vertical spindle rotation range, milling head Z–X plane: ±45° Vertical spindle quill stroke: 127 mm Vertical spindle quill feed: 0.04/0.08/0.15 mm/rev

Kondisi: sangat baik (bekas), Tahun pembuatan: 2003, lebar kerja: 215 mm, daya pengelasan (maks.): 750 kVA, Komplette Gitter- und Matten-Schweißanlage Die Anlage besteht aus: - Matten-Schweißlinie SCHLATTER PG 24, halbautomatisch, Baujahr 2002 - Gitterträgeranlage SMEI, vollautomatisch, Baujahr 2003 Fjdpfeqy Ek Aox Abhspc - Richt- und Schneidemaschinen 1x Wafios R4 2x VITARI NR16 1x VITARI NR10 - Kaltziehlinie SMEI, Eingangsdraht max. 10 mm, Geschwindigkeit – 4 m/s - Stumpfschweißmaschine SMEI - Drahtanspitzgerät SMEI

Kondisi: baru, Tahun pembuatan: 2024, SINGLE-BLADE EDGING SAW Fpedpfofw Nv Rex Abhoc usable cutting length from 4.2 to 8.2 m maximum cutting thickness 160 mm parallel guide sawdust hopper

Kondisi: sangat baik (bekas), Tahun pembuatan: 2018, Kontrol CNC: HEIDENHAIN TNC 640 Sumbu Perjalanan sumbu X mm: 2.200; Perjalanan sumbu Y mm: 2.200; Perjalanan sumbu Z mm: 1.610; Sumbu A derajat: +185° Meja kerja Jumlah palet: 4; Dimensi meja mm: ø1.800x1.400; Ukuran maksimum benda kerja (D x T) mm: ø2.850x2.000; Berat maksimum benda kerja kg: 4.000 Spindel Kecepatan spindel rpm: 15.000; Daya penggerak spindel kW: 63/73 (100/40%ED); Torsi spindel Nm: 300/348 (100/40%ED) Fjdpfxow Rmplj Abhopc Pendinginan Pendinginan melalui tengah spindel bar: 80 (Tipe A); Kapasitas tangki: 2.500 Sistem alat Dudukan alat: HSK-100A; Slot penyimpanan alat: 304

Kondisi: sangat baik (bekas), Tahun pembuatan: 2004, Maier ML 26 E CNC Lathe TECHNICAL DATA Number of axes: 11 Spindle bore: 32 mm Travel speed: 32 m/min Control system: Maier Pro GE-Fanuc Guide bushing: 451.001 Main Spindle Passage: 26 mm C-axis: Yes Mechanical indexing 5°: Yes Spindle stroke: 220 mm Main spindle, speed: 0 – 6000 rpm Power: 3.7 kW / 5.5 kW (7.5 kW) Collet: 161E Sub Spindle Passage: 26 mm C-axis: Yes Mechanical indexing 5°: Yes Max. Travel (Z): 220 mm Sub spindle, speed: 0 – 6000 rpm Main spindle, power: 1.1 kW Collet: 161E Cross Machining Basic holders for bar stock 5 pcs. 16 x 16: Yes Number of driven tools: 4 Power of driven tools: 0.5 kW Backworking Drive power: 0.5 kW Number of tools: 4 of which driven: 4 Collets: ER16 Tool Turret Number of tools: 16 Number of driven tools: 8 Drive power: 0.5 kW C-axis: 360 ° Fsdpfx Aju S Rivebhepc Z-axis: 175 mm X-axis: 200 mm Collets: ER16 SCOPE OF DELIVERY Includes (not an exhaustive list): Maier ML 26 E CNC Lathe Oil mist separator Transformer Chip conveyor High-pressure pump / belt filter system Fire suppression system LNS bar feeder Complete operating documentation Exact scope of delivery according to photo documentation. No guarantee is given for the correctness, completeness, or currentness of the information provided.
