Pusat permesinan - universal

DECKEL-MAHO DMU 80 P

Kondisi: diremaj di bengkel (bekas), Tahun pembuatan: 2006, CNC Universal – Mesin Milling & Bor DECKEL MAHO DMU 80 P duoBlock Iedjxn Aczepfx Ahvstp Dengan kontrol lintasan MILL PLUS iT Tahun pembuatan: 2006 Perjalanan sumbu: X 800 Y 800 Z 800 mm Rentang kecepatan putar: 0 – 8.000 rpm tanpa tingkat (SK 50) Dengan perlengkapan berikut: Meja putar NC 900 mm x 700 mm area penjepitan (beban meja maks. 1,4 t) Kepala frais universal dengan sumbu B terkontrol Penukar alat universal dengan 40 slot majalah sebagai penangkap ganda (SK 50) Kabinet pelindung penuh dengan pintu geser dan lampu interior IKZ – 40 bar Konveyor serbuk Rotoclear Probe pengukur 3D Heidenhain TS 641 Mode operasi 3 + 4 Handwheel elektronik 50 buah dudukan alat SK 50 3 buah alas mesin yang dapat diatur ketinggiannya Perlengkapan transportasi Manual operasi

Kondisi: bekas, Tool holder interface type: HSK-A 100 Tool mounting type: Wohlhaupter Tool mounting type: Fine boring heads / Precision turning Large selection of Wohlhaupter HSK-A 100 tool holders, boring heads, adapters, and extensions available. Itsdpfeg Nqliex Ahvop Parts list with prices available on request.

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2001, Fungsionalitas: berfungsi sepenuhnya, PUSAT MESIN UNIVERSAL DMG DMU80P hi-Dyn Tahun 2001 X800 Y700 Z600mm Heidenhain iTNC530 Meja Putar NC Ø900x630mm Kepala Milling Sumbu B NC Spindel 18.000rpm ATC 180 – HSK-A63 Jendela Roto Clear Pendingin melalui spindel 40 bar Dijual Murah Penjualan murah – 50.000,00 USD Itjdpjw A Dy Tjfx Ahvsp

Kondisi: bekas, Tahun pembuatan: 1999, Pergerakan x 800 mm Pergerakan y 700 mm Pergerakan z 600 mm Kontrol Heidenhain Millplus Berat mesin sekitar 12,5 t Pusat Pemesinan CNC Universal DECKEL MAHO DMU 80 P Tahun pembuatan 1999 Itjdexqrh Eepfx Ahvep Kontrol Heidenhain Mesin 5 sumbu Ruang gerak: X 800 mm Y 700 mm Z 600 mm Monitor kontrol hilang.

Kondisi: sangat baik (bekas), Tahun pembuatan: 2006, 5-axis CNC machining center Year: 2006 Control system: Heidenhain iTNC 530 Technical specifications: X-axis travel: 880 mm Y-axis travel: 630 mm Z-axis travel: 630 mm Max. torque: 130 Nm Tool holder: SK 40 (ISO 7388IIB) Tilting axis: B: 103° Work table: Clamping surface: 1,250 x 700 mm Rotary table diameter: 700 mm Rotary axis: C: 360° Max. table load: approx. 500 kg T-slots: 11x 14 mm x 63 mm Tool magazine: Number of tool stations: 32 (2x 16) positions Tool holder: SK 40 (ISO 7388IIB) Max. tool diameter: 80 / 130 mm Itedpfxewn A Sle Ahvsp Max. tool diameter with free adjacent station: 160 mm Max. tool length: 315 mm Max. tool weight: 8.0 kg

Kondisi: siap digunakan (bekas), Tahun pembuatan: 1999, Unit Kontrol Merek: HEIDENHAIN Model: 426 Isdsxn Uyfopfx Ahvjtp DECKEL MAHO DMU 80P 5-sumbu ini diproduksi pada tahun 1999. Mesin ini dilengkapi sistem kontrol Heidenhain 426, majalah alat dengan 30 slot, dan tipe holder alat SK 40. Pendingin spindle mampu mencapai 40 bar, meningkatkan kinerja untuk pekerjaan pemesinan kompleks. Manfaatkan kesempatan untuk membeli pusat pemesinan universal DECKEL MAHO DMU 80P ini. Hubungi kami untuk informasi lebih lanjut mengenai mesin ini. Jenis Aplikasi Milling

Kondisi: bekas, Tahun pembuatan: 2009, x travel 800 mm y travel 800 mm z travel 800 mm Control system: Heidenhain iTNC 530 Main spindle speed: 50 - 18,000 rpm Main spindle drive power: 28 kW Iedpfx Asu Ag Irohvetp Max. torque: 121 Nm Tool holder: HSK-A 63 Swivel range: -30 / +180° Table clamping surface, diameter: 900 x 700 mm Max. table load: 1,400 kg Table rotary speed: 30 rpm Rotary axis (C): 360° Number of tool stations: 40 Tool holder: HSK-A 63 Max. tool diameter: 230 mm Max. tool length: 450 mm Max. tool weight: 15.0 kg Rapid traverse (X / Y / Z): 60 m/min Feed force (X / Y / Z): 13 / 13 / 9 kN Machine weight approx.: 13.0 t Space requirements approx.: 5.5 x 3.5 x 3.5 m Total power consumption: 68 kVA 5-axis machining center – universal DMG DECKEL MAHO – DMU 80 P duoBLOCK - Swivel milling head (B-axis) - NC rotary table (C-axis) - Application Tuning Cycle (ATC) - WITHOUT clamping devices

Kondisi: bekas, Tahun pembuatan: 2007, Spindle speed: 6,000 rpm Tool holder: BT50 Number of tool changer positions: 121 Control: FANUC 31iMA Horizontal Machining Center | TOYODA - FH630SX Equipped with high-pressure coolant system (IKZ) and chip conveyor. Additional equipment: + NC rotary table 360,000 x 0.001° The machine is in well-maintained condition. Technical specifications of the machine will follow shortly. Itsdpfxjt I Ec Ds Ahvjp --- #Tags: FH 630SX | FH630 | FH-630 | FH 630 SX

Kondisi: sangat baik (bekas), Tahun pembuatan: 2000, jarak pergerakan sumbu X: 800 mm, jarak lintasan sumbu Y: 700 mm, jarak gerak sumbu Z: 600 mm, gerak cepat sumbu X: 30.000 m/menit, pergeseran cepat sumbu Y: 30.000 m/menit, pergerakan cepat sumbu Z: 30.000 m/menit, dehu1930pro Itedpow Rdl Djfx Ahvep

Tahun pembuatan: 2005, Kondisi: siap digunakan (bekas), A CNC milling machine that has been converted to a horizontal configuration is available. Travel range X/Y/Z: 800mm/700mm/600mm, repeat accuracy: mm. Table diameter: 630mm, max. table load: 600kg, tool magazine: 60 slots, tool holder: 60, tool diameter: 100mm/160mm, tool length: 350mm, max. tool weight: 10kg, feed rate: 50m/min, rapid traverse: 50m/min. Machine dimensions X/Y/Z: approx. 6600mm/5400mm/2750mm, weight: approx. 10,200kg, control system: iTNC 530. Documentation available. On-site inspection is possible. Ijdpfx Ahev Amprjvetp

Kondisi: bekas, TECHNICAL DATA - Number of axes: 5 MILLING SPINDLE - Tool holder: ISO30 - Spindle speed: 18,000 [rpm] Itjdpfxsuhb A Es Ahvsp LINEAR AXES - Travel X/Y/Z axes: 705 / 425 / 610 [mm] SWIVEL AXIS A - Travel: 360 [degrees] (+/-) - Minimum resolution: 0.001 [degrees] SWIVEL AXIS B - Travel: +180/-5 [degrees] (+/-) - Minimum resolution: 0.001 [degrees] TOOL CHANGER - Tool changer type: Bras chargeur - Number of tools in magazine: 32 TABLE - Table size: 1260 x 490 [mm] ELECTRICAL SUPPLY - Supply voltage: 400 [V] - Total power: 22 [kVA] WEIGHT AND DIMENSIONS - Footprint: 2600 x 2300 [mm] - Machine height: 3000 [mm] - Machine weight: 5100 [kg] ACCESSORIES - Control: iTNC 530 - Electronic handwheel - Indexing device type: 4th/5th axis integrated * Manufacturer: Fehlmann * Model: ATS 160 CNC * Clamping diameter: 300 [mm] * Center height: 160 [mm] * Clamping type: Pneumatic - Coolant tank * with high-pressure pump - Oil mist extractor - Spindle cooling - Workpiece measuring probe system: Renishaw OMP 40-2 - Electrical transformer

Kondisi: bekas, Tahun pembuatan: 1999, X-axis 800 mm Y-axis 700 mm Z-axis 600 mm Kontrol Heidenhain TNC 426/430PB Kebutuhan daya total 15 kW Berat mesin sekitar 8,4 t Pusat pemesinan CNC 5 sumbu DECKEL MAHO DMU 80 P Tahun pembuatan 1999 Kontrol Heidenhain TNC 426/430 PB Pergerakan: X 800 mm Itsdpfx Ahjxmtvcsvep Y 700 mm Z 600 mm Sumbu A Sumbu B

Kondisi: bekas, Tahun pembuatan: 2006, Travel (X / Y / Z): 800 mm / 800 mm / 800 mm Control: Heidenhain iTNC 530 Main spindle: - Max. speed: 18,000 rpm - Drive power (main spindle): 28 / 19 kW - Max. torque: 121 / 82 Nm - Tool holder: HSK A63 Swivel axis B: 0 – 190° - Swivel time: 1.2 s NC rotary table: - Table size: 900 x 700 mm - Max. table load: 1,400 kg - Rotary axis C: 360° Tool magazine: - Number of tool positions: 60 - Tool holder: HSK A63 - Tool change time (chip-to-chip): approx. 5.0 s Feeds: - Rapid traverse (X / Y / Z): 60 m/min - Rapid traverse B: 30 m/min - Rapid traverse C: 30 m/min - Max. feed rate: 60,000 mm/min Total connected load: 64 kVA Machine weight: approx. 14.0 t Space requirements: approx. 6.0 x 6.5 x 3.2 m 5-axis CNC universal machining center DECKEL MAHO - DMU 80 P duoBLOCK Ijdpfetqmmzjx Ahvstp - 5-axis simultaneous machining - Swivel milling head - Rotary table

Kondisi: bekas, Tahun pembuatan: 2001, Technical specifications: Tool holder: SK 40 Travel paths: X-axis: 530 mm Y-axis: 450 mm Z-axis: 450 mm Max. tool weight: 260 kg Spindle speed: 12,000 rpm Max. table load: 380 kg Weight, approx.: 6,500 kg Dimensions (LxWxH), approx.: 2000 x 2200 x 2400 mm Equipment: - Heidenhain TNC 430 control Itjdpot Hr Ahjfx Ahvjp - 4th axis by SMP (France)

Kondisi: bekas, Tahun pembuatan: 2008, travel (X/Y/Z): 800 / 800 / 800 mm Control: Heidenhain iTNC 530 Main spindle: - Max. speed: 18,000 rpm - Drive power (main spindle): 28 / 19 kW - Max. torque: 121 / 82 Nm - Tool holder: HSK-A63 Swiveling axis B: 0° - 190° - Swivel time: 1.2 s NC rotary table: - Table size: 900 x 700 mm - Max. table load: 1,400 kg Ijdpfx Aoukwatjhvetp - Rotary axis C: 360° Tool magazine: - Number of tool stations: 40 positions - Tool holder: HSK-A63 - Tool change time (chip-to-chip): approx. 5.0 s Feeds: - Rapid traverse (X/Y/Z): 60 m/min - Rapid traverse (B): 30 m/min - Rapid traverse (C): 30 m/min - Max. feed rate: 60,000 mm/min Total power requirement: 64 kVA Machine weight: approx. 14.0 t Space requirement: approx. 6.5 x 6.5 x 3.5 m 5-Axis CNC Universal Machining Center DECKEL MAHO - DMU 80 P duoBLOCK - 5 axes - Swivel milling head - Rotary table
