This 4-axis DMG Gildemeister SPEED 32/10 linear was manufactured in 2008. It is equipped with a Fanuc 310iS CNC control, a main spindle with a bar capacity of 33 mm, and a maximum spindle speed of 8,000 rpm. The machine offers robust multitasking capabilities with a total of 16 driven tool stations and a turret for efficient machining. If you are looking for a high-quality lathe, you should consider the DMG Gildemeister SPEED 32/10 machine we have for sale. Contact us for further information.

• CNC: Fanuc 310iS
• Control panel type: SlimLine
• Display: 15" TFT color
• Controlled spindles (including C-axes): 2
• Controlled axes: 8
• Channels: 3
• Bar capacity: 33 mm (36 mm max)
• Draw tube inner diameter: 46 mm
• Max. spindle speed: 8,000 rpm
• Rated torque (S1): 24 Nm
• Rated power (S1): 5.5 kW
• Draw tube inner diameter: 38 mm
• Max. spindle speed: 8,000 rpm
• Rated torque (S1): 9.4 Nm
• Rated power (S1): 3.7 kW

Axis X1
• Travel: 50 mm
• Max. speed: 40 m/min
• Max. acceleration: 10 m/s²
• Rated feed force (S1): 1,200 N

Axis Y1
• Travel: 350 mm
• Max. speed: 30 m/min
• Max. acceleration: 5 m/s²
• Rated feed force (S1): 5,000 N
Njdex D Ekgspfx Am Aswf

Axis Z1
• Travel: 320 mm
• Max. speed: 40 m/min
• Max. acceleration: 5 m/s²
• Rated feed force (S1): 2,500 N

Axis X2
• Travel: 310 mm
• Max. speed: 40 m/min
• Max. acceleration: 5 m/s²
• Rated feed force (S1): 2,500 N

Axis Z2
• Travel: 320 mm
• Max. speed: 40 m/min
• Max. acceleration: 5 m/s²
• Rated feed force (S1): 2,500 N

Axis X3
• Travel: 80 mm
• Max. speed: 40 m/min
• Max. acceleration: 5 m/s²
• Rated feed force (S1): 1,200 N

Axis Y3
• Travel: 60 mm (±30 mm)
• Max. speed: 18 m/min
• Max. acceleration: 5 m/s²
• Rated feed force (S1): 5,000 N

Axis Z3
• Travel: 150 mm
• Max. speed: 40 m/min
• Max. acceleration: 5 m/s²
• Rated feed force (S1): 2,500 N

Turret
• Total stations: 16
• Fixed external tools: 8
• Tool shank size: 16×16 mm
• Driven tool stations: 16
• Collet type: ESX/ER 20
• Max. drive speed: 5,000 rpm
• Rated torque (S1): 4.8 Nm
• Rated power (S1): 1.5 kW

Tool holder slide 1
• Total stations: 10
• Fixed external tools: 6
• Tool shank size: 16×16 mm
• Driven tools: 4
• Collet type: ESX/ER 20
• Max. drive speed (GEO 7-9): 5,000 rpm
• Rated torque (S1): 2.19 Nm
• Rated power (S1): 0.55 kW
• Secondary drive speed (GEO 8-10): 3,333 rpm
• Rated torque (S1): 3.28 Nm
• Rated power (S1): 0.55 kW

Rear working slide
• Total stations: 4 + 2
• Internal fixed tools: 3
• Tool holder diameter: 25 mm
• External fixed tools: 1
• Driven stations: 2
• Collet type: ESX/ER 16
• Max. drive speed: 6,000 rpm
• Rated torque (S1): 1.75 Nm
• Rated power (S1): 0.55 kW

Media/Lubrication system
• Tank capacity: 2.9 l
• Operating pressure: 30 bar
• Stop time: 7 minutes
• Operating cycle time: 30 seconds
• Lubricant type: Castrol Magna BD 68

Pneumatic system
• Minimum operating pressure: 5 bar
• Maximum operating pressure: 6 bar
• Consumption: 60 NL/min
