Mesin penggiling permukaan

Jakobsen SJ 824

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2005, jam operasional: 42.768 h, produsen pengendali: HEIDENHAIN, kecepatan spindel (maks.): 18.000 rpm, jumlah sumbu: 5, en Iodpjx Rd Hpofx Ag Rstd

Kondisi: baru, Fungsionalitas: berfungsi sepenuhnya, diameter putar di atas sled silang: 330 mm, lubang spindel: 78 mm, diameter pembubutan di atas alas geser: 520 mm, tinggi pusat: 260 mm, panjang pembubutan: 1.500 mm, gores kuas bulu: 127 mm, diameter quill: 68 mm, panjang total: 2.670 mm, lebar total: 810 mm, kecepatan spindel (maks.): 2.000 rpm, kecepatan spindel (min.): 20 rpm, lebar tempat tidur: 300 mm, berat keseluruhan: 2.135 kg, penjepit rumah spindel: MK 4, Perlengkapan: kecepatan rotasi dapat diubah tanpa batas, Centre height: 260 mm Centre distance: 1500 mm Spindle bore: 78 mm Spindle nose in accordance with DIN 55029 Camlock D8 Spindle speed range: 20–2000 rpm Drive power: 7.5 kW Weight approx. 2135 kg Equipment includes: Isdpjctutmjfx Ag Rstd - Infinitely variable speed control - Hardened and precision-ground Z-axis guideways - Turcite coatings (on mating surfaces) for the tool and cross slides - Manual central lubrication with one pump for longitudinal and cross slides - Complete coolant system with rear splash guard and carriage splash guard - Chuck guard - Control rod with three adjustable cams - Machine lamp - Fixed centre - Set of machine leveling pads

Kondisi: bekas, Tahun pembuatan: 2007, Kecepatan putar 8000 rpm Berat 5500 kg Tahun pembuatan 2007 Kontrol Siemens 840D Dimensi (Panjang/Lebar/Tinggi) 3600 x 2800 x 2400 mm Perjalanan sumbu-x 1035 mm Iodpfx Agswm Rqaj Rstd Perjalanan sumbu-y 560 mm Perjalanan sumbu-z 510 mm Lebih banyak gambar tersedia

Kondisi: bekas, Tahun pembuatan: 2000, drehdurchmesser-mm-drehlaenge-mm-steuerung-2x-840-d-anbauteil-ku ehlmittelsystem-spaenefoerderer-ja-kw-nennstrom-generator-95-00-a -anschlussleistung-65-00-kw-3-maschinen-werden-angeboten-ladesyst em-inventarnummer-21214-maschinenbezeichnung-automatisierung-prom ot-zu-21223-baujahr-1999-x2-2000-x1-steuerung-siemens-sinumerik-8 40d-powerline-elektrische-versorgungsdaten-betriebsspannung-10-00 -kw-nennstrom-18-00-a-backup-25-00-a-2x-1999-1x-2000 Itodpfx Agoqn A Rns Rsd

Kondisi: baik (bekas), Tahun pembuatan: 1988, panjang penggilingan: 1.000 mm, lebar penggilingan: 550 mm, tinggi penggerindaan: 400 mm, diameter roda gerinda: 400 mm, lebar roda gerinda: 100 mm, Manufacturer: ELB-SCHLIFF Model: SWBE 010 ND Year of manufacture: 12/1988 Delivery time: immediate Electro-permanent magnetic chuck SAV 1000 x 400 mm Fine pole pitch 45-5 mm Iodpfx Agou Rqyno Rstd Electronic straight dresser with compensation Vertical digital readout Mounting with grinding wheel max. 400 x 100 x 127 mm Spindle motor 7.5 kW, 1435 rpm Taper wedges Coolant system with universal paper band filter Complete documentation

Kondisi: baik (bekas), Travel (X-axis): 410 mm Travel (Y-axis): 310 mm Travel (Z-axis): 400 mm Main spindle taper: SK 40 Table clamping surface: 700 x 280 mm Spindle speed: 45 – 2000 rpm Itodpei Elydsfx Ag Red Quill stroke: 63 mm Total power requirement: 2.2 kW Machine weight approx.: 1,300 kg Space required approx.: 2.1 x 2.1 x 1.7 m Voltage: 400 V 3-axis digital readout: Heidenhain Fixed angle table Coolant system Swivelling vertical milling head

Kondisi: sangat baik (bekas), 16 shank milling cutters with indexable inserts Manufacturer: Walter Ijdsdx D Tvopfx Ag Rotd Weight: 9.5 kg

Kondisi: bekas, Fungsionalitas: berfungsi sepenuhnya, Grinding length: 973 mm Centre height: 250 mm Iodpfx Aewhp Dneg Rstd Workpiece table max. swivel range: +6° / -9° Centre taper: MT5 Grinding spindle head max. travel: 100 mm Grinding spindle head max. swivelling range: +45° / -30° Max. grinding wheel diameter: 500 mm Speed range: 32 - 600 rpm Max. workpiece weight between centres: 400 kg Internal grinding device max. grindable bore: 160 mm Machine weight: approx. 5,000 kg

Tahun pembuatan: 2008, Kondisi: siap digunakan (bekas), Grinding area: 2000 x 900 mm, cross travel: 875 mm, longitudinal travel: 2450 mm, distance from table to spindle centre: 845 mm, magnetic chuck dimensions: 2000 x 800 mm, max. table load: 2.3 t, longitudinal feed: 1,000–30,000 mm/min, cross feed: 0.01–2,000 mm/min, vertical feed: 0.001–1,500 mm/min, grinding wheel dimensions: 500 x 100 x 203.2 mm, grinding spindle motor power: 22 kW, length: 6,800 mm, width: 3,450 mm, weight: 13 t. Inspection on site is possible. Itsdsuyk N Iopfx Ag Rsd

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2007, jam operasional: 620 h, 1 Ijdpow Dfhzefx Ag Rjtd
