Mobil 3D sistem pengukuran koordinat

KEYENCE WM-3000

Kondisi: sangat baik (bekas), Tahun pembuatan: 2023, Mobile 3D Coordinate Measuring Machine Camera, hand probe with display Max. measuring length 10000/3500/3500 mm Certified measuring range 3000/1500/1500 mm Triple camera Integrated probe camera Measuring accuracy ±(28 + 5 L/1000) μm* Repeatability ±10 μm* Ljdjy Aypkepfx Alkjrk Accessories

Kondisi: siap digunakan (bekas), trad001 Lrodpoxzn E Ujfx Alkjk

Tahun pembuatan: 2022, Kondisi: siap digunakan (bekas), This KEYENCE WM 3000 was manufactured in 2022. As a reliable CMM device, it provides precise dimensional measurement and quality control. Ideal for industries requiring high accuracy in component inspection. Contact us for more information about this device. Max. measuring length (W × D × H): 10,000 mm × 3,500 mm × 5,000 mm Certified measuring range (W × D × H): 3,000 mm × 1,500 mm × 1,500 mm Measurement accuracy: ±(28 + 5 L/1000) μm* Repeatability: ±10 µm Minimum display unit: Distance: 0.001 mm Angle: 0.001° Rotational angle of measuring head: Horizontal: ±90° Vertical: ±30° External input: 2 potential-free inputs Communication: Bluetooth Communication: Bluetooth 5 USB Communication: USB 3.0 Infrared Communication: 945 nm Power supply: Supplied by included power adapter Rated values: Rated voltage: 24 V DC Power consumption: 1.7 A Ambient conditions: Operating temperature: +10°C to +35°C Ljdox D Sdaepfx Alksrk Relative humidity in operation: 20 to 80% RH (non-condensing) External dimensions: 327.7 mm × 250.9 mm × 357.3 mm Additional equipment • WM 3000 measuring head • USB cable • Power supply unit • WMP3000 probe • Probe tip Ø 5 mm • Calibration device • Tripod • 3D CAD add-on software • Transport case • 4x batteries for probe Benefits of the machine Technical advantages of the machine • Battery charger • Dongle for measurement software Additional information Machine still powered on

Tahun pembuatan: 2020, Kondisi: sangat baik (bekas), Fungsionalitas: berfungsi sepenuhnya, Mobile 3D Coordinate Measuring Device – Flexible 3D Measurements Anywhere Image-Guided 3D Coordinate Measuring Device Keyence Measurement System WM-3000 Coordinate Measurement System XM-2000, XM-1600 Digital Inspection Station TECHNICAL DETAILS Camera Sensor: 4 MP CMOS Measuring Range: 600 x 300 x 200 mm Smallest Display Unit: 1 µm Smallest Angle: 0.0001° Repeatability (locked): ±3 µm Table Load Capacity: max. 25 kg Display: 15" TFT First Commissioning: 12/2020 Coordinate Measuring System Measuring Head: WM-3000 Camera Tripod: WM-S1 Tripod Extension / Base for Measuring Head: WM-EX1 Measuring Software: incl. laptop Lrsdpfjpz Itysx Alkjk Additional Software 3D CAD Import/Export: WM-H1C WM Battery Charger: WM-BC1 Probe Battery: WM-B1 Stylus: OP-88422; 2.5 mm Mouse: WM-M30D User Manual: German Euro AC Cable: OP-99032, OP-99033 Adapters for Camera Realignment: OP-88546 Calibration Cone for Needle Probe: OP-88547 Magnets for Camera Realignment Adapters: 972344 Digital Inspection Station Measuring Head: XM-2000 Digital Inspection Station Control Unit: XM-1600 Additional Software 3D CAD Import/Export: XM-H1C XM Mouse, Keyboard: XM-M26E User Manual: English AC Cable: OP-99031 MACHINE DETAILS Main Electrical Connection: 24 V Measuring Head Weight: 25.0 kg Tripod Weight: 4.5 kg Extension Weight: 4.0 kg

Tahun pembuatan: 2021, Kondisi: hampir baru (bekas), Mobile 3D coordinate measuring device Keyence WM-3000 Device in as-new condition, being sold due to purchase of a new machine Technical specifications available from the manufacturer Lrodemrrb Sjpfx Alkek Inspection possible in 47877 Willich

Kondisi: baik (bekas), Tahun pembuatan: 2022, Perlengkapan: Pelat tipe tersedia, Data Teknis - KEYENCE WM 3000 Perlengkapan tambahan Lsdpfxsw Sviqe Alkork - Kepala pengukur WM 3000 - Kabel USB - Catu daya - Probe pengukur WMP3000 - Ujung probe Ø 5 mm - Alat kalibrasi - Tripod - Perangkat lunak tambahan 3D-CAD - Koper transportasi - 4x baterai untuk probe pengukur
