Beli Cnc Pengeboran Mesin bekas (77.632)

Kondisi: hampir baru (bekas), Tahun pembuatan: 2022, Fungsionalitas: berfungsi sepenuhnya, diameter putar di atas sled silang: 120 mm, panjang pembubutan: 120 mm, diameter pembubutan: 60 mm, lubang spindel: 34 mm, kecepatan spindel (maks.): 5.000 rpm, kecepatan spindel (min.): 100 rpm, jarak pergerakan sumbu X: 150 mm, jarak gerak sumbu Z: 170 mm, daya motor spindle: 2.200 W, tinggi total: 1.500 mm, panjang total: 1.200 mm, lebar total: 1.000 mm, kecepatan pemakanan sumbu X: 15 m/menit, laju pemakanan sumbu Z: 15 m/menit, berat keseluruhan: 1.058 kg, hidung spindel: Ø 85 mm, Dijual mesin bubut CNC 2-sumbu Poly Gim MINI-88 yang sangat ringkas, tahun pembuatan 2022. Karena desainnya yang sangat ringkas, MINI-88 sangat cocok untuk produksi ekonomis suku cadang bubut presisi kecil dan sederhana, untuk produksi dalam jumlah kecil, serta untuk perusahaan dengan ruang terbatas. Mesin ini juga dapat diintegrasikan ke dalam jalur produksi yang ada dengan menghemat ruang. DATA TEKNIS Mesin: - Mesin bubut CNC 2-sumbu - Pengontrol: Fanuc 0i-TF Plus - Tahun pembuatan: 2022 - Jam operasi: 0 Rentang pemesinan: - Diameter pemesinan maks. dengan chuck: 60 mm - Diameter pemesinan maks. dengan collet: 26 mm - Diameter pembubutan: 60 mm - Panjang pembubutan: 120 mm - Diameter batang: 26 mm Spindel utama: - Rentang kecepatan: 100–5.000 RPM - Motor spindel: 2,2 kW pada 100% ED / 3 kW pada 50% ED Pergerakan: - Sumbu X: 150 mm - Sumbu Z: 170 mm Sistem perkakas: - Penerima perkakas: 16 × 16 mm - Penerima batang bor: Ø 20 mm - Unit pemrograman terkecil: 0,001 mm - Turret 8 posisi dan sistem linier PERLENGKAPAN - Chuck rahang 4 inci hidraulik - Perangkat penjepit hidraulik untuk chuck dan collet - Konveyor serpihan - Wadah suku cadang - Panduan datar pada sumbu Z - Pelumasan terpusat - Pompa pendingin - Antarmuka RS232 dan PCMCIA - Grafik garis Mesin dapat diperiksa di lokasi kami di 78132 Hornberg setelah perjanjian sebelumnya. Jika Anda memiliki pertanyaan, untuk informasi teknis lebih lanjut, atau untuk mengatur janji temu inspeksi, Arnd Sauter GmbH akan dengan senang hati membantu Anda kapan saja. Dcjdpfxewpgiwe Ap Ejk Penjualan dan kesalahan dapat terjadi.

Tahun pembuatan: 2018, Kondisi: bekas, nomor mesin/kendaraan: 01160, Diameter pemesinan maksimum: 42 mm, panjang pemesinan maksimum: 300 mm, kontroler FANUC Seri 32I-Model B, unit filter, 1 pengumpan batang dari sisi kiri BARLOAD Vito, tahun pembuatan: 2018, nomor seri: 22181574, berat: 980 kg, sabuk konveyor dari sisi kanan, konveyor serpihan, pendingin oli HABOR, sistem pemadam, tanpa perkakas. Dcjdpfx Aszqy S Eep Ejk

Tahun pembuatan: 2018, Kondisi: bekas, nomor mesin/kendaraan: 01167, 8 sumbu, diameter pemesinan maksimum: 42 mm, panjang pemesinan maksimum: 300 mm, dilengkapi dengan kontroler FANUC Series 32i-Model B, konveyor, pengangkut serpihan, pemuat batang sisi kiri BARLOAD Vito, tahun pembuatan: 2018, nomor seri: 22181650, unit filter dan pendingin, tanpa perkakas. Dcsdpfx Aszqy Ugep Eek

Kondisi: bekas, Tahun pembuatan: 2011, nomor mesin/kendaraan: 268S24, Diameter batang maksimum: 32 mm, panjang pemesinan maksimum: 250 mm, dilengkapi dengan kontrol FANUC Seri 160i-TB, ban berjalan, konveyor serpihan, pemuat batang sisi kiri FMB Turbo 3-36, nomor seri: 51-261463/876667, tahun pembuatan: 2011, unit filter dan pendingin, sistem tekanan tinggi COMBILOOP, tanpa perkakas. Dcedpfxozqy T No Ap Eok

Kondisi: bekas, Tahun pembuatan: 2012, nomor mesin/kendaraan: 282S25, Diameter batang maksimum: 32 mm, panjang pemesinan maksimum: 250 mm, kontroler FANUC Seri 160i-TB, konveyor ERUTE, magasin pemuat batang sisi kiri FMB Turbo 3-36, nomor seri: 52-261754/966566, unit filter, sistem bertekanan tinggi MÜLLER combiloop CL3, dengan konveyor serpihan, tanpa alat. Dcjdpfezqy Tiox Ap Esk

Kondisi: bekas, Tahun pembuatan: 2013, nomor mesin/kendaraan: 289S26, Diameter batang maksimum: 32 mm, panjang pemrosesan maksimum: 250 mm, pengontrol FANUC Seri 160i-TB, konveyor ERUTE, majalah pengumpan batang sisi kiri FMB Turbo 3-36, nomor seri: 53-262361 / 1117340, unit filter, sistem bertekanan tinggi MÜLLER combiloop CL3G, nomor seri: CL3459, dengan konveyor serpihan, sistem pemadam, tanpa perkakas. Djdpjzqy Tcofx Ap Ejck

Kondisi: bekas, Tahun pembuatan: 2016, nomor mesin/kendaraan: V842A0096, Mesin dengan kontrol SIEMENS Sinumerik 840 D, nomor seri V842A0096, tahun pembuatan 2016. Diameter batang maksimum 42 mm, panjang langkah maksimum 180 mm. 8 spindel yang digerakkan secara independen, kecepatan spindel maksimum 4.500 RPM, daya per motor spindel 11 kW (daya total 88 kW), torsi spindel maksimum 66 Nm, waktu penggantian alat per posisi spindel 1 detik. Maksimum 8 sled horizontal, maksimum 7 sled silang, 1 sled pemotong. Dimensi mesin tanpa peralatan periferal sekitar 7.100 x 2.400 x 3.300 mm, dimensi kabinet kontrol sekitar 5.000 x 600 x 2.300 mm. Berat mesin sekitar 18.000 kg, berat kabinet kontrol sekitar 2.500 kg. Pengumpan batang IEMCA PRA 52/P/33, tahun pembuatan 2018, nomor seri 021813EA02. Dilengkapi dengan konveyor serpihan dan sistem filtrasi ZPS 925A1851C1F, tahun pembuatan 2016, nomor seri 0013. Tanpa alat. Dcodozqy Slepfx Ap Esk

Kondisi: bekas, Tahun pembuatan: 2018, nomor mesin/kendaraan: V842A0141, Mesin dengan kontrol SIEMENS Sinumerik 840 D, nomor seri V842A0141, tahun pembuatan 2018. Diameter batang maksimum 42 mm, panjang langkah maksimum 180 mm. 8 spindel dengan penggerak independen, kecepatan spindel maksimum 4.500 RPM, daya per motor spindel 11 kW (total daya 88 kW), torsi spindel maksimum 66 Nm, waktu penggantian alat per posisi spindel 1 detik. Maksimum 8 kereta geser longitudinal, maksimum 7 kereta geser silang, 1 kereta geser pemotong. Dimensi mesin tanpa perangkat periferal sekitar 7.100 x 2.400 x 3.300 mm, dimensi lemari kontrol sekitar 5.000 x 600 x 2.300 mm. Berat mesin sekitar 18.000 kg, berat lemari kontrol sekitar 2.500 kg. Pengumpan batang IEMCA PRA 52/P/33, tahun pembuatan 2018, nomor seri 021809EA02. Dilengkapi dengan ban berjalan serpihan, sistem penyaringan ZPS 925A1851C1, tahun pembuatan 2018, nomor seri 0037, serta unit pendingin. Tidak termasuk peralatan. Dcedezqy Srepfx Ap Eek

Tahun pembuatan: 2017, Kondisi: bekas, nomor mesin/kendaraan: 01142, Diameter pemesinan maks.: 42 mm, panjang pemesinan maks.: 300 mm, sistem kontrol FANUC Seri 32I-Model B, unit filter, 1 pengumpan batang di sisi kiri BARLOAD Vito, tahun pembuatan: 2017, nomor seri: 22171258, berat: 980 kg, konveyor di sisi kanan, pengangkut serpihan, tanpa perkakas. Dcsdpfxszqy Sxo Ap Esk

Tahun pembuatan: 2017, Kondisi: bekas, nomor mesin/kendaraan: 01147, 8 sumbu, diameter pemesinan maksimum: 42 mm, panjang pemesinan maksimum: 300 mm, dilengkapi dengan kontroler FANUC Seri 32i-Model B, ban berjalan, konveyor serpihan, unit filter dan pendingin, pengumpan batang sisi kiri BARLOAD Vito, tahun pembuatan: 2017, nomor seri: 22171425, pendingin oli HABOR, tanpa perkakas. Dedpfx Aezqy Tpsp Ejck

Tahun pembuatan: 2018, Kondisi: bekas, nomor mesin/kendaraan: 01163, 8 sumbu, diameter pemesinan maksimum: 42 mm, panjang pemesinan maksimum: 300 mm, dilengkapi dengan kontrol FANUC Seri 32i-Model B, konveyor, pengangkut serpihan, unit filter dan pendingin, pengumpan batang sisi kiri BARLOAD Vito, tahun pembuatan: 2018, nomor seri: 22181648, pendingin oli HABOR, tanpa perkakas. Dcsdpfxjzqy T Ao Ap Eek

Kondisi: bekas, Tahun pembuatan: 2011, nomor mesin/kendaraan: 265S24, Diameter batang maksimum: 32 mm, panjang pemrosesan maksimum: 250 mm, dengan sistem kendali FANUC Series 160i-TB, konveyor, pengangkut serpihan, pengumpan batang sisi kiri FMB Turbo 3-36, nomor seri: 50-2614661/867593, tahun pembuatan: 2010, unit filter dan pendingin, sistem bertekanan tinggi COMBILOOP, tanpa perkakas. Dodpfxjzqy Uas Ap Esck

Tahun pembuatan: 2018, Kondisi: bekas, nomor mesin/kendaraan: 01161, 8 sumbu, diameter pemesinan maksimum: 42 mm, panjang pemesinan maksimum: 300 mm, dilengkapi dengan sistem kontrol FANUC Series 32i-Model B, konveyor, pengangkut serpihan, unit filter dan pendingin, pengumpan batang sisi kiri BARLOAD Vito, tahun pembuatan: 2017, nomor seri: 22171425, pendingin oli, tanpa perkakas. Dcsdpfxozqy Tvo Ap Eek

Kondisi: baik (bekas), Tahun pembuatan: 2004, Fungsionalitas: berfungsi sepenuhnya, diameter putar di atas sled silang: 600 mm, panjang pembubutan: 670 mm, diameter pembubutan: 490 mm, berat keseluruhan: 6.500 kg, MYYNNISSÄ: Korkealaatuinen CNC-sorvi Biglia B 658 MB (vm. 2004) käyttöistettyine työkalupaikkoineen + KID 70 tankomakasiinisyöttö Etsitkö luotettavaa ja vankkaa työjuhtaa metallin työstöön? Myytävänä on Biglia B 658 MB -CNC-sorvi hyvässä, täysin toimintakunnossa. Koneessa on käyttöistetyt työkalupaikat, automaattinen vastatuki, luotettava Fanuc-ohjaus, ja mukaan kuuluu automaattinen tankosyöttölaite. Koko paketti saatavilla heti varastosta. Yleistä tietoa Valmistaja: Biglia (Italia) Malli: B 658 MB Valmistusvuosi: 2004 CNC-ohjaus: FANUC Series 18i-TB Kunto: Hyvä, täysin toimintakuntoinen Saatavuus: Heti varastosta --- Keskeiset tekniset tiedot (sorvi) Dcsdozbx N Eepfx Ap Esk Suurin sorvaushalkaisija: 380 mm Suurin sorvauspituus: 650 mm Suurin tanko-/kappalehalkaisija: 80 mm Suurin karanaukko: 620 mm Karan kierroslukualue: 30–3000 rpm Karan teho: 26/22 kW Karaliitos: ASA 8″ Karan poraus: 90 mm Istukan halkaisija: 315 mm Bimodaalinen revolveri: 12 paikkaa Revolverin indeksiaika (1 paikka): 0,1 s Käyttöistetyt työkalupaikat: 12 paikkaa Käyttöistettyjen työkalupaikkojen maksiminopeus: 4000 rpm Maksimivääntömomentti käyttöistetty työkalupaikka: 3,7 kW Syötöt X/Z/B-akselilla: 220 / 650 / 660 mm Pikasiirto X/Z/B-akselilla: 20 / 24 / 12 m/min Automaattisen vastatuen maksimipuristusvoima: 1080 kg --- Tankosyötön tekniset tiedot Pyöreän tangon halkaisija: min. 5 mm (3/16") – max. 70 mm (2"3/4) Neliötangon sivu: min. 5 mm (3/16") – max. 50 mm (2") Kuusikulmaisen tangon korkeus: min. 5 mm (3/16") – max. 60 mm (2 1/4") Suurimmat tangon pituusvaihtoehdot: 500 mm / 1615 mm Makasiinin kapasiteetti: 250 kg (esim. noin 60 kpl 10 mm tankoa) Tangonvaihtoaika: 50 s (1000 mm tangolla) Syöttönopeus: 0–500 mm/s Palautusnopeus: 1000 mm/s Syöttöjännite: 230/400 V Ohjausjännite: 24 V Asennettu teho: 2 kW Paino: 580 kg Lisävarusteet & ominaisuudet KID 70 tankosyötin Mitta- ja kosketusvarsi Lastunkuljetin Holkki-istukka DIN 6343 Jäähdytysnestesäiliön tilavuus: 250 l Jäähdytyspumpun kapasiteetti: 150 l/min Jäähdytyspumpun teho: 0,73 kW Melutaso: 74 dB(A) Fyysiset mitat (sorvi) Mitat (P x L x K): 4000 x 1900 x 1850 mm Biglia B658/BM:n paino: n. 6000 kg Ota yhteyttä ja pyydä tarjous tästä täydellisestä tuotantopaketista! Koneet ovat heti valmiina toimitukseen. > *(Kaikki tiedot annetaan hyvässä uskossa, mutta oikeus muutoksiin pidätetään)*

Kondisi: sangat baik (bekas), Tahun pembuatan: 2009, Fungsionalitas: berfungsi sepenuhnya, MAZAK QUICK TURN NEXUS 100-II MSY Diameter pemesinan maks.: 280 mm Panjang pemesinan maks.: 400 mm Kecepatan milling maks.: 4.500 rpm Kecepatan spindle maks.: 6.000 rpm Diameter batang maks.: 42 mm Mesin dilengkapi dengan: - CNC Control Mazatrol Matrix - Chuck tiga rahang KITAGAWA B-206 untuk spindle utama - Chuck tiga rahang KITAGAWA B-205 untuk spindle kedua - Tool Eye - Poros C - Poros Y - Antarmuka untuk bar feeder - penangkap benda kerja otomatis - pompa pendingin yang diperkuat - 8 buah dudukan alat tetap - 2 buah dudukan alat bermotor Dodoy S A Riepfx Ap Eeck

Kondisi: bekas, Tahun pembuatan: 2018, en: Startech cn MAIN FEATURES FLEXIBLE AND CUSTOMISABLE PRODUCTION COMBINED WITH SPEED AND PRECISION DRILLING FROM ABOVE WITH REFERENCE TO THE TOP SIDE OF THE PANEL ALLOWS FOR ABSOLUTELY PRECISE MACHINING NUMERICAL CONTROL WITH 7" COLOUR SCREEN: EASY AND INTUITIVE TECHNICAL SPECIFICATIONS Startech CN AXES Max. workpiece dimensions X-Y-Z mm 3050 x 800 x 50 Min. workpiece dimensions X-Y-Z mm 300 x 90 x 10 Working area drilling/grooving mm 0 x 800/0 x 800 X-axis stroke mm 750 Max. traversing speed X-Y axes m/min 25 DRILLING UNIT Vertical spindles Number 7 (4X-4Y, one shared) Horizontal spindles (along Y axis) Number 2 (1+1) Horizontal spindles (along X axis) Number 1 Fixed groove saw (direction) X Groove saw diameter mm 100 Max. groove saw thickness mm 5 Motor power kW (HP) 1.5 (2) Spindle speed rpm 3350 Groove saw speed rpm 4300 INSTALLATION Power supply V (Hz) 380 / 400 (50 / 60) Installed power KVA 4.5 Compressed air requirement bar 6 Air consumption Nl/cycle 90 Extraction requirement m3/h 1200 Extraction air speed m/sec 20 Extraction nozzle diameter mm 120 GENERAL FEATURESUniversal CNC drilling machine with fixed gantry work table and moving workpiece for performing the following operations: - Vertical drilling on the panel surface - Horizontal drilling on all four sides of the workpiece - Grooving with integrated groove saw in "X" direction Self-supporting frame Machine base in steel tube construction to provide a large base for the work table. The structure is positioned on 3 self-levelling feet. The electrical cabinet is integrated into the machine base. Central Bakelite support table "Easy Motion": - an MDF sector for through drilling, automatically swivelling away for horizontal drilling - an infeed roller to facilitate panel feeding - a rear roller track to facilitate panel sliding - left and right stops - a manually adjustable central alignerIt is necessary to use the left and right stops to drill the two opposite panel sides horizontally in the "X" direction. Panel positioning along the X-axis by vacuum suction cups. Unit carriage This is a gantry structure in steel tube construction. The main working unit is installed on the gantry. F10L drilling unit includes: - 7 independent vertical spindles- chuck D10 mm- spindle spacing 32 mm - 2 horizontal drilling heads, 1 in X direction with one drill, 1 double drilling head in Y direction (1 + 1 chuck D10 mm) - speed 3350 rpm- 1 integrated saw unit in X (max. diameter 100 mm) - saw blade speed 4300 rpm- motor power 1.5 kW - vertical pneumatic stroke per spindle 70 mm - horizontal pneumatic stroke of the drilling unit Positioning of the workpiece and drive of the working unit A CNC-controlled vacuum cup clamps the workpiece and positions it sequentially under the working unit during machining. X and Y axis movement on THK linear guides with reinforced toothed belt transmission; Z axis movement is pneumatic on ball-bushing guides with position stop adjustable via the working unit position. Positioning of the work units via state-of-the-art control and drive technology -CONTROL The control system was specially developed for industrial use. Dcodpfx Apovwbp Aj Eek

Kondisi: bekas, Tahun pembuatan: 2011, Besar area kerja pada arah X: 2770 mm Besar area kerja pada arah Y: 1220 mm Ketebalan pemrosesan (ukuran Z): 80 mm Konstruksi mesin: mesin portal Daya spindle utama: 11,0 kW Kecepatan spindle utama: 1500 - 24000 rpm Spindle dengan kontrol vektor: Ya Sistem penjepitan: HSK 63 F Pendingin spindle: Pendingin udara Jumlah sumbu: 3 Penukar alat: Ya Tempat alat: 10 unit Keyboard mesin tik: Ya Mouse: Ya Sistem program: Xilog Plus DXF Interface: Ya Koneksi online memungkinkan: Ya CD Rom Drive: Ya Tipe meja: meja grid Sistem pemberhentian: silinder pemberhenti Jumlah pompa vakum: 1 Kapasitas pompa vakum: 250 m³/h Pengaman: alas pijakan keselamatan Lokasi gudang: Sonnefeld Dcedevvi Htjpfx Ap Eek

Kondisi: bekas, Tahun pembuatan: 2004, Lokasi gudang: Nattheim Dedpfx Apsvvi Hyo Eeck

Kondisi: bekas, Tahun pembuatan: 1994, Lokasi gudang: Nattheim Dsdewmm Nrepfx Ap Esck

Kondisi: bekas, Tahun pembuatan: 2002, Dimensi pemesinan (diameter alat 25mm): X=3015 mm Y=1483 mm Z=325 mm Maks. pergerakan sumbu: X=3268 mm Y=1483 mm Z=325 mm Kecepatan pemrograman maks.: X/Y = 75 m/menit / Z = 30 m/menit Dudukan alat HSK 63F Unit bor 7964, 14 spindle bor vertikal dengan rasio 32 mm (10 di x / 4 di y) Unit gergaji 7946 3,6 kW, dapat diputar pneumatik 90° Unit frais 7933 9 kW kayu dengan sumbu C Magasin alat (piringan, 6 slot) Panel kontrol manual Perangkat laser (untuk posisi cangkir vakum) Panel kontrol PC dengan monitor 17" Sistem operasi Windows 2000 Perangkat lunak: TwinCAM32 – versi kantor Pompa vakum 100 m³/jam, tipe kering, karpet alas keselamatan selektif (pembagian 3 bidang) Djdpovvi Nbofx Ap Esck Lokasi penyimpanan: Nattheim

Kondisi: bekas, Tahun pembuatan: 2008, · Working area X-Y-Z: 3,660 x 1,550 x 130 mm · Travel length X-Y: 4,200 x 2,000 mm Aggregate and Accessories Description (Basic) The machine base structure is a monolithic design made from thick-walled steel. It is reinforced with welded triangular plates throughout the entire machine bed, providing extreme stability. The use of a triangle shape with a broad base for all load-bearing elements is the key to ensuring long-term precision and stability. The machine layout allows the operator to achieve an optimal workflow with minimal space requirements. This foundation provides a balanced, secure base for the processing unit with excellent load distribution. The mobile portal-type aggregate carrier is constructed as a solid monoblock. It is positioned in the X-axis along ground prismatic guides via recirculating ball carriages. The working aggregate is mounted to this portal carrier on ground prismatic guides and recirculating ball carriages. Axis Movement: Y and Z axes are driven by precision-ground recirculating ball screws of the highest accuracy class. The X-axis drive is a backlash-free, preloaded precision rack-and-pinion system. This ensures even load distribution during positioning, which is crucial for balanced movements even in complex operations. Axis movements are realized by brushless AC servo motors. These provide outstanding positioning speeds with very short ramp times. Additionally, all motors feature fully integrated measurement systems, making this drivetrain entirely maintenance-free. · Rapid traverse in X: 40 m/min · Rapid traverse in Y: 60 m/min · Rapid traverse in Z: 22.5 m/min Vacuum System (Basic) · Vacuum pump: 100 cbm/h · Power: 2.5 kW · Max. vacuum (connection): 0.9 bar Control / Electrical Cabinet · Office PC or industrial PC (see options) · Basic NC control: ESA-GV KVARA 6.0 · Cable remote control with main functions ELECTRICAL/ELECTRONIC CNC CONTROL Universal is equipped with a powerful NC control system. The integrated office PC provides an unmatched level of familiarity to the NC system: the software operates on Windows XP, allowing fast and simple programming—even for inexperienced users. The system is open and allows connections to a CD-ROM drive, audio card, barcode reader, modem, printer, scanner systems, etc. Installation of any network systems or commercially available CAD programs is also possible. To save space, the electrical cabinet is mounted beneath the machine table, while the operator uses a separately mobile, wheeled console that can be freely positioned. PROGRAMMING SYSTEM XILOG Software features: - Import of DXF files - Import of ASCII files - Operator interface available in native language (I - GB - F - D - E) - Linear and circular interpolation in three axes, linear in space, helical on selected plane - Assisted programming - Calculator for direct transfer of computed data - Graphical and syntax aids for drilling and milling operations - Parametric programming for repeating panel machining on different p Dcedpevvi Nzofx Ap Esk

Kondisi: bekas, Tahun pembuatan: 2020, CNC-CONTROLLED MACHINING CENTER WITH MULTIFUNCTION TABLE - WORK CELL VERSION X400 CELL Drilling and Milling Made for You! The numerically controlled machining center comes equipped with a comprehensive range of accessories and tooling for milling and drilling, designed to meet any requirement in the processing of wood and similar materials. - High-performance: Equipped with drilling spindles capable of 8,000 rpm and industry-leading spindle technology, it features the most robust spindle currently available on the market, offering over 1,000 hours of maintenance-free operation. - Superior and more comprehensively equipped: Multiple configuration options via the multifunction table ensure the machine can be optimally adapted to any operational requirement. - Easier and more intuitive programming thanks to the integrated MAESTRO CNC CAD-CAM module. - User-friendly: The worktable is accessible at all times, the control cabinet and vacuum pump are integrated, and in the PRO SPACE configuration, there are no protective barriers. Load-Bearing Structure The supporting structure consists of an exceptionally robust monolithic steel base, heavily ribbed and highly rigid; the particularly wide support surface was specially designed to give the machine stability and to maintain ongoing precision under all working conditions, with no need for anchoring to the floor. The base provides a large, solid platform for the moving gantry: the work unit thus benefits from a balanced, stable, and resilient support capable of withstanding heavy use, resulting in higher quality performance and increased accuracy. The moving gantry itself is a sturdy single piece anchored on both sides of the base and runs on top-grade prismatic linear guides with recirculating ball shoes. The dual drive system on the X-axis delivers peak performance even under heavy-duty conditions. The movement of the lower mobile unit (X-axis) and the working unit along the beam of the mobile unit (Y-axis) is driven by helical rack and pinion transmission, offering increased tooth-to-tooth engagement for higher acceleration and greater speed along both the X and Y axes. The specially designed helical teeth ensure reduced wear of mechanical parts and significantly quieter operation. The vertical Z-axis is driven by a recirculating ball screw, engineered to deliver perfect balance under dynamic load and handle both rapid acceleration and deceleration. The main milling unit is directly coupled to the Z-axis slide, ensuring the highest quality of finishing work by completely eliminating potential vibrations. Movement along the X-Y-Z axes is driven by brushless motors powered by static inverters, which provide: - Reduced processing times thanks to improved acceleration - Increased positioning accuracy due to high-resolution encoders - No need for setup resetting when the machine is powered on thanks to absolute encoders - Minimal maintenance, as the brushless system eliminates the need for brushes Dcsdpfxsvvi N Io Ap Esk Axis movement and all machine work functions are managed via an industrial NS module with digital D...

Kondisi: bekas, Tahun pembuatan: 2008, · Working area X-Y-Z: 3,660 x 1,550 x 130 mm · Travel range X-Y: 4,200 x 2,000 mm Description of units and accessories (standard configuration) The base structure is a monolithic construction made of thick-walled steel. It is reinforced across the entire machine bed with welded triangular plates, providing exceptional stability. The triangular shape used for the load-bearing elements, with a wide base, is the secret to ensuring long-term precision and stability. The machine layout allows the operator an optimal workflow even with minimal space requirements. Thus, the base structure provides the machining unit with a balanced and secure foundation with particularly good load distribution. The moving portal-type aggregate carrier is constructed as a solid monoblock. It is positioned in the X direction on prismatically ground guides and recirculating ball bearing carriages. The working unit is also mounted on prismatic, ground guides and recirculating ball carriages on this mobile aggregate carrier. Axis movement: The drive system for the Y and Z axes uses ground recirculating ball screws of the highest precision class. The drive in the X-axis is via a backlash-free, preloaded precision rack-and-pinion drive. This ensures balanced load distribution during positioning. Such characteristics are essential for smooth movement even during more complex operations. The movement of the individual axes is performed by brushless AC servomotors. These motors offer excellent positioning speed due to very low ramp-up times. Furthermore, the measuring systems are fully integrated into these motors, making this drive type completely maintenance-free. · Rapid traverse speed in X: 40 m/min · Rapid traverse speed in Y: 60 m/min · Rapid traverse speed in Z: 22.5 m/min Vacuum system (standard) · Vacuum pump: 100 cbm/h · Power: 2.5 kW · Max. vacuum (connection): 0.9 bar Control / Control cabinet · Office PC or industrial PC (see options) · Standard NC control: ESA-GV KVARA 6.0 · Cable remote control with main functions ELECTRICAL/ELECTRONIC CNC CONTROL Universal is equipped with a powerful NC control. The integrated office PC gives the NC control an unmatched level of familiarity: the software operates on Windows XP, allowing fast and easy programming that is also user-friendly for inexperienced operators. The system is open, permitting the connection of a CD-ROM drive, sound card, barcode reader, modem, printer, scanning systems, etc. Additionally, all common network systems and commercially available CAD programs can be installed. To save space, the control cabinet is placed beneath the machine table, while the operator works at a separate, movable terminal on castors. PROGRAMMING SYSTEM XILOG Software features: - Import of DXF files - Import of ASCII files - User interface in the operator’s native language (available in languages: I - GB - F - D - E) - Straight line and circular interpolation in three axes, linear in space, spiral in the selected plane - supported programming - Calculator for direct data transfer - Graphic and syntax help for drilling and milling operations - Parametric programming, enabling identical panel machining on various Dodpfx Aovvi Rfop Eeck

Kondisi: bekas, Tahun pembuatan: 1999, Lokasi gudang: Nattheim Dcedpfsvvi Rxsx Ap Eek

Kondisi: bekas, Tahun pembuatan: 1995, Lokasi gudang: Nattheim Dcsdpfx Apswkirqo Ejk
