Beli Cnc Penggilingan Mesin Dan Mesin Pusat bekas (79.055)

Kondisi: perlu perbaikan (bekas), Tahun pembuatan: 1987, For sale: a compact Maho machining center, model 300 C. The power supply is defective but can be repaired. Technical data: - Year of manufacture: 1987 - Model: MH 300 C Kdjdpfx Asir U H Esfiek - CNC control: Phillips 432 - Table size: 550 x 275 mm - Travel (X/Y/Z): 300/350/220 mm - Tool holder: SK 40 - Spindle speed: 20–4,000 rpm - Main drive: 3.3 kW - Rapid traverse: 3 m/min - Quill stroke: 50 mm - Dimensions: 2,000 x 2,000 x 2,000 mm - Weight: approx. 1,900 kg Prices are subject to VAT. Inspection by appointment. Please contact us—our team will be happy to assist you. Trade-in or exchange possible! Machinery purchase and sales PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINERY, AND MORE. Are you looking for a high-quality yet affordable metalworking machine for your operation? Or are you looking to sell your equipment? For more information or contact options, please visit our website.

Kondisi: baru, Tahun pembuatan: 2026, CNC machining center CORMAK NST2131129A LOADING/UNLOADING has been designed for companies that prioritize high processing power, cost-effectiveness, and machine reliability. This automatic nesting center offers substantial capabilities, particularly in its most popular version, equipped with an innovative storage and pusher unit that enables smooth loading and unloading of full-size sheets as well as efficient collection of finished parts onto a specially adapted table. The CORMAK CNC router is capable of processing multiple sheets simultaneously in one cycle, ensuring continuous production even under heavy workloads. Key features of this advanced machine include precise and very fast material processing, enabled by: - Automatic loading and unloading system using specially designed suction cups, with automatic referencing transferring sheets to the horizontal drilling zone - Intelligent, rapid tool selection from a 12-position “revolver” type tool changer - Efficient dual drilling units and HQD/HSD spindles (industrial spindles with ceramic bearings) - Pneumatic reference pins, LCD control panel and all necessary control software included - Large safety guard - Six retractable positioning stops for workpiece fixing - Electronics from Siemens, Schneider, and Phoenix - Feed-in and outfeed tables Additionally, the center features an advanced nesting and toolpath optimization algorithm, enabling flexible production and efficient material utilization. The chip extraction system and centralized lubrication system ensure not only clean and safe operation but also the long-term reliability of the machine. Overall, the CORMAK NST2131129A CNC machining center is the ideal solution for companies seeking efficient, reliable, and versatile material processing machinery. Technical Specifications: - Working area: 2100 x 3100 mm - Z-axis travel: 300 mm - Construction: Cast iron arm / welded steel table - 12-position umbrella-type tool changer, ISO30 standard - Tool length measurement sensor - Automatic XYZ axis lubrication system - INOVANCE servo drives (1.3 kW for XY, 850 W for Z-axis) with planetary gearbox - T-slot / hybrid / feed and outfeed table - Two-layer, multi-hole, vacuum Bakelite worktable with rubbers and mounting screws, with positioning system - Spindle power: 9 kW Kedjunw N Aopfx Afiedk - HQD spindle air cooled (oil mist optional) - Spindle speed: 6,000–24,000 rpm - Power supply: 400 V, 3PH, 50 Hz - Repositioning accuracy: 0.01 mm - Linear guideways: Hiwin carriages on trapezoidal rails - Vacuum/hybrid workpiece fixing - Vacuum pump 2 x 7.5 kW (optional) - Control system software: SYNTEC 60WE - Dimensions: 10300 x 3600 x 2430 mm - Weight: 2050 kg Optional extras (at additional cost): - Vacuum pump: e.g., Becker KVT 5.5 kW or 7.5 kW - Top-class safety barriers - Latest UCanCAM V12 software - Oil mist system installation possible

Tahun pembuatan: 2010, Kondisi: hampir baru (bekas), I am selling a radius copy milling unit for edges, suitable for CNC machining centers with edge banding from brands such as HOMAG, WEEKE, BIESSE, SCM, MORBIDELLI, HOLZ-HER, IMA, FELDER, MASTERWOOD, BUSELLATO, etc. - 12,000 rpm - Radius: R2mm - HSK63 chuck Available immediately. Kdsdpohw Db Iefx Afiok

Kondisi: baru, Tahun pembuatan: 2020,

Kondisi: baru, Tahun pembuatan: 2021,

Kondisi: bekas, machineseeker-2024-06-07-001 Kdsdpfx Aexz Hrmefisk

Kondisi: bekas, TECHNICAL DATA Kedpfxjuhb R Ae Afiodk - Min./max. grindable diameter: 1 - 100 [mm] - Max. workpiece length for plunge grinding: 140 [mm] - Min./max. diameter of grinding wheel: 440/610 [mm] - Max. width of the grinding wheel: 80 [mm] - Peripheral speed of the grinding wheel: 50 [m/s] - Speed with new grinding wheel: 1565 [rpm] - Min./max. diameter of regulating wheel: 220/305 [mm] - Max. width of the regulating wheel: 67 [mm] - Max. tilt of the regulating wheel: +/- 7 [°] - Regulating wheel speed during machining: 0/140 [rpm] - Regulating wheel speed during dressing: 200 [rpm] - Installed total power: 41 [kW] - Dimensions (LxWxH): 5920 x 5071 x 2500 [mm] - Net weight: 7000 [kg] EQUIPMENT - CNC SIEMENS 840D control - 5 digitized axes (1 for dressing the grinding wheel; 2 for driven grinding wheel, 1 for upper slide; 1 for lower slide) - Grinding wheel dressing by diamond knurling wheels - Regulating wheel dressing by diamond tips - Automatic part feeding via vibrator - Parts belt conveyor

Kondisi: bekas, TECHNICAL DATA - Min./max. grindable diameter: 1 - 100 [mm] - Max. workpiece length in plunge grinding: 140 [mm] - Min./max. diameter of grinding wheel: 440/610 [mm] Kodpfxjuhb R Ns Afisdk - Max. width of the grinding wheel: 80 [mm] - Peripheral speed of grinding wheel: 50 [m/s] - Speed with new grinding wheel: 1565 [rpm] - Min./max. diameter of regulating wheel: 220/305 [mm] - Max. width of regulating wheel: 67 [mm] - Max. inclination of regulating wheel: +/- 7 [°] - Regulating wheel speed during operation: 0/140 [rpm] - Regulating wheel speed during dressing: 200 [rpm] - Installed total power: 41 [kW] - Dimensions (LxWxH): 5920 x 5071 x 2500 [mm] - Net weight: 7000 [kg] ACCESSORIES - CNC SIEMENS 840D control - 5 digitized axes (1 for dressing the grinding wheel; 2 for powered grinding wheel; 1 for upper slide; 1 for lower slide) - Dressing of grinding wheel by diamond knurl wheels - Dressing of regulating wheel by diamond-tipped tools - Automatic workpiece feeding via vibrator - Parts belt conveyor

Kondisi: bekas, TECHNICAL DATA - Workpiece diameter: 0.5 - 40 [mm] - Max. plunge grinding length: 95 [mm] WORKING GRINDING WHEEL - Grinding wheel width: 100 [mm] - Peripheral speed: 35 [m/s] - Grinding wheel speed: 2228 [rpm] - Min. wheel diameter: 260 [mm] - Max. wheel diameter: 406 [mm] DRIVE GRINDING WHEEL Kedpfx Afsuhb Rcjiedk - Grinding wheel width: 100 [mm] - Wheel inclination: +/- 6 [°] - Min. diameter of drive wheel: 150 [mm] - Max. diameter of drive wheel: 205 [mm] SUPPLY - Power: 20 [kW] - Supply voltage: 400V, 50 [Hz] DIMENSIONS - Required space: 4090 x 1640 [mm] - Machine height: 2,100 [mm] - Machine weight: 2,700 [kg] EQUIPMENT - CNC: SIEMENS SINUMERIK 840 D

Kondisi: bekas, TECHNICAL DATA - Workpiece diameter: 0.5 - 40 [mm] - Max. plunge grinding length: 95 [mm] GRINDING WHEEL - Grinding wheel diameter: 350 [mm] - Grinding wheel width: 120 [mm] - Peripheral speed: 50 [m/s] - Grinding wheel speed: 2352 [rpm] - Min. wheel diameter: 260 [mm] - Max. wheel diameter: 406 [mm] DRIVE WHEEL - Wheel width: 120 [mm] - Wheel inclination: +/- 6 [°] Kdedpfx Afsuhb Rpeiok - Min. drive wheel diameter: 150 [mm] - Max. drive wheel diameter: 205 [mm] SUPPLY - Power: 21 [kW] - Supply voltage: 400V, 50 [Hz] SPACE REQUIREMENTS - Dimensions: 3965 x 3103 [mm] - Machine height: 2,100 [mm] - Machine weight: 2,800 [kg] ACCESSORIES - CNC: SIEMENS SINUMERIK 840 D

Kondisi: bekas, TECHNICAL DATA - Workpiece diameter: 2 - 175 [mm] - Max. plunge grinding length: 240 [mm] WORKING GRINDING WHEEL - Grinding wheel diameter: 610 [mm] - Grinding wheel width: 250 [mm] - Peripheral speed: 50 [m/s] - Grinding wheel speed: 1873 [rpm] DRIVE GRINDING WHEEL - Grinding wheel width: 250 [mm] - Wheel inclination: +/- 7 [°] SUPPLY - Total drive power: 30 [kW] - Supply voltage: 400V, 50 [Hz] DIMENSIONS - Floor dimensions: 3600 x 4700 [mm] - Machine height: 2400 [mm] - Machine weight: 7700 [kg] Kodpfx Ajuhb Rijfijdk ACCESSORIES - CNC: SIEMENS SINUMERIK 840 D - Hydraulic balancing device SHS - Infeed device GFA - Extraction unit

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2016, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 7024NL256160890J, kecepatan spindel (maks.): 10.000 rpm, jarak lintasan sumbu Y: 200 mm, kecepatan rotasi (maks.): 4.000 rpm, Diameter batang (maks.): 80 mm, jarak antara pusat: 700 mm, condition-ball-screw-in-x-y-and-z-axes-replaced-complete-major-m aintenance-package-carried-out-approx-one-year-ago-not-used-since TECHNICAL-DETAILS Distance-between-centers-700-mm Spindle-speed-range-1-4-000-rpm Tool-spindle-speed-10-000-rpm Bar-capacity-80-mm Mount-MT5-live-center-included No-center-point Turret-12-stations-bolt-mounted driven-tool-overhang---100-mm Kjdjy A Icrepfx Afiodk Assemblies-integrated-bearing-MK4-for-center-point Chip-and-cooling-system Scraper-belt-chip-conveyor-with-magnetic-separator-discharge-hei ght-approx-1-000-mm Coolant-system-increased-pressure-5-bar-pump-800-W-flow-rate-20- l-min Coolant-shower-at-chuck-incl-high-performance-pump Compressed-air-purge-system-for-tool-holders Compressed-air-purge-system-for-tailstock-center Line-filter-for-coolant-system MACHINE-DETAILS Control-M730UM-CELOS---ERGOline-Touch Total-power-18-5-18-5-15-kW-25-duty-cycle-50-duty-cycle-cont Tool-spindle-power-5-5-5-3-7-kW-3-min-5-min-cont EQUIPMENT Interface-for-oil-mist-separator-diameter-150-mm Signal-light-red-yellow-green-blue EtherNet-IP-interface-for-automation Robot-interface-for-gantry-robot-DMG-Mori-Seiki Transformer-45-kVA-three-phase-autotransformer X-axis-direction-ISO Note-The-machine-does-not-include-a-chuck-tool-presetting-device -or-clamping-equipment.

Kondisi: siap digunakan (bekas), Fungsionalitas: berfungsi sepenuhnya, lebar roda gerinda: 100 mm, diameter roda gerinda: 350 mm, berat keseluruhan: 2.000 kg, 1 Kjdpfx Afeyym Emoisdk

Kondisi: bekas, Tahun pembuatan: 2011, Area kerja X-Y: 4.422 x 1.753 mm; Perjalanan X-Y: 4.955 x 1.918 mm; Panjang lintasan sumbu Z: Z = 400 mm; Spindel milling 5-sumbu MORBIDELLI; Rotasi sumbu C: 650°; Kemiringan sumbu B: 290° (-10°); Daya: 11 kW pada 20.000 rpm, dapat diatur via inverter; Pendingin cairan; Antarmuka HSK 63F; Konveyor serbuk; Pelumasan sentral CNC otomatis; Penukar alat RAPID 24 (24 slot alat); Ekstensi kepala bor dengan 30 +6 spindel; 8 alat bantu posisi; 2 laser silang; Pompa vakum 250 m³/jam; Kontrol PC dengan Windows Office; Berat sekitar 5.000 kg.\nLokasi penyimpanan: Pelanggan Kdodpfx Afoy D Rv Deiek

Kondisi: bekas, Tahun pembuatan: 2001, en-001 Kedpfxoy D Nxde Afiodk

Kondisi: bekas, Tahun pembuatan: 2006, en-tech-details-2024-06-28 Kdedjy D I Htspfx Afijk

Kondisi: bekas, Tahun pembuatan: 2008, Fungsionalitas: berfungsi sepenuhnya, Pusat Putar/Milling dengan Spindel Lawan Dengan 10 sumbu CNC (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Kontrol: FANUC 31:iA Spindel Utama Kodpfx Aey Dtkqsfijdk Daya spindel: 15/11 kW Diameter batang: 51 mm Putaran spindel: 5000 rpm Spindel Lawan Daya spindel: 11/7,5 kW Diameter batang: 51 mm Putaran spindel: 50000 rpm Spindel Putar/Milling Daya: 7,5/3,7 kW Putaran: 12000 rpm Panjang putar maks revolver bawah: 1005 mm Perjalanan sled X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 / 1090 / 1005 / 1008 mm Perjalanan sled Y1/ Y2: + - 70 / + - 50 mm Rentang putar sumbu B1: + - 95 ° Majalah rak linear termasuk robot pendukung Steady rest CNC Sistem filter siklon cairan pendingin termasuk 2 pompa cairan pendingin Pendingin oli spindel

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2003, Fungsionalitas: berfungsi sepenuhnya, For sale: Well-maintained EMCO Hyperturn 665 MC Plus with IEMCA Master 880MP-E bar feeder, chip conveyor, and high-pressure coolant pumps! Machine was exclusively used for brass parts! CNC turning and milling center | EMCO HYPERTURN 665 MC Plus with main and sub-spindle, C and Y axes, 2x turrets with 12 driven tool stations each! Technical specifications: Swing diameter over bed: 600 mm Swing diameter over cross-slide: 500 mm Control: Siemens Sinumerik 840 D Max. turning diameter: 430 mm Max. turning length: 744 mm Max. bar capacity: 65 mm X-axis travel: 270 mm Z-axis travel: 750 mm X2-axis travel: 205 mm Z2-axis travel: 750 mm Y-axis travel: 100 mm (+/- 50 mm) Main spindle speed: 0 - 5,000 rpm Sub-spindle speed: 0 - 7,000 rpm Turrets: 2x 12 stations, all driven! Tool holder: VDI 30 Upper turret: X, Z, Y axis Lower turret: X, Z axis Sub-spindle left/right movement: Z3 axis C11 spindle: 65 mm diameter (hollow chuck cylinder) Kjdpfsxzq Ncox Afisdk C12 spindle: 45 mm diameter (solid chuck cylinder) with parts ejector Turret type: Sauter 2x 14 bar high-pressure pumps Accessories: Complete tool cabinet with driven and static tool holders, carbide inserts, and toolholders Collet chucks for main and sub-spindle Complete documentation etc. Machine available immediately! Machine ready for operation! We will load the machine! Transport can be organized upon request!

Kondisi: bekas, Tahun pembuatan: 2006, Area kerja X-Y-Z: 5300 x 1700 x 180 mm Panjang lintasan X-Y-Z: 6040 x 1810 x 280 mm Kepala bor dengan 30 + 8 spindle Kecepatan putar: 6000 rpm Daya: 2,2 kW Pelumasan sentral otomatis Meja kerja TV dengan 10 penyangga L=1500 4 area kerja 2 laser silang Pompa vakum 250 m³/jam Kontrol PC Windows Unit frais vertikal ISO 30, 7,5 kW dengan penukar alat RAPID 14 dan poros vektor Unit bor tambahan (poros E) Dongle untuk perangkat lunak XILOG Lokasi penyimpanan: Nattheim Kdjdpfxex Twd Ho Afisk

Kondisi: bekas, Tahun pembuatan: 2016, MORBIDELLI AUTHOR M400 MAIN FEATURES 5-AXIS MACHINING UNIT "PRISMA": TOP-LEVEL QUALITY AND PRODUCTIVITY SOFTWARE XILOG MAESTRO: EXTREMELY SIMPLE PROGRAMMING MATIC WORKTABLE: ONE POSITIONING FOR MULTIPLE OPERATIONS TECHNICAL DATA AUTHOR M400 AXES Working area X-axis (reference side) mm 3,680 Working area Y-axis (max. loadable workpiece on rear stops) mm 1,680 Workpiece passage Z / number of Z axes mm 170 / 1 Workpiece length in pendulum operation mm 1,650 Travel speed X-Y axes Pro-Speed m/min 85 Z-axis speed m/min 30 INSTALLATION Installed power KVA 62÷82 Compressed air requirement NL/min 400 Extraction air requirement m³/h 4,430 Extraction air velocity m/s 25 Extraction port diameter mm 250 GENERAL FEATURES CNC-controlled drilling and milling center in gantry design with workpiece support table, suitable for performing: - Vertical drilling on the panel surface - Horizontal drilling on all four sides of the workpiece - Grooving with disc cutter - General milling operations 3-4-5 axes MACHINE STRUCTURE The base structure is a monolithic construction made of thick-walled steel. It is reinforced by welded reinforcements across the entire machine bed, ensuring extreme stability. The specially designed table form, with a broad base, is key to guaranteeing lasting precision and stability. The machine layout allows the operator an optimal workflow while keeping space requirements to a minimum. The mobile gantry carrier is constructed from a solid monoblock. It is positioned in the X-direction on prismatically ground guides with recirculating ball carriages. The machining unit on this mobile aggregate carrier is also guided on prismatically ground guides and recirculating ball carriages AXIS TRAVEL All axes move on large-section linear prism guides and recirculating ball shoes with a large support surface, ensuring optimal sliding even at maximum speeds and accelerations. The precise and rapid positioning of the moving gantry (X-axis) is achieved by helical rack and pinion. Large-section recirculating ball screws ensure precise positioning of the working unit along the mobile gantry (Y- and Z-axes). MOTORS, DRIVES AND INVERTERS The perfect mechanical dynamics and maximum positioning accuracy are controlled by high-quality drives and brushless motors, dimensioned to allow speeds of up to 90 m/min while maintaining the best finishing quality CONTROL The control unit consists of a numerical controller for milling and drilling machines with the "Xilog Maestro" graphical user interface running on: - Office operating system Windows 7 - 17” color LCD screen - QWERTY keyboard - Swiveling control panel - Machine operation interface with Xilog Maestro software Xilog Maestro Features Programming - Parametric graphical programming - Import of DXF files (2D; geometries "SPLINE", "POLYLINE 3D", line or circle interpolation in three axes, linear in space, spiral interpolation in the selected plane) - Supported programming with graphic and syntax aids for drilling and milling operations - Automatic optimization of drilling operations and tool change cycles - Capability for panel zero-point shifting to execute drilling on inclined or curved panel edges Kdsdjy Dta Sspfx Afisk

Kondisi: bekas, Tahun pembuatan: 2007, Working area: 2780 x 1140 mm (vertical milling), 2500 x 950 mm (horizontal drilling). Travel path X-Y: 2980 x 1271 mm. Z-axis travel length: 200 mm. Clearance height: 180 mm. The machine base is a monolithic construction made from thick-walled steel, reinforced throughout the machine bed with welded-in triangular plates for exceptional stability. The triangular design, particularly with a broad base for load-bearing components, is key to ensuring long-term precision and rigidity. The machine layout allows users optimal workflow with minimal space requirements. This chassis design provides the machining unit with a balanced and secure foundation, enabling outstanding load distribution. The mobile aggregate carrier is constructed as a solid monoblock. It is positioned along the X-axis on precision-ground prism guides using recirculating ball carriages. The working unit, mounted on it, also travels on prism guides and recirculating ball carriages for robust performance. Description of aggregates and standard accessories Drilling unit: Drill head with 10 + 4 spindles: · 6 individually selectable vertical spindles in X · 4 individually selectable vertical spindles in Y · 2 horizontal spindles in X (1+1) Kdodpfxox Twdye Afiok · 2 horizontal spindles in Y (1+1) · Speed: 4,000 rpm · Power: 2.2 kW · Pitch: 32 mm · Drill holder: M10 with 11 mm centering · Extraction nozzle: D = 160 mm Vertical milling unit (Position 2): · Tool holder: HSK 63F · Speed: 1,500 – 24,000 rpm, infinitely variable via inverter · Motor power: 4.4 kW (6 HP) at 12,000 rpm (S1) · Clockwise/anti-clockwise operation · Ceramic bearings · Included: 4 tool holders (right-hand), without collet Tool changer: · Lateral tool magazine, 7-fold (TR7), fully enclosed against chip contamination · 7 tool slots for HSK 63F tool holders, arranged in a row · Max. tool diameter: D=120 mm · Max. weight per tool holder: 4.5 kg · Max. total tool weight (TR7): 20 kg · Angle heads can be accommodated Horizontal milling unit (Position 1): Horizontal unit with two opposing outputs for milling and grooving. · Speed: 9,000 – 18,000 rpm, infinitely variable via inverter · 1 output for collets 3-20 mm (ER32) · 1 output for saw/collet 3-12 mm (ER20) (for saw blade D=120 mm / bore 50 mm) · Motor power: 3 kW (4 HP) · Max. front milling tool diameter: 20 mm · Max. front milling tool length: 110 mm · Max. rear milling tool diameter: 12 mm · Max. rear milling tool length: 80 mm · Max. saw blade diameter: 100 mm · Saw blade bore (ER32): 50 mm · Saw blade arbor diameter (ER20): 12 mm Work table: The work table is designed to provide the operator with maximum freedom of movement. The vacuum quick-clamping system allows for highly flexible, precise positioning and optimal workpiece holding. · 4 supports, 900 mm, steplessly manually adjustable in X · 8 round vacuum cups, D = 110 mm, steplessly adjustable in Y (2 per support) · 2 stops in X (left/right) · 1 stop in Y per support (6 in total) · Retractable reference stops, CNC-controlled · Includes: 4 plug-in adapters for vacuum cups · Standard pendulum processing (2 working zones) Axis movement: The X, Y, and Z axes are driven via precision-ground recirculating ball screws of the highest accuracy. The X-axis ball screw is centrally located for maximum performance.

Kondisi: bekas, Tahun pembuatan: 2006, en Ksdpfjx Twccsx Afisdk

Kondisi: bekas, Tahun pembuatan: 1999, tinggi total: 3.000 mm, panjang total: 6.400 mm, lebar total: 4.300 mm, 3269 CNC Machining Center HOMAG BAZ 41/30K Used, year of manufacture 1999 Working dimensions: X 3000 mm / Y 1300 mm / Z 250 mm Edge banding unit Drilling and milling unit with 4 spindles Kdsdpfsy Dtp Hex Afiok Flush milling unit Sanding unit Interchangeable air nozzle Adjustable milling and drilling unit Underfloor milling unit 12-position tool changer (rotary disk changer) Control system: WoodWOP 5.0 Installation dimensions with safety fence approx. 6400 x 4300 x 3000 mm (L x W x H) Sale on behalf of a customer, ex-site (near 71063 Sindelfingen), without dismantling, transport, or installation Dismantling, loading, and transport can be arranged by us as an option Errors in description and price excepted To avoid possible misunderstandings, a visit and inspection on site by prior appointment is possible and recommended Sold as is Technical specifications, condition description, year of manufacture, and scope of delivery as per manufacturer’s brochure or previous owner, no warranty Interim sale reserved For used machines, any warranty is excluded, purchased as seen Images and videos are for illustration purposes only and do not represent the actual scope of delivery Terms of payment: Prices plus statutory VAT, payment before collection or dispatch Delivery terms: ex-site

Kondisi: bekas, Tahun pembuatan: 2005, Technical Details: Kjdpfx Afjwp D Nboiedk Turning diameter: 275 mm Turning length: 900 mm Spindle bore: 65 mm Drive power 100% duty cycle: 25/20 kW Spindle speeds: 1 - 5000 rpm Spindle diameter at front bearing: 110 mm C-axis: 1 - 500 rpm Number of tool carriers: 4 Turret: 1 X-axis: 290 mm Y-axis: 165 mm Z-axis: 360 mm B-axis: 360° Rapid traverse speed: 18/30 m/min Number of tools: 2x2 + 2x2 Number of driven tools: 2x2 + 2x2 mm Tool speeds: 8000 / 2000 rpm Drive power: 25% duty cycle 5.8 kW Tool holder: TRAUB 60 Turret: 2/3/4 X-axis: 170 mm Z-axis: 600/950 mm Y-axis: +/- 60 mm Rapid traverse speed: 18/15/30 m/min Number of driven tools: 10 mm Tool speeds: 1 - 6000 rpm Drive power: 25% duty cycle 5.8 kW Tool holder: DIN 69880 40 x 63 Total connected load: 95 kW Machine weight approx.: 16 t Space requirement approx.: 10.0 x 3.5 x 3.0 m with CNC TRAUB TX 8i, bar loader TRAUB Stamag DNH61 / 3000, Main and counter spindle with C-axis 1 vertical tool carrier with B-axis 3 turret tool carriers Extraction unit, coolant system with coalescence separator and chip conveyor 2 pcs. 3-jaw chucks SMW KNCS-N 170-43 2 pcs. HAINBUCH Spanntop collet chucks 40 pcs. various non-driven tool holders 6 pcs. various driven tool holders Spare parts package

Kondisi: bekas, Tahun pembuatan: 1990, translation_001 Kdsdpsw I R Ndefx Afiek
