Beli Horizontal Panel Saw bekas (21.870)

Kondisi: bekas, Tahun pembuatan: 2009, Panjang pemotongan: 4200 mm Lebar pemotongan: 3200 mm Maks. tonjolan mata gergaji: pada mata gergaji tegak 0° = 70 mm, pada mata gergaji miring 45° = 50 mm Kecepatan maju: 0-80 m/menit Kecepatan mundur: 100 m/menit Berat: sekitar 5400 kg Daya motor: 14 kW Skor mata gergaji pendahulu: 1,5 kW Alat: diameter: 350 mm Lubang: 30 mm Koneksi ekstraksi bawah: 140 mm Koneksi ekstraksi pada balok tekan: 100 mm Lokasi penyimpanan: Pemasok Cedeyf Nu Tepfx Abhogn

Kondisi: bekas, Tahun pembuatan: 2001, Lebar potong: 3300 mm Panjang potong: 3350 mm Berat: sekitar 4000 kg Tonjolan mata gergaji: 100-(115) mm Gerobak gergaji: Kecepatan maju: 1–100-(1–130) m/menit. Kecepatan balik: 100-(130) m/menit. Mata gergaji utama: 400-(430) mm Motor: 7,5 - (11–13,2) kW Scriber: 215 mm Motor: 2,2 kW Penekan: Gerak cepat: 1–60 m/menit. Balik: 60 m/menit. Ekstraksi: Kecepatan udara: 30–35 m/detik. Konektor ekstraksi: 200 mm / 115 mm Udara tekan: Tekanan: 5–6 bar Konsumsi: 20–30 l/menit. Lokasi penyimpanan: Nattheim Cgjdpevvkqgsfx Abhen

Kondisi: bekas, Tahun pembuatan: 2023, Exhibition Machine Garbsen HORIZONTAL PANEL SAW GABBIANI P Manufacturer: SCM Model: GABBIANI P80 Year of manufacture: 2023 1.00 unit MAIN FEATURES INDIVIDUALLY SELECTABLE AIR CUSHION TABLES: AN INDISPENSABLE TOOL SIDE SAFETY DEVICES: MORE SPACE FOR WORKING FLOATING CLAMPS: THE GUARANTEE FOR A PERFECT CUT TECHNICAL DATA GENERAL INFORMATION gabbiani p80 Saw blade projection mm: 80 Working table height mm: 950 Number of standard clamps: 5 Number of clamps for versions 33/38/43: 9 / 10 / 10 Number of clamps for versions 33/38/43 with FlexCut 1 unit (single clamp with double fingers included): 10 / 11 / 11 CUTTING DIMENSIONS Version 33 mm: 3300x2100 Version 33 (Opt.) mm: 3300x3200 Version 38 mm: 3800x3200 Version 38 (Opt.) mm: 3800x3800 Version 43 mm: 4300x3200 Version 43 (Opt.) mm: 4300x4300 AXIS SPEEDS Variable saw carriage speed m/min: 6 – 60 Variable pusher speed ( ) m/min: 60 MAIN SAW BLADE Motor power (S6 -40%) - 50Hz (star-delta start) kW (HP): 7 (9) (11) Rotation speed – 50Hz rpm: 4650 Saw blade diameter mm: 340 Main saw blade shaft diameter mm: 80 SCORING SAW Motor power (S6 -40%) - 50Hz kW (HP): 1.5 (2) Rotation speed – 50Hz rpm: 5850 Scoring blade diameter mm: 200 Scoring saw spindle diameter mm: 80 INSTALLATION Installed power kW: 12÷15 Machine base voltage Euro voltage (400 V / 50 Hz) Compressed air requirement NL/min: 300 Required air pressure bar: 7 Extraction air requirement m³/h: 2440 Extraction air speed m/sec: 20 Extraction spigot diameter mm: 4x120 ( ) Note: For countries where EC standards apply, the forward feed speed of the pusher is limited to 25 m/min. GENERAL CHARACTERISTICSAutomatically controlled horizontal panel saw with PC/PLC control unit, for cutting panels of solid wood, MDF, chipboard, plywood and similar materials. Machine frame and work table - Machine frame constructed as steel tube design - Work table made of rib-reinforced steel with Bakelite coating - Longitudinal fence on the left sideSaw carriage made of steel, consisting of: - a motor for the main saw blade and a motor for the scoring blade - Vertical lift of the saw blade on linear ball guides and shoes - Guide wheels made of hardened and ground steel - Balanced mass distribution for best cutting quality - Direction of travel against the longitudinal fence - Saw carriage drive via rack and pinion - Carriage runs on cylindrical guides - Cylindrical guides made of hardened and ground steel (5 years warranty), protected by special dust wipers - Pneumatic switch for fast and safe change of main saw blade and scoring bladePressure beam - Pressure beam with uniform pressure on the workpiece over the entire cutting length with recesses to avoid collisions with the clamps; pneumatic height adjustment via high-precision racks and pinions, pressure adjustable from 1.5 to 6 bar - Double extraction system with a unit above the pressure beam for cleaning the work table and a unit below on the saw carriage - Lateral automatic aligner with pneumatic cylinder over the entire length. Slides on linear ball guides and shoes.* Travel: 1200 mm* Minimum working width: 60 mm* Maximum working width: 1200 mmPositioning pusher and rear section of the machine - Positioning pusher over the entire length with motor drive via a robust shaft. Positioning pusher... Csdjx Twcvspfx Abhsgn

Kondisi: siap digunakan (bekas), Technische Daten Schnittmaße: 4300 x 4300 mm Max. Schnitthöhe: 125 mm Hauptsägeblatt max. Ø 450 mm Motor: 13,5 kW Vorschnittsägeblatt max. Ø 150 mm Motor: 2,2 kW Sägenwagen-Geschwindigkeit verstellbar von: 10 bis 125 m/min Schiebervorschub: 10 bis 80 m/min Automatische Seitenausrichtvorrichtung 3 Luftkissentische 7 pneumatische Spannzangen Windows PC-basierte Steuerung CADmatic Software Cjdpfx Aeucitbebhegn Einfache Wartung und Sägeblattwechsel Schnellwechselsystem für Sägeblätter Absaugleistung: 5000 m³/h Stromversorgung und Motoren Spannung: 400 V Anschluss: Drehstrom Leistung: 35 kW Abmessungen Länge: 6900 mm Breite: 8200 mm

Kondisi: baru, NEW MACHINE Numerical power control with NX Cut System software and NX Pareto Optimizer Barcode labeller with software Cutting length mm 3800 Cutting width mm 3800 Blade projection mm 90 Front panel loading and unloading Automatic lateral aligner integrated in the saw carriage No. 1 fixed front table made of Bakelite with air cushion system for unloading panels No. 2 mobile front tables made of Bakelite with air cushion system for unloading panels Main saw blade, max. diameter 380 mm, 15 kW motor Scoring blade, max. diameter 200 mm Saw carriage feed speed forward 1 - 90 m/min, reverse 120 m/min Csdpforufznsx Abhegn Pusher speed 85 m/min Pusher carriage with 9 grippers

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2004, Fungsionalitas: berfungsi sepenuhnya, panjang pemotongan (maks.): 4.400 mm, lebar pemotongan (maks.): 4.300 mm, diameter utama gergaji: 350 mm, model controller: G-VISION, Perlengkapan: doser, TECHNICAL DETAILS Cutting dimensions: 4,400 x 4,300 mm Saw blade projection: 90 mm Saw carriage feed speed: 5 - 100 m/min Pusher feed speed: 125 m/min Pusher return speed: 60 m/min Return speed: 100 m/min Main saw blade diameter: 350 mm Main saw blade motor power: 12.5 HP Scoring saw diameter: 180 mm Scoring saw motor power: 2 HP Extraction connection: 200 mm Compressed air: 6.7 bar MACHINE DETAILS Control: G-VISION Dimensions & Weight Dimensions (L x W x H; assembled): 6,400 x 7,500 x 1,800 mm Dimensions (L x W x H; transport) machine: 6,500 x 1,500 x 1,800 mm Csdpfx Abjyf Epyehegn Dimensions (L x W x H; transport) pusher: 5,200 x 1,200 x 1,200 mm Total weight: 3,200 kg EQUIPMENT Automatic horizontal panel saw with clamps Frontal stack feeding Three front air cushion tables Automatic pusher with lateral and upper guides and 7 pneumatic clamps Automatic side aligner Automatic saw blade projection adjustment Electronic control of speed and position Easy access to the saw carriage Pneumatic quick-change tool unit Multitasking operating system Microsoft Windows XP/2000/NT Sequential control of cutting patterns Parametric control of feed speed Direct control of machine functions Adjustment of cutting patterns

Kondisi: diremaj di bengkel (bekas), Tahun pembuatan: 2008, Fungsionalitas: berfungsi sepenuhnya, diameter mata gergaji: 250 mm, panjang pemotongan (maks.): 4.600 mm, ketinggian potong (maks.): 2.070 mm, kedalaman pemotongan: 60 mm, lubang pisau gergaji: 30 mm, Dengan mengajukan penawaran, Anda wajib melakukan pengambilan tepat waktu paling lambat tanggal 27.02.2026! Mesin telah direkondisi di bengkel pada tahun 2025, diuji fungsinya dan dibersihkan! DETAIL TEKNIS Panjang potong: 4.600 mm Tinggi potong vertikal: 2.070 mm Tinggi potong horizontal: 1.958 mm Kedalaman potong: 60 mm Daya motor gergaji: 3,9 kW Diameter mata gergaji: ∅ 250 mm Cgedpjyfnursfx Abhon Lubang mata gergaji: 30 mm Kecepatan putar mata gergaji: 5.250 rpm Sambungan ekstraksi debu: ∅ 100 mm Pembatas strip: 600 mm DETAIL MESIN Dimensi & Berat Dimensi (P x L x T): 5.826 x 2.838 x 1.428 mm Berat: sekitar 910 kg Daya terpasang/sambungan listrik: 4,8 kW / 3 ~ 400 V | 50 Hz PERLENGKAPAN Rem motor elektromagnetik Roller tumpuan dengan rem mekanis

Kondisi: belum diuji (bekas), Tahun pembuatan: 2014, Fungsionalitas: belum diuji, panjang pemotongan (maks.): 4.200 mm, diameter mata gergaji: 320 mm, lebar pemotongan (maks.): 3.500 mm, berat keseluruhan: 4.800 kg, Perlengkapan: doser, DETAIL TEKNIS Rentang pemotongan: 4.200 x 3.500 mm Ketinggian gergaji di atas meja: 80 mm Diameter mata gergaji: 300-320 mm Diameter mata skor: 150 mm Kecepatan maju gerobak gergaji: 5-100 m/menit Kecepatan mundur gerobak gergaji: 130 m/menit Kecepatan maju pendorong material: 25 m/menit Kecepatan mundur pendorong material: 80 m/menit Cgodpfx Asyc Sggjbhsn DETAIL MESIN Daya motor: 9 kW Daya motor scorer: 1,2 kW Dimensi & Berat Berat: sekitar 4.800 kg PERLENGKAPAN Printer label Panel kontrol di sisi kiri 4 meja bantalan udara Dongle lisensi AV untuk optimasi Ardis Catatan: Penjual tidak dapat melakukan pemuatan kontainer dan pengepakan laut.

Kondisi: bekas, Tahun pembuatan: 2018, Fungsionalitas: berfungsi sepenuhnya, lebar pemotongan (maks.): 1.250 mm, lebar potong di pagar rip: 1.250 mm, ketinggian potong (maks.): 104 mm, tinggi potong dengan pisau scoring (maks.): 104 mm, diameter mata gergaji: 315 mm, panjang meja: 3.200 mm, diameter utama gergaji: 315 mm, jenis penyesuaian ketinggian: mekanis, berat keseluruhan: 750 kg, diameter nosel ekstraksi: 120 mm, panjang pemotongan: 3.200 mm, jenis arus masuk: tiga fasa, tegangan masuk: 400 V, diameter sambungan ekstraksi: 80 mm, – buatan Austria – tahun produksi: 2018 – sistem pandu troli X-Roll – buku manual DTR dan sertifikat CE SPESIFIKASI TEKNIS: Csdpfx Aoyhdu Tsbhsgn – panjang troli: 3200 mm – lebar pemotongan sisi kanan: 1250 mm – diameter pisau utama: maks. 315 mm – diameter scorer: 100 mm – motor utama: 5,5 kW – motor scorer: 0,75 kW – rem – sistem pandu troli X-Roll – pengaturan tinggi pemotongan – pengaturan sudut manual: 0° - 45° – tinggi potong maks.: 104 mm – dapat dipasang mata frais: ketebalan: 6 - 20 mm – diameter maksimum mata frais: 228 mm – dua pengunci – pelindung bergerak – diameter nozzle: 80 dan 120 mm – dimensi (p/l/t): 340 / 210 / 170 cm – berat: ~750 kg

Kondisi: bekas, Tahun pembuatan: 2008, Fungsionalitas: berfungsi sepenuhnya, panjang pemotongan (maks.): 3.000 mm, lebar pemotongan (maks.): 1.300 mm, lebar potong di pagar rip: 1.300 mm, tinggi potong dengan pisau scoring (maks.): 40 mm, diameter mata gergaji: 315 mm, jenis penyesuaian ketinggian: mekanis, panjang pemotongan: 2.500 mm, – produksi Austria – tahun produksi: 2008 – penutup pelindung mata pisau – dengan scoring blade PARAMETER TEKNIS: – panjang meja geser: 2500 mm – diameter maksimum mata pisau utama (tanpa scoring blade): 315 mm – diameter maksimum mata pisau utama (dengan scoring blade): 250 mm – diameter lubang mata pisau: 30 mm – tinggi potong maksimum untuk mata pisau 250 mm: 40 mm – pengunci poros – mata pisau utama dapat diatur naik/turun dan kemiringannya – penutup pelindung mata pisau – dengan meja geser – lebar potong pada guide: 1300 mm – motor utama: 4 kW – penggaris dengan stop: 1700 mm – scoring blade – diameter maksimum scoring blade: 80 mm – diameter poros scoring blade: 20 mm – motor scoring blade: 0,65 kW – diameter konektor hisap: 50, 100 mm – dimensi transportasi (p/l/t): 250 / 170 / 110 cm – berat: 454 kg Codpfx Aoxm Rm Sjbhegn

Kondisi: sangat baik (bekas), 1 Codpjyg Ibnefx Abhogn

Kondisi: baru, Tahun pembuatan: 2024, ALL ALTENDORF F25 MODELS AVAILABLE FOR IMMEDIATE DELIVERY! Manual height and tilt adjustment 0 – 46° of saw blade with digital display Motor power 5.5 kW Saw blade speed 3600/4200 rpm Double roller carriage, carriage length 3200 mm Angle-mitre fence, cross-cutting up to 3450 mm Max. saw blade diameter 315 mm, max. blade projection 104 mm Cutting height 100 mm, 70 mm at 45° Machine height 88 cm Note regarding used machines: • Errors in technical information and prior sale reserved. • Stated prices apply as ex-works prices – loaded free of charge at site! • The machines have been cleaned and function-tested. Cgodpfx Ajg Dgr Hsbhjn • All machines are sold as seen, without any warranty or guarantee claims. Buyers are free to inspect the machines at the location. • Special agreements are only possible in written form. (We only respond to inquiries that include your address and telephone number!)

Kondisi: baru, SCM gabbiani p90 Panel Saw - Demonstration Machine - Special Offer! Csdpfeiz A Amex Abhegn Technical Specifications: Saw Blade Projection: 90 mm Worktable Height: 950 mm Standard Number of Grippers: 5 CUTTING DIMENSIONS: 3300 x 3200 mm Variable Saw Carriage Speed: 6 - 60 m/min Variable Pusher Speed: 0 - 60 m/min Saw Blade Motor Power: 7.0 kW Speed: 4,650 rpm Saw Blade Diameter: 340 mm Main Saw Blade Bore: 80 mm Scoring Motor Power: 1.5 kW Speed: 5,850 rpm Scoring Blade Diameter: 200 mm Scoring Shaft Diameter: 80 mm Compressed Air Requirement: 300 NL/min Air Pressure: 7.0 bar Extraction Air Requirement: 2,440 m³/h Extraction Air Velocity: 20 m/sec Extraction Port Diameter: 4x120 mm Including the following options: 590134 Cutting Depth 3200 mm (Version 33) OF0263 eye-M Control Console with Integrated PC 590261 Cut Editor OF0454 Maestro Pattern 590271 Maestro Connect: Preparation without 'Gateway' for retrofit installation OF0457 Human-Machine Interface Software (HMI) MAESTRO ACTIVE 590258 Rear Table with Rollers, at the side of the longitudinal fence 590246 Fixed Air Cushion Table 2,500x800 mm with rollers and reinforced fan 590239 2 x Movable Air Cushion Tables 1,500x600 mm with rollers and reinforced fan 590244 Saw Carriage with Independent Lift Control for Main and Scoring Blades 590245 Optimized Vertical Lift of the Saw Blade in 2 Stages (medium/maximum) 590143 Device for Grooving with Manual Height Adjustment of the Saw Blade 590241 Grooving Function (forward/backward movement of saw carriage) 590164 Double Lateral Automatic Aligner 301230 Foot Switch for Start and Stop of the Work Cycle 590044 Compact Labelling Unit – Label Printing with Barcode 590144 4 x Additional Grippers 900088 Magnetic Tape Monitoring of Pusher Position 102015 European Safety Regulations (CE marking) 109993 MACHINE LANGUAGE: German

Kondisi: sangat baik (bekas), Tahun pembuatan: 1999, Cutting length: 3,200 mm Cutting width: 3,200 mm Cgsdpfjhvan Ijx Abhen Cutting height: 65 mm Maximum saw blade diameter: 300 mm Main saw motor: 5.5 kW Maximum scoring saw blade diameter: 160 mm Scoring unit motor power: 1.5 kW Air cushion tables: 3 pcs. — 1 x 2,500 x 500 & 2 x 1,500 x 500 mm Office version for optimizing panel layouts Clamping grippers: 8 pcs Saw carriage height adjustment with THK guides Pressure beam with slotted passages Side aligner Pneumatic quick-change system for saw blade Extraction port diameter: 1 x 120 mm & 1 x 150 mm Setup dimensions (L x W): 5,700 x 6,000 mm Weight: approx. 2,500 kg INVERTER NEW Note – Used Machines: • Technical information may be subject to error and prior sale. • Listed prices are ex-location and include free loading. • The machine has been cleaned and functionally tested. • All machines are sold as seen, without any claim to warranty. Buyers are welcome to inspect the machine at its location. • Special agreements are only valid in written form. (We will only respond to inquiries that include your address and telephone number!)

Kondisi: bekas, nomor mesin/kendaraan: 007486, Lebar maksimum panel: 2100 mm Csdpfxjt Sn Azj Abhogn Panjang maksimum panel: 4300 mm Proyeksi maksimum mata gergaji utama: 135 mm

Kondisi: bekas, nomor mesin/kendaraan: 005711, Max. panel width: 4500 mm Max. panel length: 2200 mm Max. main saw blade projection: 95 mm Number of longitudinal clamps: 5 Number of cross clamps: 8 Second flexible hold-down: yes Cgsdpfshvm Dijx Abhen

Kondisi: bekas, nomor mesin/kendaraan: 005255, Lebar maksimum panel: 4300 mm Panjang maksimum panel: 2200 mm Maks. overhang mata gergaji utama: 110 mm Jumlah penjepit: 7 Codpfeg E Tcxox Abhogn

Kondisi: bekas, nomor mesin/kendaraan: 008021, Lebar maksimum panel: 4300 mm Panjang maksimum panel: 2200 mm Maks. keluar mata gergaji utama: 125 mm Jumlah chuck penjepit: 11 Codpfx Absw Uz Spshogn Stasiun berputar: ya Sistem pemuatan untuk panel tipis: ya Sistem pemuatan dengan vakum: ya

Kondisi: bekas, nomor mesin/kendaraan: 005456, Lebar maksimum panel: 2200 mm Panjang maksimum panel: 4500 mm Codpfxswuz Dys Abhsgn Maks. keluaran mata gergaji utama: 123 mm Jumlah penjepit memanjang: 8 Jumlah penjepit melintang: 5 Penahan fleksibel kedua: ya Stasiun berputar: ya

Kondisi: bekas, nomor mesin/kendaraan: 008131, max-breite-paneel-4400-mm Cedpfx Abew Idh Hehegn

Kondisi: bekas, nomor mesin/kendaraan: 007618, max-breite-paneels-4400-lange-4400-vorstand-hauptsageblatt-75-an zahl-spannzangen-7 Cgjdou N Slispfx Abhen

Kondisi: bekas, nomor mesin/kendaraan: 006006, Max. panel width: 2300 mm Max. panel length: 4300 mm Max. projection of main saw blade: 135 mm Cedeu Rv Uqopfx Abhsgn Number of longitudinal clamps: 7 Number of cross clamps: 20 Second flexible hold-down: yes Rotating station: yes

Kondisi: bekas, nomor mesin/kendaraan: 005552, Lebar maksimum panel: 2200 mm Panjang maksimum panel: 4300 mm Proyeksi maksimum mata gergaji utama: 125 mm Cgodpjm Tnbwsfx Abhsn Jumlah penjepit: 10

Kondisi: bekas, nomor mesin/kendaraan: 005445, Lebar panel maks.: 3200 mm Panjang panel maks.: 2120 mm Julur maksimum mata gergaji utama: 165 mm Jumlah penjepit longitudinal: 4 Jumlah penjepit transversal: 9 Stasiun berputar: ya Cgsdpfsiiiuyjx Abhsn Sistem pemuatan untuk panel tipis: ya

Kondisi: bekas, nomor mesin/kendaraan: 007470, Lebar maksimum panel: 3800 mm Panjang maksimum panel: 2200 mm Proyeksi maksimum mata pisau utama: 130 mm Cedet H Twaspfx Abhegn Jumlah penjepit: 7
