Beli Penyadapan Chucks bekas (3.768)

Kondisi: sangat baik (bekas), Tahun pembuatan: 2006, Swing diameter 330 mm Turning length 750 mm Control unit WEILER D3 Quill diameter 50 mm Quill stroke 130 mm Taper in tailstock quill MK-3 Gbedpox Szpwofx Adtsg Spindle speeds 1-4500 rpm Main spindle taper MK-5 Machine weight approx. 1400 kg Required space approx. 1900 x 1300 x 1800 mm This WEILER E30x750 is in very well-maintained condition and can be inspected by arrangement with the seller. - Lever quick-action chuck for collets DIN 6343-48/173E and Rubber-Flex collets, clamping range 3–42 mm diameter, with mechanical and electrical interlock, max. speed 4500 rpm - 1 set of collets DIN 6343-48/173E - Adjustable hollow spindle stop 38–48 mm for main spindle - Travelling steady with sliding jaws, passage 10–85 mm - Three-jaw chuck with wedge-bar system, diameter 160 mm, bore 42 mm, mounting as per DIN 55027 /5, including 1 set of master jaws and hard reversible top jaws - Lever quick-action chuck for collets DIN 6343-48/173E and Rubber-Flex collets, clamping range 3–42 mm diameter, with mechanical and electrical interlock, max. speed 4500 rpm - 1 set of collets DIN 6343-48/173E - Adjustable hollow spindle stop 38–48 mm for main spindle

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2005, Fungsionalitas: berfungsi sepenuhnya, panjang pembubutan: 1.185 mm, diameter pembubutan: 640 mm, kecepatan spindel (maks.): 4.000 rpm, diameter pembubutan di atas alas geser: 640 mm, torsi spindle sekunder (maks.): 5.000 Nm, Turning and Milling Center with Main and Counter Spindle and Comprehensive Equipment! TECHNICAL DETAILS Turning diameter: 640 mm Turning length: 1,185 mm Swing diameter: 640 mm Distance between spindle noses: 1,500 mm SLIDE I X-axis travel: 550 mm Y-axis travel: 180 mm Z-axis travel: 1,185 mm B-axis: 240° Feed rate X-axis: 0 - 40,000 mm/min Feed rate Y-axis: 1 - 24,000 mm/min Feed rate Z-axis: 1 - 70,000 mm/min Feed rate B-axis: 1 - 20 rpm Rapid traverse X/Y/Z: 40 / 24 / 70 m/min Feed force X/Y/Z S6: 7.00 / 11.00 / 7.50 kN Tool interface: HSK 63 Milling spindle speed: 10 - 12,000 rpm Drive power 100% duty cycle: 13.20 kW Drive power 40% duty cycle: 22.00 kW Milling spindle torque: 60 / 100 Nm Max. tool length: 350 / 200 mm Tool diameter: 80 mm Tool diameter with 2 free spaces: 120 mm Max. tool weight: 6 / 10 kg SLIDE II X-axis travel: 180 mm Z-axis travel: 1,050 mm Feed rate X-axis: 1 - 24,000 mm/min Feed rate Z-axis: 1 - 36,000 mm/min Rapid traverse X + Z axes: 24 / 36 m/min Feed force Z / X S6: 11.00 / 9.00 kN Turret (positions): 12 Tool interface: DIN 69880 Ø40 Driven tools - quantity: 12 Speed: 1 - 4,000 rpm Drive power 100% duty cycle: 10.70 kW Gsdpfxowyvc Us Adtebg Torque S1: 32 Nm SLIDE III Z-axis travel: 1,150 mm Feed rate Z-axis: 1 - 36,000 mm/min Rapid traverse Z-axis: 36 m/min Feed force Z-axis S6: 13.00 Nm MAIN SPINDLE Model: ISM90 Speed: 10 - 4,000 rpm Drive power 100% duty cycle: 36.00 kW Drive power 40% duty cycle: 45.00 kW Torque at 40% / 100% duty: 800 / 630 Nm Spindle bore: 80 mm COUNTER SPINDLE Speed: 10 - 5,000 rpm Drive power 100% duty cycle: 21.00 kW Drive power 40% duty cycle: 28.00 kW Torque at 40% / 100% duty: 320 / 240 Nm Spindle bore: 80 mm MACHINE DETAILS Electrical Data Total power requirement: 70.00 kW Dimensions & Weight Machine weight: approx. 20.00 t Space requirement: approx. 8.50 x 4.50 x H3.10 m Control Control manufacturer: Siemens Control model: SINUMERIK 840D EQUIPMENT Chip conveyor Oil mist separator DMG Automation WH10top Main spindle ISM90: through-hole clamping system, C-axis, 3-jaw power chuck SMW-AUTOBLOK KNCS-NB-315-91 Counter spindle ISM76: partial through-hole clamping system, C-axis, 3-jaw power chuck SMW-AUTOBLOK KNCS-NB-315-91 Pickup system with integrated conveyor belt Automatic safety hood Differential pressure clamping With pump station for coolant: Pump 1: 17 l/min at 80 bar / Pump 2: 20 l/min at 8 bar / Pump 3: 40 l/min at 20 bar Hainbuch collet chuck including collets Ø30, 45, 50, 55, 60, 65, 72, 82, 85, 90 1 workpiece gripper for turret

Kondisi: bekas, L + Z lathe ZMM - SLIVEN (Bulmak - Bulgaria) Type CU 325 Machine no. 8169 Year of manufacture: 2002 Centre distance 1000 mm Swing over bed 320 mm Centre height over bed 160 mm Swing over cross slide 190 mm Centre height over cross slide 95 mm Spindle bore 32 mm Spindle speed (right-hand rotation): 85 - 2000 rpm, 12 steps Spindle speed (left-hand rotation): 130 - 1300 rpm, 6 steps Feed: longitudinal and transverse Gjdpfjvt U Tmjx Adtjbg Chuck flange: short taper DIN 55027 size 5 Tailstock taper: MT 3 Drive power: 2.2 kW Electrical connection: 400 Volt, 50 Hz - 3-axis digital readout RSF, type Z 730 - Spindle speed control with 12 gearbox steps in machining direction - Spindle speed control with 6 gearbox steps against machining direction - 3-jaw chuck BISON Ø 160 mm with 1 set of stepped jaws - 4-position universal tool post - Coolant tank with pump integrated in the machine base - Spindle brake actuated via direction lever - Emergency stop via foot pedal and emergency switch - Foldable chuck guard - Machine lamp - Splash guard - Travelling steady rest - Quick-action drill chuck with MT 3 taper - Multiple change gears - Operating manual with electrical diagram Required space (L x W x H): 2100 x 800 x 1600 mm Weight: 750 kg Good condition

Kondisi: baik (bekas), Tahun pembuatan: 2006, 9-axis CNC turning and milling center * CNC control: Fanuc MSX-701 * Upper milling spindle (B-axis), as full 4th axis, positioning accuracy 0.0001° * 40-position tool magazine * 10-position lower turret, all stations powered * 2 x 3-jaw quick-change chuck KNCS-N 315/91 * KNOLL high-pressure coolant system, adjustable pressure: 12/25/35/45/55/62/72 bar, with maintenance-free rotary filter system * Chip conveyor * Blow-off system for main spindle chuck (controlled via M-function) * Blow-off system for cutting tool (controlled via M-function) * Coolant gun incl. accessories * Oil mist extraction * Direct measuring system X1, X2, Y-axis * Bar feeder interface * Dual foot switch for both spindles * Island and pocket programming for MAPPS * High-speed fixed cycle for MAPPS * Program memory expansion to 8 MB * Program restart * 3-stage signal lamp * Memory Card 512MB (CF Card) Swing diameter over cross slide (tool spindle 1): 750 mm Swing diameter over cross slide (turret 2): 400 mm Max. turning diameter (tool spindle 1): 660 mm Max. turning diameter (turret 2): 275 mm Max. workpiece length: 1,498 mm Max. bar material: 90 mm Travel paths: X1 axis (tool spindle): 750 mm Y axis (tool spindle): 420 (+/-210) mm Z1 axis (tool spindle): 1,635 + 100 mm for tool change B axis (tool spindle): +/- 120°, full B-axis indexed at 1°, locked at 0.0001° X2 axis (turret): 195 mm Z2 axis (turret): 1,525 mm SZ axis (sub spindle): 1,610 mm Rapid traverse: (X1,Z1) 50 m/min / (Y,X2,Z2,SZ) 30 m/min Main and sub spindle: Spindle speeds stepless (spindle 1+2): 30–3,000 rpm C-axis (spindle 1+2): 0.001° Main spindle motor: 22/18.5 kW Sub spindle motor: 22/18.5 kW Torque (spindle 1+2): 1,000 Nm Disc turret: Number of tool stations: 10 Driven tool speed: 6,000 rpm Drive power: 5.5/3.7 kW Milling spindle head: Gbedpfx Aex S Ip Dodtog Tool interface: HSK A63 Max. speed: 12,000 rpm Drive power: 18.5/11 kW Torque: 120/44 Nm Tool changer: 40 positions Tool diameter 70/140 mm Tool length 400 mm Tool weight 8/10 kg Total power consumption: 90 kVA Overall dimensions (L x W x H): 5,301 x 2,997 x 2,788 mm Machine weight: 26.6 t Accessories: Measuring arm (see photo), tool measurement in machine Toolholders + box, reduction sleeves, driven tools Set of clamping jaws Set of collets

Kondisi: baru, The Turnado 280/2000 is a powerful and robust universal lathe from the category of conventional lathes, distinguished by state-of-the-art technology. This machine series impresses with its durable construction and a high-performance motor, ensuring precision and versatility. The Turnado 280/2000 is ideally suited for a wide range of applications, as it comes standard with extensive accessories such as a quick-change tool post system and a 3-axis digital position display, enhancing user-friendliness and efficiency. Additionally, you benefit from the stable construction of the heavy-duty machine bed, which features a large spindle bore for machining larger workpieces. Questions regarding installation or accessories can be answered easily, and thanks to the central lubrication system, machine maintenance is greatly simplified. Discover the advantages offered by the Turnado 280/2000 and order your universal lathe online now. Gbsdpfxjuzk S Ej Adtog

Kondisi: sangat baik (bekas), Tahun pembuatan: 2007, panjang pembubutan: 1.545 mm, diameter putar di atas sled silang: 660 mm, lubang spindel: 65 mm, jarak pergerakan sumbu X: 580 mm, jarak lintasan sumbu Y: 160 mm, jarak gerak sumbu Z: 1.545 mm, Manufacturer: MAZAK Model: INTEGREX 200-4 ST Control: MAZATROL MATRIX Year of manufacture: 2007 Multitasking machining in a single machine setup Sub spindle takeover with full C-axis functionality Gjdjx S Hm Iopfx Adtebg The INTEGREX-IV series is capable of performing all machining operations completely High-speed milling spindle with swiveling capability up to 240° Lower turret with driven tooling (live tooling) Chip conveyor with coolant system and 15 bar high-pressure through-spindle coolant (IKZ) Double chuck KNCS-N 210-53 (SMW Autoblok) MAZAK Flex-GL150F gantry loader Gripping range: 200 × 120 mm (length) / 15 kg Max. turning diameter: 660 mm X-axis travel: 580 mm Y-axis travel: 160 mm Z-axis travel: 1545 mm B-axis: 270° Spindle bore: 65 mm Spindle speed: 5000 rpm Spindle power: 22 kW Sub spindle speed: 5000 rpm Sub spindle through-hole: 65 mm Sub spindle power: 18.5 kW Tool changer: 40 stations B-axis interface: Capto C6 B-axis spindle speed: 12,000 rpm Length: 5200 mm Width: 2550 mm Height: 2600 mm Weight: 14,000 kg

Kondisi: baik (bekas), colchester-combi-4000-en Gedpsx S N Hdofx Adtebg

Kondisi: bekas, Tahun pembuatan: 1987, de-hu-001 Godpfx Adjx Sy Urjtsbg

Kondisi: baru, Tahun pembuatan: 2025, Fungsionalitas: berfungsi sepenuhnya, Turning diameter over bed 500 mm Turning diameter over cross slide 270 mm Turning diameter in gap 700 mm Gap length 357 mm Centre height 250 mm Centre distance 1000 mm Bed width 340 mm Max. workpiece weight 300 kg Spindle speed 22 – 2000 rpm Spindle bore D53 mm Drive power 5.5 kW Weight approx. 1950 kg Dimensions LxWxH = 2550 x 1100 x 1500 mm Gbodpfewwt I Njx Adtog Accessories, Equipment: - 3-axis digital readout system - Chuck guard - 3-jaw chuck D250 mm - 4-jaw chuck D300 mm - Toolholder guard - Stop for long slide - Fixed steady rest - Travelling steady rest - Fixed centre - Reducing adapters for main spindle - Tailstock - Coolant system - 4-way toolpost - Machine light - Rapid traverse on longitudinal and cross slide - CE marking - Machine manuals

Kondisi: baik (bekas), Tahun pembuatan: 2005, Fungsionalitas: berfungsi sepenuhnya, Technical details Swing diameter over bed: 730 mm Centre distance: 3000 mm Control: Heidenhain MANUALplus 4110 Total power requirement: kW Machine weight approx.: 6.5 t Required floor space approx.: 7400 x 2100 mm Additional information: Very well-maintained cycle lathe with only 15,652 operating hours. Working area: Centre distance: 3000 mm Swing diameter over bed: 730 mm Swing diameter over cross slide: 450 mm Bed width: 480 mm Godpfxox S Ehdo Adtebg Main spindle: Spindle mount per DIN 55027 size 11 Spindle bore: 130 mm Spindle diameter in front bearing: 170 mm Spindle taper: 1:20 Taper in tailstock quill: MK 6 Main drive: AC drive with 2-stage ZF gearbox (transmission shifts automatically) Drive power (100%/60% duty cycle): 22/28 kW Total speed range: 1 – 2,200 rpm Max. spindle torque: approx. 2,200 Nm X-axis (cross slide) performance data: Maximum travel: 400 mm Feed force: 14 kN Speed: 4 m/min Z-axis (bed slide) performance data: Feed force: 18 kN Speed: 7 m/min Permissible workpiece weights: Between centres without steady rest: 2,000 kg With one steady rest: 2,200 kg With two steady rests: 2,500 kg Overhung in faceplate: 750 kg Tailstock: Quill diameter: 115 mm Quill stroke: 225 mm Internal taper of quill: MK 6 Equipment and accessories: CNC control Heidenhain MANUALplus 4110 3-jaw hand chuck SCHUNK, model ROTASplus 400-102 2 x steadies Toolholder from PARAT Chip conveyor Coolant system Work area enclosure with two sliding doors Machine length: 5,700 mm, with chip conveyor 7,400 mm Machine width: 2,100 mm

Kondisi: baru, The Turnado 230/2000 is a state-of-the-art conventional lathe, part of the universal lathe product line. With this machine, KNUTH has created a precise and high-performance tool distinguished by its robust construction and long service life. Equipped with a powerful motor and a wide range of useful accessories, this machine meets various production requirements. Its solid construction and heavy, one-piece cast bed ensure high stability during machining, while the intuitively operated panel on the headstock and the 3-axis position display provide ease of use and high accuracy. Additionally, the adjustable longitudinal stops allow for automated feed shut-off, significantly simplifying repetitive machining. The Turnado 230/2000 is perfectly suited for long workpieces, thanks to the standard accessories, which include both a travelling and a fixed steady rest. If you are ready to acquire this robust universal lathe, order now or request a quotation. Gbodpfsp Ebgrox Adtsg

Kondisi: baru, Tahun pembuatan: 2025, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: LZ280/3, diameter putar di atas sled silang: 190 mm, lubang spindel: 43 mm, diameter pembubutan: 330 mm, diameter pembubutan di atas alas geser: 330 mm, tinggi pusat: 165 mm, panjang pembubutan: 670 mm, gores kuas bulu: 90 mm, diameter quill: 45 mm, kecepatan spindel (maks.): 4.000 rpm, kecepatan spindel (min.): 30 rpm, GDW precision lathe LZ 330 V EconomyLine The LZ 330 V EconomyLine is a powerful geared-head lathe with a continuously variable spindle speed range from 30 to 4,000 rpm. The standard paint finish includes RAL 7035 (light grey) for the enclosure and RAL 7016 (anthracite grey) for the base, splash guard, and chuck guard. Features & Accessories: ✅ 3-axis position display with 6'' color screen ✅ Multifix A quick-change tool post including 1 turning tool holder ✅ Coolant system & central lubrication ✅ Chip tray, splash guard & spindle brake ✅ LED machine lamp & K32 collet board ✅ Electromechanical end-stop system for threading/feeds ✅ Tool cabinet with telescopic pull-outs including operating tools Additional equipment package (optional): ➕ 3-jaw chuck Ø 160 mm (up to 4,600 rpm) ➕ Keyless drill chuck (3–16 mm, B16/MK3) ➕ Live center MK3 & boring bar holder ➕ 4 additional turning tool holders & 1 boring bar holder 📦 Delivery: Gsdpfx Ajv Dan Dedtjbg ✔️ Disposable packaging & secure transport incl. insurance Perfect for precise and demanding turning applications in industry and workshops! 🚀

Kondisi: bekas, studer-s40-2-en Gbedpfxox S N D Ao Adteg

Kondisi: bekas, Tahun pembuatan: 2020, jam operasional: 6.875 h, nomor mesin/kendaraan: IntNr231185, EMAG WEISS Cylindrical Grinding Machine EMAG WEISS Type W11-CNC / UNIVERSAL CYLINDRICAL GRINDING MACHINE W 11-CNC SL650 Spindle Hours: approx. 6,850 hours Power-On Hours: 20,422 hours Distinctive Feature: 2-in-1 control concept: 100% conventional cylindrical grinding or switchable to 100% CNC cylindrical grinding Technical data: • Control: CNC-controlled (Heidenhain, Siemens, or Fanuc, depending on year of manufacture) • Maximum grinding length: 650 / 1,500 mm ; 25.5 / 59 in • Center height: 200 mm ; 8 in • External grinding Ø: 1 / 390 mm ; 0 / 15.5 in • Max. workpiece weight between centers (live center taper MK 4): 100 kg ; 220.5 lb • Max. workpiece weight between centers: 250 kg ; 551 lb • Infeed: X-axis travel: 380 / 480 mm ; 15 / 19 in • Infeed: Z-axis travel: 1,150 / 1,650 mm ; 45.5 / 65 in • Grinding wheel Ø: 400 / 500 mm ; 15.5 / 19.5 in • Rated power (100% duty cycle): 9 / 11 kW ; 12 / 15 hp • Peripheral speed: 20 - 50 m/s Machine equipment: • Grinding wheel drive: High-performance motor for precise grinding results • Tailstock: Adjustable tailstock for different workpiece lengths • Workpiece clamping: Chuck or center (depending on application) • Coolant system: Integrated, prevents overheating and ensures optimal grinding results • User-friendly interface: Intuitive CNC operator panel for simple programming and operation • Measuring systems for real-time monitoring and quality assurance • Machine bed: Cast-iron Karstens base with high static-dynamic rigidity • X-axis: High-precision linear guides, ball screw, and glass scale • Z-axis: V-flat or linear guides, ball screw, and glass scale • Control: Touch screen with integrated CNC controller based on Windows (dialog programming, DIN programming, program storage) • Electrical cabinet: According to VDE with CE marking • Coolant and extraction system • Paper band filtration system with 250 l capacity • Mechanical mist extraction with 1600 m³/h, automatically actuated, without support leg • Measuring axis for processing multiple diameters with wide range • Measuring head. Measuring position freely programmable. • Robotic interface prepared • Only 10 x I/O provided without interface plug, software and PLC Applications: • Cylindrical external and internal machining • Precision grinding for machine building, automotive, and tool making • Production of shafts, bushings, rollers, and other rotationally symmetric workpieces Gjdsx Sv U Uspfx Adtjbg Special features: • High rigidity of the machine body for vibration-free operation • CNC control for complex grinding cycles and flexible machining • Custom adaptation to specific customer requirements possible Optional retrofittable equipment: • Automated loading and unloading systems • Special chucks and specific grinding wheel holders Optional grinding wheels available: • See photos The machine can be inspected under power by appointment. Subject to technical changes and errors; machine may be sold prior to inquiry!

Kondisi: bekas, Tahun pembuatan: 2005, jam operasional: 60.683 h, Fungsionalitas: berfungsi sepenuhnya, panjang pembubutan: 1.524 mm, diameter pembubutan: 820 mm, kecepatan spindel (min.): 3.300 rpm, lubang spindel: 104 mm, jarak pergerakan sumbu X: 870 mm, jarak lintasan sumbu Y: 500 mm, jarak gerak sumbu Z: 1.598 mm, gerak cepat sumbu X: 40 m/menit, pergeseran cepat sumbu Y: 40 m/menit, pergerakan cepat sumbu Z: 40 m/menit, Perlengkapan: kecepatan rotasi dapat diubah tanpa batas, EN: MAZAK CNC Turning Machine MODEL: INTEGREX e-500 HS /U1500 with Mazatrol 640M PRO control system for sale. The machine is in good condition and can be inspected under power at its current location. Maintenance records are available. In 2025, the X and Y axes were replaced. The milling spindle and gearbox were renewed in 2024. Technical Data: - Max. swing diameter: 820 mm - Max. turning diameter: 820 mm - Max. turning length: 1,524 mm Main Spindle - Speed range: 0–3,300 rpm - Drive power: 30 kW / 22 kW - Max. torque: 588 Nm - Spindle nose: A2-11" - Spindle bore: 104 mm - Indexing: 0.0001 Sub Spindle - Speed: 0–3,300 rpm - Drive power: 30 kW / 22 kW - Max. torque: 588 Nm - Spindle nose: A2-11" - Indexing: 0.0001 Milling Spindle - Drive power: 37 kW - Max. torque: 260 Nm - Speed range: 0–10,000 rpm - Tool holder: SK50 Tool Magazine - Number of tool positions: 120 Travel - X: 870 mm - Z: 1,598 mm - Z2: 2,458 mm - Y: 500 mm - B-axis: -30 to 210°, 0.0001° increment Feed Rate - X/Y/Z: 40 mm/min Machine Data - Connected load: 104 kVA - Operating voltage: 400V / 50 Hz - Required floor space (LxW): 7 x 3.5 m Special Equipment - Tool magazine, 120 positions Gbodpfxex Syldo Adtog - High-pressure coolant system, 70 bar - Renishaw probe - Laser measuring system for rotating tools - Interface set - Air/water cooling through the spindle - Overload monitoring system - Mayfran Consep 2000 chip conveyor - SMW quick-change chuck

Kondisi: sangat baik (bekas), Tahun pembuatan: 2009, Fungsionalitas: berfungsi sepenuhnya, Technical Details Faceplate diameter: 1800 mm Swing diameter: 2000 mm Turning height: 1270 / 1120 mm Control: SIEMENS 840 D Max. workpiece weight: 5000 kg Ram dimensions: 250 x 250 mm Table speed range: 1 - 320 rpm Crossrail adjustment: 400 mm Ram slide horizontal travel (X): -2770 / +2275 mm Ram slide vertical travel (Z): 1250 mm C-axis: 360° (0.001°) Milling drive: 37 kW Milling speed range: 10 - 3000 rpm Table drive power: 100 kW Torque: 31784 Nm Feed range (X/Z): 0.1 - 15,000 mm/min Total power requirement: kW Machine weight approx.: 55 t Space requirement approx.: m Additional Information Used CNC vertical turning lathe for turning, drilling, and milling operations The machine was only commissioned in 2011. CNC Control: Siemens Sinumerik 840 D Number of NC axes: 4 (X, Z, C, crossrail adjustment) Max. workpiece diameter: 2040 mm Max. workpiece height: 1270 mm Ram slide stroke: 1250 mm Max. workpiece weight: 5000 kg (per pallet/chuck) Main spindle speed range: 1.0 - 320 rpm Main spindle drive power: 100 kW Drilling-milling spindle: 37 kW Crossrail travel path: 2 steps of 200 mm each Total electrical connected load: 218 kVA Travels: X-axis: -1650 to +2165 mm Z-axis: 1250 mm Rapid traverse X/Z-axis: 15 m/min Number of tool magazine positions: 80 positions in the chain magazine, including 60 x HSK 100 and 20 x Capto C6 12-position disc magazine for turning toolholders and attachment heads Coolant unit with filtration and circulation system Chip conveyor Oil mist extraction system 1 x Pallet with jaw boxes, diameter 1800 mm 1 x hydraulic chuck with base jaws, diameter 1800 mm Godpsx S Efpofx Adtsbg Various drilling and milling heads 2 x measuring probes Several tool holders for turning tools Special features: Pallet changer with two stations, equipped with a faceplate Ø1800 mm and a six-jaw compensating chuck with mechanical centrifugal force compensation Ø1800 mm. Note: The machine is set in a pit. Condition Description: About half a year ago, the Carnaghi cross roller bearing was replaced. All Siemens components in the control cabinet were completely renewed at the end of 2023. Additionally, the machine features a probe for tool measurement and an external Renishaw probe for workpiece measurement. As a special feature, a probe is installed on the Z-axis (Z1 axis). This provides an accuracy and time advantage since the tool does not need to be removed for measuring. Currently, this probe is out of operation and should be overhauled before recommissioning. Furthermore, the machine features a Rotomors six-jaw compensating chuck with centrifugal force compensation, which was completely overhauled in 2020/21.

Kondisi: bekas, Tahun pembuatan: 1998, 1 Gjdpfx Adoxp Rzbotobg

Kondisi: sangat baik (bekas), Tahun pembuatan: 1998, jam operasional: 50.000 h, Fungsionalitas: berfungsi sepenuhnya, The machine does not feature automation or a fully automatic dressing device (these are only available on the RZ 400/410 model series). This is a stand-alone machine, but it comes fully equipped with extensive, heavy-duty accessories. The machine achieves extremely precise grinding quality. Technical Data – Gear Grinding Machine Reishauer RZ 362A Machine type: Gear grinding machine Manufacturer: Reishauer AG, Wallisellen, Switzerland Model: RZ 362A Year of manufacture: 1998 Machine number: 73889 Commission number: 309 CE marking: Available Electrical Data Mains connection 3 × 400 V, 50 Hz Machine voltage 3 × 400 V, 50 Hz Control voltage 1 × 230 V, 50 Hz / 1 × 24 V DC Contactor voltage 1 × 24 V DC Valve voltage 1 × 24 V DC Standard electrical wiring diagrams Grinding Wheel Data Minimum / maximum external diameter 280 / 350 mm Maximum width with limitations 84 / 104 mm Number of gears with limitations up to 3 Maximum usable width with shifting movement 90 mm For modules > 7 or more than 3 gears, Reishauer guidelines apply Grinding Wheel Speeds In grinding operation 1,100 – 2,300 rpm During profiling 50 – 95 rpm In setup mode (special operation) maximum 200 rpm Grinding Infeed In grinding operation per grinding stroke 0.01 – 1.0 mm Total infeed (fx total) 9.99 mm In setup mode (special operation) maximum 2 m/min Grinding Stroke Maximum grinding stroke 175 mm Automatic wheel retraction for workpiece change 65 mm Shift Movement Maximum shift travel per continuous shift per 1 mm grinding stroke 0 – 1.0 mm Workpiece Data Minimum workpiece pitch diameter depending on grinding wheel diameter With grinding wheel Ø 280 mm: 50 mm With grinding wheel Ø 320 mm: 10 mm With grinding wheel Ø 350 mm: 10 mm Automatic centering with sensor (only RZ 362A): 20 mm Maximum workpiece outside diameter 360 mm With “Felsomat” loading system (optional, only RZ 362A) 300 mm With automatic sensor-based centering (only RZ 362A) 320 mm Minimum distance from grinding wheel center to workpiece center 165 mm Maximum gear width 175 mm For pitch diameters < approx. 150 mm, width reduction due to chuck and tailstock geometry Maximum workpiece weight 60 kg With “Felsomat” loader (optional, only RZ 362A) 4 kg Distance between centers Fixed manual tailstock (optional) 645 mm Special manual tailstock (optional) 745 mm Hydraulic tailstock (optional, only RZ 362A) 515 mm (645 mm with reduced grinding stroke) Gear Data Number of teeth min. 6, max. 600 Module without automatic centering min. 0.5 module (DP 48) Module with automatic centering min. 0.8 module (DP 32) Maximum module 7.0 (DP 3.5) Helix Angle Minimum 10° Maximum 40° Maximum helix angle left and right 45° Shift movement limitations with large helix angles, especially above 30° Profile and Crowning Corrections Tip relief and crowning height Crowning length and taper Maximum corrections depending on profiling tool and process parameters Weights (without oil filling) Machine approx. 5,000 kg Control cabinet approx. 1,100 kg Hydraulic unit approx. 600 kg Grinding oil system RTO 100 (optional) approx. 1,600 kg Grinding oil system RTM 100 with magnetic pre-filter (optional) approx. 1,650 kg Grinding oil system RTA 150 (optional) approx. 2,500 kg Godpfx Adex Sxbdotjbg Portal loader “Felsomat” (optional, only RZ 362A) approx. 1,600 kg Loading unit approx. 1,000 kg Workpiece magazine approx. 400 kg

Kondisi: bekas, Tahun pembuatan: 2019, sp-hu-001 Gbjdpfsx Szlrex Adtjg

Kondisi: bekas, Tahun pembuatan: 2001, jam operasional: 51.500 h, nomor mesin/kendaraan: IntNr230346, gebr. CNC-Langdrehautomat STAR SR20R, Baujahr 2001 Steuerung: Fanuc, Serie 18i-T 7 Achsen (X/Z/Y/C1/X1/Z1(C2)) Stangendurchmesser max.: 20 mm max. Drehlänge: 205 mm Hauptspindel, max. Drehzahl: 10.000 U/min, C-Achse 0,001° Gegenspindel mit Spannzange, max. Drehzahl: 8.000 U/min, C-Achse Gjdpfx Adox Sv Uhotebg Werkzeugaufnahme für 19 Werkzeuge (Linear-Werkzeughalter, Frontapparat, Rückseitenbearbeitung) Teileförderband Standard-Führungsbuchse Lademagazin FMB turbo 3-26/3200 / A /, Baujahr 2001 Kühlmittel: Öl Löschanlage: Kraft & Bauer Die Maschine kann nach Terminvereinbarung unter Strom besichtigt werden. Technische Änderungen, Irrtümer und Zwischenverkauf vorbehalten. ENGLISH TRANSLATION: Used CNC sliding headstock lathe STAR SR20R, year 2001 Control: Fanuc, Series 18i-T 7 axes (X/Z/Y/C1/X1/Z1(C2)) Bar diameter max.: 20 mm Max. turning length: 205 mm Main spindle, max. speed: 10,000 rpm, C-axis 0.001° Counter spindle with collet, max. speed: 8,000 rpm, C-axis Toolholder for 19 tools (linear toolholder, front attachment, rear machining) Parts conveyor belt Standard guide bush unit Bar feeder FMB turbo 3-26/3200 / A /, year 2001 Coolant: oil Fire extinguishing system: Kraft & Bauer The machine can be inspected under power by prior appointment. Subject to technical changes, errors, and prior sale.

Kondisi: baru, Tahun pembuatan: 2024, IMMEDIATELY AVAILABLE, 3-year warranty from date of invoice FREE DELIVERY Infinitely variable electronic spindle speed: 40-4000 rpm Spindle: MT 2 Table height adjustment via rack and pinion Maximum thread cutting capacity: M12 Gjdpfeig H Rdjx Adtsbg Thread cut depth adjustable via digital depth readout Digital speed display Digital drilling depth display Drilling depth stop via stop ring Feed: manual Table height adjustment via rack and pinion Continuous/standard drilling capacity in steel: Ø 15 mm / 18 mm Drilling depth: 70 mm Throat: 220 mm Column diameter: 70 mm Usable table area (W x D): 300 x 250 mm Machine dimensions (W x D x H): 420 x 520 x 850 mm Weight: 65 kg Maximum distance spindle/table/base: 300 / 370 / 420 mm Motor: single-phase with frequency converter, 230 V, 0.54 kW OPTIONAL Drill Package 2 (No. 296591) - Vice Felix 80 - Quick-action drill chuck B16 1-13 mm - Taper shank B16 / MT II - Reducing sleeve MT II / MT I Price: €307 Factory warranty: 3 years Free delivery including packaging (within Germany only) NOT THE RIGHT MACHINE? WE ARE AN AUTHORIZED FLOTT SERVICE PARTNER AND CAN OFFER YOU ALL PRODUCTS FROM THE FLOTT RANGE! REQUEST A QUOTE!

Kondisi: baik (bekas), Tahun pembuatan: 1988, diameter putar di atas sled silang: 900 mm, lubang spindel: 105 mm, diameter pembubutan: 1.200 mm, panjang pembubutan: 5.000 mm, panjang total: 8.000 mm, lebar total: 1.800 mm, tinggi total: 1.550 mm, lebar tempat tidur: 650 mm, berat benda kerja (maks.): 10.500 kg, de-to-hu-it-lt-lv-nb-pl-pt-001 Gbedowrxpbepfx Adtsg

Kondisi: bekas, Tahun pembuatan: 2003, nomor mesin/kendaraan: IntNr230334, en-GB-2024-06-machinery-0001 Gbjdpfx Asx Sv T Rodteg

Kondisi: baru, Tahun pembuatan: 2024, NEW FLOTT SB 25 plus Column Drilling Machine - Thread cutting device - Control panel with OLED display - LED lighting - Fast-adjusting, ergonomic drilling depth stop - Stepless speed control via central rotary dial - Thermal overload protection - Spindle stop - Drill guard with electrical interlock - Continuous/standard drilling capacity (mm): 23/25 Gjdpfx Adsf S Tfnetsbg - Thread cutting capacity (depending on pitch): M16x1 - Spindle: MT III - Drilling depth (mm): 115 - Throat depth (mm): 260 - Usable work surface (W x L) (mm): 420 x 340 - Table height adjustment with rack and pinion - Infinitely variable spindle speeds (rpm): 20 – 2000 - Dimensions (mm): 430 x 715 x 1800 For additional TECHNICAL DATA, please refer to the product datasheet! OPTIONAL Drill Package 4 (296593) – €595.00 - [felix] 2.0 120 machine vice - Quick-action drill chuck B18 3–16 mm (accuracy 0.17 mm) - Tapered arbor B18/MT III - Reducing sleeve MT III/MT II - Reducing sleeve MT III/MT I 3-year warranty for single-shift operation Delivery: free to your door including packaging (within Germany) NOT THE RIGHT MACHINE? WE ARE AN OFFICIAL FLOTT PARTNER AND CAN OFFER YOU THE FULL FLOTT PRODUCT RANGE! CONTACT US FOR A QUOTE!

Kondisi: bekas, Tahun pembuatan: 1999, jam operasional: 78.000 h, nomor mesin/kendaraan: IntNr231160, IntNr231160 Maschinentyp: CNC-Langdrehautomat Hersteller: STAR Modell: SV-20 Baujahr: 1999 Zustand: sehr gut (gebraucht) Sehr gepflegte Maschine direkt vom Anwender Die Maschine wurde ausschließlich mit Öl betrieben Godjx Sv T Depfx Adtebg Betriebsstunden: ca. 78.000 Std. FANUC 16i-T Steuerung mit 9 Achsen 9 Achsen (X / C1 / Y / E / B / A / X / C2) Stangendurchmesser max.: 20 mm Max. Drehlänge: 205 mm / 195 mm Hauptspindel, max. Drehzahl: 10.000 U/min, C-Achse Gegenspindel mit Spannzange, max. Drehzahl: 10.000 U/min, C-Achse 4-fach Werkzeughalter 3 Querbohr-Einheiten Revolver mit 8 Stationen Diverse zusätzliche Werkzeughalter, Pinolen Teileförderband Tankinhalt: 170 L Kühlmittel: Öl Lademagazin: FMB Turbo 3-26 /3200/A / von Ø3–Ø26 mm, Baujahr 1999 Feuerlöschanlage: Kraft & Bauer / GUT Feuerschutz Späneförderer: Mayfran Eine Besichtigung der Maschine unter Strom ist nach Terminvereinbarung möglich. Technische Änderungen, Irrtümer und Zwischenverkauf vorbehalten.
