Beli Planet Gear bekas (7.037)

Kondisi: bekas, Tahun pembuatan: 2008, Kontrol Siemens 840D Dksdpfx Aewzypnshuok

Kondisi: baik (bekas), Tahun pembuatan: 2020, 001 Dksdpfx Ahsyw Ncpousk

Kondisi: sangat baik (bekas), Dijual: motor reducer dari produsen Jerman ternama KEB Antriebstechnik. Konstruksi industri yang kokoh, dirancang untuk kerja kontinu dalam kondisi berat. Perangkat menghasilkan torsi tinggi pada kecepatan rendah, ideal untuk mesin, konveyor, feeder, dan aplikasi industri lainnya. Data teknis: Produsen: KEB Antriebstechnik Dksdpfjywaq Dox Ahujk Model: ZG 2 KPR 71 G 6 TS 140 G 92 Daya: 0,55 kW Kecepatan keluaran: sekitar 20 rpm Torsi: 259 Nm Tegangan: 230/400 V Frekuensi: 50 Hz Tingkat perlindungan: IP55 Tipe pemasangan: B3 pada kaki Berat: sekitar 26 kg Dimensi: Diameter poros: sekitar 30 mm Panjang poros: sekitar 60 mm Kondisi: Bekas Layak pakai secara teknis Terdapat tanda-tanda pemakaian dan karat permukaan pada poros Kondisi visual sesuai dengan foto

Kondisi: bekas, Tahun pembuatan: 1998,

Kondisi: bekas, Wheel diameter – max. 180 mm Wheel width 45 mm Module – max. 4 Dkjdpfx Ahju Uu S Teuek Module – min. 0.5 Stroke length max. 0 – 52 mm Internal spindle taper MK 4 Table diameter 160 mm Table bore diameter 75 mm Strokes per minute 355 – 630 spm Feed range 0.008 – 0.4 mm/stroke Space requirement approx. 2.30 x 1.50 x 2.36 m Drive power 6 kW Machine weight approx. 2,500 kg Year of manufacture: approx. 1970 Hydraulic clamping on the table Change gears

Kondisi: hampir baru (bekas), Wheel diameter - max. 420 mm Wheel width 120 mm Module - max. 8 Module - min. 0.5 Control system BWO CNC Strokes 32–800 strokes/min Total power requirement 50 kW Machine weight approx. 9 t Space requirement approx. 5.3 x 3.9 x 3.4 m Machine elevation 200 mm Leveling feet Wheel diameter - max. 420 mm x-axis travel 360 mm z-axis travel 154 mm Dsdpfx Ahotycgfjuskk l-axis travel 137 mm Max. table load 1,000 kg Control system Total power requirement 50 kW Machine weight approx. 8,400 t Space requirement approx. 5.3 x 3.9 x 3.5 m - Linear guideways - Machine elevation 200 mm - With automatic workpiece clamping device - Counterholder Year of manufacture: approx. 1989

Kondisi: baik (bekas), Tahun pembuatan: 1982, Wheel diameter – max. 600 mm Wheel width 500 mm Module – max. 15 Module – min. 1 Total power requirement 2 kW Machine weight approx. 2 t Space requirements approx. 2x1.5x2 m The tooth rounding is achieved by a combination of the cutter shifting movement and the continuous rotary motion of the workpiece. The alternate movement of the cutter is controlled by the rotation of a cam, which is shaped to create either a radius or a chamfer. A series of 4 cams allows machining within the module range from 1 to 16 (inclusive). An adjustment device enables changing between the minimum and maximum module value for each cam. The rotation of the workpiece is controlled by a three-stage gear unit, which forms the indexing system. The workpiece lock and the rapid approach of the cutter to the workpiece are controlled by pneumatic servo devices. The practicality and speed of the equipment, along with the extensive selection of profiles available on the cams and the ability to process internal gears, make the machine a universal solution suitable for both small and large batch production. --> Technical specifications Max module: 15 Dkjdpfx Ahjwftuxsuek --> Max diameter: 600 mm --> Spindle/head speeds: 1,450 – 2,100 – 2,800 rpm --> Production output teeth per minute: 35 – 50 – 75 --> Spindle motor power: 2,800 rpm – 1.5 HP --> Workpiece rotation motor power (self-braking): 1.5 HP --> Automatic motor power (self-braking): 0.35 HP --> Coolant system motor power: 0.25 HP --> Dimensions: 2,000 x 1,500 mm --> Total weight: 2,000 kg Accessories Cam x 5 Indexing gears Tooling Serial No. 152/0589/94 Machine with full enclosure Counter-holder

Kondisi: baik (bekas), Tahun pembuatan: 1991,

Kondisi: bekas, Wheel diameter - max. 0-200 mm Module - max. 25 Dodpjtuxa Uefx Ahuekk Module - min. 0.5 with accessories and sub-table Year of manufacture approx. 1995

Kondisi: baik (bekas), Tahun pembuatan: 1978, Pitch circle diameter max. 152 mm Number of teeth: 8-50 pcs. Weight: 7,500 kg Technical Data – Min./max. root cone angle: 15° / 55° – Pitch circle Ø: 152 mm – Max. tooth height with 21° finishing cutter head: 10.7 mm – Max. tooth width at root with 21°: 28 mm – Cutter head Ø: 200 mm – Number of teeth range: 8–50 – Max. cutter head Ø: .21" Workpiece spindle – Diameter of tapered bore at wide end: 99.219 mm – Clamping length over 304.8 mm: 15.478 mm – Taper depth: 15.875 mm Dkedpfxexq Hgce Ahuok – Diameter of entire spindle bore: 22.225 mm The GLEASON 726 REVACYCLE bevel gear cutting machine machines workpieces with the highest precision and accuracy. The root angle can range from 15° to 55°, and the bevel gear is machined at a high speed of 49.7 m/min. The GLEASON NO 726 machine weighs approx. 9 tons. Technical specifications of the bevel gear cutting machine GLEASON 726 REVACYCLE - Maximum tooth height: 14.8 mm - Maximum tooth width at root: 28 mm - Maximum root angle: 55° - Minimum root angle: 15° - Cutting head speed: 32.6–49.7 m/min - Feed rates (seconds per tooth): 2–3.1 - Indexing range: 8–50 mm - Diameter of tapered bore at larger end: 99 mm - Taper per foot: 15.4 mm - Taper depth: 15.8 mm - Counterbore behind taper: 57.2 x 77.9 mm - Diameter of through spindle bore: 22.3 mm - Main drive motor power: 10 HP - Main drive motor speed (60 Hz/50 Hz): 1800/1500 rpm - Hydraulic motor speed (60 Hz/50 Hz): 1800/1500 rpm - Coolant pump speed (60 Hz/50 Hz): 3600/3000 rpm - Chip conveyor motor speed (60 Hz/50 Hz): 1800/1500 rpm - Footprint (L x W): 320 x 221 cm - Total weight of 726 REVACYCLE machine: approx. 9 t

Kondisi: bekas, Wheel diameter – max. 180 mm Wheel width 45 mm Module – max. 4 Module – min. 0.5 Stroke length max. 0 – 52 mm Internal spindle taper MK 4 Table diameter 160 mm Djdpfx Astycg Sohujkk Table bore diameter 75 mm Strokes per minute 355 – 630 spm Feed range 0.008 – 0.4 mm/stroke Space requirement approx. 2.30 x 1.50 x 2.36 m Drive power 6 kW Machine weight approx. 2,500 kg With rack cutting attachment Change gear set Year of manufacture: approx. 1981

Kondisi: baik (bekas), Tahun pembuatan: 1998, Max. pitch circle diameter external gearing: 300 mm Max. pitch circle diameter internal gearing: 300 mm Max. outside diameter of workpiece (clamping): 450 mm Module – max.: 6 Gear width – max.: 100 mm Max. helix angle (with tool Ø 125 mm): +/- 45° Stroke rate – stepless: 130 – 1300 strokes/min Workpiece weight: 1000 kg Min. distance table surface – tool spindle: -55 / +300 mm Max. distance table surface – tool spindle: 200 mm Max. table-to-tool spindle distance: 350 mm Manual column lateral adjustment: +/- 25 mm Manual swivel angle of tool spindle: +/- 0.5° Max. tool speed: 15 rpm Max. workpiece speed: 27 rpm Max. tool diameter: 7 inches Voltage: 400 V Frequency: 50 Hz Max. power consumption: 70 A Dksdpfx Ahevu E Nuoujk Total power requirement: 48 kW Machine weight: approx. 11 t Space requirements: approx. 4.27 x 3.11 x 2.87 m Table bore: 40 mm Main spindle taper: SK 45 Control: Siemens Sinumerik 840 C Gear shaping machine Gleason PFAUTER Mod. PSA 300 The CNC modular gear cutting machine with skiving cutter for machining external and internal cylindrical gears, with straight or helical involute toothing, as well as any other profile that can be produced by means of generating or indexing shaping. The operating cycle is controlled by a CNC unit equipped with specialized gear cutting software. Field of application --> The PSA 300 was designed for manufacturing: - Spur gears with external teeth - Spur gears with internal teeth - Helical gears with external teeth - Helical gears with internal teeth

Kondisi: baik (bekas), Wheel diameter – max. 630 mm Dkjdpfx Aeua It Uehusk Wheel width 375 mm Module – max. 10 Clamping table 550 mm Table bore 125 mm Cutter speeds steplessly adjustable 62 – 390 rpm Spindle taper MORSE 5 Axial feeds 0.40 – 6.80 mm/rev Radial feeds 0.10 – 1.76 mm/rev Distance milling spindle – clamping spindle 50 – 425 mm Number of teeth, min. 8 Cutter diameter x width 192 / 215 mm Cutter traverse 200 mm Main drive motor 7.5 kW Total connected load 21 kVa Machine weight approx. 8.2 t Machine equipment: - Universal milling head with tangential traverse - Pressure reduction valve for counter-holder - Magnetic chip conveyor - Year of manufacture approx. 1976

Kondisi: baik (bekas), Tahun pembuatan: 1998, Spindle diameter: 90 mm Control system: Siemens SINUMERIK 840 C Operating voltage: 400 V Stroke position adjustment: 100 mm Table bore: 150 mm Strokes per minute: 100-1200 strokes/min Machine weight approx.: 8.0 t Key specifications: Standard module: 6 mm Dodpfx Aoxyadtjhuekk Maximum workpiece pitch circle diameter: 250 mm Maximum gear width (spur gearing): 60 mm Helix angle adjustment: 45° to +0.5° Axis angle: 0° to 90° Center distance between workpiece and reciprocating spindle: -80 mm to +320 mm Stroke position, stroke length, maximum stroke position range (depending on stroke length): 0 mm to 80 mm Stroke position adjustment range: 0 mm to 80 mm Stroke drive Infinitely variable stroke rates (standard): 100 to 1200 DH/min Stroke drive motor: 9 kW Maximum cutting speed: 150 m/min Feeds Rotary axes (tool C1-, workpiece C2-axis): Infinitely variable feed, relative to 100 mm pitch circle diameter: 1.0 to 9,420 mm/min Radial axis (column slide X1-axis): Infinitely variable feed: 1.0 to 9,420 mm/min, rapid traverse corresponds to maximum feed rates Connected load / Weight Total connected load: 26 kVA Total weight (standard configuration): approx. 9,000 kg

Kondisi: baik (bekas), Tahun pembuatan: 1972, Diameter roda - maks. 80 mm Lebar roda 60 mm Modul - maks. 3 Modul - min. 0,1 Djdpsw N S D Sefx Ahuekk Kebutuhan daya total 0,4 kW Berat mesin sekitar 120 kg Kebutuhan ruang sekitar 0,6x0,6x0,75 m Mesin ini digunakan untuk penggerindaan roda gigi bevel kecil / roda gigi lurus. Untuk proses milling roda gigi bevel digunakan Mikron 102.01.

Kondisi: bekas, raddurchmesser-300mm Djdpfxjxu Ntte Ahuekk

Kondisi: baik (bekas), Tahun pembuatan: 1975, de-to-hu-20240624 Dksdpfx Ajyb Sx Tjhuok

Kondisi: bekas, Raddurchmesser - max. 40 mm Radbreite 45 mm Modul - max. 1 Einspannlänge max. 75 mm Zähnezahl 5 - 399 Fräserdrehzahlen 320 - 3200 U/min Maschinengewicht ca. 0,6 t Vollautomatische Abwälzfräsmaschine mit Ladeeinrichtung Grösster Verarbeitungsdurchmesser 20mm, 40mm bei manuellen Einlegen, max Fräslänge 45mm, max Arbeitsstücklänge 75mm, max Modul 1, Zähnezahl: 5 bis 399, Vibrationsmagazin, automatisches Einlegen, Kühlung mit Pumpe Dodpeyh Rmgsfx Ahujkk

Kondisi: bekas, Tahun pembuatan: 2003, Kontrol BWO Diameter lingkar kepala maks. 700 mm Diameter lingkar kaki min. 50 mm Tinggi profil maks. 35 mm Kecepatan putaran spindle 0 - 5400 min-1 Beban meja maks. 500 kg Dimensi mesin 370x220x300 cm Berat total sekitar 15000 kg Jam operasi 94082 jam Perlengkapan: Kontrol BWO Semua sumbu dikendalikan CNC Ekstraksi kabut oli Sistem pembersihan cairan pendingin dengan unit pendingin Dodpfjxt Ur Ssx Ahuskk Unit penyeimbang Dittel Aksesori: Batu gerinda Ø400mm inklusif Flens cakram gerinda 1 roller dressir berlian prod. Dr. Kaiser Ø160mm Pusat konter Panel kontrol listrik: Lebar 70cm x panjang 280cm x tinggi 220cm Mesin Lebar 220cm x panjang 370cm x tinggi 300cm Instalasi cairan pendingin: Lebar 170cm x panjang 240cm x tinggi 250cm

Kondisi: hampir baru (bekas), Tahun pembuatan: 2023, General Data • Machine type: Gear skiving machine • Machine number: 32335 • Year of manufacture: 2023 • Operating hours: unknown (The machine was only used for testing purposes and never used in production.) Machine Description • Gear skiving machine for machining soft and hard materials • For manufacturing skivable profiles on cylindrical workpieces • Especially suitable for internally and externally toothed cylindrical gears • Equipped with integrated re-sharpening unit • Axes of the re-sharpening unit: +A3, +C3, +X3 • Integrated swivel gripper for workpiece handling • Workpieces are transferred from the transfer station to the workpiece table • Machining is performed using a skiving cutter • The machine was temporarily installed in another facility • According to reports, the machine was operated for only one hour – short test period Machine Specification Workpiece Dimensions • Internal diameter range: 40 – 300 mm • External diameter range: up to 450 mm Spindle • Tool spindle (C2): 2,990 rpm • Grinding spindle of the re-sharpening unit (C3): 12,000 rpm Tool Holder • Tool interface: HSK B125 Dksdpfx Aoywyt Sshusk Control System • Control: Sinumerik 840 D Special Features • Integrated re-sharpening unit with axes +A3, +C3, and +X3 • Integrated swivel gripper for automated workpiece handling Other Information • Total power consumption: approx. 100 kVA • Operating voltage: 400 V AC / 50 Hz • Machine dimensions: approx. 3,900 x 5,700 x 5,400 mm (H x W x D) • Machine weight: approx. 11,000 kg Optional Accessories • Hydraulic unit • Chip conveyor • Coolant chiller with filter and centrifuge

Kondisi: baik (bekas), Gear hobbing machine, milling machine, tool milling machine, vertical milling machine, gear cutting machine, gear hobbing machine, high-performance hobbing machine - Manufacturer: Liebherr, high-performance hobbing machine type SS 5-K/500 - Working range: max. Ø 500 mm - Max. cutter diameter: 186 mm - Accessories: includes extensive accessories, see photos - Machine dimensions: 2300/1460/H1870 mm - Accessories dimensions: pallets 1420/1300/H300 / 1200/800/300 mm Dkedpfxsv Dtmme Ahuok - Weight: 5300 kg plus 535 kg accessories

Kondisi: bekas, Tahun pembuatan: 1967, Raddurchmesser - max. 600/400 mm Modul - max. 10 Modul - min. 1 Zähnezahl beliebig Schlittenverstellung senkrecht 350 mm Schleifscheibendurchmesser 80 mm Gesamtleistungsbedarf 1 kW Dedpfsywnukjx Ahujkk

Kondisi: baik (bekas), Tahun pembuatan: 1965, de-to-hu-it-lt-lv-nb-nl-pl Dodpfx Aoywnt Tohujkk

Kondisi: siap digunakan (bekas), electrical connection: three-phase 220/380 V rated power: 0.25 kW Dkeded Aug Repfx Ahuok motor speed: 700 rpm output speed of gearbox: 6 rpm required space: 400 x 250 x 250 mm weight: 50 kg 4 units available!

Kondisi: siap digunakan (bekas), nomor mesin/kendaraan: 251, Output speed: 31.5 rpm Output power: 0.37 kW Dksdpfx Ahed Avb Djuok Electrical connection: 220/380 V Required space: 200 x 200 x 490 mm Weight: 15 kg with HEIDENHAIN rotary encoder
