Planer lebar

Steton 5-head four-sided planer. FAM /5

Kondisi: sangat baik (bekas), Fungsionalitas: berfungsi sepenuhnya, Weinig Powermat 500 Four-Sided Planer Working width: 230 mm Working height: 160 mm Number of spindles: 6 Spindle arrangement: - Bottom: 5.5 kW, 8000 rpm - Right: 5.5 kW, 8000 rpm - Left: 7.5 kW, 8000 rpm - Top: 7.5 kW, 8000 rpm - Bottom: 7.5 kW, 8000 rpm Dcedpfxovfr Rgo Akaen - Universal: 5.5 kW, 8000 rpm Spindle no. 6 equipped with PowerLock system Feed speed adjustable via frequency inverter, up to 30 m/min Feed rollers integrated in the worktable (1 ribbed roller for wet wood) Electro-motorised adjustment of working height and width Pneumatic material hold-downs Cardan shaft drive Total power: 41 kW Year of manufacture: 2005 CE certified

Kondisi: bekas, Tahun pembuatan: 2025, Cutting height at 90°: 170 mm Cutting length: 430 mm Mitre range horizontal: 45°-90°-25° Djdpeiixxnjfx Akaecn Mitre range vertical: 60°-90°-30° Swivel adjustment with hand crank: yes Roller conveyor / support table: no Saw blade diameter: 420 mm Speed: 2800 rpm Motor power: 3 kW Motor brake: yes Extraction connection: 100 mm Machine length: Machine width: Weight: 110 kg

Kondisi: baru, Tahun pembuatan: 2026, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 330, kecepatan rotasi (maks.): 2.900 rpm, model mesin: 5,5kW, Perlengkapan: Penandaan CE, Styropor-/Styrodur-Zerkleinerer KP2 Dcodpfx Aoy Nantjkajn

Kondisi: bekas, Technical data: Max. planing width: 230 mm Max. planing height: 120 mm Dsdpfxjmiik Ts Akaecn Spindle diameter: 40 mm Number of spindles: 5 Spindle configuration: bottom 5.5 kW right + left 11 kW top 7.5 kW universal 5.5 kW Each spindle driven by a separate motor Number of steel feed top rollers: 5 Number of rubber feed top rollers: 3 1 rubber roller on the table Extraction port diameter: 150 mm Infinitely variable feed speed: 4-24 m/min Cardan shaft feed drive Table lubrication pump Operating pressure: 6 bar Electric height adjustment of the machine body Power supply: 400 V Overall dimensions: Length: 4,240 mm Width: 1,550 mm Height: 1,560 mm

Kondisi: baik (bekas), Tahun pembuatan: 2004, Saya menjual mesin pembuatan alur lidah dan alur ekor semi-otomatis GreCon Profijoint PJ7/6100-LI. Tahun pembuatan 2004. Panjang input 100-1.000 mm Lebar kayu 40-150 mm / lebar 510 mm dalam 1 putaran Ketebalan kayu 20-50 mm Dcodpfsmig Tdox Akajn Mesin pembuatan alur lidah dan alur ekor otomatis dengan injeksi perekat pada 1 sisi Pemutaran material secara otomatis untuk putaran ke-2 pada meja putar Pengumpanan otomatis ke dalam mesin pengepres Mesin pengepres 3,00 - 6,10 m dengan siklus otomatis dan gergaji pemotong akhir. Luas total 10,50 x 3,50 m Konstruksi yang stabil dan kuat. Kondisi sangat baik. Tersedia segera.

Tahun pembuatan: 2006, Kondisi: hampir baru (bekas), Pneumatic tensioning and leveling device for band saws. Dodpfx Aedy A A Njkascn

Kondisi: bekas, Tahun pembuatan: 1994, USED WEINIG PROFIMAT 23 AUTOMATIC 5-SPINDLE MOULDER Configuration: - 1) bottom horizontal spindle Dcjdpfxsrm Rxwo Akaon - 2) right vertical spindle - 3) left vertical spindle - 4) top horizontal spindle - 5) bottom horizontal spindle Working width: 230 mm Year: 1994 Voltage: 380/50

Kondisi: sangat baik (bekas), Four-sided planer Weinig Unimat 23 EL Working width: 230mm Working height: 160mm Spindle configuration: Bottom: 5.5 kW Right: 4 kW Left: 5.5 kW Right: 4 kW Dodpfx Aerb An Uskascn Top: 11 kW Bottom: 5.5 kW Top: 7.5 kW Bottom: 7.5 kW Variable feed speed via variator: 6-36 m/min Feed driven by cardan shaft Table with powered rollers Pneumatic pressure elements CE certificate Year of manufacture: 2003

Tahun pembuatan: 2002, Kondisi: diremaj di bengkel (bekas), Full-automatic finger jointing line: Type Doppel-Pack with automatic infeed with multiple cross-cut saw with stacking unit Specification: Wood input length: min. 150 mm max. 1000 mm average 400 mm Dodpfjg D Ugkjx Akaocn Wood cross-section: min. 20 x 40 mm max. 80 x 180 mm Wood output length: 6030 mm Max. wood cross-section with 10 mm finger size: Hardwood 120 cm² Softwood 150 cm² Finger jointing possible vertical and horizontal Type of glue: PVAC white glue, double-sided glue application Power supply: Connection voltage: 400 V Control voltage: 24 V 50 Hz System completely pre-wired up to the control cabinet. Finger length / optional wood cross-section and glue type can still be customized. Performance: 6 milling tables/min Working height: 960 mm Table width: 600 mm Glue application: double-sided Technical parameters: Input material: Input length of parts (min. - max.): 150-1000 mm Part width (min. - max.): 40-155 mm Part thickness (min. - max.): 20-80 mm Working height: 960 mm Bundle width: 600 mm Glue application: double-sided application (both sides of the part)

Kondisi: baik (bekas), Tahun pembuatan: 1973, Weinig four-side planer / U250 / Unimat 250 Planing width: 250mm Planing height: 120mm Bottom spindle 7.5 kW Right spindle 5.5 kW Left spindle 7.5 kW Right spindle 7.5 kW Dcsdpfxsrigq Sj Akaen Top spindle 7.5 kW Bottom spindle 7.5 kW Saw unit spindle 7.5 kW Includes planing heads Includes milling tools Includes knives Complete accessories included Good condition – immediately available Location: Austria, near Sankt Pölten
