Sabuk pengangkut Venjakob 3.000mm

Venjakob Gurtbandtransport

Kondisi: sangat baik (bekas), Single-Sided Destacking Station - Upper traverse horizontally movable by 180° - Console table with vacuum clamps - Internal lifting platform with motorized sheet metal roller conveyor - Sliding front safety guard - Separate control cabinet and operator panel Nodscggy Sopfx Aglokt - External roller conveyor for stack of sheets from the destacking unit - External powered roller conveyor from destacking unit, also with belt for transferring sheets at 90° - Operating capacity (cycles/min): 12–15 - Sheet thickness (min/max) mm: 10–40 - Min. sheet dimensions mm: 250 x 320 - Max. sheet dimensions mm: 1200 x 3000 - Total connected load kW: 10

Kondisi: sangat baik (bekas), TECHNICAL DATA (NOT OF THIS MACHINE) — RETURN DEVICE for Edge Banding Machine (LEFT SIDE) When combined with a single-sided edge banding machine, it allows a single operator to ensure continuous feeding of the machine. Nsdpfx Agoff R Tqslskt Air curtain section, infeed and outfeed (overall dimensions: 3520 x 2560 mm) 180° transfer (3120 x 2140 mm) with motorized roller conveyors and motorized belts Motorized conveyor (9080 x 1560 mm) Workpiece dimension range (MIN/MAX): Length — 240 mm / 2800 mm Width — 120 mm / 1300 mm Thickness — 8 mm / 60 mm (optionally up to 100 mm)

Kondisi: baik (bekas), Tahun pembuatan: 1989, Pressing area 2550 x 1350 mm Number of press cylinders: 6 Total pressing force: 140 t Opening width approx. 400 mm Operating voltage: 3 x 400 V + N, 50 Hz Total connected load approx. 26 kW Required space (L x W x H) approx.: 3400 x 1600 x 2000 mm Weight: approx. 5,500 kg Hydraulic heating platen press Bottom cylinder design Electrically heated platens Press pressure steplessly adjustable via pressure switch Hydraulic pump Central control panel with all controls Digital temperature display for both heating platens Press cycle counter Emergency safety cable Rack compensation gear Main switch Note - Used machines: • Technical data subject to errors and prior sale. • Quoted prices are ex works, loaded free of charge. • The machines have been cleaned and function-tested. • All machines are sold as seen, without any warranty or guarantee. Buyers are welcome to inspect machines at our premises. • Special agreements must be in writing. Nodpowd N Rmefx Aglskt (We only respond to enquiries that include your address & phone number!)

Kondisi: bekas, Tahun pembuatan: 2004, nomor mesin/kendaraan: P 04-09-002, neu U05 10 001, Automatic Spray Machine Venjakob HGS-K Nedpfx Ageumvr Tolskt All images are sample images only. - Manufacturer: Venjakob - Year of manufacture: 2004 - Working width: 800 mm (expandable to 1000 mm) - Current condition: not refurbished - Offer price refers to refurbished condition - Operator side: right - Dual-drive system for gun carriage - Dry extraction: 4,000 m³/h - Extraction port diameter: 400 mm - Conveyor belt transport system - Feed speed continuously adjustable from 3 to 8 m/min - With paint recovery system - Gun control: LS 1 - Installed paint circuits: 1 pc - Airless spray system: 4 units Krautzberger KAA 1300 - Number of paint pumps: 1 pc - Pump manufacturer: Wagner 35-70 - Suitable for solvent-based paints - Suitable for water-based paints - Total connected load: 7 kW, current consumption: 17 A, fuse protection: 35 A - Location: in stock - Voltage fluctuation tolerance max. +/- 5% _____ Optionally, we can also provide you with a quote for the assembly and commissioning of the system, as well as training for your staff. On request, we also offer regular maintenance and servicing of the machine. For further information, please contact us!

Kondisi: sangat baik (bekas), BRIDGE LOADER with DOUBLE LOADING STATION Nksdpfx Ajd Rg Dpjglst Vacuum system (with its own pump) No. 4 vertical support columns for the upper crossbeam No. 1 upper horizontal crossbeam (for the movement of the motorized trolley) No. 1 motorized trolley, to which horizontal arms are connected No. 2 horizontal metal arms with adjustable vacuum suction cups No. 2 floor rollers for feeding panel stacks into the Loader No. 1 motorized roller table that feeds panels to the Unloader, also equipped with several crosswise motorized conveyor belts (at 90°). Approx. dimensions: 7232 mm. Separate electrical and control panel OMRON electronic control Perimeter safety and protection metal fences Working capacity (cycles/minute): approx. 16 - 20 Min./max. panel thickness: approx. 10 – 50 mm Minimum panel size: approx. 250 x 320 mm Maximum panel size: approx. 1200 x 3200 mm Installed power: 23.3 kW

Tahun pembuatan: 2013, Kondisi: bekas, KUKA industrial robot with 6 articulated axes featuring point-to-point positioning. Independent control panel Panel alignment table Bar code scanner mounted on the robot arm Panel feed system comprising: * 1 motorized roller conveyor for pre-loading the sheet stack * 1 motorized roller conveyor * 1 motorized roller conveyor for unloading the sheet stacks Nsdor Am Sqepfx Agljkt Technical specifications: * Model: KR210-2 * Number of axes: 6 * Permissible rated load: 210 kg * Machine weight: 1,267 kg * Sound level: 75 dB * Installed power: 25.8 kW * Panel dimensions – Min./Max. length: 300/3,000 mm * Panel dimensions – Min./Max. width: 180/1,500 mm * Panel dimensions – Min./Max. thickness: 8/60 mm * Max. panel weight: 90 kg

Kondisi: sangat baik (bekas), Tahun pembuatan: 2011, jam operasional: 216 h, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 20MS090000/007, panjang total: 3.000 mm, jenis arus masuk: AC (pendingin udara), lebar total: 2.500 mm, tinggi total: 1.900 mm, berat keseluruhan: 1.450 kg, berat kosong: 1.450 kg, lebar kerja: 900 mm, sambungan udara terkompresi: 6 batang, kecepatan throughput: 50 mm/dtk, Laminating and longitudinal splicing machine For veneer thicknesses from 0.4 to 3 mm with direct gluing. With edge pre-gluing up to 5 mm. Machine with very low usage, Nedpew E Rfbjfx Aglokt Available ex site. Electric motor, separate for chain drive and glue application. Glue is applied to the edge of the newly inserted veneer strip, which increases the bond strength. Robust, durable stainless steel feed chain with pivot joints. Separate adjustment for temperature, speed, and pressure. Quick and easily accessible glue trough for fast and easy refilling or cleaning. Multiple heating zones for individual temperature settings. Extended glue trough life due to integrated cooling unit. Continuously adjustable feed speed. INCLUDES GLUE COOLER Technical Data: Throat depth: 900 mm Veneer strip width min.: 45 mm Veneer strip length min.: 300 mm Veneer strip thickness: 0.4 – 3.0 mm (up to 5 mm) Veneer moisture content: max. 8 – 12 % Working height: 900 mm Feed speed: 5 – 50 m/min Heated section length: 1000 mm Max. heating temperature: 250 °C Electrical connection: 9.0 kW, 400 V, 50 Hz Compressed air: 6.0 bar Dimensions (L x W x H): 2400 x 2300 x 1900 mm Weight: 1500 kg

Kondisi: bekas, Tahun pembuatan: 1993, nomor mesin/kendaraan: 4610.17, - Produsen Bürkle - Tipe DAL 1-1300 R Nodpfjumvkvsx Aglokt - Tahun pembuatan sekitar 1990 - 1993 - Lebar kerja 1300 mm - Mesin akan diperbaiki, kemudian dalam kondisi sangat baik - Tinggi kerja 870 mm - Tinggi benda kerja 3 - 80 mm - Sisi pengoperasian di kanan - Rol aplikasi cat 50 Shore - Rol pengukur keras berlapis krom sekitar 174 mm - Silinder tekanan balasan dilapisi karet - Transportasi dengan sabuk - Panjang 1050 mm - Kecepatan maju dapat diatur dengan handwheel 6 - 30 m/menit - Total daya terpasang sekitar 2 kW - Berat 3250 kg - Dengan panel kontrol - Volt, Hz 400 / 50 - Nomor mesin 4610.17 - Nomor barang 8479 8997 - Fluktuasi tegangan max. +/- 5 % - Gambar hanya sebagai contoh

Kondisi: sangat baik (bekas), Tahun pembuatan: 2020, HOMAG Centateq N-500 -BHP 100 / VANTAGE 710 #0-250-71-6275 -Tahun pembuatan: 2020 -Ukuran meja: 3100 x 2250 mm Nksdpfxjxfkdze Agljt -Sistem penahan: depan kanan, depan kiri, belakang -2x sistem vakum 580/690 m3/h -Spindel alat 10kW, pendingin udara -Antarmuka agregat untuk spindel utama, sumbu C -Majalah penukar alat, belakang, tetap -Unit milling dengan cincin sensor

Kondisi: hampir baru (bekas), Fungsionalitas: berfungsi sepenuhnya, panjang pemotongan (maks.): 3.100 mm, tinggi potong dengan pisau scoring (maks.): 70 mm, diameter mata gergaji: 305 mm, kecepatan pemakanan sumbu X: 40 m/menit, laju pemakanan sumbu Z: 50 m/menit, panjang total: 3.100 mm, lebar total: 3.100 mm, berat keseluruhan: 3.000 kg, daya: 7 kW (9,52 hp), persyaratan ruang panjang: 3.100 mm, lebar yang dibutuhkan: 3.100 mm, Perlengkapan: doser, kecepatan rotasi dapat diubah tanpa batas, SCHEER PA 4136 Panel Dividing System – 3100 x 3100 The PA 4136 is a high-performance, electronically controlled panel saw designed for precise, efficient, and automated cutting of wood-based materials. It is ideally suited for industrial use in joineries, furniture production, and panel processing plants. Condition & Service: Condition: Very good Functionality: Fully operational Warranty: 12 months CE-compliant and dust tested (limit value < 2 mg/m³) Key Technical Data & Features: - Longitudinal saw FM 20-3100 with hardened guides - Automatic forward & return movement of the saw unit (return lowers automatically) - Feed drive via three-phase gear motor, frequency inverter-controlled - Feed speed: 2 – 40 m/min (stepless) - Return speed (rapid traverse): 50 m/min - Extraction ducts in machine base & pressure beam - Scoring saw blade adjustable from outside (without opening hood) - Safety hood interlock with lamellar curtain SZ 5008 - 3-stage cutting height adjustment LA 4143 - 6 cut-outs in the pressure beam for remnant cuts up to 5 mm - Saw motor: 7.0 kW | Scoring motor: 1.1 kW (can be switched off) - Cutting length: 3100 mm | Cutting height: 70 mm Material Handling & Feed: - Angle pressure device WP 5003 with pressure claw for cross cuts - Adjustment range: 2400 mm - Fully automatic control via DNC-AT - Material feed table HP 5091 Nedpfxewrn Efs Aglskt - 2 overhead guides, rack and pinion guide - Servo drive for material pusher - Feed speed: 25 m/min (safety-limited) - Return speed: 40 m/min - 6 clamping fingers, 4 double roller tracks - Table length: 3100 mm | Fence depth: 3150 mm - Closed pertinax surface in the angle stop area Control & Operation: - Operating system: Ubuntu Linux - Integrated PC with hard disk, parallel & serial interface - Network capable (LAN/WLAN), remote maintenance via Internet (TeamViewer, Remote Desktop) - USB print function - Multilingual dialog programming - 15" flat screen, multifunction keyboard on pivoting control panel - Graphical display of cutting patterns and workflows Software / Programs: - OPTIMAX: Office optimization, offcut calculation, material requirement - OPTIMIN: Direct optimization on the machine PC with parts list input - Processing via USB, diskette, or online (optional) - Manual, automatic & special operating modes (e.g., grooving, veneered parts) Additional Equipment: - Angle stop table HP 5085: 1,720 x 800 mm | pertinax surface - Workpiece support table HP 5025: 1,720 x 800 mm | pertinax surface - Air cushion system LK 5030 integrated in both tables - Circular saw blade KSB 4005: Ø 305 mm, Z = 60 - Circular saw blade KSB 4006: Ø 200 mm, Z = 60, conical Reliability for Continuous Operation: This machine is in use worldwide – even under extreme conditions. Whether in the dry climate of Africa or high humidity in Southeast Asia (e.g., Thailand): The PA 4136 runs reliably in 3-shift operations – 365 days a year – and stands out for its exceptional stability and endurance. Guarantee: We are so convinced of the quality and stability of our machines that we offer a 7-year warranty on the machine construction and guide rails. (Excludes electrical supply parts and wearing parts.) 📞 Contact us for an individual offer or to arrange a viewing appointment. Machine available from stock. Delivery, commissioning, and training available as options.
