Mesin Pembubut Horisontal

DMG Mori Seiki NLX2500Y 700

Kondisi: bekas, Tahun pembuatan: 2006, Fungsionalitas: berfungsi sepenuhnya, panjang pembubutan: 780 mm, diameter pembubutan: 270 mm, daya motor spindle: 15 W, jarak pergerakan sumbu X: 195 mm, jarak lintasan sumbu Y: 120 mm, jarak gerak sumbu Z: 780 mm, CNC Lathe Nakamura-Tome WT-300 Year of manufacture: 2006 CNC Control: FANUC Series 18i-TB Machine weight: 12,000 kg Machine dimensions: Length: 5,230 mm Width: 2,500 mm Height: 2,300 mm Machining capacity: Max swing diameter over upper/lower carriage: Ø 310 mm (both upper and lower) Distance between spindles (min - max): 120 mm – 1,200 mm Max turning diameter main spindle / sub-spindle: Ø 270 mm Max turning length: 780 mm Spindle / sub-spindle bar capacity: Ø 65 mm Axis travels: X1 / X2 axis: 195 mm Y axis: 120 mm (±60 mm) Z1 / Z2 axis: 780 mm B axis: 850 mm C axis: 360° (continuous) Main spindle and sub-spindle: Rotational speed: 50 – 4,500 rpm Dcjdpswx Hicefx Aaror Spindle nose: ASA A2-6 Chuck diameter: Ø 225 mm Minimum controlled C axis angle: 0.001° Spindle motor power (cont. 30 min): 11/15 kW (both spindles) Turret No. 1 and No. 2 (identical): Static / live tool stations: 24 stations (12 live) Live tool speed: 3,600 rpm Live tool motor power: 3.7 / 5.5 kW Turning / boring tool size: 25×25 mm / Ø 32 mm Rapid traverses: X1 / X2 / Y axis: 16,000 mm/min Z1 / Z2 axis: 24,000 mm/min B axis: 36,000 mm/min C axis: 100 rpm B axis: 27,000 mm/min Included accessories: LNS bar feeder model MOVE (length capacity 2,300 mm) Chip conveyor Coolant collection tank with wash pump High-pressure pump with external coolant tank Various fixed and live tool holders Tool presetter arm with double RENISHAW head fitting Parts discharge arm Manuals, electrical diagrams, and CE Declaration

Tahun pembuatan: 2007, Kondisi: siap digunakan (bekas), - BEKAS - MESIN BUBUT CNC 8-SUMBU DENGAN KEPALA MILLING, KEPALA TURRET BAWAH, DAN COUNTER SPINDLE DIAMETER PUTAR MAKSIMAL: 660 mm PANJANG PEMBUBUTAN MAKSIMAL: 1495 mm DIAMETER PEMBUBUTAN MAKSIMAL: 660 mm KAPASITAS BATANG: 65 - 65 mm SPINDLE: 35–5000 rpm; 22 kW; 254 mm COUNTER SPINDLE: 35–5000 rpm; 18,5 kW; 254 mm KEPALA: CAPTO C6; -30°+195°; 15–12.000 rpm; 18,5 kW JARAK GERAK SUMBU X: 580 mm JARAK GERAK SUMBU X2: 150 mm JARAK GERAK SUMBU Y: 160 mm JARAK GERAK SUMBU Z: 1545 mm JARAK GERAK SUMBU Z2: 1490 mm JARAK GERAK SUMBU B: 1550 mm PERGERAKAN CEPAT X-Y-Z: 38 - 26 - 38 m/menit KEPALA TURRET BAWAH: 9 POSISI MAJELAS ALAT: TIPE RANTAI; 80 POSISI COOLANT TEKANAN TINGGI: 18 Bar UNIT KONTROL: MAZATROL MATRIX BERAT: 11.800 kg Dcjdpfjw Ey R Hjx Aarer DIMENSI TOTAL: 5.090 x 3.270 x 2.830 mm AKSESORIS: KONVEYOR SERPIHAN; FILTER KERTAS; SETTER ALAT

Kondisi: sangat baik (bekas), CNC otomatis pemotong panjang Merek: STAR Tipe: SR-38B Tahun pembuatan: 2016 dengan: Kontrol FANUC 31i - B Spindel sinkron Pemrosesan sisi belakang Alat bertenaga 2x sumbu C Sumbu B yang dapat diprogram Sumbu Y2 Sumbu X3 Pompa tekanan tinggi Dedpfjxl Etqox Aarecr Ekstraksi kabut oli Konveyor bagian Konveyor serpihan Sistem pemadam kebakaran Majalah pengumpan batang FMB TURBO 5-55

Kondisi: baru, Wir verfügen über verschiedene elektronische Komponenten für DMG-Maschinen sowie Teile von BOSCH, Siemens und weiteren Herstellern. Auf Anfrage sende ich Ihnen gerne detaillierte Fotos aller verfügbaren Teile. Dodpfxsddxv Uo Aarocr

Kondisi: hampir baru (bekas), Tahun pembuatan: 2012, jam operasional: 23.252 h, jarak pergerakan sumbu X: 735 mm, jarak lintasan sumbu Y: 650 mm, jarak gerak sumbu Z: 560 mm, produsen pengendali: 3D-Control Siemens 840D, diameter benda kerja (maks.): 840 mm, berat benda kerja (maks.): 600 kg, tinggi total: 2.897 mm, panjang total: 3.567 mm, lebar total: 2.615 mm, lebar meja: 650 mm, panjang meja: 650 mm, berat keseluruhan: 12.100 kg, kecepatan spindel (min.): 18.000 rpm, panjang alat: 315 mm, berat alat: 8.000 g, Year of manufacture: 2012 CNC Control: 3D Control Siemens 840D Axes Travel X-axis mm: 735 Travel Y-axis mm: 650 Travel Z-axis mm: 560 C-axis indexing degrees: 360º (0.001) A-axis indexing degrees: ±120 (0.001) Feed rates m/min: 40 Rapid traverse m/min: 40 Axis acceleration m/s²: 6 NC milling/turning table: Number of pallets: 1 Pallet dimensions mm: Ø650 Max. workpiece size (D x H) mm: Ø840 x 500 Max. workpiece weight kg: 600 Spindle Max. spindle speed rpm: 18,000 Dcodpexrr I Iefx Aarer Spindle drive power kW: 13/9 (40%ED/cont) Cooling Coolant supply through the spindle bar: 40 Tank capacity liters: 600 Tool system Tool holder: SK 40 Number of tools in magazine: 30 Tool changer type: Double gripper With free adjacent positions mm: 160 Max. tool length mm: 315 Max. tool weight kg: 8 Chip-to-chip time sec.: 4.9 Equipment Electronic handwheel Chip conveyor Fixed table with integrated rotary table Infrared probe Internal coolant supply Rinsing gun Paper band filter Machine operating hours: Power-on hours: 23,252 Spindle hours: 6,497 Basic machine: Dimensions / Weight Length mm: 3,567 Width mm: 2,615 Height mm: 2,897 Weight kg: 12,100

Kondisi: bekas, TECHNICAL DATA - Number of axes: 5 MILLING SPINDLE - Tool holder: SK 40 - Spindle drive power: 12 [kW] - Spindle speed: 12,000 [rpm] LINEAR AXES - Travel X/Y/Z axes: 510 x 510 x 460 [mm] SWIVEL AXIS A - Travel: [degrees] - Minimum resolution: 0.001 [degrees] SWIVEL AXIS B - Travel: 360 [degrees] - Minimum resolution: 0.001 [degrees] TOOL CHANGER - Tool changer type: Bras chargeur - Number of tools in magazine: 40 TABLE - Table size: 400 x 400 [mm] - Max. table load: 300 [kg] - Max. machinable diameter: 500 [mm] - Max. machinable height: 405 [mm] Dcedsuhbr Hjpfx Aaror PALLET CHANGER - Pallet size: 400 x 400 [mm] - Number of pallets: 2 ELECTRICAL SUPPLY - Supply voltage: 400 [V] - Total connected load: 50 [kVA] WEIGHT AND DIMENSIONS - Machine weight: 11,500 [kg] MACHINE HOURS - Operating hours: 32,763 [h] EQUIPMENT - Control: Mazatrol PC-Fusion 640 - Teach-in programming - Interfaces: RS232/RJ45/PCMCIA - Synchronized tapping - Coolant tank * with high-pressure pump: 15 [bar] - Through-spindle coolant supply (IKZ) - Spindle cooling - Chip conveyor: MAYFRAN - Tool measurement probe system

Kondisi: sangat baik (bekas), Tahun pembuatan: 2006, jam operasional: 10.000 h, Fungsionalitas: berfungsi sepenuhnya, PENAMBAHAN BARU 1 MESIN FRAIS CNC HERMLE C 600V TAHUN 2006 KONTROL CNC HEIDENHAIN ITNC 530 JARAK GERAK 600 x 450 x 450 mm - KECEPATAN PUTAR SPINDEL TANPA TAHAPAN HINGGA 10.000 RPM - MESIN DENGAN HANDWHEEL ELEKTRONIK - PROBE PENGUKUR - SEKITAR 30 HOLDER TOOL - SISTEM PENDINGIN - MEJA TETAP, DLL. HARGA ATAS PERMINTAAN + 19% PPN, ex lokasi, tanpa kemasan, tanpa asuransi. Data teknis sesuai dokumen terlampir, tidak mengikat - kesalahan dan penjualan sebelumnya dapat terjadi. Waktu pengiriman: segera - dapat dijual sebelumnya. Pembayaran: segera setelah penerimaan faktur, bersih - sebelum pengambilan. Dengan senang hati kami akan mendemonstrasikan mesin di bawah daya dan semua fungsinya atas permintaan. Dsdpfxexf Huvo Aarscr

Kondisi: bekas, Tahun pembuatan: 2007, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 0506, Kontrol FANUC 18i-TB Diameter batang maks.: 32 mm Maks. langkah spindle headstock: 310 mm Kecepatan putar spindle: 350 - 7.000 rpm Diameter batang maks. spindle belakang: 32 mm Kecepatan putar maks. spindle belakang: 350 - 7.000 rpm Jumlah alat yang dapat digunakan: 21 Pemegang pisau bubut multi-cutting: 6 Alat penggerak untuk pemesinan silang: 3 Alat bor sisi depan: 4 Alat bor sisi belakang: 4 Pemrosesan sisi belakang: 4 Kecepatan putar alat penggerak: 5.000 rpm Dcjdpfx Aaoxgnvdersr Barfeeder FMB turbo 3-36

Kondisi: sangat baik (bekas), Tahun pembuatan: 2004, Maier ML 26 E CNC Lathe TECHNICAL DATA Number of axes: 11 Spindle bore: 32 mm Travel speed: 32 m/min Control system: Maier Pro GE-Fanuc Guide bushing: 451.001 Main Spindle Passage: 26 mm C-axis: Yes Mechanical indexing 5°: Yes Spindle stroke: 220 mm Main spindle, speed: 0 – 6000 rpm Power: 3.7 kW / 5.5 kW (7.5 kW) Collet: 161E Sub Spindle Passage: 26 mm C-axis: Yes Mechanical indexing 5°: Yes Max. Travel (Z): 220 mm Sub spindle, speed: 0 – 6000 rpm Main spindle, power: 1.1 kW Collet: 161E Cross Machining Basic holders for bar stock 5 pcs. 16 x 16: Yes Number of driven tools: 4 Power of driven tools: 0.5 kW Backworking Drive power: 0.5 kW Number of tools: 4 of which driven: 4 Collets: ER16 Tool Turret Number of tools: 16 Dcjdsu S Rivopfx Aaror Number of driven tools: 8 Drive power: 0.5 kW C-axis: 360 ° Z-axis: 175 mm X-axis: 200 mm Collets: ER16 SCOPE OF DELIVERY Includes (not an exhaustive list): Maier ML 26 E CNC Lathe Oil mist separator Transformer Chip conveyor High-pressure pump / belt filter system Fire suppression system LNS bar feeder Complete operating documentation Exact scope of delivery according to photo documentation. No guarantee is given for the correctness, completeness, or currentness of the information provided.

Kondisi: bekas, Tahun pembuatan: 2017, diameter pembubutan: 658 mm, produsen pengendali: MAZATROL, model controller: SMOOTH X, jumlah spindel: 2, CONTROL .. CNC Control: MAZATROL SMOOTH X FUNCTIONALITY .. Number of spindles: 2 .. Number of turrets: 1 TURNING WORK AREA Dedpfxsxu Ufzj Aarscr .. Maximum turning diameter: 658 mm .. Maximum bar work clamping diameter: 80 mm .. Maximum workpiece length: 1519 mm MAIN SPINDLE .. Speed range up to: 4000 rpm .. Drive power: 30 kW .. C-axis: yes SUB SPINDLE .. Speed range up to: 4000 rpm .. Drive power: 26 kW .. C-axis: yes CROSS SLIDE .. Z-axis travel: 1585 mm .. X-axis travel: 615 mm .. Y-axis travel: 250 mm .. B-axis swivel range up to: 210° .. Rapid traverse Z: 50,000 mm/min .. Rapid traverse X: 50,000 mm/min .. Rapid traverse Y: 40,000 mm/min CROSS SLIDE .. B-axis swivel range up to: 0.0001° .. - Speed range up to: 12,000 rpm .. - Drive power: 24 kW TOOL MAGAZINE .. Number of tool positions: 72 .. Maximum tool diameter: 90 mm .. - with free adjacent position: 125 mm .. Maximum tool length: 400 mm .. Maximum tool weight: 12 kg DIMENSIONS / WEIGHT .. Space requirement -left/right-: 4910 mm .. Space requirement -front/back-: 2800 mm .. Overall height: 2720 mm .. Total weight approx.: 16,900 kg ADDITIONAL TURNING EQUIPMENT .. Hydraulic unit: yes .. CE compliant: yes
