Beli Mesin Uji Gigi Bevel bekas (79.503)

Kondisi: siap digunakan (bekas), Tahun pembuatan: 1979, Fungsionalitas: berfungsi sepenuhnya, Diameter roda gigi maksimum: 330 mm Modul maksimum: 6 Lebar roda: 180 mm Modul minimum: 0,5 Rsdpfx Aaozh H R Ne Isw Berat mesin: 5500 kg Aksesori tersedia, lihat pada foto

Kondisi: siap digunakan (bekas), Fungsionalitas: berfungsi sepenuhnya, Mesin Frais Roda Gigi Modul roda gigi terbesar: 8 mm Diameter roda gigi terbesar: 500 mm Lebar velg maksimum: 100 mm Jarak lintasan spindel: 150 mm Jarak lintasan spindel maksimum: 125 mm Diameter flange spindel produk atau meja kerja: 560 mm Rjdozhwa Uspfx Aa Ijw Lubang dasar di meja atau flange spindel produk: 110 mm Jumlah pukulan ganda: 18 Rentang perubahan siklus ganda: 55-560/menit Rentang langkah keliling: 6-590 mm/menit Rentang umpan radial: 0,02–0,2 mm/detik Jarak antara bidang bawah (tanah) dan permukaan kerja meja: 920 mm Jarak maksimum antara permukaan meja dan permukaan spindel alat: 270 mm Jarak minimum antara permukaan meja dan permukaan spindel alat: 120 mm Jarak maksimum antara sumbu meja dan sumbu alat: 355 mm Jarak minimum antara sumbu meja dan sumbu alat: 0 mm Nilai limbus dan nonius untuk pengaturan jarak produk dan alat: 0,01 mm Retraksi otomatis meja Gerakan meja relatif terhadap sumbu alat: 355 mm Kecepatan gerak cepat meja: 1,5 m/menit Kecepatan rotasi meja berkecepatan tinggi: 4,5 rpm Kedalaman bor: 25 mm Pergeseran alat pada kecepatan idle: 0,5 mm Jumlah perbandingan posisi saat pergeseran alat pada sudut: ± 20 mm Jumlah motor: 6 Daya motor penggerak utama: 4/4,5/7,5 kW Daya motor penggerak hidrolik: 2,2 kW Daya motor akselerator rotasi meja: 0,75 kW Daya motor pompa pendingin: 0,6 kW Daya motor pompa pelumas: 0,25 kW Daya suplai motor periferi: 2,4 kW Dimensi (P x L x T): 1975 x 1690 x 2510 mm Catu daya: 3x 380 V; 50 Hz Berat mesin: 7500 kg

Kondisi: bekas, Tahun pembuatan: 2009, produsen pengendali: Siemens, model controller: 840 D, Deskripsi: Umum: Tahun pembuatan: 2009 Kontrol: Siemens 840 D Diameter gigi luar: 1.200 mm Diameter gigi dalam: 1.200 mm Lebar gigi maksimum: 260 mm Rsdpszdxi Nefx Aa Isw Diameter benda kerja maksimum: 1.500 mm Rangka Mesin: Jarak lintasan: 600 mm Penyesuaian samping: +/- 60 mm Kepala stang: Diameter poros stang: 125 mm Konektor alat: SK 45 Jarak poros stang ke meja: 0 - 820 mm Panjang stroke: 270 mm Modul maksimum: 16 mm Diameter alat maksimum: 300 mm Kecepatan putar maksimum kepala potong: 25 rpm Meja: Diameter meja: 900 mm Lubang meja: 320 mm Kedalaman lubang: 520 mm Kecepatan putar maksimum: 12 rpm Beban maksimum meja: 95 kN Perlengkapan / Aksesori: Pembuangan serpihan: 2x conveyor sabuk magnetik Pasokan cairan pendingin: Sistem oli pemotong dengan filter dan kontrol suhu Mode pengaturan: Handwheel elektronik

Kondisi: sangat baik (bekas), Tahun pembuatan: 1991, Diameter roda – maks. 10 – 330 mm Lebar roda 180 mm Modul – maks. 7 Modul – min. 0,5 Panjang penjepitan 420 mm Redpfx Aezd Hgiea Ijw Jumlah gigi 10 – 600 Sudut heliks – maks. +/- 45° Kecepatan putar 1100 – 1900 rpm Diameter batu gerinda 280 – 350 mm Lebar batu gerinda 84 – 104 mm Berat mesin sekitar 5,1 t Kebutuhan ruang sekitar 4,5 x 6,0 x 2,3 m

Kondisi: baik (bekas), jenis bahan bakar: diesel, Tahun pembuatan: 2005, Daf LF 220 4X2 Pengangkut Mesin / Truk Oprij 2005 - DKM - APK 6-2027 - Euro 3 Dimensi Bak Muatan: Panjang: 620cm Lebar: 235cm Tinggi lantai muatan: Kapasitas muatan: 5740KG Video dapat dikirim melalui Whatsapp. Stok terus tersedia, lihat website. Harga ex-Nuland. Van de Wert Trading B.V. memiliki stok mesin, truk, trailer, dan attachment yang bervariasi. Semua pengiriman kami dengan harga dagang dalam kondisi apa adanya (AS-IS), tanpa jaminan (lihat syarat dan ketentuan umum kami). Untuk melihat unit dan/atau test drive, Anda dapat membuat janji temu tanpa kewajiban. Silakan hubungi terlebih dahulu karena kami tidak selalu berada di tempat. Van de Wert Trading B.V. Bedrijfsstraat 3 Redezhk U Ejpfx Aa Isw 5391 LR Nuland

Kondisi: sangat baik (bekas), Tahun pembuatan: 2024, jam operasional: 12.675 h, Fungsionalitas: berfungsi sepenuhnya, Dijual empat unit mesin pemesinan gigi gerinda identik merk KAPP. KAPP NILES KX 260 TWIN Tipe mesin: Pusat gerinda gigi CNC / Mesin gerinda presisi dan gerinda gear Produsen: KAPP NILES GmbH & Co. KG Jumlah mesin yang dijual: 4 unit Alamat pada plat nama: Callenberger Straße 52, 96450 Coburg, Jerman Model: KX 260 TWIN OEM No. Mesin: XXX Tahun produksi: 2024 No. inventaris PPS: XXX Kontrol: Siemens SINUMERIK Konsep mesin: TWIN / Konsep dua spindle dengan meja putar Proses pengerjaan: Gerinda gigi terus-menerus, opsional gerinda profil Konsep otomatisasi: Pengisian otomatis, sel robot / FANUC loader terlihat Robot: FANUC Robot M-710iC/45M terlihat Kondisi: Mesin dalam keadaan ON / layar aktif / tampilan sangat modern dan bersih secara keseluruhan Kapasitas mesin KAPP NILES KX 260 TWIN: - Diameter puncak roda maksimum: 260 mm - Panjang benda kerja maksimum: 770 mm - Rentang modul: 0,5 – 6 mm - Lebar gigi maksimum: 320 mm, dengan opsi hingga 520 mm - Sudut heliks maksimum: ±45° Data ini sesuai dengan seri KAPP-NILES-KX-TWIN; KAPP NILES mendeskripsikan KX 260 TWIN sebagai mesin untuk gerinda gigi terus-menerus dengan alat dapat dan tidak dapat didandani, serta menyebutkan batas ini untuk model KX 260 TWIN. Konsep teknik mesin: Seri KX TWIN dirancang KAPP NILES untuk volume produksi tinggi di produksi massal dan menengah pada roda gigi dan poros. Konsepnya meliputi dua spindle benda kerja identik yang terletak berlawanan pada meja putar. Saat satu benda kerja diproses, pada spindle kedua dapat dilakukan pengisian dan pengeluaran secara paralel serta penyetelan. Rsdpfx Aaozdv Shj Isw Perlengkapan/keunggulan yang terlihat: - Kontrol CNC Siemens SINUMERIK - Antarmuka pengoperasian KAPP NILES - Konsep spindle ganda / dua spindle benda kerja - Meja putar / meja indeks - Sel pengisian otomatis - Robot FANUC M-710iC/45M - Gripper robot / gripper penanganan terlihat - Rumah pelindung / sel keamanan - Dudukan roda gerinda / area spindle gerinda terlihat - Area gerinda profil/wälz jelas terlihat - Area pendingin/minyak gerinda - Pencahayaan ruang kerja - Kabin pelindung penuh - Remote kontrol manual / roda tangan elektronik pada panel kontrol - Lampu sinyal/indikator - Tanda CE pada badan mesin terlihat - Tempat dokumen/berkas mesin di mesin terlihat Data listrik sesuai nama mesin: Tegangan utama: 400 V AC Frekuensi: 50 Hz Tegangan daya utama: 400 V AC Tegangan kontrol: 24 V DC Pencahayaan: 22 W / 230 V Daya terpasang: 110 kVA Arus nominal: 79 A cos φ: 0,64 Sekering: 100 A gL Berat lemari kontrol: 1.000 kg Jam operasi sesuai counter pada foto: T1 Waktu operasi total: sekitar 12.675 jam T2 Waktu siklus kerja: sekitar 5.538 jam Foto dan video tambahan tersedia atas permintaan.

Kondisi: sangat baik (bekas), We are offering you a Zwick / Roell universal testing machine (tabletop tensile testing machine). Rjdpfxezdr Hns Aa Ijw Zwick / Roell materials testing machine Model: BDO-FB0.5TH - Load testing in tensile/compression direction: 500 N - Height: 1565 mm, Width: 292 mm, Depth: 469 mm - Test area width: unlimited - Test area depth: 100 mm - Max travel without accessories: 1266 mm - PC or printer interface: RS 232 - Required PC connection for operation: COM 1 - Power supply: 115/230 V (PH, N, PE) - Rated power: 0.4 kVA - Mains frequency: 50/60 Hz - Weight: 47 kg - Type: BDO-FB0.5TH - Condition: used - Scope of delivery: (see picture) (Technical specifications subject to change and errors excepted!) We are happy to answer further questions by phone.

Kondisi: sangat baik (bekas), Zwick Type: BZ2.5/TN1S Zwick Tabletop Testing Machine for Tensile Strength Measurement Application Range: Wide range of applications, from the testing of plastics and elastomers, to paper, textiles, foam, wire, and component testing. Load Frame: Maximum test force FN in tension/compression: 2.5 kN Height (h1): approx. 770 mm Width with electronics unit: 320 mm Depth with electronics unit: 414 mm Workspace height h min ... h max: Crosshead bracket mounted facing upwards: 227 ... 573 mm Crosshead bracket mounted rotated by 180°: 57 ... 403 mm (each without connecting bolts) Rjdpfx Aezdry Ija Iew Connections: Electrical connection: 115/230 V 4/2A-1PH/PE/N Power consumption: 0.4 kVA Mains frequency: 50/60 Hz 2.5 kN Condition: used Scope of delivery: (see picture) (Specifications and technical details subject to change; errors and omissions excepted!) We are happy to answer further questions by phone.

Kondisi: baik (bekas), Zwick Type: BZ1.0 / TH1S Zwick Tabletop Testing Machines Zwick with a maximum force of 1.0 kN. Rsdpfx Ajzdryzea Iew Traverse travel: 1150 mm. Test speed: 0.1 ... 1800 mm/min Scope of delivery: (see images) (Subject to changes and errors in the technical data and specifications!) If you have further questions, please do not hesitate to contact us by phone.

Kondisi: baik (bekas), Tahun pembuatan: 1990, DIJUAL: Mesin Pembuat dan Pemotong Gigi CNC LIEBHERR WSC 501 Mesin pembentuk vertikal dengan pahat gear (Shaping / Mortising) presisi tinggi, ideal untuk produksi roda gigi dalam dan luar. Mesin kokoh, dapat dicoba dalam kondisi operasi di bengkel. Rsdpfx Aaozd Rdxj Iow 📌 Gambaran Umum Merek: LIEBHERR Model: WSC 501 Tahun Pembuatan: 1990 Teknologi: Kontrol Numerik (CNC asli Liebherr) Kapasitas pemrosesan: Gigi bagian dalam dan luar (innen + aussen) Kondisi: Sangat baik, komputer dan siklus otomatis berjalan 100%. 📊 Spesifikasi Teknis & Dimensi Mesin Parameter / Kapasitas Nilai Standar Pabrik Diameter nominal maksimum benda kerja Ø 500 mm Modul maksimum 8 mm Langkah maksimal luncur (Z) 200 mm Penyesuaian posisi langkah 200 mm Diameter maksimum pahat gear Ø 160 mm Diameter meja chuck Ø 550 mm Lubang tengah meja Ø 150 mm Jarak maksimum sumbu pahat / sumbu benda kerja (X) 350 mm Kecepatan osilasi maksimal Hingga 1.200 langkah/menit Berat mesin sekitar 9.500 kg

Kondisi: baik (bekas), Tahun pembuatan: 1990, DIJUAL: Mesin Pembuat Spline / Gear Shaping CNC LIEBHERR WSC 501-1 (Tahun 1990) Mesin shaping vertikal berperforma tinggi untuk pembuatan roda gigi, dirancang untuk machining presisi pada gigi dalam maupun luar secara intensif. Peralatan berat buatan Jerman, tersedia segera dan dapat diuji dalam kondisi terhubung listrik. 📌 Presentasi Umum Merek: LIEBHERR Model: WSC 501-1 Tahun Pembuatan: 1990 Tipe: Mesin Pembuat Spline Vertikal dengan Kontrol Numerik Teknologi: CNC original Liebherr Kapasitas Machining: Untuk roda gigi dalam maupun luar (innen + aussen) Rodpfxezd Rcbo Aa Isw Kondisi Teknis: Mesin terhubung listrik dan sedang beroperasi di bengkel. PLC, komputer, dan layar kontrol berfungsi optimal. 📊 Tabel Lengkap Kapasitas & Spesifikasi Parameter Teknis Kapasitas / Nilai Maksimum Diameter nominal maksimum benda kerja Ø 500 mm Modulo maksimum 8 mm Stroke maksimum slide (Sumbu Z) 200 mm Setting posisi stroke 200 mm Diameter maksimum tool shaping Ø 160 mm Diameter meja penjepit benda Ø 550 mm Lubang tengah meja Ø 150 mm Penyesuaian radial maksimum meja (Sumbu X) 350 mm Frekuensi maksimal osilasi Hingga 1.200 stroke / menit Berat total mesin ± 9.500 kg

Kondisi: bekas, Tahun pembuatan: 1999, Wheel diameter – max. 280 mm Wheel width 330 mm Module – max. 5 Module – min. 1 Control LIEBHERR CNC Total power requirement 28 kW Machine weight approx. 12 t Space requirement approx. m L I E B H E R R CNC-controlled Gear Hobbing and Profile Grinding Machine Type LCS 282 Year of manufacture 1999 # 1099 _____ Max. wheel diameter 280 mm Module 1 - 5 Helix angle +/- 35° Distance table center to tool center 15 – 285 mm Grinding slide vertical stroke 330 mm Shift path/tool travel 200 mm Min. number of teeth 7 Grinding spindle position above table min./max. 70 - 360 mm Workpiece clamping length 420 to max. 620 mm Grinding worm / profile grinding wheel Ø 145 x 210 / 175 mm Grinding worm/profile tool speed 2,500 – 10,000 rpm Max. table speed 750 rpm Spindle drive 28 kW Total drive approx. 50 kW - 400 V – 50 Hz Total weight approx. 12,000 kg Accessories / Special Equipment Rjdpfxst Hwu Aj Aa Iew • LIEBHERR CNC control Type LH 90 GG is an easy-to-program CNC control unit (B+R/IPC 5000) with gearing-specific operator interface and diagnostics functions for fast troubleshooting. (Remote diagnostics also possible) • Equipped with automatic threading device for inserting the grinding wheel into the tooth gap • The machine operates with three grinding methods: a. Generating grinding with CBN grinding worms = fastest processing b. Profile grinding with CBN profile grinding wheels (one or two wheels) = highest precision machining! c. Combination of a and b (most economical solution): pre-grinding with grinding worm / finish grinding with the profile grinding wheel in single part operation • Automatic shifting of the grinding worm or automatic positioning of the profile wheel • Automatic workpiece loading device with a ring loader mounted to the counter column, which automatically loads raw and finished parts. The workpieces are conveyed to the ring loader via a separate FLEX LINK chain conveyor, picked up and also removed. This enables unmanned operation. • Hydraulic workpiece clamping in the table, but without clamping fixtures. Tailstock carriage is present on the counter column, but without tailstock itself. Carriage stroke up to approx. 350 mm • Complete work area enclosure with sliding door and separate CO2 extinguishing system/IR sensor No original coolant system (since there is central supply), and no dresser available Condition : good to very good – demonstration ready under power, compact design! Delivery : ex stock - as inspected Payment : strictly net - after receipt of invoice We appreciate your interest – over 200 gear machines in stock at all times.

Kondisi: bekas, Tahun pembuatan: 1983, Workpiece diameter 250 mm Centre distance 0 mm Maximum honing length: --- mm Maximum module: 5 FÄSSLER (Switzerland) Conventional gear honing machine Model D - 250 Year of manufacture 1983 * Serial No. 31 205.049.22 _____ Gear diameter: 10 - 250 mm Module: 1 - 5 Gear length / Max. table stroke: 500 mm Centre height of tailstocks: 220 mm Max. workpiece weight: 50/100 kg Swivel range of the honing head: +/- 35° Honing tool speeds: 20 - 500 rpm Honing tool size / width: 300 / 40 mm Rjdjt Hwzpspfx Aa Iow Workpiece speeds: 500 - 3,000 rpm Total cross slide travel: 270 mm Cross slide rapid traverse: 50 mm Cross slide mechanical infeed: 1 - 8 mm/⌀ Roughing / finishing infeed: 1-29 / 0.2-2.8 μm/sec Table speed hydraulic: 0 - 6 m/min Total drive: 5.5 kW - 380 V - 50 Hz Weight: 3,200 kg Accessories / Special equipment: - Pre-settable machining parameters via counters and control switches for automatic operation, with workpiece counter - All roughing and finishing infeeds adjustable via decade switches, table reversal times adjustable via potentiometer, rapid infeeds adjustable by time (1s = 0.04mm) - Ampere display, etc. - Capability for crowning and taper honing via templates, also possible off-centre; workpiece must be pre-machined accordingly - Stand-alone honing oil system with magnetic separator and fine filter - Mechanical tailstocks for manual loading, oil mist separator - Sliding doors with foot switch, stand-alone hydraulics

Kondisi: bekas, Tahun pembuatan: 1992, Wheel diameter – max. 150 mm Wheel width: 300 mm Module – max.: 4.5 Module – min.: [not specified] Total power requirement: 20 kW Machine weight: approx. 6 t Floor space required: [not specified] CNC-controlled horizontal gear hobbing machine with workpiece portal loading system, Type A 35 / 36 CNC, year of manufacture 1992 Workpiece diameter / wheel diameter for automatic loading, max.: 150 mm Workpiece diameter for manual loading, max.: 200 mm Maximum workpiece length: approx. 400 mm Axial hobbing length (Z-axis): 300 mm Module range HSS/Carbide cutters: 3 / 4.5 mm Number of teeth, min./max.: 2-999 Distance between tool and workpiece, min./max.: 0 - 190 mm Maximum workpiece spindle speed: 0-350 rpm Swivel range of milling slide left/right: 50° / 60° Cutter size (diameter x length): 102 x 230 mm Cutter displacement max. (Y-axis): 100 mm Radial slide travel max. (X-axis): 10-150 mm Tailstock travel max. (W-axis): 420 mm Cutter speeds stepless: 0 - 1,500 rpm Feed rates all axes steplessly adjustable: 3.5 or 4 m/min Spindle drive approx.: 8.8 kW Total drive approx.: 20 kW - 220 V/400 V / 50 Hz Rsdpfx Ast Hwxbsa Iew Weight approx.: 6,000 kg Accessories / Special equipment: MIKRON CNC control type 788 (BWO) with monitor for up to 8 axes (ABC and WYZ and WV) with conversational programming for the creation of various gearing cycles, such as helical gearing, worm and worm gear cutting, crowned gearing, with and without shifting, as well as further sub-programs. Heavy-duty shifting milling head with high cutter speeds and a long shifting travel, suitable for 2 cutters, with quick-change system and hydraulic counter bearing. Workpiece spindle head (C) with quick-change system (collet chuck). Heavy-duty tailstock with travel 420 mm (W), in combination with an automatic workpiece loading unit, make GÜDEL-Switzerland, with linear portal loader, approx. 1000 mm stroke (V), double gripper with jaws for loading and unloading shaft-shaped workpieces (currently approx. 60 mm long x 25 mm Ø x module 1.5), but without workpiece storage system. Separate coolant unit with magnetic chip conveyor. Comprehensive full enclosure with sliding doors. 2 machines with workpiece marking unit, make BORRIES, unfortunately no other accessories.

Kondisi: bekas, Tahun pembuatan: 1995, Wheel diameter – max. 80 mm Wheel width 120 mm Module – max. 3 Module – min. 1 Control unit SIEMENS 840 C Total power requirement 30 kW Machine weight approx. 7,500 kg Space requirement approx. LIEBHERR CNC-controlled gear hobbing machine Model LC 82 Year of manufacture 1995 #0836 _____ Max. wheel diameter 80 mm Module 1–3 Helix angle +/- 45° Distance table center to tool center 15–160 mm Vertical hob carriage travel 250 mm Shifting distance/tool traverse path 180 mm Min. number of teeth 3! Cutter diameter x length approx. 90 x 200 mm Cutter speeds up to max. 800 rpm Redpfst Hw R Dsx Aa Ijw Feeds in axial/radial/tangential directions 20/4/5 mm/rev Max. workpiece clamping length 250 mm Spindle drive approx. 8 kW Total drive approx. 30 kW – 400 V – 50 Hz Total weight approx. 7,500 kg Equipment / Special features • SIEMENS CNC control type 840 C for 6 axes (i.e. hob drive/table drive/swivel angle of hob head/axial feed/radial feed/tangential feed), with gearing-specific operator interface and diagnostic functions for rapid troubleshooting. • With device for automatic threading of the hob into the tooth gap • Automatic shifting of the hob axis • Automatic component loading unit SSL = Rapid Swivel Loader using mechanical indexing gear and cam disk for quick loading times, with triple rotary gripper for loading blanks/processing position/unloading. Current workpiece size Ø 30 x 120 mm, helical gearing (pinion) • Workpiece feeding via plate chain conveyor (PKB) for workpiece transport with positive-fit workpiece carrier. Additional feed belt for raw and finished parts • Chip conveyor, complete work area enclosure, intermediate coolant tank with pump Complete enclosure of the workspace with sliding door and oil mist extraction, etc. The machine can also be used for dry gear cutting. Condition: satisfactory to good – under power, ready for demonstration, compact design! Delivery: ex stock – as inspected Payment: strictly net – upon receipt of invoice

Kondisi: bekas, Tahun pembuatan: 1985, Wheel diameter – max. 80 mm Wheel width 150 mm Module – max. 2.5 Module – min. Total power requirement 10 kW Machine weight approx. 2400 kg Fully automatic hobbing machines for worm gears Type A 33 / 1 Year of manufacture 1985 Serial No. 14.06/14.07/14.15 TECHNICAL DATA: Max. gear diameter without loading magazine approx. 80 mm Max. gear diameter with loading magazine approx. 50 mm Rjdpfxjt Hw D Ro Aa Iow Module max. 2 / 2.5 Axial milling length approx. 150 mm Max. workpiece installation length approx. 200 mm Milling slide swivels up to 90 degrees Cutter diameter 24 – 50/63 mm Max. radial travel of milling slide 0–14/18 mm Max. cutter shift 25 mm Cutter speeds 212 – 2,000 rpm Axial feed range, stepless 0.05 – 4.0 mm/rev Radial feed range, stepless 0.2 – 200 mm/min Milling spindle drive 3 kW Total drive approx. 10 kW – 50 Hz – 380 Volt Weight approx. 2,400 kg Accessories / Special equipment: Fully automatic workflow and minimal idle times thanks to freely programmable SIEMENS S5 PLC control for all processing steps such as rapid traverse, feed, cutter on/off, for the loading device, tailstock, optional shifting, etc., and with part counter, program numbering, and 30-stage numerical fault display. Pneumatic workpiece loading and unloading device aligned parallel to the workpiece axis for shaft-type parts approx. 140 mm long x 8 mm diameter, with pneumatic double gripper for feeding and removing workpieces; blanks are loaded externally in exchange cassettes and inserted into the loading unit. The double gripper places the parts between workpiece spindle and tailstock, the tailstock quill pushes the parts into the main spindle collet, clamping them simultaneously. Finished parts are ejected from the main spindle and returned by the gripper to the (finished parts) cassette. The entire process is electronically monitored and controlled. The entire loading device is enclosed in Plexiglas. Hydraulic workpiece clamping device with collets and hydraulic ejector Separate coolant system with magnetic separator * separate hydraulic unit * various change gears Condition: good – 3 machines available, currently 1 machine ready for demonstration (powered), Machine is set up for hobbing worm shafts/armature shafts used in variable transmission drives for vehicle seats, window winders, etc.

Kondisi: bekas, Tahun pembuatan: 1973, Wheel diameter - max. 400 mm Wheel width 75 mm Total power requirement 25 kW Machine weight approx. 7000 kg LORENZ High-Performance Gear Shaping Machine Model: LS 400 Year of manufacture: 1973 S/N: 11 884 ----- Max. external gear diameter: 400 mm* (possibly larger) Max. internal gear diameter: approx. 350 mm Max. wheel width: 75 mm Module range: 0.5-6 Stroke length: approx. 82 mm Adjustable stroke position: 0–80 mm Ram overhang (ram spindle/machine body): 250 mm Spindle taper: approx. MK 5 Strokes per minute roughing/finishing: 118–1,000 /min. Table size: 400 mm Table bore: 125 mm Mounting height between table and ram head min./max.: approx. 280/350 mm Fixed ram spindle overhang: 250 mm Table axial travel: approx. 295 mm Number of teeth: approx. 12–150/300 Rodpet Hw Hlsfx Aa Iew Feed range Tooth depth: 0.01–0.063 mm/stroke Rotary feed at tool diameter 125: 0.125–3.150 mm/stroke Spindle/main drive approx. 19 kW / 25 kW – 380 V – 50 Hz Weight: 7,000 kg Accessories / Special Equipment: • Built-in intermediate plate 200 mm for increased ram height, • Hydraulic workpiece clamping system (RINGSPANN make) integrated in the table for flat workpieces • Automatic stroke speed changeover and automatic feed changeover for roughing and finishing operations in up to 4 cuts • Separate control cabinet, separate hydraulic unit • Integrated coolant system with magnetic chip conveyor, two-hand actuation • Approx. 40 change gears, 4 shaper tool holders, 2 pulleys for stroke drive, etc. Condition: Good, under power - ready for demonstration Delivery: ex-stock - as inspected Payment: strictly net, upon receipt of invoice

Kondisi: bekas, Tahun pembuatan: 1969, Wheel diameter - max. 265 mm Wheel width 45 mm Module - max. 4 Module - min. 0.3 Workpiece diameter - max. 300 mm Stroke length max. 0-50 mm Stroke position adjustment 25 mm Distance spindle/clamping surface max. 170/245 mm Spindle taper internal MK 4 Table size 180 mm Table bore 95/75 mm Strokes per minute 450 - 840 Total power requirement 10 kW Machine weight approx. 5200 kg Space requirement approx. m max. gear Ø (outer) approx. 265 mm max. workpiece Ø for internal gearing 300 mm max. gear width 45 mm Module range 0.3 - 4 Stroke length 0 - 50 mm Stroke position adjustment 25 mm Distance table to spindle min./max. 170/245 mm Spindle internal taper (outer 90/50 inner) MK 4 Redpfx Aajt Hwruj Isw Table size 180 mm Table bore 95 / 75 mm Table traverse (cross) approx. 175 mm Stroke rate steplessly adjustable 450 - 840 strokes/min Feed range 0.09 - 0.6 mm/stroke Rotary feed 2722 - 681 strokes/cutter revolution Main drive 10 kW- 380 V -50 Hz Weight 5,200 kg Accessories / Special equipment * Selector switch for various operating programs and manual control * Multi-cut device for roughing/finishing/scoring * Hydraulic external clamping device mounted on table (for internal gearing - a type of collet chuck) * Separate control cabinet and separate hydraulics * Hydrostatic linear guide with oil recooler, external * Lateral table shifting for optimal ram retraction * Stepless stroke speed adjustment via GS motor * Built-in coolant system * Pre-settable pulse counter for precise table stop after each cut, with digital display * Various change gears

Kondisi: bekas, Tahun pembuatan: 1974, Maximum wheel diameter - 400 mm Wheel width 75 mm Total power requirement 25 kW Machine weight approx. 7 t LORENZ High-performance gear shaping machine Type LS 400 Year of manufacture 1975 S/N 12592 _____ Max. external gear diameter 400 mm* (possibly larger) Max. internal gearing diameter approx. 350 mm Max. gear width 75 mm Module range 0.5-6 Stroke length 82 mm Stroke position adjustability 0 - 100 mm Distance from shaping spindle to machine body 205 mm Spindle taper approx. MT 5 Stroke rates roughing/finishing 118 - 1,000 rpm Table size 400 mm Table bore 125 mm Mounting height between table and shaping head min./max. 190/290 mm Fixed outreach from shaping spindle 250 mm Axial travel of the table approx. 295 mm Number of teeth approx. 12 - 150 Feed range tooth depth 0.01 - 0.063 mm/stroke -"- Rotary feed at tool diameter 125 0.125 - 3.150 mm/stroke Spindle/Total drive approx. 19 kW / 25 kW - 380 V - 50 Hz Weight 7,000 kg Accessories / Special features: " Hydrostatic linear guide with separate hydraulic unit, " built-in intermediate plate 100 mm to raise the shaping head, " hydraulic workpiece clamping (RINGSPANN make) integrated in table for flat workpieces and for workpiece internal clamping, various clamping chucks for different workpiece diameters " stepless stroke rate adjustment for roughing and finishing operations Rjdpfx Ast Hww Doa Ijw (SIMOREG DC-Master), " automatic stroke rate change and automatic feed change for ROUGHING and FINISHING in up to 3 cuts, " automatic and motorized shaping stroke locking in upper position after finishing operation, " separate control cabinet and control panel, " integrated coolant unit with chip conveyor and magnetic separator, " approx. 20 change gears, Condition : satisfactory to good, demonstration-ready shortly Delivery : ex stock – as inspected Payment : strictly net – payment upon receipt of invoice

Tahun pembuatan: 1991, Kondisi: bekas, Maximum wheel diameter: 400 mm Maximum number of teeth: 150 Maximum module: 5 Total power requirement: 16 kW Machine weight approx.: 10 t PRÄWEMA CNC Gear Edge Milling Machine with Continuous Hobbing Process for chamfering external and internal gears on sliding sleeves, synchronizer rings, coupling bodies, starter gears, spur gears, etc. Model: SynchroForm W 2 - 1 Year: 1991 Machine No.: 05610 Workpiece diameter min./max.: 30 - 400 mm Number of teeth: 6 - 150 Rsdpfx Ast Hwylea Iow Maximum module: 5 Tool holder/shank diameter: SK 30 / 20 mm Maximum tool speed/spindle power (constant): 4,000 rpm / 1.8 kW Cross and longitudinal feed rates: 0.001 - 12 m/min Maximum workpiece speed (1.5 kW, C-axis): 2,000 rpm Total drive: approx. 16 kW, 380 V, 50 Hz Weight: approx. 10,000 kg Accessories / Special Features - BWO (Heckler & Koch) CNC control type 785 H for 7 axes in total, with screen input and all necessary monitoring and fault diagnostic systems for fully automatic operations. - 2 milling spindle units (left/right) that can be CNC-adjusted to all necessary angles: Z and W axes = tool cross-slide / X and U axes = tool longitudinal slide, L and O axes = milling spindle, C axis = workpiece spindle rotation. Manual adjustment: tool slide rotary plate (B and E axes), tool slide vertical adjustment (V and Y axes), tool head tilting (A and D axes), each with ROD for digital read-out in the control unit. - Hydraulic workpiece clamping device integrated with automatic loading system via workpiece feeder/conveyor and swing loader, as well as air system monitoring for the workpiece. - Coolant system with chip conveyor, soundproof enclosure, central lubrication system, integrated hydraulic system, pneumatically operated safety doors, deburring device, etc. Working principle: Gear hobbing with electronically synchronized tool and workpiece axes, enabling machining of both symmetrical and asymmetrical straight chamfer forms. Characterized by high productivity and precision. Condition: Good to very good – will be available for demonstration under power soon Delivery: Ex stock – as inspected Payment: Strictly net – upon receipt of invoice We always have further machines for the machining of transmission components in stock. Please contact us with your requirements at any time.

Kondisi: bekas, Tahun pembuatan: 1996, Workpiece diameter: 240 mm Center distance: 0 mm Max. honing length: 500 mm Max. module: 5 Total power requirement: 12 kW Machine weight approx.: 5,000 kg Space requirement approx.: [missing dimension] REISHAUER (Switzerland) CNC-controlled Gear Honing Machine Model: RZR, Year of manufacture: 1996 # 74 105 Wheel diameter min./max.: 10 - 240 mm Module: 0.5 - 5 Helix angle: +/- 30 ° Workpiece slide travel (Z-axis): 275 mm Honing tool traverse (X-axis): 128 mm Rodpfot Hwvmox Aa Isw X-axis infeed per stroke: 0.001 mm/stroke Crowning approx.: 0.5 ° Workpiece clamping length approx.: 500 mm Max. workpiece oscillation approx.: 3,000 mm Honing tool diameter outer/inner x width: 325/308 x 45 mm Honing tool speed: 100 - 1,200 rpm Dressing speed of honing tool: 30 - 1,000 rpm Spindle drive: 4 kW Total drive: approx. 12 kW - 400 V - 50 Hz Total weight approx.: 5,000 kg Accessories / Special Equipment SIEMENS CNC path control type 810 G allows input of all relevant gear data and the setup of the workpiece via conversational interface. With DNC interface RS 232 for data import and export. A-axis = swivel angle / Z-axis = table movement / X-axis = honing tool infeed, S-axis = honing wheel speed, U-axis = crowning adjustment With integrated device for automatic threading of the honing wheel into the gear gap The tool swivel angle (A-axis) is also moved electronically, quickly, and accurately and hydraulically clamped, allowing for faster setup times. Hydraulic workpiece clamping via foot switch between workpiece spindle and tailstock; both units are movable on the workpiece table according to the workpiece. Fully enclosed working area with sliding doors and safety interlock High-end original REISHAUER honing oil filtration system Type RTO 40.10, with centrifuge and cooling unit for consistent honing oil temperature, oil mist filter, etc. Various diamond dressing tools mounted on arbors. Separate ventilated and cooled electrical and control cabinet, separate hydraulic unit.

Kondisi: bekas, Tahun pembuatan: 1977, Wheel diameter - max. 400 mm Wheel width 280 mm Module - max. 4 Module - min. 1 Total power requirement 15 kW Machine weight approx. 6000 kg Space requirement approx. m L O R E N Z Universal Gear Hobbing Machine Model: F 400 Year of manufacture: 1977 Serial No.: 8687 _____ Wheel diameter min./max. 400 mm Module range 1 - 4 Redpfx Ajt Hw Hxja Ijw Number of teeth approx. 8 – 210 Milling width approx. 280 mm Max. workpiece installation length approx. 450 mm Milling slide swivels up to 60° Cutter size (diameter x length) 160 x 220 mm Cutter shift max. 180 mm Cutter speeds 125-500 rpm Table diameter x bore 375 x 80 mm Feed rates: axial 0.31 - 4.00 mm/rev radial 0.12 – 1.60 mm/rev tangential 0.035 – 4.5 mm/min Milling spindle drive approx. 8 kW Total drive approx. max. 15 kW - 380 V - 50 Hz Weight approx. 6,000 kg Accessories / Special Equipment • Various milling programs selectable for climb and conventional milling, as well as radial / axial milling processes, possibly for worm milling • Universal milling head with shifting capability • Hydraulic workpiece clamping in the table and hydraulic tailstock • Hydraulically swiveling counter-holder connection for easier loading • Differential for helical gearing • Infinitely variable speed adjustment, display for speed and amperage • Change gears, various accessories, coolant system * Very robust design Condition: Good – demonstration available soon Delivery: Ex stock - as inspected Payment: Upon receipt of invoice, strictly net

Kondisi: bekas, Tahun pembuatan: 1993, Maximum wheel diameter: 330 mm Wheel width: 180 mm Total power requirement: 12 kW Machine weight: approx. 7,500 kg R E I S H A U E R (Switzerland) CNC Gear Grinding Machine Model: RZ 301 AS (*A = automatic threading) Year of manufacture: 1993 #71206 _____ Wheel diameter min./max.: 10 - 330 mm Module: 0.5 - 7 Helix angle: +/- 45° Slide stroke: 180 mm Maximum number of teeth: 10 - 600 Workpiece clamping length: 420 to max. 620 mm Max. workpiece weight: 60 kg Grinding worm dimensions x width: 3 x 50 x 84 - 104 mm Grinding worm speed: 1,100 - 1,900 rpm Spindle drive: 4 kW – total power approx. 12 kW – 380 V, 50 Hz Total weight: approx. 7,500 kg Accessories / Special Features: A modern CNC controller enables the input of all relevant gear parameters and workpiece setup in dialog with the control system. Programming language (German/English) selectable, and DNC interface for data import/export. The machine operates using a continuous generating grinding process with automatic grinding cycles and in-machine automatic dressing of the grinding wheel. Equipped with an integrated automatic device for threading the grinding wheel into the gear gap, resulting in significant time savings; device is hydraulically pivotable. Rjdpfxet Hwyfe Aa Iow About 10 years ago, the profiling axis (V-axis) was retrofitted electronically by BURRI, providing higher accuracy, easier profile correction, faster dressing; currently fitted with a REISHAUER dressing device type SP-DR with a profile diamond disk. The workpiece swivel angle (A-axis) is also actuated electronically, quickly and precisely, and hydraulically clamped; this allows for faster setups and simplified workpiece loading. The shift grinding device guides the workpiece tangentially past the grinding wheel during grinding, ensuring a consistently uniform engagement of the grinding wheel profile. DITTEL grinding wheel balancing system Hydraulic workpiece clamping with external chuck and tailstock in the workpiece slide Complete working enclosure with sliding doors and oil mist extraction No original coolant system present (central supply); however, a separate grinding oil centrifuge is available Separate electrical and control cabinet, standalone hydraulic unit in cabinet, grinding wheel flanges

Tahun pembuatan: 1975, Kondisi: bekas, Wheel diameter – max. 280 mm Number of teeth – max. 100 Module – max. 6 Module – min. 1 Total power requirement: 6 kW Machine weight approx. 2,500 kg Space requirement approx. ___ m HURTH Automatic gear edge milling machine for universal use in deburring and chamfering of gears Type ZK 7 – Year of manufacture 1975 – Serial no. 26 000 Max. workpiece diameter: approx. 280 mm Workpiece length: approx. 200 mm Module range for deburring: 1–6 module for chamfering: 1–4 module Rjdpfxjt Hw Dke Aa Iew Workpiece tooth count: 6–100 Workpiece spindle bore: 102 mm Horizontal adjustment of workpiece head: approx. 340 mm Vertical adjustment of milling slide: 180 mm Swiveling of milling slide: 105° Cross adjustment of milling slide: approx. 300 mm Cutter speeds: 250–2,800 rpm Cutter stroke rates: 30–210 per min. Cutter stroke adjustable: 6–12 mm Milling spindle mounting: 40 SK Total drive: approx. 6 kW, 380 V, 50 Hz Weight: approx. 2,500 kg Accessories / Special equipment: • Electric workpiece clamping device with collet chuck system, device for expanding mandrels, and standard workpiece holder, large quantity of clamping tools included. Foot switch for clamping release. • Mechanical dividing device for number of teeth with approx. 20 different index plates. • Adjustable tooth gap centering mechanism mounted on the workpiece head. • Mechanical collet chuck fitted to the tool head for various cutter diameters and types (form, face, shell end mills, etc.). Approx. 50 different used and new cutters of all kinds included. • Hydraulic working stroke of the tool spindle towards the workpiece, with attached hydraulic unit. • Workpiece counter. Condition: good – ready for demonstration, very interesting due to extensive accessories. Delivery: ex stock – as inspected Payment: strictly net – upon receipt of invoice We look forward to your order. We have approx. 100 other gear cutting machines available in stock. Please contact us for more information.

Tahun pembuatan: 1991, Kondisi: bekas, Maximum wheel diameter: 0 mm Maximum number of teeth: 0 Maximum module: Minimum module: Total power requirement: kW Machine weight approx.: t Space requirement approx.: m CNC-controlled synchro ring milling machine Rodpfxot Hwv Ho Aa Iow Ideal for synchro rings, BWO control 785 H
