Pusat pembubutan dan milling CNC

MAZAK Nexus VCN-510C

Kondisi: baru, Tahun pembuatan: 2026, panjang total: 1.450 mm, lebar total: 800 mm, tinggi total: 1.800 mm, berat keseluruhan: 500 kg, daya: 4,75 kW (6,46 hp), FC 120 ZK Working capacity Ø 120x120 mm, Number of belt stations (Z): 1, Number of brush stations (K): 1, Abrasive belt dimensions: 120x1850 mm, Brush band dimensions: 120xØ200 mm, Abrasive belt speed: 20 m/s, Brush band speed: 15 m/s, Guedpfot D D Nzex Aa Dsd Feed speed: 12 m/s, Abrasive belt motor per head (x1): 3 kW, Brush motor per head (x1): 1.5 kW, Feed motor: 0.25 kW, Total power: 4.75 kW, Power consumption: 12A, Extraction port per head Ø (2x): 80 mm, Dimensions: 1450x800x1800 mm, Weight: 500 kg

Kondisi: sangat baik (bekas), Tahun pembuatan: 2019, MAZAK QUICK TURN 350MB 1250U Diameter ayun maksimum: 830 mm Diameter pembubutan maksimum: 420 mm Panjang pembubutan maksimum: 1.250 mm Kecepatan milling maksimum: 5.000 rpm Kecepatan spindle maksimum: 3.300 rpm Mesin dilengkapi dengan: - CNC CONTROL Mazatrol SmoothG - Chuck tiga rahang SMW KNCS 400, diameter 400 mm - Tool Eye - Sumbu C - Tailstock NC - Pompa pendingin yang diperkuat - Konveyor serbuk/pengerik - 8 buah dudukan alat tetap Gujdpfx Aasy Igz Dj Dod - 2 buah dudukan alat penggerak

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2023, gaya penjepit: 2.500 kN, diameter sekrup: 55 mm, berat keseluruhan: 8.400 kg, Hydraulic injection moulding machine from 2023. This HAITIAN MA 2500 III offers a clamping force of 250 tonnes and a platen size of 850 x 850 mm. The machine features an impressive injection pressure of 1850 bar and a screw diameter of 55 mm. If you are looking for a high-quality injection moulding machine, the HAITIAN MA 2500 III we are offering for sale is well worth considering. Contact us for further details on this machine. • Clamping Unit • Opening force: 165 kN • Platen size: 850 x 850 mm • Opening stroke: 540 mm • Tie bar distance: 580 x 580 mm • Max. mould height: 580 mm • Min. mould height: 220 mm • Ejector stroke: 150 mm • Ejector force: 62 kN • Min. mould dimensions: 410 x 410 mm • Injection Unit • Euromap classification: 1000 • L/D ratio: 20 • Shot volume: 570 cm³ • Effective injection volume: 519 g • Injection rate: 281 g/s • Plasticising capacity: 47.7 g/s • Injection pressure: 1850 bar • Screw speed: 180 rpm • Screw stroke: 240 mm • Carriage force: 99 kN • Pump motor power: 37 kW • Heater power: 21.45 kW • Oil tank capacity: 340 l • Dimensions • Machine size: 6.19 x 1.60 x 2.42 m • Control System • Controller: KEBA 2985 - CP053 • Features: • 15" colour touchscreen • Euromap 67 robot interface • USB storage • 200-tool memory • Cycle history • Alarm tower • RFID login/password • Multilingual interface • Process graphs • Maintenance pages • Metric/imperial selectable • Included Options/Extras (machine-integrated) • Bimetallic screw + barrel • Masterbatch dosing interface • Hydraulic radial exhaust • Festo air-blast system • 12-zone central lubrication (PSG) • 4-way flowmeter • Robot interface • Includes 3-zone screw • CE-certified safety cell Additional Equipment • Robot included: HILECTRO V-1300ID Cartesian Robot (2023) • Type: 3-axis servo Cartesian robot • Suitable for: 380T to 530T presses • Travel paths: X 2000 mm / Y 880 mm / Z 1300 mm • Max. extractable weight: 12 kg • Power supply: 400 VAC / 50-60 Hz • Accuracy: 0.1 mm Gsdpey N Sqmefx Aa Doud • Robot weight: 530 kg • Included: touchscreen controller, USB programs, pneumatic gripper, vacuum suction cup, conveyor belt ready • Included peripherals: FORMAX E3 Monofase hopper loader (2 units) • Hopper capacity: 3.0 l • Power: 1150 W • Inlet diameter: 40 mm • Throughput: 70 kg/h • Voltage: 230 V • Weight: 13 kg each

Kondisi: bekas, Tahun pembuatan: 2008, fa512b7e Godjyv Ipfjpfx Aa Djud

Kondisi: baik (bekas), Tahun pembuatan: 2008, Fungsionalitas: berfungsi sepenuhnya, Okuma Multus B300-W Mesin Bubut-Milling 6 Axis - Okuma OSP P200L - Tahun pembuatan 2008 - Waktu pemotongan 10.500 jam - Spindel milling H1 6000 rpm - Spindel utama 3800 rpm, Rota NC 315-86 - Spindel sub 5000 rpm - ATC 60 sistem HSKA-63 (60 alat) - Geometri sangat baik - Sensor alat Marpos Gedsyg Rf Nopfx Aa Djud

Kondisi: baik (bekas), Tahun pembuatan: 2018, jam operasional: 7.819 h, Fungsionalitas: berfungsi sepenuhnya, jarak pergerakan sumbu X: 2.000 mm, jarak lintasan sumbu Y: 800 mm, jarak gerak sumbu Z: 720 mm, gerak cepat sumbu X: 50 m/menit, pergeseran cepat sumbu Y: 50 m/menit, pergerakan cepat sumbu Z: 50 m/menit, STANDARD TECHNICAL SPECIFICATION – MAZAK CAPACITY Table working area (length): 2,500 mm Table working area (width): 820 mm Longitudinal (crosswise) X-axis travel: 2,000 mm Column (crosswise) Y-axis travel: 800 mm Spindle head (vertical travel) Z-axis: 720 mm Minimum distance from spindle nose to top of table: 140 mm Maximum distance from spindle nose to top of table: 860 mm Table load capacity (uniform load): 1,700 kgf Spindle head rotation (B-axis): ±110° SPINDLE HEAD Spindle taper: 7/24 taper, No. 40 Maximum spindle speed (standard): 18,000 min⁻¹ Minimum spindle speed (standard): 35 min⁻¹ Main spindle motor output (continuous rating): 26.0 kW FEED RATES Rapid traverse (X-axis): 50 m/min Rapid traverse (Y-axis): 50 m/min Rapid traverse (Z-axis): 50 m/min TABLE Table length: 2,500 mm Table width: 820 mm T-slot width: 18 mm Number of T-slots: 7 Distance between centers: 100 mm Distance from machine base to table top: 870 mm AUTOMATIC TOOL CHANGER Guodeya Hngjpfx Aa Dsd Tool magazine capacity (standard): 30 Tool magazine capacity (optional): 48 Tool selection: Mazatrol memory random access Tool holder type: CAT-40 / MAS BT-40 Max. tool diameter with adjacent tool: 80 mm Max. tool diameter without adjacent tool: 130 mm Max. tool weight (with basic holder and pull stud): 8 kgf Max. total tool magazine weight: 150 kgf Max. tool length (from measurement line): 350 mm Tool change time (chip-to-chip): 4.7 s MACHINE DIMENSIONS Machine height (floor to top): 3,355 mm Machine width: 4,250 mm Machine depth: 4,046 mm Machine weight: 14,000 kg OTHER Power supply voltage: AC380/400/415V ±10% Supply frequency: 50/60 ±1 Air pressure: 0.5–0.9 MPa Air consumption: 260 l/min Coolant tank capacity: 450 L STANDARD MACHINE EQUIPMENT – MAZAK GENERAL MACHINE OPTIONS Foundation kit (base bolts & plates) One set of setting tools Work area lighting Power transformer for European market USB interface (1 port) MANUALS AND DOCUMENTATION One set of documentation (CD) SPINDLE SPEED Spindle speed: 18,000 rpm (#40) MACHINE BODY COLOR Mazak standard color (F white / S black) SAFETY & HEALTH Worldwide safety measures Work area door interlock with locking switch Full enclosure Full chip and coolant splash guard TOOL MAGAZINE 30-position tool magazine COOLING SYSTEMS Full cooling system HIGH-PERFORMANCE / HIGH-PRESSURE COOLING Through-spindle coolant (5 bar, 71 PSI) AUTOMATION SYSTEMS Automatic power on/off + warm-up MEASUREMENT SYSTEMS Automatic tool length measurement & breakage detection POSITIONING SYSTEM Absolute positioning system CHIP CONVEYOR Preparation for chip conveyor (left side) NC CONTROL – 15 functions 19" color LCD (touch screen) 3-D coordinate conversion Reposition sensor B) Shape compensation for rotary axes EIA/ISO code input function (standard) Background tool path checking LAN connector High smoothing control Mazak 2D software (shape compensation) Mazak 3D high speed package Mazak tapping / pre-drilling Tornado (Mazatrol) Mazatrol SmoothX CNC Movable operator panel SD memory interface (1 slot) + USB interface (1 slot) Smooth standard software

Kondisi: diremaj di bengkel (bekas), Tahun pembuatan: 2008, Fungsionalitas: berfungsi sepenuhnya, tegangan masuk: 400 V, jarak pergerakan sumbu X: 760 mm, jarak lintasan sumbu Y: 510 mm, jarak gerak sumbu Z: 570 mm, tinggi benda kerja (maks.): 520 mm, berat benda kerja (maks.): 300 kg, jumlah slot dalam magazin alat: 34, tinggi total: 2.935 mm, panjang total: 3.600 mm, lebar total: 3.700 mm, lebar meja: 860 mm, model controller: FANUC, pasokan pendingin: 12 batang, jarak dari tengah meja ke hidung spindel: 780 mm, daya motor spindle: 15 W, pergerakan cepat sumbu Z: 40 m/menit, gerak cepat sumbu X: 40 m/menit, pergeseran cepat sumbu Y: 40 m/menit, hidung spindel: ISO 40, kecepatan spindel (maks.): 10.000 rpm, kecepatan spindel (min.): 80 rpm, tinggi meja: 560 mm, beban meja: 300 kg, diameter alat: 80 mm, panjang alat: 300 mm, berat alat: 8 g, Perlengkapan: dokumentasi / manual, kecepatan rotasi dapat diubah tanpa batas, konveyor serpihan, Vertical machining center with automatic pallet changer "DOOSAN model VC500" equipped with Fanuc 21i-MB CNC Gjdpfx Aaju T Hg Ts Dsud

Kondisi: sangat baik (bekas), KARDEX SHUTTLE Tipe-No.: SHUTTLE-XP-500-3050x864 Gusdjzcx T Hspfx Aa Ded Varian: H/N55/N22D18B/N75D20/20 Beban bersih maksimum yang diizinkan: 2x34.100 kg Beban per rak maksimum: 265 kg Dimensi sekitar PxLxT: 3.050 x 3.074 x 3.750

Kondisi: bekas, Tahun pembuatan: 2018, jam operasional: 10.104 h, jarak pergerakan sumbu X: 650 mm, jarak lintasan sumbu Y: 765 mm, jarak gerak sumbu Z: 520 mm, gerak cepat sumbu X: 40 m/menit, pergeseran cepat sumbu Y: 40 m/menit, pergerakan cepat sumbu Z: 36 m/menit, Perlengkapan: konveyor serpihan, DOOSAN VC 630 5AX (Pusat pemesinan 5-sumbu) Model: VC 630 5AX HEIDENHAIN TNC640 NC Gsdpfx Aoymc Ngoa Deud Tahun pembuatan: 2018 Kondisi: Bekas, sangat baik, masih dalam produksi Jam operasi: 26.290 jam Jam spindle: 10.104 jam Sumbu X: 650 mm Sumbu Y: 765 mm Sumbu Z: 520 mm Sumbu A: +30° hingga -120° Sumbu C: 360° Pergerakan cepat sumbu X: 40 m/menit Pergerakan cepat sumbu Y: 40 m/menit Pergerakan cepat sumbu Z: 36 m/menit Beban maksimum meja: 500 kg Spindle: 16.000 rpm 30/24 kW Holder alat: HSK 63A Pendingin melalui spindle: 18 bar Tinggi: 3.295 mm Lebar: 3.200 mm Panjang: 4.585 mm Berat: 13.500 kg

Kondisi: sangat baik (bekas), Tahun pembuatan: 2012, jam operasional: 10.600 h, Pusat pemesinan 5 sumbu Merek: DMG MORI Tipe: DMU 80 Monoblock Tahun: 2012 (jam spindle 10.600) CNC: Heidenhain iTNC 530 Dilengkapi dengan: - Meja putar terintegrasi diameter 700 mm / 650 kg - Spindle 29 kW – 12.000 rpm - Penukar alat 32 posisi - Probing TS 649 - 3D quickset - Pendingin pusat 40 bar - Sensor alat laser BLUM - Pistol semprot pendingin - Konveyor serbuk chip Spesifikasi: Luas meja: 1250 x 700 mm Sumbu X: 880 mm Sumbu Y: 630 mm Sumbu Z: 635 mm Sumbu B: -120/+30° Sumbu C: 360.000° Kecepatan spindle: 20 - 12.000 rpm Daya spindle: 29 kW Taper spindle: SK 40 Feed cepat XYZ: 42 m/menit Godpfozgbv Dox Aa Doud Dimensi mesin dengan konveyor: 3440 x 2850 x T 2750 mm Berat sekitar: 7480 kg
