Beli Gildemeister Ctx bekas (228)

Kondisi: sangat baik (bekas), Tahun pembuatan: 2008, Fungsionalitas: berfungsi sepenuhnya, TECHNICAL SPECIFICATIONS: CNC: Siemens 840D powerline _ Working Range Max. swing over bed: 400 mm Max. swing over cross slide: 270 mm Turning length: 650 mm Cross travel (X): 220 mm Longitudinal travel (Z): 700 mm _ Main Spindle Spindle nose in accordance with DIN 55026 A (outer bolt circle): A6 Spindle bore in front bearing: 90 mm Spindle through-hole: 65 mm Spindle nose taper: metric 72 (MT5) Motor power 40/100% DC: 15/12 kW Max. torque 100% DC: 400/320 Nm Speed range: 4,000 rpm _ Cross Slide X/Z X axis travel: 220 mm Z axis travel: 700 mm Ball screw X/Z (dia x pitch): 32×5 mm Rapid traverse speed X/Z: 15 m/min Feed force X/Z: 3/6 kN _ Tool Turret Number of tool stations for direct mounting: 8 Tool shank cross-section: 20×20 mm Turret tool disk wrench opening: 220 mm Shank diameter for boring bars: 25 mm _ Tailstock Max. quill force: 680 daN Center: MT 4 Quill diameter: 65 mm Hydraulic quill stroke: 40 mm _ Coolant System Tank capacity: 500 l Pump power: 1.2 kW Flow rate: 37 l/min Pressure: at 1.9 bar Reservoir capacity: 25 l Nedpfxex Ihn Es Aahsdf _ Power Requirements Connected load: 22 kVA Operating voltage: 400 V Frequency: 50 Hz Protection (slow/VDE 0100) rec.: 35 A Voltage fluctuation at 400 V: +6% / −10% _ Dimensions and Weight Dimensions L/W/H (incl. chip conveyor): 2,100 / 1,750 / 1,710 mm Machine weight (without chip conveyor): approx. 2,800 kg _ Year of manufacture: 2008

Kondisi: bekas, Tahun pembuatan: 1999, de-01 Nedpfew Syd Sox Aahedf

Kondisi: bekas, Tahun pembuatan: 1983, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: M02-4-320, Mesin bor lubang dalam Spesifikasi teknis lihat gambar lampiran Ndedpfsx Ezllsx Aahof

Kondisi: hampir baru (bekas), Tahun pembuatan: 2013, jam operasional: 7.100 h, Fungsionalitas: berfungsi sepenuhnya, panjang pembubutan: 650 mm, diameter putar di atas sled silang: 350 mm, diameter pembubutan: 385 mm, kecepatan spindel (min.): 4.500 rpm, lubang spindel: 67 mm, jarak pergerakan sumbu X: 255 mm, jarak gerak sumbu Z: 800 mm, For sale: Used DMG NEF400 V3, 5th Generation ISM 2-axis universal lathe with C-axis. Travel distances: X: 255 mm Z: 800 mm Swing diameter over bed: 385 mm Max. workpiece diameter: 350 mm Turning length: 650 mm Equipment: - Main spindle as integrated spindle motor Max. speed: 4,500 rpm Drive power: 8.0/11.5 kW (100/40% duty cycle) - 12-position disk turret VDI30 with 6 powered tool stations - C-axis and spindle brake (hydraulic) - Automatic tailstock, MT4, travel: 680 mm - CNC control: Siemens 840D Solutionline with ERGOline Control, Sinumerik Operate, and ShopTurn 3G Nodpsxzqnrofx Aahodf - Operating system: Linux - Technology cycle for applying alternating speed for vibration-critical setups - Tool measurement system, manually deployable in the workspace - Hydraulic unit - Coolant spray gun - Mechanical oil mist separator - Reinforced coolant pump 12 bar, 23 l/min - Chip conveyor, discharge height 1,250 mm, discharge to the right Bar machining package including: - Workpiece pick-up device with left-discharge conveyor for parts up to max. 65 mm diameter, 150 mm length, max. 3 kg weight - Hollow clamping device, draw tube internal diameter max. 67 mm - Interface for bar feeder - Foot switch for tailstock operation - Hydraulic three-jaw chuck SMW-AUTOBLOK, RMS sensor (Relocation Machine Security) Machine available immediately! Ready for operation upon delivery! We will load the machine for you! Transport can be organized upon request!

Kondisi: sangat baik (bekas), Tahun pembuatan: 2001, Gildemeister MF Sprint 65 Mesin dalam kondisi sangat baik Ndsdexm Td Tspfx Aahsf Hainbuch SK65 2 x turret dengan alat berpenggerak Jam kerja sedikit: 22.670

Kondisi: sangat baik (bekas), Tahun pembuatan: 2004, Siemens Sinumerik 840D control system Bar capacity: 65 mm Spindle speed: 5,000 rpm 2 x 12-position turrets with driven tools Nodpjwh U D Hjfx Aahjdf Turret 1 with Y-axis Parts catcher Belt filter system Chip conveyor IRCO Profimat bar loader

Kondisi: bekas, Tahun pembuatan: 2007, produsen pengendali: Siemens, model controller: 840 D, Description: General: Year of manufacture: 2007 Control system: Siemens 840 D Turning diameter: 100 mm Turning length: approx. 580 mm Bar capacity: 32 mm Main spindle: Technology: Motor spindle Speed: 8,000 rpm Max. torque: 100 Nm Max. power: 26 kW C-axis: 0.001° Bar capacity: 32 mm Clamping cylinder: Hollow clamping cylinder Chuck: Hainbuch Spanntop Counter spindle: Technology: Motor spindle Speed: 8,000 rpm Max. torque: 100 Nm Nodpfx Aexzmp Eeahjdf Max. power: 26 kW C-axis: 0.001° X-axis: 145 mm Z-axis: 380 mm Clamping cylinder: Semi-hollow clamping cylinder Chuck: Hainbuch Spanntop Tool turret I (X/Y/Z): Technology: Tool turret Number of stations: 12 Tool interface: VDI 25 Tool drive: 6,000 rpm X-axis: 220 mm Y-axis: 60 (+/- 30) mm Z-axis: 320 mm Tool turret II (X/Z): Technology: Tool turret Number of stations: 12 Tool interface: VDI 25 Tool drive: 6,000 rpm X-axis: 120 mm Z-axis: 345 mm Equipment / Accessories: Chip disposal: Chip conveyor Coolant supply: High pressure coolant system (IKZ unit) Bar loader: Irco Breuning Part removal: Parts gripper + transfer conveyor Tailstock: Stroke 250 mm, quill MK 3 Chuck: 2x Hainbuch Spanntop Tool holders: Various driven and static holders

Kondisi: baik (bekas), Tahun pembuatan: 1998, d1b3cb87 Ndsdpfx Aoqn A Rgoahof

Kondisi: baik (bekas), Tahun pembuatan: 2008, panjang pemakanan sumbu X: 575 mm, panjang umpan sumbu Y: 90 mm, panjang umpan sumbu Z: 300 mm, L.-Nr. 3.2-115 Ndedpfx Aaeubvv Tshsf 1 gebrauchte CNC-Drehmaschine GILDEMEISTER Modell CTV 160, Baujahr 2008 1 used CNC lathe GILDEMEISTER type CTV 160, year of manufacture 2008 Siemens 840D Steuerung 3-Backenfutter Späneförderer Kühlmitteleinrichtung Siemens 840D control 3-jaw chuck Chip conveyor Coolant equipment Technische Daten / Technical details: Drehdurchmesser / Turning diameter: 160 mm X-Achse / X-axis: 575 mm Z-Achse / Z-axis: -- mm Y-Achse / Y-axis: 300 mm (+-90 mm) Drehzahlbereich / Spindle speed range: 6000 UpM / rpm Gewicht der Maschine ca. / Weight approx.: 6000 kg Technische Daten, Zubehör und Beschreibung der Maschine sind unverbindlich – Technical data, accessories, and description of the machine are not binding.

Kondisi: diremaj di bengkel (bekas), Tahun pembuatan: 2003, Mesin Bubut Universal GILDEMEISTER NEF 320 K Dengan kontrol Siemens SINUMERIK 810 DE (SIMATIC PANEL TOUCH SCREEN) Ndsdpfxsxn Ar Ao Aahef Tahun pembuatan: 2003 Lubang spindle: 52 mm Jarak antara senter: 750 mm Diameter kerja di atas tempat tidur: 320 mm Diameter kerja di atas support pelana: 150 mm Panjang lintasan: 185 mm Kisaran putaran: 14 – 3550 rpm, tanpa tingkat Dilengkapi dengan aksesoris berikut: Pelindung geser dengan pencahayaan dalam Pemegang alat Multifix dengan 2 insert Chuck 3 rahang SCHUNK ROTA plus Ø 200 mm 2 set rahang lunak tambahan Sistem pendingin cairan Pistol pembersih serbuk 6 buah kaki mesin Manual operasi Mesin dalam kondisi sangat baik!

Kondisi: baik (bekas), Tahun pembuatan: 1999, jam operasional: 42.733 h, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 01500001111, panjang pembubutan: 1.500 mm, diameter pembubutan: 500 mm, lubang spindel: 70 mm, kecepatan spindel (maks.): 2.800 rpm, kecepatan spindel (min.): 8 rpm, berat keseluruhan: 3.200 kg, Diremajakan ulang oleh Gildemeister Bielefeld pada 2010 Diameter pembubutan: 500 mm Diameter putaran di atas dudukan pelana: 290 mm Nsdpfxsxx Uqro Aahsdf Panjang pembubutan: 1.500 mm Rentang putaran: 8 - 2.800 rpm dengan tiga tingkat transmisi Lubang spindle sekitar Ø 70 mm Chuck tiga rahang Ø 250 mm, merk Röhm Pinol senter ekor: MK4

Kondisi: sangat baik (bekas), Tahun pembuatan: 2000, Siemens control Bar capacity 32 mm 2 x 12-station turrets with driven tools Main / counter spindle Y-axis on upper turret Parts catcher Chip conveyor Ndsdpswh U Edofx Aahsf IRCO bar feeder magazine

Kondisi: bekas, Tahun pembuatan: 1996, Swing diameter over bed: 710 mm Swing diameter over cross slide: 420 mm Turning length: 2000 mm Control: Heidenhain Manual Plus 3110 Spindle bore: 92 mm Main spindle speeds: 16 - 1800 rpm Cross slide travel: 385 mm Spindle nose according to DIN 55027 - size 11 Spindle diameter at front bearing: 140 mm Drive power at 100% duty cycle: 22.00 kW Spindle torque at 100% duty cycle: 2750 Nm Feed rate X/Z axis: 1 - 5000 mm/min Rapid traverse X axis: 6.00 m/min Rapid traverse Z axis: 8.00 m/min Tailstock quill taper: MT 5 Nodpfx Aoxxmiyeahsdf Quill stroke: 210 mm Quill diameter: 110 mm Total connected load: 40.00 kW Machine weight approx.: 5.60 t Space requirement approx.: 5.00 x 3.00 x H2.50 m With chip conveyor

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2007, jam operasional: 23.567 h, Fungsionalitas: berfungsi sepenuhnya, kecepatan spindel (maks.): 5.000 rpm, jarak pergerakan sumbu X: 165 mm, jarak lintasan sumbu Y: 80 mm, jarak gerak sumbu Z: 678 mm, saluran batang: 70 mm, model controller: Fanuc 310i, 1 Ndedpex Af Dkefx Aahof

Kondisi: sangat baik (bekas), Tahun pembuatan: 2002, Maszyna w idealnym stanie. Możliwość inspekcji podczas pracy w dowolnym momencie. Nsdorgpv Tjpfx Aahedf

Kondisi: diremaj di bengkel (bekas), Tahun pembuatan: 2002, Mesin Bubut Kendali Siklus GILDEMEISTER NEF 320 Dengan kontrol MANUAL PLUS 4110 Tahun pembuatan: 2002 Lubang spindle: 50,8 mm Jarak antar senter: 750 mm Diameter ayunan di atas alas: 320 mm Diameter ayunan di atas carriage: 150 mm Tinggi senter: 160 mm Rentang kecepatan putar: 10 – 4000 rpm variabel tak bertingkat Dilengkapi dengan aksesoris berikut: Pelindung geser dengan pencahayaan dalam Pemegang alat Multifix dengan 2 mata penyisip Chuck rahang 3 Schunk ROTA – S plus Ø 200 mm 2 set rahang lunak Pemrograman kontur ICP Ndodpoxn Apbefx Aahjf Tailstock dengan pinol bor yang dapat diperluas Wadah serbuk logam Unit pendingin Pistol penyemprot serbuk logam 6 buah kaki mesin Manual pengoperasian

Kondisi: baik (bekas), Tahun pembuatan: 1985, 10595 Nedpfx Aasxvw Rcehsdf

Kondisi: baik (bekas), Tahun pembuatan: 2004, jam operasional: 27.098 h, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 01510005551, diameter putar di atas sled silang: 290 mm, lubang spindel: 70 mm, panjang pembubutan: 1.000 mm, diameter pembubutan: 500 mm, kecepatan spindel (maks.): 3.000 rpm, panjang total: 2.800 mm, lebar total: 1.925 mm, tinggi total: 1.850 mm, berat keseluruhan: 2.700 kg, kecepatan rotasi (maks.): 3.000 rpm, Mesin dalam kondisi baik dan berfungsi dengan baik. Mesin dapat dilihat dalam keadaan hidup. Nedpsxy R Nmefx Aahjdf Diameter putar di atas tempat tidur/sadel: 500mm/290mm, lintasan sadel: 260mm, panjang putaran: 1000mm, pemboran spindle: 70mm, diameter spindle: 120mm, kecepatan putar: 3050 rpm, daya penggerak: 12kW, torsi: 920Nm, rapid traverse X/Z: 8m/menit/10m/menit, langkah umpan X/Z: 5m/menit, langkah tailstock: 180mm, diameter tailstock: 80mm. Dimensi mesin X/Y/Z: sekitar 3400mm/2000mm/1850mm, berat: sekitar 2700kg. Dokumentasi tersedia. Inspeksi di lokasi dimungkinkan.

Kondisi: sangat baik (bekas), Swing diameter over bed: 212 mm Distance between centers: 750 mm Spindle speeds: 10–4,000 rpm Ndsdpsud Nb Ijfx Aahsf Control: HEIDENHAIN Manual Plus Various accessories MARCELS MASCHINEN CH

Kondisi: bekas, CNC control unit, numeric control, removed from GILDEMEISTER GDM 65/2A GILDEMEISTER type Eltropilot EP20 GD-2A Year of manufacture: 1989 Order no.: 150 299 Serial no.: 0.854.183 Power connection: 220 VAC 50 Hz Rack with 20 module slots - 11 modules installed Dimensions (W x H x D): 480 x 260 x 220 mm Weight: approx. 7 kg The control came from a Gildemeister GDM 42/2A lathe. You can find additional components from Gildemeister under stock numbers: Ndodsh Ecnaepfx Aahof 60343, 60346, 60347

Kondisi: bekas, Tahun pembuatan: 1999, Turning diameter 500 mm Turning length 1500 mm Control system Manual Plus Spindle bore diameter 70 mm Speed range 8 - 2800 rpm Number of gear steps 3 Max. swing diameter over cross slide 290 mm Spindle nose DIN 55027 size 8 Tool holder type C Quill stroke 180 mm Machine weight approx. 3.2 t Dimensions L x W x H 3.0 x 1.8 x 1.8 m Machine description: This machine is suitable for turning chuck and shaft workpieces. Commercially available steel grades, cast iron, copper, aluminium, brass, gunmetal, and machinable plastics can be turned on this machine. --> N.E.F. plus concept Ndjdjub Amljpfx Aahof The machine is supplied as standard with the following equipment: - Cycle control - AC main drive - Compound slide with AC drive and control panel - Tailstock movable with tailstock clamp, manually clamped, equipped with subsequent center - Coolant supply - Swarf protection covers, manually operated - Safety cover for the chuck - Quick-change tool holder Hahn & Kolb Multifix C - Reducing ring for spindle Accessories as per pictures: - 2 pcs steady rests - Various clamping jaws - Hahn & Kolb Multifix type C - Various turning tool holders Technical data: Working area: - Swing diameter over bed: 500 mm - Swing diameter over cross slide: 285 mm - Chuck diameter: 250 (315) mm - Cross slide: 260 mm - Distance between centers: 1000/1500 mm Spindle: - Spindle nose DIN 55027: size 8 - Spindle bore diameter: 70 mm - Taper of spindle nose: 80 metric - Spindle diameter at front bearing

Kondisi: diremaj di bengkel (bekas), Tahun pembuatan: 2005, CNC cycle-controlled lathe GILDEMEISTER NEF 520 With MANUAL PLUS 4110 control Year of manufacture: 2005 Spindle bore: 70 mm Distance between centers: 1000 mm Swing diameter over bed: 500 mm Nsdpfx Aasuda Tnohjdf Swing diameter over cross slide: 290 mm Center height: 250 mm Stepless speed range: 10 – 3050 rpm Including the following accessories: Sliding guard with internal lighting 8-position Sauter turret VDI 30 with driven tools 10 pcs. VDI 30 tool holders 2 pcs. driven tools VDI 30 Coolant system 3-jaw chuck SCHUNK ROTA Ø 250 mm ICP contour programming Tailstock with retractable quill Chip tray Operating manuals

Kondisi: sangat baik (bekas), Monitor display (108142) Manufacturer: DMG Gildemeister Type: Supply 11098 I.D. No. 259284 The monitor was removed from a machine with mechanical damage. Functionality has been tested. Nedpfx Aaeigqr Hshedf

Kondisi: bekas, Hydraulic self-centering steady rest, SMW AUTOBLOK steady rest Hydraulic steady rest with hydrostatic bearing Nodpfxsiv Irls Aahodf Suitable for GILDEMEISTER / MAX MÜLLER lathe MD 5 Type: SLK 8-70 N Clamping range: 8 to 70 mm Operating pressure: approx. 60 bar Steady rest base: 245 x 240 mm Design: fixed - 3 pcs. roller bearings Ø 35 mm - Roller width: 18 mm - hydraulically self-centering Dimensions (L x W x H): 350 x 250 x 550 mm Net weight: 65 kg Good condition

Kondisi: bekas, Spare parts donor We are dismantling the CNC lathe GILDEMEISTER model GDM 42/2A CNC control: Eltropilot EPL 2 Machine no. 4.5733, Year of manufacture: 1989 Machine not operational – electrical issues Standard turning diameter: 185 mm Max. swing diameter: 400 mm Cross slide travel (X): 190 mm Ndsdpfxsdzqm Ro Aahjf Longitudinal slide travel (Z): 450 mm Spindle bore in spindle: 52.7 mm Bar capacity in draw tube: Ø 42 mm Feed rate in X and Z up to 3000 mm/min. Spindle speed: 40–6300 rpm, stepless Main spindle drive power: 22 kW Power supply: 400 Volt, 50 Hz, 45 kVA - Hydraulic 3-jaw chuck FORKARDT Ø 200 mm - 12-position tool turret, VDI 40, every second station driven - Driven tools possible in 6 positions - Chip conveyor with integrated coolant system - Separate electrical cabinet - 10 tool holders VDI 40 included Machine footprint (L x W x H): 5000 x 2500 x 2100 mm Total weight: approx. 5.7 tons Good condition Transport dimensions: Base machine footprint (L x W x H): 3000 x 2300 x 1900 mm Base machine weight: approx. 4.8 tons Chip conveyor footprint (L x W x H): 4300 x 1200 x 1650 mm Chip conveyor weight: approx. 500 kg Electrical cabinet footprint (L x W x H): 2500 x 550 x 2000 mm Electrical cabinet weight: approx. 450 kg Main motor missing Individual parts available upon request.
