Beli Otomatis Mesin Bubut bekas (77.008)

Kondisi: bekas, Tahun pembuatan: 2006, panjang pembubutan: 205 mm, kecepatan spindel (maks.): 10.000 rpm, kecepatan spindel (min.): 500 rpm, diameter pembubutan: 20 mm, berat keseluruhan: 3.500 kg, lebar total: 1.150 mm, panjang total: 6.850 mm, tinggi total: 1.765 mm, Perlengkapan: dokumentasi / manual, star-ecas-20-de Redpfjzavitjx Anxeu

Kondisi: bekas, NOMOR KATALOG 7650 Data teknis: - panjang kerja maks: 1500 mm - diameter kerja maks: 250 mm - penggilingan (frais cakram): 7,5 kW - spindel – 2800 rpm 3 kW - kecepatan putar spindel: 700/1200/1500/2000 rpm - unit penggerinda: 0,75 kW - motor hidrolik: 3 kW - daya total: 17,75 kW Rodpfxey Uw Smo Anxju - kebutuhan udara: 6-8 bar - feeder untuk balok hingga 150x150 mm - diameter pipa hisap: 100 mm, 160 mm - dimensi pengiriman panjang/lebar/tinggi: 4350x2300x1980 mm - berat sekitar 3000 kg KEUNGGULAN – produksi Jerman – copy lathe hidraulik otomatis – dokumentasi teknis asli DTR – belum dicat ulang – mesin bubut bekas, kondisi sangat baik Harga net: 69.900 PLN Harga net: 16.640 EUR Harga net dihitung dengan kurs 4,2 PLN/EUR (jika terjadi fluktuasi kurs yang signifikan, harga dapat berubah)

Kondisi: baik (bekas), Tahun pembuatan: 2006, Diameter pemesinan maksimum: 20 mm, panjang pemesinan maksimum: 200 mm, diameter pengeboran maksimum: 8 mm, kecepatan spindle: 180 – 7200 rpm, diameter pemesinan belakang maksimum: 16 mm, panjang pemesinan belakang maksimum: 70 mm, kecepatan spindle belakang: 100 – 3600 rpm, motor spindle: 2,2 kW, dilengkapi dengan barfeed, ekstraktor asap, dan konveyor serbuk logam. Rodpfxsza D Hyj Anxou

Kondisi: bekas, Detail Teknis: Lubang spindle: 60 mm Panjang pembubutan: 45 mm Diameter pembubutan maks.: 56 mm Kedalaman bor maks.: 70 mm Putaran: 48 - 1500 (spindle) rpm Pemotongan ulir: putaran: 24 - 750 rpm Revolver alat – jumlah stasiun: 8 Kebutuhan daya total: 5,5 kW Berat mesin sekitar: 2,4 t Kebutuhan ruang sekitar: P:2,1x1,0x1,8 m Mesin bubut otomatis dengan kontrol cam berbasis template. Benda kerja dijepit menggunakan collet. Kepala revolver: disc turret Hahn & Tessky Esslingen, perjalanan alat 80 mm, penyesuaian 36 mm, jarak collet/kepala revolver min./maks.: 72/188 mm 2 unit support pembubutan, panjang kerja 45 mm 2 unit support pemotongan, panjang kerja sekitar 40 mm Sistem pendingin Rjdpfxsu Iwyie Anxeu Mesin belum terhubung. Penjualan dengan harga lepas.

Kondisi: baik (bekas), Tahun pembuatan: 1975, Turret lathe make: HESTIKA Type: HR42 Year: approx. 1975 Max. spindle bore: 42 mm with turret head and Multifix Toolholder Type: B Spindle speeds: 88 - 2800 rpm Rsdpovgbqfofx Anxeu Collet chuck, coolant system, machine documentation included. Machine in good condition.

Kondisi: baik (bekas), Tahun pembuatan: 1965, Turret lathe manufacturer: HESTIKA Type: HR32 Year: approx. 1965 Redpfjvgbphex Anxeu Max spindle bore: 32 mm with tool turret, collet chuck system, Spindle speeds: 200–3200 rpm with coolant system, machine documentation included. Good condition, immediately ready for operation.

Kondisi: baik (bekas), Tahun pembuatan: 2004, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: X12018, berat keseluruhan: 2.850 kg, Perlengkapan: dokumentasi / manual, Karena penghentian produksi, kami menjual mesin otomatis long turning Citizen C32 VIII yang terawat baik, tahun 2004. Perlengkapan: - 2x spindle - alat penggerak - 6 sumbu yang dapat diprogram - 2x sumbu C - konveyor serbuk logam - pemberi batang Iemca (Boss 332 E/R, tahun 2005) - konveyor hasil kerja - lampu sinyal - alat pemadam api Tipe: C32 VIII Nomor produksi: MCL2032/0413 Tahun pembuatan: 2004 Redpfx Aeyl St Sonxeu Berat: 2850 kg Nomor seri: X12018 Opsi pembelian juga tersedia untuk peralatan tambahan (alat penyedot uap oli, centrifuge untuk hasil, kompresor, dll). Jika Anda memiliki pertanyaan tambahan atau membutuhkan informasi lebih lanjut, silakan kirim pesan atau hubungi kami.

Kondisi: baik (bekas), Tahun pembuatan: 2005, Fungsionalitas: berfungsi sepenuhnya, ML26-HU Rsdpfxezavctj Anxou

Kondisi: baik (bekas), Tahun pembuatan: 2004, Fungsionalitas: berfungsi sepenuhnya, maier-ml16-001 Rjdpfx Anszavb Asxou

Kondisi: baik (bekas), Tahun pembuatan: 2003, en Rjdozaud Aspfx Anxou

Kondisi: sangat baik (bekas), Tahun pembuatan: 2018, Fungsionalitas: berfungsi sepenuhnya, CNC long turning automatic lathe | Manufacturer: MAIER | Model: MLK 26F1.5 | Year of manufacture: 2018 The machine can be inspected under power by appointment. Condition: Well-maintained, fully operational / ready for use. Operating hours: approx. 28,797 h. Rodpey Sp Twjfx Anxsu TECHNICAL DATA: - Axes: 11 - Turning diameter over bed: 32 mm - Spindle bore: 32 mm - Channel 1/Z1 > Spindle stroke: 180 mm (as short turning lathe), 340 mm (as long turning lathe) - Main spindle speed: 6,000 rpm - Spindle motor power: 5.5 / 3.7 kW - Channel 2/Z2 > Turning length (sub spindle): 340 mm - Sub spindle speed range: 8,000 rpm - Collets: 1536E - Drive motor power: 5.5 / 3.5 kW - Total power requirement: 28.7 kW, 60 A - Machine weight approx.: 4.4 t - Space requirement approx.: 8.0 x 2.7 x 2.1 m EQUIPMENT: - CNC control: FANUC 31i-B - 1 pc. sub spindle - NC C-axis on main and sub spindles - Tool holders for 5 fixed turning tools, cross-section 16 x 16 mm - Bar feeder, make FMB Turbo Ø 3-36, year of manufacture: 2018 Guide channel DM12 - Chip conveyor - Electronic handwheel - High-pressure system, make KNOLL, 50 bar with paper band filter system - Fire protection system, make KRAFT & BAUER - Extraction system - CE marking - Documentation Additional accessories available for separate purchase. No guarantee for completeness and accuracy of the technical details and equipment features. - Subject to prior sale -

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2020, Fungsionalitas: berfungsi sepenuhnya, CNC long turning machine | Manufacturer: MAIER | Model: ML 20 C5Y2 Basic | Year of manufacture: 2020 The machine can be inspected under power by appointment. Condition: Fully functional, well-maintained / ready for operation. Operating hours: approx. 19,498 h TECHNICAL DATA: - Axes: 8 - Swing over bed: 32 mm - Spindle bore: 20 mm - Channel 1/Z1 > Spindle stroke: 220 mm - Main spindle speeds: 8,000 rpm - Spindle motor: 5.5 / 3.7 kW - Counter spindle bore: 20 mm - Counter spindle speed range: 8,000 rpm - Channel 2/Z2 > Turning length (counter spindle): 240 mm Redpfx Aey Sp Smenxju - Collets: 161E - Drive motor power: 5.5 / 3.5 kW - Total power consumption: 19.4 kW / 35 A - Machine weight: approx. 4.2 t - Space requirement: approx. 8.0 x 2.7 x 2.2 m EQUIPMENT: - Control: FANUC 31i-B - 1 pc. counter spindle - NC C-axis on main and counter spindle - Guide channel DM12 - Tool holders for 5 fixed turning tools, cross-section 12 x 12 mm - Bar feeder, make: FMB Turbo Ø 3–36, year: 2020 - Chip conveyor - Electronic handwheel - KNOLL high-pressure unit (50 bar) with paper band filter system - Fire suppression system, make: Kraft & Bauer - Extraction unit - CE marking - Documentation Additional accessories available for purchase. No guarantee for completeness or accuracy of the technical data and equipment. Subject to prior sale.

Kondisi: baik (bekas), Tahun pembuatan: 2004, Mesin dalam kondisi teraliri listrik dan dapat diperiksa Rsdpsy Eb Rhefx Anxeu

Kondisi: baik (bekas), Tahun pembuatan: 2002, Mesin dalam kondisi baik dengan kontrol Fanuc Series 16i-T, dilengkapi dengan feeder batang otomatis FMB Turbo 5-42. Redpsy Eb N Dofx Anxju

Kondisi: Pembawa suku cadang rusak (bekas), Tahun pembuatan: 1987, Fungsionalitas: belum diuji, nomor mesin/kendaraan: 652, lebar total: 1.250 mm, panjang total: 2.050 mm, tinggi total: 1.450 mm, TRAUB TB single-spindle automatic lathe – defective / for spare parts For sale: used single-spindle automatic lathe TRAUB type TB. The machine is being sold explicitly as defective or untested. Sale exclusively as a project for hobbyists, a source of spare parts, or for refurbishment. The machine was taken out of service for safety and age reasons. No guarantee concerning function, accuracy, or occupational safety. TRAUB automatic lathes are robust mechanical production machines designed for series production and automatic turned parts, known for their solid cast construction and durable mechanics. Technical data Manufacturer: TRAUB Type: TB Machine type: Single-spindle automatic lathe Control: Mechanical / cam-controlled Field of application: Series production of turned parts Material feeding via bar stock Multiple tool slides Coolant system available Three-phase power connection Compressed air required depending on configuration Condition Used Sold explicitly as defective Untested condition Ideal as a spare parts donor or restoration project Rjdoy Uq Stjpfx Anxou No warranty No returns On-site inspection expressly recommended Loading and transport by buyer Note Year of manufacture, exact configuration, and accessories according to photos or nameplate. Sale is made excluding any liability for material defects.

Kondisi: bekas, Tahun pembuatan: 1989, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 119, daya motor spindle: 5 W, panjang pembubutan: 160 mm, kecepatan spindel (maks.): 6.000 rpm, kecepatan spindel (min.): 99 rpm, diameter pembubutan: 16 mm, berat keseluruhan: 2.300 kg, jenis arus masuk: tiga fasa, saluran batang: 16 mm, lebar total: 1.340 mm, panjang total: 1.850 mm, tinggi total: 1.685 mm, tegangan masuk: 380 V, Jumlah stasiun alat bermotor di turret alat 1: 6, Jumlah stasiun alat bertenaga di turret alat 2: 6, Perlengkapan: dokumentasi / manual, kecepatan rotasi dapat diubah tanpa batas, Dijual mesin bubut panjang saya, beserta aksesoris yang terlihat di gambar. Dilengkapi dengan penyedia batang dan konveyor serpihan. Kontroler mesin merek Yasnac. Mesin ini memiliki dua kepala revolver, sehingga mampu melakukan kontrol Multi-axis dan Multi-group. Rsdpjy Udcfjfx Anxeu

Kondisi: baru, Tahun pembuatan: 2023, Fungsionalitas: berfungsi sepenuhnya, Hydrafeed Top Fusion Bar Feeder otomatis 3,2 meter. Dibuat pada 2023, namun belum pernah digunakan atau dipasangkan ke mesin, sehingga masih sebagian besar dalam kemasan asli. Dapat menampung batangan hingga panjang 3,2 m dengan penyesuaian otomatis untuk diameter batang dari 8mm sampai 51mm. Kami tidak memiliki cukup ruang di gedung baru untuk dipasangkan ke mesin DMG turnmill kami, sehingga harus membeli versi 1,5 meter. Harga baru £28,750 + VAT, jadi lebih dari 40% penghematan dari harga daftar untuk mesin yang masih benar-benar baru. Rodpfx Anjvzzzmjxju

Kondisi: bekas, Tahun pembuatan: 2001, Fungsionalitas: berfungsi sepenuhnya, Diameter batang (maks.): 32 mm, INDEX MS32P CNC Multi-Spindle Tahun Pembuatan: 2001 Nomor Seri: 150127 Bar Feeder: IEMCA SIR-MS32/33/P (3 Meter) Kontrol: Siemens 840D Konveyor Serpihan Knoll Terintegrasi Unit Filtrasi Tekanan Tinggi Knoll Eksternal 6 Spindel Kapasitas 32mm Rjdpfey Ruu Dex Anxsu 1 Sinkron Konfigurasi Performa Tinggi 6+1 Kemampuan Back-Working: Dilengkapi dengan spindel sinkron yang dapat berputar untuk pemesinan bagian belakang secara simultan. Proses Selesai pada Satu Mesin: Memungkinkan pengeboran, tapping, dan milling pada sisi cutoff saat bagian berikutnya sedang dikerjakan di spindel utama, menghasilkan produk jadi secara langsung. Keunggulan Quill "P": Model "P" menggunakan quill hidrostatik (sumbu Z).

Kondisi: bekas, Tahun pembuatan: 2005, CNC Mitsubishi Mieldas 635 LC Maximum machining diameter: Ø 32 mm (from Ø 10 mm) Maximum machining length: 320 mm with chuck Maximum frontal drilling diameter: Ø 12 mm Maximum frontal tapping diameter: M10 (tap), M8 (die) Spindle through-hole diameter: Ø36 mm Main spindle speed: from 200 to 8,000 rpm Main spindle speed change: Continuous, S + 4-digit numeric value Main spindle indexing: 1° Rjdsy Uvy Aopfx Anxeu Main spindle C-axis resolution: 0.001° Maximum chuck diameter (sub spindle): Ø 32 mm Maximum part length for pick-off operation: 145 mm from sub spindle Maximum part overhang: 25 mm from sub spindle Maximum drilling diameter in sub-spindle process: Ø 10 mm Maximum tapping diameter in sub-spindle process: M8 Sub spindle speed: from 200 to 7,000 rpm Sub spindle speed change: Continuous, S + 4-digit numeric value Sub spindle indexing: 1° Sub spindle C-axis resolution: 0.001° Tool spindle Maximum tapping diameter: Ø 7 mm Spindle speed (tapping): M6 Spindle speed range: 200 to 5,000 rpm, continuous, S + 4-digit numeric value Opposite tool holder Maximum drilling diameter: Ø 7 mm Maximum tapping diameter: M6 Spindle speed range: 200 to 4,500 rpm Spindle speed change: Continuous, S + 4-digit numeric value Collet and chuck models Main spindle collet: MC081-M Guide bushing: FG531-M Rego type collet: ER16/AR16 Sub spindle collet: FC081-M-K Number of tools: Up to 18 tools + α Tool dimensions Tool (multi-tool holder): 16 x 169 x 130 mm Sleeve (opposite tool holder): Ø 25.4 mm Maximum tool diameter for powered tools mounted in the turret Front drilling/milling tool: Ø 10 mm Rapid feed rate: 20 m/min Minimum programmable increment: X1 axis: 0.001 mm Y1 axis: 0.001 mm Z1 axis: 0.001 mm X2 axis: 0.001 mm Z2 axis: 0.001 mm Z3 axis: 0.001 mm Axis travel X1 axis: 108 mm Y1 axis: 275 mm Z1 axis: 325 mm X2 axis: 228 mm Z2 axis: 130 mm Z3 axis: 410 mm Bar length: 2,500 mm Center height: 1,132 mm IEMCA BOSS 332-E BAR FEEDER INCLUDED The machine is supplied complete with manuals and CE Declaration of Conformity. All technical data stated are indicative and may be subject to change without prior notice; therefore, they are not binding.

Kondisi: sangat baik (bekas), Tahun pembuatan: 2018, 2018 Citizen Miyano BNA-42DHY3 mit Fanuc Series Oi-TF Steuerung & Iemca KID 80/16 Stangenlader Doppelspindel, Doppelturm. Achsen 'X, Y, Z' (Hauptspindel) + Subspindelachsen. Bearbeitungsfähigkeit: Simultane Vorder-/Rückseitenbearbeitung (Superimposed Machining). Maximale Rohteillänge: 100 mm. Maximale Stangendurchmesser Hauptspindel: Ø42 mm, Subspindel: Ø34 mm. Verfahrwege Achsen: 'X1'=140 mm, 'Z1'=235 mm, 'Y'=70 mm (±35 mm), 'X2'=140 mm, 'Z2'=360 mm. Anzahl der Spindeln: 2 (Haupt- + Subspindel). Maximale Drehzahl Hauptspindel: 6.000 U/min (7,5/5,5 kW Motor), Subspindel: 5.000 U/min (5,5/3,7 kW Motor), Maximale angetriebene Werkzeugdrehzahl: 5.000 U/min (1 kW Motor). 'C'-Achse serienmäßig auf beiden Spindeln (0,001°-Auflösung). Hauptrevolver mit 8 Stationen, Subrevolver mit 6 Stationen. Drehmeißelaufnahme 20 x 20 mm. Innenwerkzeugaufnahme Ø25 mm. Revolverschaltzeit ca. 0,2 s. Betriebsstunden: 3.696. /Nr. DW 1241 (2018/09) Rjdpey U H Ttsfx Anxeu Mit Iemca KID 80/16 Typ 16 Stangenlader. S/Nr. 021927QA01 (2019), Cromar Späneförderer, Kühlsystem, Teilefänger, Teileförderband, Satz angetriebener/stehender Werkzeughalter, Spannzangen, Signalturm und Handbücher. Gesamtmaße L2.240 x B1.450 x H1.680 mm. Gewicht: 3.100 kg.

Kondisi: bekas, TECHNICAL DATA - Number of spindles: 6 - Number of sub-spindles: 1 SPINDLES - Max. bar diameter: 22 [mm] - Spindle speed: 10,000 [rpm] - Spindle drive power: 8.5/15 [kW] NUMERICAL AXES - Slide unit 1.1: X and Z axes controlled by CNC - Slide unit 1.2: X and Z axes controlled by CNC - Slide unit 2.1: X and Z axes controlled by CNC - Slide unit 2.2: X and Z axes controlled by CNC - Slide unit 3.1: X and Z axes controlled by CNC - Slide unit 3.2: X and Z axes controlled by CNC - Slide unit 4.1: X and Z axes controlled by CNC - Slide unit 4.2: X and Z axes controlled by CNC - Slide unit 5.1: X and Z axes controlled by CNC - Slide unit 5.2: X and Z axes controlled by CNC - Slide unit 6.1: Z axis controlled by CNC - Slide unit 6.2: X and Z axes controlled by CNC ELECTRICAL SUPPLY - Supply voltage: 380 [V] - Total drive power: 77 [kW] WEIGHT AND DIMENSIONS - Footprint: 3329 x 2032 [mm] - Machine height: 2654 [mm] - Machine weight: 7100 [kg] MACHINE HOURS - Power-on hours: 36,508 [h] - Operating hours: 26,721 [h] - Spindle hours: 20,860 [h] EQUIPMENT - Control: Siemens 840D SL - Dual NCU - Machining force monitoring: ARTIS - Chip conveyor - Coolant tank * with high-pressure pump: 80 [bar] Rjdpfxeyzi Ums Anxou - Bar feeder: IEMCA SIR mS22P/33 - Fire extinguishing system * * NB: Functionality not guaranteed. Inspection by a qualified company on the buyer's side is recommended. - Electrical transformer

Kondisi: diremaj di bengkel (bekas), Tahun pembuatan: 2019, Fungsionalitas: berfungsi sepenuhnya, cnc-gildemeister-sprint-20-8 Redsy Rngajpfx Anxou

Kondisi: diremaj di bengkel (bekas), Tahun pembuatan: 2016, Fungsionalitas: berfungsi sepenuhnya, CNC long-turning automatic lathe GILDEMEISTER SPRINT 20/8 linear Equipped with Fanuc 31i control Year of manufacture: 2016 Spindle bore: 20 mm MAIN SPINDLE Max. turning diameter: 20 mm Speed range: max. 10,000 rpm Z1 stroke: 80 mm SUB SPINDLE Max. turning diameter: 20 mm Z2 stroke: 300 mm Speed: max. 10,000 rpm SLIDE 1 X1 stroke: 50 mm Y1 stroke: 350 mm 6-position tool holder 12 x 12 5 live tools including spindles with ESX 16 collet chuck SLIDE 2 X2 stroke: 240 mm 4-position tool holder for external machining with 12 x 12 interface 4-position tool holder for internal machining, diameter 20 mm 5 live tools including spindles with ESX 16 collet chuck 6 + 2 axes, 2 Y-axes standard Linear drive for maximum precision Includes the following accessories: Full enclosure with internal lighting Various tool holders C-axis for main and sub spindle Bar feeder LNS Quick Load Servo 80 S2 Part discharge conveyor Hinged belt chip conveyor 4-color signal tower Rodpfx Aey Rm Snonxsu Fire extinguishing system Coolant unit 250 l (Pump capacity 120 l/min, 1.5 bar) THE MACHINE IS IN EXCELLENT CONDITION!! THE MACHINE HAS ONLY 4,426 PROGRAM RUNNING HOURS!!

Kondisi: baik (bekas), Tahun pembuatan: 2009, Fungsionalitas: berfungsi sepenuhnya, CNC Swiss-Type Lathe Manufacturer: Traub Model: TNL 12 Control: Traub Year of manufacture: 2009 TECHNICAL DATA Headstock - Max. bar diameter (mm): 12.7 - Quality of bar material (DIN 671) (mm): Ø Xh9 - Max. spindle speed (rpm): 12,000 Max. turning length / headstock stroke - With fixed guide bush (mm): 130 - With rotating guide bush (mm): 80 - With programmable guide bush (mm): 80 C-axis resolution (degrees): 0.001 Rapid traverse Z1 (m/min): 30 Tool Carrier 1 - Travel X1 (mm): 35 - Travel Y1 (mm): 38 (-10 +28) - Rapid traverse X1 / Y1 (m/min): 15 - Chip-to-chip time (s): 0.3 Tool Carrier 2 - Travel X2 (mm): 35 - Travel Z2 (mm): 50 - Rapid traverse X2/Z2 (m/min): 15 - Chip-to-chip time (s): 0.3 Driven Tool for Tool Carrier 1 and 2 - Max. speed (rpm): 8,000 - Max. tools (quantity): 2xG - Clamping diameter for drilling tools (mm): 0.5–7 Subspindle / Front Attachment - Max. bar diameter (mm): 12.7 - Max. longitudinal stroke 23, 24 / Xg (mm): 140 | 228 - Rapid traverse 23,24/X3 (m/min): 30 - Tool stations (quantity): 4 - Max. speed (rpm): 12,000 - C-axis resolution (degrees): 0.001 Rear Tool Device, Dragged / Stationary - Z-stroke dragged with working spindle (mm): 80 - Tool holder diameter (mm): 20 - Tool stations (quantity): 3 Rear Tool Device (X4 Axis) - X4 stroke (mm): 39 - Rapid traverse (m/min): 15 Rjdpfx Ansy N A S Usxju - Tool holder diameter (mm): 28 - Tool stations (quantity): 4 Driven Tool Unit for Rear Device (with X4 Axis) - Max. speed (rpm): 10,000 - Driven tool stations (quantity): 4 - Clamping diameter for drilling tools - Driven (mm): 0.5–7 - Non-driven (mm): 0.5–10 Coolant System - Pump pressure, single stage (bar): 3 - Tank capacity (l): 180 - Delivery rate (l/min): 40 FEATURES - Chip conveyor - Bar feeder FMB Minimag 18 - High-pressure coolant system - Fire extinguishing system Subject to technical changes and errors.

Kondisi: baik (bekas), Tahun pembuatan: 2007, Fungsionalitas: berfungsi sepenuhnya, CNC Swiss-Type Lathe Manufacturer: Traub Machine Model: TNL 12 Control: Traub Year of Manufacture: 2007 TECHNICAL DATA Headstock - Max. bar diameter (mm): 12.7 - Quality of round material (DIN 671) (mm): Ø Xh9 - Max. spindle speed (rpm): 12,000 Max. turning length / headstock stroke - with fixed guide bushing (mm): 130 - with rotating guide bushing (mm): 80 - with programmable guide bushing (mm): 80 C-axis resolution (degrees): 0.001 Rapid traverse Z1 (m/min): 30 Tool Carrier 1 - X1-axis travel (mm): 35 - Y1-axis travel (mm): 38 (-10 +28) - Rapid traverse X1 / Y1 (m/min): 15 - Chip-to-chip time (s): 0.3 Tool Carrier 2 - X2-axis travel (mm): 35 - Z2-axis travel (mm): 50 - Rapid traverse X2/Z2 (m/min): 15 - Chip-to-chip time (s): 0.3 Driven Tool for Tool Carrier 1 and 2 - Max. speed (rpm): 8,000 - Max. tools (qty): 2xG - Clamping diameter for boring tools (mm): 0.5–7 Sub-Spindle / Front Attachment - Max. bar diameter (mm): 12.7 - Max. longitudinal stroke 23, 24 / Xg (mm): 140 | 228 - Rapid traverse 23,24/X3 (m/min): 30 - Tool positions (qty): 4 - Max. speed (rpm): 12,000 - C-axis resolution (degrees): 0.001 Backworking Attachment, Synchronized / Fixed - Z-axis stroke, synchronized with working spindle (mm): 80 - Tool holder diameter (mm): 20 - Tool positions (qty): 3 Backworking Attachment (X4-Axis) - X4-axis stroke (mm): 39 - Rapid traverse speed (m/min): 15 - Tool holder diameter (mm): 28 - Tool positions (qty): 4 Driven Tool for Backworking Attachment (with X4-Axis) - Max. speed (rpm): 10,000 Rjdjy N A Atjpfx Anxeu - Max. driven tools (qty): 4 - Clamping diameter for boring tools - driven (mm): 0.5–7 - non-driven (mm): 0.5–10 Coolant System - Single-stage pump pressure (bar): 3 - Tank capacity (l): 180 - Delivery rate (l/min): 40 FEATURES - Chip conveyor - FMB Minimag 18 bar feeder - High-pressure system - Fire extinguishing system Subject to changes and errors in technical specifications and details.
