Beli Masterwood Project 327 bekas (42)

Kondisi: baru, Maximum workpiece length: 4,400 mm Milling spindle: 1 unit Main motor: 19.2 kW CNC machining center MASTERWOOD 4 WIN with automatic loading and unloading ----- Specially designed for efficient and flexible window and door production in wood processing HIGHLIGHTS: - Multiple tool magazines for optimal tool configuration - Simultaneous processing of up to 6 workpieces - Patented clamping system for optimal workpiece processing - CNC-controlled worktable with automatic positioning of beams and clamps - Automatic reclamping for switching between exterior and interior profiling - INTEGRATED window construction software (machine can be operated directly or, optionally, via external industry software from the office) - Powerful 19.2 kW HSK-63 E motor - Infeed and outfeed conveyors - Auxiliary table for arch window production and door leaf processing Request an offer and see for yourself the unbeatable price-performance ratio! Kodpfsd Nv Dcex Aahjfa VIDEO of the machine attached! The technical description of the machine is provided in the PDF document next to this listing. We would be happy to accept your used machine as a trade-in at a fair price! (Technical specifications according to manufacturer's information - subject to confirmation!)

Kondisi: sangat baik (bekas), Fungsionalitas: berfungsi sepenuhnya, Point-to-point CNC drilling machine MASTERWOOD SPEEDY 207 Used machine Designed for custom furniture manufacturing, kitchen furniture, bathroom furniture, and various applications Drilling head with 5 independent vertical chucks and 1 dual horizontal chuck Saw unit for longitudinal cuts Machine table with a drilling capacity of 1390 x 750 mm and two lateral pneumatic reference stops, controlled by the CNC unit, enabling processing of panels up to 2800 x 750 mm in a single cycle with an intermediate stop Capability to drill panels up to 2800 mm in length Pneumatic tool stroke: 60 mm Max. panel thickness: 50 mm Spindle speed: 4500 rpm Saw speed: 6000 rpm Vacuum pump motor: 1.5 HP Vacuum cup diameter: 80 mm Front stop complete with 4 locking cylinders for drilling narrow workpieces and strips Multitasking CNC control unit complete with interactive graphical programming, 9” display, drilling programs, work cycle optimization, graphic, parametric, and diagnostic modes Kedpfx Aewd Irvoahofa Overall dimensions – machine: 2500 x 1800 x 1800 mm (H) – Weight: 850 kg Overall dimensions – control cabinet: 800 x 520 x 1200 mm – Weight: 120 kg

Kondisi: bekas, Tahun pembuatan: 2004, Mesin untuk pengeboran dan pemasangan fitting anuba dengan 2 sumbu CNC Ksdpfxsw Uf Rie Aahofa

Kondisi: seperti baru (mesin pameran), Tahun pembuatan: 2021, The PROJECT TF 600 S machining center was developed for efficient carcass production. Technical specifications: Axes: X-axis: Max. workpiece length: 2,800 mm Min. workpiece length: 200 mm Traversing speed: 130 m/min. Y-axis: Max. workpiece width: 1,200 mm Min. workpiece width: 50 mm Traversing speed: 75 m/min. Z-axis: Max. workpiece thickness: 60 mm Min. workpiece thickness: 8 mm Traversing speed: 30 m/min. Units for 6-sided processing: 1. Upper drilling unit: Vertical spindles in X-direction: 7 pcs Vertical spindles in Y-direction: 5 pcs Horizontal twin drilling spindle in X-direction: 2+2 pcs Horizontal twin drilling spindle in Y-direction: 1+1 pcs Spindle spacing: 32 mm Spindle speed: 3,400 rpm Motor: 2.2 kW 2. Upper drilling unit: Vertical spindles in X-direction: 7 pcs Vertical spindles in Y-direction: 5 pcs Horizontal twin drilling spindle in X-direction: 2+2 pcs Horizontal twin drilling spindle in Y-direction: 1+1 pcs Spindle spacing: 32 mm Spindle speed: 3,400 rpm Motor: 2.2 kW 3. Upper grooving saw in X-direction: Speed: 3,400 rpm Max. saw blade diameter: 120 mm Groove position: between 55 and 800 mm 4. Upper milling unit: For milling and grooving Motor: 3.5 kW Collet: ER 25 Max. tool diameter: 16 mm 5. Lower milling unit: For milling and grooving Motor: 3.5 kW Collet: ER 25 Max. tool diameter: 16 mm 6. Lower drilling unit: Vertical spindles in X-direction: 3 x 3 pcs Kfodpsw Ugpyofx Aahea Spindle spacing: 32 mm Spindle speed: 3,400 rpm Control via Windows PC Software: MASTERWORK-MACHINE-VERSION Mobile control panel with color display, keyboard, and mouse Wireless barcode reader Additional features: - Intelligent, patented worktable: The worktable automatically moves up/down and left/right to provide optimal contact surface for all drilling and milling operations. Through-feed drilling and milling are also possible. - Controlled workpiece hold-down device - Energy-efficient air cushion tables using an integrated fan (instead of external compressed air) - Rack and pinion drive on X and Y axes and linear guides - Ball screw on Z-axis and linear guides - CE safety devices: light barrier and safety fence, as well as two clamping pressure stages - Automatic central lubrication Further data: Dimensions: 5,280 x 2,480 x 2,190 mm (LxWxH) Extraction ports: 2 x 200 mm, 1 x 100 mm Required air pressure: 8 bar

Kondisi: baru, Tahun pembuatan: 2020, jam operasional: 1 h, de SWISS KRONO Kft. bietet die CNC-Bohr- und Fräsmaschine MW2131KS von Masterwood an. Als Anhang fügen wir die Beschreibung der Maschinen sowie zusätzliche Bilder und Informationen in einem freigegebenen Ordner bei. Kfodpjrxubwefx Aahja en SWISS KRONO Kft. offers the CNC drilling and milling machine MW2131KS from Masterwood. As an attachment, we are including the machine description as well as additional images and information in a shared folder.

Kondisi: sangat baik (bekas), 23 spindles left/right spindles 3 pneumatic clamps Kfedjw Adwrspfx Aahoa spindle pitch 32 mm pedal control CE marking 380V power supply

Kondisi: bekas, Maximum workpiece length 4400 mm Milling spindle 1 unit Main motor 19.2 kW Control Beckhoff CNC machining center MASTERWOOD 4 WIN ----- Specifically designed for efficient and flexible production of wooden windows and doors HIGHLIGHTS: - Various tool magazines for optimal tool configuration - Simultaneous loading of 4 workpieces - Patented clamping system for optimal processing of workpieces - CNC-controlled work table with automatic positioning of beams and clamps - Automatic reclamping for switching between exterior and interior profiling - INTEGRATED window manufacturing software, meaning the machine does not have to (but can, of course) be operated from the office with external industry software - Powerful 19.2 kW HSK-63 E motor Please note that this stock machine is located with us in Oberkochen and is already equipped with many useful options. Tools available at short notice upon request! Request a quote and see for yourself the unbeatable price-performance ratio! VIDEO of the machine available on request! Kfjdpjt Tqxzofx Aahsa Enclosed you will find the technical description of the machine as a PDF document. We would also be pleased to take your used machine in part exchange at a fair price! Suitable stationary or mobile extraction systems available on request (see e.g. #5674 NESTRO NE 300) Suitable compressor available on request (#5997 Kaeser Aircenter SM 15) (Technical data as per manufacturer – subject to change!)

Kondisi: siap digunakan (bekas), Technische Daten Leistung und Motoren Spannung: 380 V Anschluss: Drehstrom Leistung: 2,2 kW Motor: 3 PS Gesamtabmessungen Länge: 840 mm Breite: 780 mm Höhe: 1850 mm Gewicht: 340 kg Kjdpst Dgavjfx Aahofa

Kondisi: baik (bekas), Tahun pembuatan: 2000, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 00110033, Year of manufacture: 2000. X-axis travel: 3200 mm, Y-axis: 1250 mm, Z-axis: 150 mm. Milling spindle: 8 kW, 24,000 rpm, ISO 30. Drilling head: vertical drills on X-axis – 8 units, vertical drills on Y-axis – 3 units, double horizontal drills on X-axis – 2 units, double horizontal drills on Y-axis – 1 unit. Vacuum pump: 100 m³/h. Additional details available in the attached documentation. Kfjdpfev Hbzwex Aahea

Tahun pembuatan: 2023, Kondisi: baru, nomor mesin/kendaraan: 28086221201 (AABM0013), MASTERWOOD CNC Processing Centre Type PROJECT TF 100 2.0 "PARTNERSHIP EDITION" - MAST0337 Technical Specifications: Axes: X-Axis: Max. workpiece length: unlimited Min. workpiece length: 250 mm Travel speed: 0-25 m/min. Y-Axis: Max. workpiece width: 1,000 mm for all units Min. workpiece width: 85 mm Travel speed: 0-50 m/min. Z-Axis: Max. workpiece thickness: 60 mm Min. workpiece thickness: 10 mm Travel speed: 0-20 m/min. Units: 16-position drilling head: Vertical spindles in X-direction: 5 pcs Vertical spindles in Y-direction: 5 pcs Horizontal double drilling spindle in X-direction: 2+2 pcs Horizontal double drilling spindle in Y-direction: 1+1 pcs Drill spindle pitch: 32 mm Spindle speed: 4,000 rpm Motor: 1.7 kW Grooving saw: in X-direction Speed: 4,000 rpm Max. saw blade diameter: 125 mm Motor: 1.7 kW (grooving saw is integrated in the drilling head) Control System: Personal Computer Operating system: Windows 10 Pro - 64 bit Processor: Intel Hard disk with min. 300 GB storage CD-ROM drive Colour monitor Integrated video card 2 Ethernet cards Software: MASTERWORK MACHINE VERSION Kjdpfeiukvkex Aahsfa Additional Data: Required air pressure: 8 bar Air consumption: max. 750 l/min. Extraction: Volume: 2,000 m³/h Air speed: 25 - 30 m/sec. Extraction port: 1 x 150 mm Further equipment features: - Air flotation tables at working area - Roller table at infeed and outfeed - Board measurement sensor - Ball screw and linear guides - Rack and pinion drive - DXF file import (Operating manual, wiring and pneumatic diagrams included in digital format) "PARTNERSHIP EDITION" consists of: Milling unit, incl. MASTERWORK software expansion Speed: 1,000 to 18,000 rpm Motor: 4.5 kW with ISO 30 interface Includes integrated extraction control (only the drilling head is extracted during drilling, only the milling unit during milling) 6-position tool changer 3 pcs ISO 30 collet chucks incl. collet Tooling set, consisting of: HW Dowel drills: 5 pcs 5mm – overall length 70 mm – blind hole drill 1 pc 5mm – overall length 70 mm – through hole drill 4 pcs 8mm – overall length 57.5 mm – blind hole drill 2 pcs 10mm – overall length 57.5 mm – blind hole drill 1 pc 10mm – overall length 70 mm – blind hole drill 1 pc 8mm – overall length 70 mm – blind hole drill 1 pc 15mm – overall length 70 mm – blind hole drill 1 pc 35mm – overall length 70 mm – blind hole drill 1 HW grooving saw blade d=125 mm, bore=20 mm, width: 4.0 mm, Z=35 WSA 1 DIA cutter, right – overall length 103 mm, working length 43 mm, D=18 mm, shank: 20x50 mm, Z 1+1 1 DIA cutter, left – overall length 103 mm, working length 43 mm, D=18 mm, shank: 20x50 mm, Z 1+1 1 VHW reversible tip finish cutter, right, D=10 mm Folding roller conveyor at infeed Folding roller conveyor at outfeed Automatic central lubrication Plus options: Complete package for CLAMEX connectors € 3,500.00 Complete door package € 3,500.00 PaletteCAD start software package + CAM interface € 3,000.00 Freight, installation, commissioning € 3,000.00 Available immediately ex location Seevetal Subject to prior sale.

Kondisi: baru, en_MASTERWOOD CNC machining center model PROJECT TF 100 2.0 "PARTNERSHIP EDITION" – MAST0337 The Masterwood CNC machining center PROJECT TF is ideal for complex CNC processing within a minimal space, suitable for solid wood, panel materials, or other substrates. Advantages: - Extremely compact footprint - Maximum time savings thanks to extremely fast production cycles - Rapid ROI due to low acquisition costs - Easy-to-learn technology for fast operator training - Clean workpieces even with low extraction power, as machining is done from below - Exceptionally fast, simple, and flexible programming with MASTERWORK software (standard) - Extremely fast and easy programming of complete cabinets using Palette CAD (optional) Kfjdovwf Iijpfx Aahoa Technical Specifications: Axes: X-axis: Maximum workpiece length: unlimited Minimum workpiece length: 250 mm Traverse speed: 0–25 m/min Y-axis: Maximum workpiece width: 1,000 mm for all units Minimum workpiece width: 80 mm Traverse speed: 0–50 m/min Z-axis: Maximum workpiece thickness: 60 mm Minimum workpiece thickness: 10 mm Traverse speed: 0–20 m/min Note: Minimum and maximum workpiece sizes depend on weight and length-to-width ratio! Machining Units: 16-spindle drilling head: Vertical spindles in X direction: 5 Vertical spindles in Y direction: 5 Horizontal double drilling spindle in X direction: 2+2 Horizontal double drilling spindle in Y direction: 1+1 Spacing of drilling spindles: 32 mm Drilling spindle speed: 4,000 rpm Motor: 1.7 kW Grooving saw: X direction Speed: 4,000 rpm Max. saw blade diameter: 125 mm Motor: 1.7 kW (grooving saw integrated in the drilling head) Control system: - Personal computer - Processor: Intel Core i3-8100 CPU, 3.60 GHz - RAM: 8 GB - Hard disk: 300 GB - CD-ROM drive - Color monitor - Integrated video card - 2 Ethernet cards - Operating system: Windows 10 Pro – 64 bit - Program: MASTERWORK MACHINE VERSION Further specifications: Required air pressure: 8 bar Air consumption: max. 750 l/min Dust extraction: Volume: 2,000 m³/h Airspeed: 25–30 m/sec Extraction connector: 1 x 150 mm Additional equipment features: - Air tables at work area - Infeed and outfeed roller tables - Panel measuring sensor - Recirculating ball screw and linear guides - Rack-and-pinion drive - DXF file import (Operation manual, circuit diagram, and pneumatic plan included in digital format) "PARTNERSHIP EDITION" includes: Milling unit, incl. MASTERWORK software extension - Speed: 1,000 to 18,000 rpm - Motor: 4.5 kW, ISO 30 tool holder - Integrated extraction control (dust extraction only at the position of the active unit: drilling head during drilling, milling unit during milling) - 6-position tool changer - 3 ISO 30 collet chucks incl. collet Tooling package consisting of: HW dowel drill bits: 5 pcs. 5 mm – total length 70 mm – blind hole drill 1 pc. 5 mm – total length 70 mm – through hole drill 4 pcs. 8 mm – total length 57.5 mm – blind hole drill 2 pcs. 10 mm – total length 57.5 mm – blind hole drill 1 pc. 10 mm – total length 70 mm – blind hole drill 1 pc. 8 mm – total length 70 mm – blind hole drill 1 pc. 15 mm – total length 70 mm – blind hole drill 1 pc. 35 mm – total length 70 mm – blind hole drill 1 HW grooving saw blade d=125 mm, bore=20 mm, width: 4.0 mm, Z=35 WSA 1 DIA milling cutter, right-hand – total length 103 mm, cutting length 43 mm, D=18 mm, shank: 20x50 mm, Z 1+1 1 DIA milling cutter, left-hand – total length 103 mm, cutting length 43 mm, D=18

Kondisi: baru, Fungsionalitas: berfungsi sepenuhnya, Versatile high-speed solution for furniture production and more 9 controlled axes High axis speeds: 130 m/min / X-axis 75 m/min / Y-axis Processing of even the smallest parts (from 70x35 mm) True 6-sided machining 2 automatic, independently controlled clamping vices Horizontal processing also possible from the vice side 3 independent drilling heads with a total of 47 drilling spindles Grooving saw unit Milling spindles above and below Air cushion table in infeed and working area Kedpfx Aetu I Ntjahofa Panel return system at outfeed Barcode scanner

Kondisi: diremaj di bengkel (bekas), Tahun pembuatan: 2008, Fungsionalitas: berfungsi sepenuhnya, tinggi benda kerja (maks.): 140 mm, lebar meja: 1.250 mm, panjang meja: 3.200 mm, kecepatan rotasi (min.): 1.500 rpm, kecepatan rotasi (maks.): 24.000 rpm, berat keseluruhan: 3.000 kg, jumlah slot dalam magazin alat: 12, berat alat: 6 g, Perlengkapan: kecepatan rotasi dapat diubah tanpa batas, Masterwood Projekt 300M Nesting machine Werkbereik 3200 x 1250 mm Elektrospindel 12,5 pk Kedpfxew Dtnpj Aahefa Gereedschapswisselaar met 12 posities 250 m³ Becker vacuümpomp Boorkop met verticale en horizontale boren Zaagunit in X-richting Bouwjaar 2008 Windows besturingssysteem Masterwork CAD-CAM systeem Mobiele bediening Machine volledig nagekeken en werkend

Kondisi: siap digunakan (bekas), Technische Daten Vertikalhub des Kopfes: 150 mm Max. Werkstückhöhe: 180 mm Max. Zapfenlänge: 260 mm Querhub des Kopfes: 70 mm Min./Max. Türhöhe: 740 bis 1030 mm Arbeitstischmaße: 470 x 140 mm Tischneigung: von -45° bis +45° Türanschlag Automatische Kettenschmierungspumpe Manueller Vertikalhub Stromversorgung und Motoren Spannung: 380 V Anschluss: Drehstrom Kedpfxot Dga Ao Aahjfa Leistung: 2,2 kW Motor: 3 PS Abmessungen Länge: 840 mm Breite: 780 mm Höhe: 1850 mm Gewicht: 340 kg

Kondisi: siap digunakan (bekas), Technische Merkmale Einheit für Bohr-, Schraub- und Anubascharniersetzer Montiert auf Schwenkarm -10 bis 90° CNC-gesteuert Schlittenführung: THK Bohraggregat: 9 PS 3000/24000 U/min Auf Schwenkarm -10 bis 90° CNC-gesteuert Werkzeugwechsler, 7 Werkzeugaufnahmen 6 Werkstückauflagen mit Saugern und Spannvorrichtungen Schlösser – Dübel – Schließbleche – Schließplatten – Bänder – Zylinder – Garnitur Maximale Werkstückstärke: 120 mm Verfahrweg: 1000 mm CNC-Steuerschrank Industrie-PC MASTER SYSTEM CAD CAM Leistung und Motoren Spannung: 400 V Anschluss: Dreiphasig Gesamtmaße Kodpfetqkatox Aahsfa

Kondisi: siap digunakan (bekas), Caractéristiques techniques Puissance et moteurs Tension : 380 V Ksdpfeui Ebhox Aahefa Raccordement : Triphasé Puissance : 1,5 kW Moteur : 2 CV Dimensions générales Longueur : 1200 mm Largeur : 1250 mm Hauteur : 1650 mm Poids : 350 kg

Kondisi: siap digunakan (bekas), Technische Merkmale 3-achsengesteuerte Stemmmaschine Maximal bearbeitbare Massivteilgröße: 275 x 160 mm Maximale Stemmtiefe: 130 mm Hydraulikmotor: 0,75 kW Arbeitstisch: Abmessungen: 1000 x 310 mm Längsverstellung: 400 mm Querfahrt: 150 mm 2 Aufsatztische, Länge 1200 mm Verlängerung mit elektronischem Anschlag: 2600 mm Fahrgeschwindigkeit elektronischer Anschlag: 40 m/min Werkstückspannung mit hydraulischen Kolben (2 vorne und 2 vertikal) Stemmaggregate: Manuelle Höhenverstellung Motorisierte Höhenverstellung Nonius für schnelle Ermittlung des Meißel-Schwingwinkels 2,2 kW Motor Betriebsdruck Pneumatik: 6-8 bar Absaugstutzendurchmesser oben: 80 mm Absauggeschwindigkeit: 25-30 m/sec Kfedpfxot Dgaie Aahoa Leistung und Motoren Spannung: 380 V Anschluss: Drehstrom Leistung: 3 kW Motor: 3 PS Gesamtabmessungen Länge: 1000 mm Breite: 1400 mm Gewicht: 850 kg
