Kondisi: bekas, Tahun pembuatan: 2012, Fungsionalitas: berfungsi sepenuhnya, Kondisi: berfungsi penuh, terawat dengan baik, sedang berproduksi. Tersedia segera! Mesin gergaji panel SCM SIGMA IMPACT 87, tahun 2012, merupakan mesin gergaji panel industri yang kuat, akurat, dan andal, dirancang untuk operasi pengolahan panel dan produksi furnitur dengan produktivitas tinggi. Ideal untuk pabrik pengolahan kayu, produsen kabinet, serta produksi skala besar. Spesifikasi teknis: Dimensi pemotongan: 3200 × 2100 mm Proyeksi pisau utama: 87 mm Diameter pisau utama: 350 mm Kecepatan pisau utama: 3900 rpm Daya motor utama: 5,5 kW Pisau scoring: 1,5 kW, 6300 rpm, 160 mm Kecepatan gerobak: 6–30 m/menit Kecepatan pendorong: 27–38 m/menit Penjepit standar: 5 Lubang ekstraksi debu: 3 × 120 mm atau 1 × 150 mm Kedpfjycg Rmsx Aglowt

Kondisi: sangat baik (bekas), Tahun pembuatan: 2007, Fungsionalitas: berfungsi sepenuhnya, MESIN GERGAJI PANEL HOLZMA HPP250 320x320 Panjang potong: 3200 mm Lebar potong: 3200 mm 3 meja udara Kontrol daya Tahun produksi: 2007 Kwsdpfsycc H Dsx Agljt

Kondisi: sangat baik (bekas), Tahun pembuatan: 2022, jam operasional: 105 h, Panel saw with movable sliding table and saw blade tiltable up to 46°, enabling safe operation and reducing required space by 50% compared to a conventional panel saw; combines the functions of both a panel saw and a pressure beam saw. Easy and quick program-controlled adjustments via the "Ready" control panel from the operator station. Instant positioning thanks to the motorized and programmable rear fence, allowing fast and precise positioning of workpieces. Robust and reliable telescopic fence with scale and two flip stops: trimming panels up to 2500x3200 mm (optional 3200x3200 mm). The large, fixed table ensures optimal support of the panel during processing. Technical specifications class px 350i Max. sliding table stroke mm 2600 3200 3800 Saw blade tilting deg 0÷46° Max. saw blade diameter (cutting) mm 350 Max. saw blade diameter (routing + cutting) mm 300 Kodpfx Ajyb T Trjglowt Max. cutting height (D350) from table at 90°/45° mm 105/72 Max. cutting height (D300) from table at 90°/45° mm 80/50 Saw blade speed rpm 4000 Rip capacity, rear fence mm 1300 Additional technical features Three-phase motor  7 kW 50 Hz Extraction hood diameter mm 120 (1) - 100 (2) Dimensions mm L 3859 x H 1368 Location: ex site customer - Available at short notice -

Kondisi: bekas, Tahun pembuatan: 2002, Fungsionalitas: berfungsi sepenuhnya, Ukuran potong 3.200 x 3.200 mm Tinggi potong maks. 50 mm Motor gergaji utama 5,5 kW Diameter mata gergaji utama 300 mm Motor scoring saw 1,1 kW Diameter mata scoring saw 150 mm Gerakan kereta gergaji dapat diatur 6 - 32 m/menit Kecepatan penggeser program 18 m/menit Jumlah penjepit: 6 buah Jumlah meja bantalan udara: 3 buah Kwedsyba Shspfx Aglst Perlengkapan penahan sudut manual untuk pemotongan lebar 100 - 1.250 mm Kontrol PC berbasis Windows 2000

Kondisi: bekas, Tipe 693 Euro5 Tahun pembuatan: 1996 Data Umum Panjang potong: 3200 mm Lebar potong: 2650 mm Tinggi potong maks.: 60 mm Gergaji utama Kecepatan putar: 2870 min⁻¹ Daya: 5,5 kW Diameter maks. Ø280 Gergaji skor Kecepatan putar: 2850 min⁻¹ Daya: 1,1 kW Diameter maks. Ø125 Ksdpfx Agoyac Ebjlewt Daya terpasang total: 8 kW Berat mesin: 3150 kg

Kondisi: bekas, Kereta 320cm Bilah dapat dimiringkan Pemotong 400V Kwodpfsyac Agjx Aglet

Kondisi: bekas, Tahun pembuatan: 2009, Fungsionalitas: berfungsi sepenuhnya, panjang pemotongan (maks.): 3.800 mm, tinggi potong dengan pisau scoring (maks.): 80 mm, diameter mata gergaji: 380 mm, ketinggian potong (maks.): 100 mm, diameter utama gergaji: 380 mm, tegangan masuk: 380 V, Panel saw GIBEN SMART dengan pemuatan depan, panjang potong efektif 3800 mm, dalam kondisi operasi. Kwodjx U Emropfx Aglst

Kondisi: bekas, Tahun pembuatan: 2023, Exhibition Machine Garbsen HORIZONTAL PANEL SAW GABBIANI P Manufacturer: SCM Model: GABBIANI P80 Year of manufacture: 2023 1.00 unit MAIN FEATURES INDIVIDUALLY SELECTABLE AIR CUSHION TABLES: AN INDISPENSABLE TOOL SIDE SAFETY DEVICES: MORE SPACE FOR WORKING FLOATING CLAMPS: THE GUARANTEE FOR A PERFECT CUT TECHNICAL DATA GENERAL INFORMATION gabbiani p80 Saw blade projection mm: 80 Working table height mm: 950 Number of standard clamps: 5 Number of clamps for versions 33/38/43: 9 / 10 / 10 Number of clamps for versions 33/38/43 with FlexCut 1 unit (single clamp with double fingers included): 10 / 11 / 11 CUTTING DIMENSIONS Version 33 mm: 3300x2100 Version 33 (Opt.) mm: 3300x3200 Version 38 mm: 3800x3200 Version 38 (Opt.) mm: 3800x3800 Version 43 mm: 4300x3200 Version 43 (Opt.) mm: 4300x4300 AXIS SPEEDS Variable saw carriage speed m/min: 6 – 60 Variable pusher speed ( ) m/min: 60 MAIN SAW BLADE Motor power (S6 -40%) - 50Hz (star-delta start) kW (HP): 7 (9) (11) Rotation speed – 50Hz rpm: 4650 Saw blade diameter mm: 340 Main saw blade shaft diameter mm: 80 SCORING SAW Motor power (S6 -40%) - 50Hz kW (HP): 1.5 (2) Rotation speed – 50Hz rpm: 5850 Scoring blade diameter mm: 200 Scoring saw spindle diameter mm: 80 INSTALLATION Installed power kW: 12÷15 Machine base voltage Euro voltage (400 V / 50 Hz) Compressed air requirement NL/min: 300 Required air pressure bar: 7 Extraction air requirement m³/h: 2440 Extraction air speed m/sec: 20 Extraction spigot diameter mm: 4x120 ( ) Note: For countries where EC standards apply, the forward feed speed of the pusher is limited to 25 m/min. GENERAL CHARACTERISTICSAutomatically controlled horizontal panel saw with PC/PLC control unit, for cutting panels of solid wood, MDF, chipboard, plywood and similar materials. Machine frame and work table - Machine frame constructed as steel tube design - Work table made of rib-reinforced steel with Bakelite coating - Longitudinal fence on the left sideSaw carriage made of steel, consisting of: - a motor for the main saw blade and a motor for the scoring blade - Vertical lift of the saw blade on linear ball guides and shoes - Guide wheels made of hardened and ground steel - Balanced mass distribution for best cutting quality - Direction of travel against the longitudinal fence - Saw carriage drive via rack and pinion - Carriage runs on cylindrical guides - Cylindrical guides made of hardened and ground steel (5 years warranty), protected by special dust wipers - Pneumatic switch for fast and safe change of main saw blade and scoring bladePressure beam - Pressure beam with uniform pressure on the workpiece over the entire cutting length with recesses to avoid collisions with the clamps; pneumatic height adjustment via high-precision racks and pinions, pressure adjustable from 1.5 to 6 bar - Double extraction system with a unit above the pressure beam for cleaning the work table and a unit below on the saw carriage - Lateral automatic aligner with pneumatic cylinder over the entire length. Slides on linear ball guides and shoes.* Travel: 1200 mm* Minimum working width: 60 mm* Maximum working width: 1200 mmPositioning pusher and rear section of the machine - Positioning pusher over the entire length with motor drive via a robust shaft. Positioning pusher... Kwedpfxex Twcvs Agljt

Kondisi: baik (bekas), Tahun pembuatan: 1998, platen gergaji yang masih dalam kondisi baik panjang potong maks. 3200 mm Kedpfsx Sdrhox Aglswt Harga belum dibongkar, dari lokasi Austria wilayah Linz

Kondisi: sangat baik (bekas), Tahun pembuatan: 2004, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 0-341-07-8874, panjang pemotongan (maks.): 3.200 mm, tinggi potong dengan pisau scoring (maks.): 72 mm, diameter mata gergaji: 350 mm, ketinggian potong (maks.): 70 mm, lebar pemotongan (maks.): 3.200 mm, kecepatan pemakanan sumbu X: 80 m/menit, laju pemakanan gandar Y: 60 m/menit, diameter utama gergaji: 350 mm, panjang total: 5.800 mm, tinggi total: 2.000 mm, lebar total: 6.410 mm, Perlengkapan: doser, Panel beam saw HOLZMA tipe HPP 32/32/L Mesin dengan eksekusi sisi kiri Motor utama 7,5 kW Unit pra-potong, motor 1,1 kW Perangkat penekan samping tengah dengan tekanan samping yang dapat diatur tanpa batas 3 meja "udara": ukuran 1800x600 mm 6 buah penjepit: 3 buah stop jari ganda; 3 buah stop jari tunggal Printer label Kjdpsx Sap Nofx Aglswt Perangkat lunak optimasi rencana pemotongan Perangkat lunak impor CSV

Kondisi: bekas, Tahun pembuatan: 2001, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: AE/22614, panjang pemotongan (maks.): 3.200 mm, lebar pemotongan (maks.): 4.500 mm, panjang total: 5.000 mm, tinggi total: 2.350 mm, lebar total: 7.000 mm, MESIN POTONG PANEL OTOMATIS SCM MOD. SIGMA N 65 - SESUAI STANDAR CE Kwsdpfxjx Rvazo Agljt - Dimensi pemotongan: 4500x3200 mm - Tinggi keluar mata pisau: 65 mm - 6 penjepit - Kecepatan gerak carriage pisau: 12 m/menit - Diameter mata pisau utama: 300 mm - poros diameter 80 mm - Diameter mata scoring: 160 mm - poros diameter 55 mm - Motor pisau utama: 5,5 kW - Dimensi mesin: 7000x5000x2350 mm - No. seri: AE/22614 - Tahun: 2001 - Dilengkapi dengan manual dan deklarasi CE

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2020, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 1000031582, panjang pemotongan (maks.): 3.800 mm, diameter mata gergaji: 350 mm, lebar pemotongan (maks.): 3.800 mm, lubang pisau gergaji: 65 mm, kecepatan throughput: 417 mm/dtk, RINCIAN TEKNIS Diameter mata gergaji min.: 200 mm Diameter mata gergaji maks.: 350 mm Diameter lubang mata gergaji: 65 mm Panjang potong maks.: 3.800 mm Lebar potong maks.: 3.800 mm Jumlah penjepit pengumpan: 6 Kecepatan maksimum pengumpanan: 25 m/menit RINCIAN MESIN Data listrik Daya motor utama: 18,0 kW Tegangan: 400 V Konsumsi arus: 36 A Daya: 18,0 kW Dimensi & Berat Kwodpsx Rbkrjfx Aglot Dimensi (P x L x T): 6.050 x 1.750 x 2.400 mm Berat: 5.000 kg Paket pengiriman: 3 unit PERLENGKAPAN Dokumentasi Tanda CE Perangkat lunak Optiplanning - versi Mudah, layanan SOPHIA

Kondisi: baru, Tahun pembuatan: 2025, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 561, panjang pemotongan (maks.): 3.100 mm, ketinggian potong (maks.): 95 mm, lebar pemotongan (maks.): 3.100 mm, kecepatan pemakanan sumbu X: 100 m/menit, penggerak gergaji: 11 W, masa garansi: 12 bulan, Perlengkapan: doser, 1 Kwodox Nqrvjpfx Agljt

Kondisi: sangat baik (bekas), Tahun pembuatan: 2017, Fungsionalitas: berfungsi sepenuhnya, panjang pemotongan (maks.): 3.800 mm, diameter mata gergaji: 380 mm, ketinggian potong (maks.): 90 mm, lebar pemotongan (maks.): 3.800 mm, diameter utama gergaji: 380 mm, berat keseluruhan: 4.400 kg, Large Format Panel Saw SIGMA IMPACT 90 (SCM Group) suitable for precise cutting of furniture components, single or stacked boards. Manufacturer: SCM Group Model: Sigma Impact 90 Year of manufacture: 2017 Cutting width: 3,800 mm Cutting depth: 3,200 mm Max. cutting height: 90 mm Air tables: 1x 2,500x600mm, 3x 2,500x600mm Air flotation integrated in the base frame. Max. diameter of main saw blade: 380 mm Scoring unit diameter: max. 300 mm Kwjdex Nc Ayepfx Aglst Rear pusher: brushless motor, max. speed 120 m/min! Saw carriage: brushless motor, max. speed 150 m/min! THK linear guides for saw carriage movement. THK linear guides for rear pusher movement. Automatic central lubrication for THK guideways. HI-TRONIC Package: - Main motor 15 kW (S6 duty) - Lifting of main and scoring blades via ball screws - Optimized main blade stroke - Electronic 2-axis scoring adjustment - Grooving with main blade (electronic depth adjustment) - Postforming cuts - Non-through cuts (cutouts) - Blade clamping by AKE flange Number of clamps: 10 pcs (max) Automatic exclusion of side clamp (up to 800 mm width) Start/stop foot pedal Label printer Control software: WINCUT Optimization software: OTTIMO PERFECT CUT TOP (1x hardware key) Operator PC Eye-S: Windows + 21" touchscreen Air-conditioned electrical panel Automatic panel dimension measurement Laser line for cut marking Automatic twin side pressure device – motorized (60–2,200 mm) Machine condition: Fully operational Possible to inspect in current operation. Availability: Approximately April 2026

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2002, Giben mesin pemotong rip Tahun pembuatan: 2002 Komputer baru dipasang tahun 2024 Rits Gripper 7 pcs Dimensi transportasi: 4 paket 7,5 meter kubik Kwedpfx Aex Huhisglst Total sekitar 5000 kg Data teknis Total panjang gergaji: 665 cm Panjang potong: 3700 mm Pendorong: 3300 mm Tinggi potong: 90 mm

Kondisi: sangat baik (bekas), berfungsi dan tampak sempurna, sangat terawat tanpa tanda aus pada meja, pengangkatan dan kemiringan elektrik 0-45°, motor 5,5 kW + pre-cutter, tahun pembuatan 2009. Kwodpfex Dx I Sjx Agljt

Kondisi: seperti baru (mesin pameran), Tahun pembuatan: 2023, jam operasional: 10 h, Fungsionalitas: berfungsi sepenuhnya, frekuensi input: 50 Hz, tegangan masuk: 400 V, daya: 8,83 kW (12,01 hp), Perlengkapan: doser, Mayer panel saws impress with their well-thought-out machine concept and numerous detailed solutions precisely tailored to every requirement. Each machine type stands for absolute top performance. The more varied the requirements of the materials to be cut, the more the small details determine the success of the entire process. With heavy and robust saws, Mayer relies on long-lasting quality and high-grade engineering. The overall concept is also impressive: the heavy-duty design with steel pressure beam and pusher, easy one-man operation, maximum process reliability with the modular cutting optimization program, as well as new software packages, guarantee top performance and precision for efficient panel cutting. The modular cutting optimization program with barcode labeling ensures maximum process reliability. The saw carriage, equipped with main and scoring saw units, runs on a hardened and ground round-shaft guide system. The extremely smooth operation of the saw carriage at cutting speeds from 5 to 100 meters per minute is achieved by the high-precision drive via rack-and-pinion system. High-end cut edges are produced through automatic cutting height adjustment for optimal blade entry angle and superior smoothness of the carriage. The dual measuring system guarantees maximum repeatability. The pressure beam opens automatically according to the material height, minimizing material handling times. The "Greenline Package" with controlled extraction sliders and direct motor control can reduce energy consumption by up to 30%. Optional Equipment 22 Electronic cutting height adjustment 25 Motorized scorer adjustment from the control panel 30 Air cushion table 2300 x 600 mm 42 Single-finger package clamp 41 Additional package clamp, position 493 mm 61 Thermal label printer 90 Network connection preparation Additional Technical Data Scoring saw: 150 mm Extraction connections: 120 / 100 mm Feed speed: 5-100 m/min Saw blade projection: 77 mm Saw carriage and pusher can execute cuts up to 3200 mm in length Return speed: 130 m/min Angle table: 2300 x 600 mm 2x Material tables: 1800 x 600 mm Kwedpfx Agox Anurjlot Includes delivery and installation within postal code regions 70,71,72,73,77,78,79,86,87,88,89.

Kondisi: bekas, Tahun pembuatan: 2023, Working area: 5600x5600 mm 1x Gabbiani G 3 130 (56) - High-performance panel saw 1x Compact label printer 1x "eye-M EVO" operator console 1x Human-Machine-Interface software (HMI) MAESTRO ACTIVE 1x Maestro pattern 1x High-performance fixed air cushion table with guide, 2500x600 mm, with infeed rollers 3x High-performance movable air cushion tables - 2500x600 mm, with infeed rollers 1x Double side automatic aligner with motor drive 1x Foot switch for START/STOP of the work cycle 1x Grooving unit with height adjustment of the saw blade via the control panel 1x "Autosetting" device on the saw carriage for cutting length/width 1x Main saw blade motor 25 HP (18 kW) 50 Hz with star-delta start 1x Quick-release saw blade system with mechanical "AKE" flanges 1x Selective collet closure (area 0 - 1600 mm) 3x Additional double collets 4x Additional collets with single finger 1x Compact Office label printer Ksdpfexlvktox Aglowt 1x Cut editor 1x Maestro optiwise - Advanced - No. 1 license 1x Maestro connect: service contract for 1 year (including "plug&play" gateway kit) 1x Base 1x MACHINE LANGUAGE: German 1x PC LANGUAGE: German 1x SPEC01 special version 01 1x European safety regulations (CE marking) Including 123 hours of on-site commissioning (within Germany) (daily working hours: 8 hours including travel to/from site). Including 1 day online training MAESTRO OPTIWISE PRO (if required) Including 1 year MAESTRO CONNECT Including MAESTRO PATTERN IMPORT (value €255 free of charge) Location:

Kondisi: diremajakan ulang (bekas), Fungsionalitas: berfungsi sepenuhnya, Panel Dividing System PA 4115 – 3100 x 3100 DNC-AT Condition: completely overhauled Warranty: 1-year guarantee Technical Specifications: Left-side adjustable angle stop according to AGA 4383 Longitudinal Panel Saw FM 16-3100: - Hardened guides - Automatic forward and return travel of the saw unit - Return travel with automatic lowering - Feed speed: 2–50 m/min (stepless via potentiometer) - Return speed: 70 m/min (rapid traverse) - Integrated extraction channels in machine base and pressure beam - Scoring saw adjustable from outside (no need to open safety cover) Saw Unit with Regulated DC Drive: - Precise positioning (e.g. for cut-outs) - Slowed immersion exit from the cut - Includes safety cover interlock, lamella curtain SZ 5008 - Offcut device SP 5004 – offcuts down to min. 5 mm - Main saw motor: 7.0 kW - Scoring saw motor: 1.1 kW (individually switchable) - Cutting length: 3100 mm - Cutting height: 70 mm - Dust tested: threshold value of 2 mg/m³ significantly undercut - CE compliant Angle Pressure Device WP 5003: - With pressure claw for cross cuts - Adjustment range up to 2400 mm - Semi-automatic function Material Feed Table HP 5021 (mounted at rear of FM 16): - Parallel fence with 6 spring-loaded clamping fingers - Direct drive of material pusher by servomotor - Table surface closed with Pertinax plates (suitable for narrow strips) - Feed speed: 25 m/min (safety restricted) - Return speed: 40 m/min - Table length: 3100 mm - Fence depth: 3100 mm Multi-microprocessor control - Integrated PC with hard drive - Operating system: LINUX - Interfaces: serial + parallel, USB - Network connectivity (including wireless LAN) - Optimize cutting plans in the office and send directly to machine - Multitasking capable - Print function via USB - Remote maintenance via Internet (Remote Desktop, TeamViewer) - Multilingual dialog programming - 15” flat screen + multifunction keyboard - Swiveling control panel - Graphical display of cutting plans and workflows Additional Features: Angle stop table HP 5043 (front-mounted): Kwodpfx Agjxhg Ibeljt - Machined steel angle, Pertinax table support - Table size: 1800 × 800 mm Workpiece support table HP 5025 (front-mounted): - Pertinax support - Table size: 1800 × 800 mm Air cushion device LK 5030 - Integrated into HP 5043 and HP 5025 Accessories: - 1 circular saw blade KSB 4005 – Ø 305 mm, Z=60 (for main saw) - 1 circular saw blade KSB 4006 – Ø 200 mm, Z=60 conical (for scoring saw)

Kondisi: bekas, Tahun pembuatan: 2009, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: 731, panjang pemakanan sumbu X: 3.800 mm, panjang pemotongan (maks.): 3.800 mm, tinggi potong dengan pisau scoring (maks.): 100 mm, diameter mata gergaji: 380 mm, ketinggian potong (maks.): 100 mm, lebar pemotongan (maks.): 3.800 mm, kecepatan pemakanan sumbu X: 70 m/menit, diameter utama gergaji: 380 mm, tinggi total: 1.650 mm, berat keseluruhan: 4.500 kg, jarak pergerakan sumbu X: 3.800 mm, berat benda kerja (maks.): 80 kg, diameter nosel ekstraksi: 120 mm, frekuensi input: 50 Hz, arus masuk: 35 A, tegangan masuk: 400 V, sambungan udara terkompresi: 6 batang, kecepatan rotasi (maks.): 4.800 rpm, kecepatan rotasi (min.): 2.800 rpm, tekanan udara: 6 batang, lubang pisau gergaji: 80 mm, Perlengkapan: doser, Gergaji ini rutin diservis dan dalam kondisi kerja yang sangat baik. Saat ini beroperasi harian dalam satu shift. Dijual karena akan beralih ke sistem produksi yang lebih baru. Masih berfungsi dan dapat dilihat beroperasi hingga 10 Oktober 2025. Dilengkapi juga dengan satu set mata gergaji dan pra-pemotong. Tersedia opsi pembelian vacuum board lifter yang dapat dilihat di video. Kodpfx Asxf Im Tsglewt

Kondisi: sangat baik (bekas), Gergaji Format Sliding dengan balok tekan FIMAL CONCEPT 350 -bekas- Dapat dimiringkan hingga 46°, stop sudut dapat diperpanjang hingga: 2.500 mm, indikator digital pada stop sudut, stop kemiringan +/- 50°, Kwodpfx Aoxdl N Ajglet deteksi panjang potong otomatis, kecepatan gerak meja gergaji variabel, layar sentuh, laser garis pemotongan ----- Data Teknis ----- panjang potong: 3.200 mm, lebar potong: 1.300 mm, ketinggian potong maks.: 100 mm, kecepatan dorong agregat gergaji maks.: 0 - 40 m/menit, daya motor gergaji utama: 5 kW, diameter mata gergaji utama: 350 mm, diameter port hisap bawah: 120 mm, diameter port hisap pada balok tekan: 100 mm, koneksi udara tekan: 7 bar Info Kualitas: - inspeksi dasar menyeluruh - pembersihan dasar menyeluruh - kelistrikan telah diperiksa - siap pakai segera

Kondisi: sangat baik (bekas), Tahun pembuatan: 2012, Panel saw SCM Sigma Impact dengan pengisian belakang. Mesin sudah dibongkar. Kwodjw Rdkaopfx Agljt

Kondisi: seperti baru (mesin pameran), Tahun pembuatan: 2023, Fungsionalitas: berfungsi sepenuhnya, panjang pemotongan (maks.): 3.200 mm, diameter mata gergaji: 350 mm, ketinggian potong (maks.): 105 mm, lebar pemotongan (maks.): 1.300 mm, panjang total: 4.300 mm, berat keseluruhan: 1.300 kg, frekuensi input: 50 Hz, tegangan masuk: 400 V, daya: 7,35 kW (9,99 hp), kecepatan rotasi (maks.): 4.000 rpm, rentang pivot: 45 °, The Concept 350 combines the advantages of various saw systems: the flexibility of a panel saw, the cutting quality of a pressure beam saw, and the ergonomics of a crosscut saw. This is the sawing concept for modern industrial production. This machine is a returned leasing unit. Further technical details: - Motorized rip fence with 4 synchronously operating aluminium stops - Screen control with 8" touchscreen - Air requirement: 6 bar - Sliding table: 1,000 x 400 mm (extension table) - Outrigger table size: 3,200 mm with 2 digital fence jaws - Extraction port: 1 x 100 mm, 1 x 120 mm - Feed speed: 0 - 40 m/min Special equipment: - Programmable saw blade height adjustment - Mitre fence +/-50° - Cutting line laser - Additional support table 800 x 200 mm With the new Concept 350, you no longer need a conventional panel saw! The workpiece rests on the machine table and is precisely positioned by a pressure beam. The saw unit, tiltable from 90-45°, is guided with precision and cuts your workpiece at a constant feed rate of 0-40 m/min. This guarantees the best cutting results. The standard crosscut fence allows for quick sizing and efficient work – with significant space savings compared to any conventional panel saw! Advantages over a panel saw with sliding table: - Requires significantly less space - Pressure beam secures the workpiece on the machine and guarantees optimal cutting results - Pressure beam prevents the operator from coming into contact with the saw blade - Ergonomic operation as the operator no longer has to push the material through the blade Kodewzuipspfx Aglswt - Time savings, as the operator does not need to guide the material during the sawing process Includes delivery and installation within postal codes 71, 72, 73, 77, 78, 79, 86, 87, 88, 89

Kondisi: bekas, Tahun pembuatan: 2011, Numerical WINCUT control Kwjdpfx Agjwwrywslst Working dimensions (mm): 3800 x 3800 Max. blade projection (mm): 107 Front panel loading: No. 10 clamps on the pusher carriage Side aligner Scoring unit (max. blade diameter / power): 160 mm / 1.5 kW Main saw unit (max. blade diameter / power): 380 mm / 7.5 kW Adjustable saw carriage speed (m/min): 1 - 135 Pusher carriage speed: 70 m/min No. 3 air flotation front tables TECHNICAL DATA TO BE VERIFIED WHEN THE MACHINE IS IN OUR WAREHOUSE

Kondisi: baru, Tahun pembuatan: 2025, Fungsionalitas: berfungsi sepenuhnya, panjang pemotongan (maks.): 3.300 mm, diameter mata gergaji: 315 mm, ketinggian potong (maks.): 82 mm, kecepatan pemakanan sumbu X: 100 m/menit, laju pemakanan sumbu Z: 150 m/menit, panjang total: 3.300 mm, lebar total: 3.350 mm, berat keseluruhan: 3.000 kg, penggerak gergaji: 9.000 W, daya: 9 kW (12,24 hp), kecepatan rotasi (maks.): 4.400 rpm, kecepatan mata gergaji: 4.400 rpm, Perlengkapan: kecepatan rotasi dapat diubah tanpa batas, SCHEER PA 4500 – 3300 x 3350 S7WIN10 Year of manufacture: 2025 | Condition: NEW | Control: PA-WIN10 + SIMATIC S7 | High-Performance Panel Saw System for Maximum Precision & Efficiency The SCHEER PA 4500 is a robust, industry-proven panel dividing saw designed for precise machining of coated and uncoated wood-based panels. Engineered for demanding applications, its standard configuration already meets all requirements for modern cutting operations. Main Technical Data: - Cutting length (max.): 3300 mm - Cutting height (infinitely variable): up to 82 mm - Main saw blade: Ø 315 mm | 60 teeth | Cut width 3.2 mm - Scoring saw blade: Ø 200 mm | conical | Cut width 3.2–4.0 mm - Main saw motor: 9.0 kW - Scoring unit motor: 1.1 kW Kwsdpfewrpcxox Aglst - Saw carriage drive: 2.32 kW - Main saw blade speed: approx. 4400 rpm - Saw carriage feed: 0–100 m/min (variable adjustment) - Saw carriage return: 150 m/min (lowered) - Electrical connection: 400V / 50Hz / 3Ph - Pneumatics: 6 bar, 15 NL/cycle - Extraction: 3 x 140 mm | Capacity: 3300 m³/h at 20 m/s - Working height: approx. 930 mm - Angle stop: left Machine Concept & Highlights: - Heavy-duty cast honeycomb frame for vibration damping - Absolute value encoder for highest positioning accuracy (no referencing required) - Distance- and time-optimized saw carriage movement - Automatic oil mist lubrication & guideway blow-off - Program-controlled saw blade adjustment (height & scoring side) - ProLock quick-change system for the saw blade - "Dust-tested" – emissions only 0.65 mg/m³ Machine Equipment: - 1x Angle pressure device WP 8500-1400 Adjustment range: 0–2200 mm Pressure force: approx. 480 N Cycle-controlled retraction function for panel handling - 1x Feed table HP 5130 – 33 x 33 Rear-mounted with hardened guides & racks Roller conveyor system for smooth panel transport - 6 clamp fingers (spacing: 70 / 262 / 454 / 838 / 1173 / 2630 mm) Servo drive with ±0.1 mm accuracy - 1x Angle stop table HP 5137-1-1465 - 1x Workpiece support table HP 5135-1-1465 Each with Pertinax coating, 1465 x 800 mm - 1x Air cushion system LK 5169 Central radial fan, max. pressure 2800 N/m² - 1x Control cabinet Dust-tight, separately mounted, vibration-protected - 19" TFT flat panel monitor, keyboard, trackball Control & Software: - SIMATIC WinLC RTX soft PLC with S7 functionality - PA-WIN10 user interface on Windows 10 Professional (64 bit) (upgrade to latest Windows version possible at any time) - True-to-scale real-time simulation and graphical cut pattern editor - Integrated interfaces (label printing, panel storage management, etc.) - Network-compatible, future-proof, and modularly expandable Operating Modes & Operation: - Manual mode: single cut, chain dimension, trimming, remnant cutting - Automatic mode: processing of cut plans, online order processing - Editor: batch list-based planning & optimization - Maintenance & diagnostics: saw blade measurement, single component control, etc. 📞 Contact us for a personalized quote or to arrange a viewing. Delivery, installation, commissioning, and training are optionally available.
