Beli Pelat penjepit bekas (411)

Kondisi: baru, Lebar pelat: 4000 mm Kedalaman pelat: 1500 mm Tinggi pelat: 310 mm Berat: 4930 kg Ruang yang dibutuhkan: sekitar 4000 x 1500 x 310 mm GERD WOLFF pelat penjepit 4000 x 1500 x 310 mm Jika Anda tidak menemukan ukuran yang diinginkan, Anda dapat mengirim email kepada kami dengan formulir PDF yang telah diisi (terlampir). Kami dapat membuat pelat penjepit sesuai keinginan Anda. Ukuran alur-T: 52 x 28 Jarak antar alur-T: 300 mm Jumlah alur: 5 Jarak tepi: 150 mm Berat: 4930 kg Kualitas cor HT250 Iodpfx Adournk Ssqsih Kerataan kurang dari 0,12 mm Finishing permukaan sesuai DIN 876 / III

Kondisi: bekas, Tahun pembuatan: 1970, Length 5000 mm Width 1700 mm Quantity 1 Plate thickness 250 mm Machine weight approx. 6 t Required space approx. 5 x 1.7 x 0.25 m Worktable of a milling machine. Can be used as a plate field. Iodou Rt D Njpfx Adqjih The plate has 7 longitudinal T-slots with a width of 30 mm.

Kondisi: baik (bekas), Pelat pemasangan, meja lempengan, meja las, mesin bor lempengan, pelat perata, -dengan: lubang bor -lebar: 1000 mm -panjang: 1000 mm -tinggi luar: 150 mm, tebal pelat: 100 mm -jumlah: 7 pelat tersedia Ijdsckk T Topfx Adqeih -harga: per unit -berat: 720 kg/unit

Kondisi: bekas, Clamping plate with T-slots made of cast iron Base plate from a radial drilling machine Assembly table, assembly station, base plate for pillar slewing crane Length: 1850 mm Width: 915 mm Plate thickness: 230 mm Table surface with T-slots: 1030 x 750 mm - Clamping surface with 22 mm T-slots, spacing = 250 mm - Top surface milled parallel to the underside = clamping surface Iiedpeh R D Uzsfx Adqoh - Milled underside; also the ribs rest flatly and provide support - Ideal as a base plate Net weight: 1140 kg Good condition

Kondisi: bekas, Tahun pembuatan: 2005, Technical details: Pallet size: 400 x 400 mm Number of pallets: 15 Table load capacity: 400 kg Machine weight approx.: 0.060 t Space requirements approx.: 0.4 x 0.4 m Isdpfx Adevc Adljqsih 15 pallets for Makino A 55, size 400 x 400 mm with T-slots available.

Kondisi: bekas, Detail teknis: Panjang pelat: 4600 mm Lebar pelat: 1450 mm Tinggi pelat: 300 mm Ketebalan pelat: 300 mm Berat mesin sekitar: 7,2 t/pelat 2 unit pelat penjepit (harga per pelat) Material: baja cor Permukaan machining akhir Alur-T sesuai DIN 650: Iodpfx Adowtctgoqjih a=40; h=66; b=71; c=29 mm Jarak tengah 300 mm 6x lubang tembus Ø 41,0 mm

Kondisi: baru, Lebar pelat: 1000 mm Kedalaman pelat: 1000 mm Tinggi pelat: 300 mm Berat: 975 kg Pelat penjepit GERD WOLFF 1000 x 1000 x 300 mm Iodpfxjurnk Eo Adqeih Jika Anda tidak menemukan ukuran yang diinginkan, Anda juga dapat mengirimkan email kepada kami dengan formulir PDF yang sudah diisi (terlampir). Dengan demikian, kami dapat membuat pelat penjepit sesuai permintaan Anda. Ukuran alur-T: 52 x 28 mm Jarak alur-T: 300 mm Jumlah alur: 3 Jarak ke tepi: 200 mm Berat: 975 kg Kualitas cor: HT250 Kerataan kurang dari 0,12 mm Pemrosesan permukaan sesuai DIN 876 / III

Kondisi: bekas, Tahun pembuatan: 1990, Length 8000 mm Width 3000 mm Quantity 2 Plate thickness 400 mm Machine weight approx. 14 t Space requirement approx. 8 x 3 x 0.4 m 2 plates available. Each plate features 10 longitudinal T-slots, each 32 mm wide. The quoted price is per unit. Iisdov Ey Nqepfx Adqoh

Kondisi: baik (bekas), Straight edge, scraping straightedge, inspection straightedge, straightening straightedge, straightening beam, clamping plate, marking/scraping plate, surface plate, measuring table, straightening plate, marking plate, inspection plate, control plate, precision measuring table - Scraping Straightedge: 145 x 1515 mm - Dimensions: 145/1515/H265 mm - Weight: 99 kg Iedpfsw H Nu Dox Adqeih

Kondisi: bekas, Steel straightening and welding plate Milled steel plate with a good surface finish, heavy-duty straightening plate Length: 1900 mm Width: 1500 mm Thickness: 70 mm (uniform) - Machined surface, milled finish - Plate equipped with several symmetrical boreholes Weight: approx. 1600 kg Iisdpfx Aedzqr Rjdqeh Good condition Height-adjustable feet made of cast steel are available in our shop.

Kondisi: bekas, Tahun pembuatan: 2005, Technical details: Pallet size: 400 x 400 mm Iiedsvb H Apspfx Adqeh Number of pallets: 15 Table load capacity: 400 kg Machine weight approx.: 0.060 t Space requirements approx.: 0.4 x 0.4 m 15 pallets for Makino A 55, size 400 x 400 mm with T-slots available.

Kondisi: sangat baik (bekas), Tahun pembuatan: 2019, Fungsionalitas: berfungsi sepenuhnya, nomor mesin/kendaraan: div., Perlengkapan: Pelat tipe tersedia, CMS 530 Ki; E 3.5.2; Year of manufacture: 2019; Quantity: 4 CMS 530 Ki; E 2.5.2; Year of manufacture: 2019; Quantity: 12 CMS 530 HP; E 7.2; Year of manufacture: 2014; Quantity: 4 CMS 822 HP; E 7.2; Year of manufacture: 2014; Quantity: 9 CMS 822 HP; E 3.5.2; Year of manufacture: 2014; Quantity: 4 Scomar Banding Machine; E 10; Quantity: 2 EMIL NESTEL; String Machine; Quantity: 1 Steiger Patent Machine; E 12 / E 8; Quantity: 1 Iiodpfx Adjwqdx Seqeh Hirschburger; Spool Machine; Quantity: 1 Stoll System; M1 plus, Quantity: 3 Various suppliers

Kondisi: baru, Plate width 2000 mm Plate depth 1000 mm Plate height 310 mm Weight 1650 kg Required space approx. 2000 x 1000 x 300 mm Clamping plates – T-slot plates – Plate field 2000 x 1000 x 310 mm If you cannot find your required size, you can also send us an email with the completed PDF form. With this, we can have a plate manufactured individually for you. Number of slots: 3 Clamping plates – T-slot plates – Plate field 2000 x 1000 x 310 mm If you cannot find your required size, you can also send us an email with the completed PDF form. With this, we can have a plate manufactured individually for you. Number of slots: 3 Edge distance: 185 mm Slot spacing: 270 mm Slot width: 28 mm Cast iron quality: HT250 Flatness less than 0.12 mm Surface machined according to DIN 876 Edge distance: 185 mm Slot spacing: 270 mm Ijdpfotq Dwtsx Adqjih Slot width: 28 mm Cast iron quality: HT250 Flatness less than 0.12 mm Surface machined according to DIN 876/III

Kondisi: sangat baik (bekas), Mounting plate, scribing and spotting plate, measuring plate, measuring table, straightening plate, marking-out plate, test plate, inspection plate, precision measuring table Iedpfjw H Apbsx Adqsih - Mounting plate with 14 mm T-slots - Clamping surface: 1500 x 3000 mm - Plate thickness: 40 mm - Plate with support ribs - Including: 6 adjustable leveling feet - Dimensions: 1560 x 3000 x H355 mm - Weight: 2300 kg

Kondisi: bekas, Table unit from a DROOP & REIN gantry milling machine Clamping plate with T-slots made of cast steel/grey cast iron Table unit with clamping plate and extremely robust guideway Table clamping surface: 5500 x 2000 mm Travel path of the table clamping plate: approx. 3100 mm Table height/overall height: 1050 mm Table load capacity: max. 20 tons Ballscrew: Ø 100 mm Thread pitch: 20 mm (single start) - Machining table is very stably guided on the bed - Metal telescopic way cover - Originally from a DROOP & REIN gantry milling machine - Longitudinal table movement via ballscrew and SIEMENS servo motor - Clamping surface with 11 T-slots, 28 mm - Drive by SIEMENS servomotor 1FT6134-6AB71-1AG2 with encoder IC200448S/R (RN 000 B25) Iodpfxsthuzpe Adqjih Overall length: 9500 mm Width: 2000 mm Overall height: 1050 mm Net weight: 28 tons Good condition

Kondisi: baru, Plate depth: 4000 mm Plate width: 2000 mm Plate height: 600 mm Weight: 6700 kg GERD WOLFF clamping cube 4000 x 2000 x 600 mm If you did not find the size you require, simply send us an email with the completed PDF form. This allows us to offer you a custom plate, tailored to your specific requirements. Ijdpfxjvu Hmhs Adqjih T-slot dimensions: 52 x 28 mm T-slot spacing: 500 mm Number of slots: 8 x 8 Edge distance: 250 mm Weight: 6700 kg Cast quality: HT250 Flatness: less than 0.12 mm Surface machined according to DIN 876/II Keywords: Clamping cube, cubic clamping table, multi-side clamping, angle clamping cube, precision cube, CNC clamping cube, clamping angle, machine cube, 90-degree clamping fixture, drilling hole cube, modular clamping cube, workpiece positioning, assembly cube, fixing cube, clamping block.

Kondisi: baik (bekas), Clamping plate, marking and scribing plate, surface plate, measuring table, alignment plate, marking plate, inspection plate, control plate, precision measuring table - Clamping plate: with support ribs - Clamping surface: 2010 x 4010 mm - Plate thickness: 55 mm - Plate: with support ribs Ijdpfx Aow Hz Rkedqjih - Quantity: 1 piece of clamping plate available - Price: per piece - Dimensions per piece: 2010/4010/H350 mm - Weight: 6100 kg/piece

Kondisi: bekas, Straightening and welding plate made of solid steel Machined steel plate from a tool frame Ijdpfshwn Tusx Adqoih Length: 2980 mm Width: 1580 mm Thickness: 94 mm - Solid steel plate - Milled surface - 4 bolted towing brackets - Plate equipped with several symmetrically placed bores Net weight: 3,400 kg

Kondisi: baru, Plattensyvyys 1000 mm Levyjen korkeus 600 mm Paino 2200 kg GERD WOLFF Aufspannwürfel 1500 x 1000 x 600 mm Jos et löytänyt haluamaasi kokoa, lähetä meille sähköpostilla täytetty PDF-lomake. Näin voimme tarjota sinulle yksilöllisen levyn, joka on räätälöity vaatimustesi mukaan. T-urien koko: 38 x 22 mm T-urien väli: 140 mm Iodpfxevn U Ugo Adqjih Urailuku: 10 Reunaetäisyys: 80 mm Paino: 2200 kg Valurautalaatu HT250 Tasaisuus alle 0,12 mm Pinta työstetty DIN 876/II -standardin mukaisesti Avainsanat: Kiinnityskuutiot, kuutio-kiinnityspöytä, monipuolinen kiinnitys, kulma-kiinnityskuutiot, tarkkuuskuutiot, CNC-kiinnityskuutiot, kiinnityskulmat, konetyöstökuutiot, 90 asteen kiinnityslaite, porausreikäkuutiot, modulaariset kiinnityskuutiot, työkappaleen asettelu, asennuskuutiot, kiinnityskuutiot, kiinnityspalat.

Kondisi: bekas, Clamping plate, machine table with metal base Clamping table, assembly table, angle plate Clamping surface: 1200 x 370 mm T-slot spacing: 90 mm Table height: 870 mm Iodpfxowkvi Ne Adqoih - The slotted table was originally a machine table from a milling machine - 4 pcs. T-slots, 16 mm - Metal base with height-adjustable feet - Multi-ply wood panel L x W x H 1200 x 400 x 18 mm Overall dimensions L x W x H 1400 x 770 x 870 mm Weight: 250 kg Good condition

Kondisi: baru, Plate width 700 mm Plate depth 700 mm Plate height 1000 mm Machine weight approx. 750 kg Space requirement approx. 700 x 700 x 1000 mm The GERD WOLFF clamping tower, with overall dimensions of 700 x 700 x 1000 millimeters, is equipped with T-slot plates on all four sides. If you have not found your required size, you can also send us an email with the completed PDF form. With this, we can have a plate custom-manufactured for you. Iijdpfjudddqox Adqoh T-slot width: 22 and 38 millimeters Plate thickness: 65 millimeters T-slot spacing: Edge distance: 39 mm Number of slots: 9 Surface machined according to DIN 876/III Weight: 750 kg Material: EN-GJL-250 The cast iron grade EN-GJL-250, characterized by lamellar graphite, is notable for its high thermal conductivity, excellent damping properties, and good rigidity. This material also combines good machinability with high compressive strength and vibration damping characteristics. EN-GJL-250 is particularly suitable for mechanically stressed machine components as it is easily machinable while providing excellent surface finish. Clamping cube – T-slot plates – plate field

Kondisi: bekas, Steel straightening and welding plate, solid material Machined steel plate from a tool frame Length: 2980 mm Width: 1380 mm Thickness: 74 mm Iiedpfx Adshwn Tijqeh - Solid steel plate - Milled surface - 4 bolted towing brackets - Plate equipped with several symmetrical boreholes Net weight approx. 2,380 kg

Kondisi: baru, Tahun pembuatan: 2025, Platen width 1000 mm Platen depth 1000 mm Platen height 1000 mm Weight 2400 kg Maximum load 10,000 kg The GERD WOLFF clamping cube, with an overall dimension of 1000 x 1000 x 1000 millimeters, is equipped with T-slot plates on all four sides. Thanks to its impressive static load capacity of 10 tons, this cube is the ideal choice for demanding applications in heavy metal industry environments. Deformation under a load of 10 tons is only 0.016 millimeters, ensuring maximum precision and stability. If you cannot find the required size, you can also send us an email with the completed PDF form. We can use this to manufacture a custom-made plate tailored to your requirements. Parameters can be freely combined. Load capacity: 10 tons Iedpfxeuddg Es Adqoih T-slot width: 17.9 and 31.6 millimeters Plate thickness: 85 millimeters T-slot pitch: Edge distance: Number of slots: Cast quality: HT250 Flatness less than 0.12 mm Surface machined to DIN 876/III Weight: 2400 kg Clamping cube – T-slot plates – platen field.

Kondisi: bekas, Straightening and welding plate, made of cast steel and gray cast iron, heavily ribbed Heavy-duty straightening plate Length: 1600 mm Width: 1005 mm Thickness: 280 mm Plate thickness: approx. 85 mm throughout - Center hole Ø 245 mm, 400/800 mm - Threaded holes M20, approx. 55 mm deep Ijdpsdzqbasfx Adqeih - Through holes Ø 27 mm Weight: approx. 2.5 t Good condition Former press table – most likely machined parallel on both sides

Kondisi: bekas, Round clamping plate with T-slots Alignment plate and clamping table Diameter Ø 1500 mm Central centering bore Ø 80 mm Plate thickness 54 mm Iiodpjv Ed Svjfx Adqoh Working height 970 mm - 6 T-slots, 18 mm - 3 threaded holes, M20, bolt circle 1000 mm - Steel base without central bore Weight 785 kg Good condition
