Beli Handwheel bekas (1.506)

Tahun pembuatan: 2004, Kondisi: sangat baik (bekas), Used machining center Brand: Hermle Model: U740 Year: 2004 Serial No.: 16716 Nsdpfx Abjktkdbovjkw Weight: 7,300 kg Power: 26 KVA CNC: Heidenhain iTNC 530 Type: 4 + 1 axis (Spirsin model 8117CF/225) 16-position tool changer General technical data: Rapid Traverse Rates: - X axis: 30 m/min - Y axis: 30 m/min - Z axis: 20 m/min - B axis: 15 rpm Travel: - X axis: 915 mm / 895 to 915 mm (Tool head -5º to 90º / Tool head > 50º to 95º) - Y axis: 500 mm (At all tool head positions) - Z axis: 500 mm / 470 mm (Tool head 90º-95º) Positioning accuracy on the 3 axes: 0.010 mm (At 20ºC) Maximum table load: 700 kg Table dimensions: 900 x 500 mm Spindle speed: 12,000 rpm Water-cooled spindle motor with hollow shaft design Milling head with automatic angular adjustment from -5º to +95º Tool holding system: SK 40 16-position tool magazine - Maximum tool diameter: 80 mm - Maximum tool diameter with adjacent positions free: 100 mm - Maximum tool length: 250 mm - Maximum tool weight: 6 kg Coolant system with 210-liter tank and 30 l/min flow rate Electronic handwheel for manual machine operation Chip conveyor: - Brand: BMF - Model: SPE 63/12-300 Z600 - Year: 2004

Kondisi: hampir baru (bekas), Fungsionalitas: berfungsi sepenuhnya, panjang penggilingan: 650 mm, lebar penggilingan: 300 mm, diameter roda gerinda: 160 mm, berat keseluruhan: 2.550 kg, daya: 4 kW (5,44 hp), Brand: CCP - STANKOIMPORT Model: 3E711B Grinding dimensions: 650x300mm (X, Y) - 320mm (Z) Magnetic table surface: 630x200mm Maximum table load: 150kg Distance spindle axis to table surface: 80 - 445mm Maximum wheelhead travel: 365mm Manual table travel: (700mm, 250mm) Table longitudinal feed speed: 2 - 30 m/min Cross feed speed: 0.01 - 1.5 m/min Vertical feed graduation: 0.002mm Micrometric vertical feed graduation: 0.0005mm Cross feed graduation: 0.5mm Micrometric cross feed graduation: 0.001mm Cross travel per handwheel revolution: 5mm Vertical travel per handwheel revolution: 0.20mm Automatic cross feed (longitudinal table stroke): 0.2 - 30mm Automatic wheelhead feed: 0.002 - 0.08mm Njdpfx Aeqy H Dpsbvjkw Grinding wheel dimensions: 250x76x40mm Minimum grinding wheel diameter: 160mm Spindle motor: 4kW Weight: 2550 kg.

Kondisi: baru, kapasitas angkut: 300 kg, diameter meja putar: 600 mm, Capacity: 300 kg Max. height, center of gravity: 200 mm Max. eccentricity, center of gravity: 150 mm Table diameter: 600 mm Motor power: 0.37 kW Table tilt: Manual, via handwheel Nedpfjuf Nk Eox Abvjkw Rotation speed: 0.1 – 1.0 rpm Manual operation: By foot pedal (right/left rotation) Automatic operation: By selector switch on control panel Tilt angle (degrees): 0–90 Frequency inverter: Danfoss Electrical components: Schneider

Kondisi: baru, kapasitas angkut: 100 kg, diameter meja putar: 400 mm, Capacity: 100kg Nkodpsuf Niujfx Abvew Max. height, center of gravity: 150mm Max. eccentricity, center of gravity: 100mm Table diameter: 400mm Motor power: 0.2kW Table tilt: Manual, via handwheel Rotation speed: 0.4 – 4.0 rpm Manual operation: Via foot pedal (Clockwise and Counterclockwise rotation) Automatic operation: Via selector on control panel Tilt angle (degrees): 0-90 Frequency inverter: Danfoss Electrical components: Schneider

Kondisi: bekas, Fungsionalitas: berfungsi sepenuhnya, ketebalan lembaran (maks.): 6 mm, Hydraulic Shear HACO 3000x6mm TS-3006 Brand: HACO Njdpfxewx Ix Ss Abvekw Model: TS-3006 Power Supply: 380V Three-phase Cutting Length: 3,050 mm Cutting Thickness: 6 mm Type: Vertical cut, motorized blade angle adjustment (0.5 to 3º) Backgauge: 750 mm (Motorized with manual handwheel for fine adjustment) Manual blade clearance adjustment via lever at the rear Weight: 4,500 kg Motor Power: 7.5 kW

Kondisi: bekas, Fungsionalitas: berfungsi sepenuhnya, Tahun pembuatan: 2000, berat keseluruhan: 4.500 kg, Gunting hidrolik potong vertikal Merek: HACO Model: TS 306 Penjual: Casanova Tiga fasa 380V Tahun: 2000 Tipe: Potong vertikal (kemiringan pisau) Panjang potong: 3050mm Kapasitas: 6mm Pengaturan sudut potong: 0,5-3 derajat Jumlah penahan: 13 Nksdpoxgdlnjfx Abvew Pukulan per menit: 8-14 Lengan siku: 1000mm Batas belakang: 750mm Batas belakang bermotor dengan roda tangan penyesuaian halus Motor: 7,5 kW Berat: 4500kg

Kondisi: sangat baik (bekas), Tahun pembuatan: 2018, Fungsionalitas: berfungsi sepenuhnya, kedalaman pengeboran: 1.600 mm, panjang pemakanan sumbu X: 3.000 mm, panjang umpan sumbu Y: 2.100 mm, panjang umpan sumbu Z: 1.500 mm, berat keseluruhan: 50.000 kg, kecepatan pemakanan sumbu X: 10.000 m/menit, laju pemakanan gandar Y: 10.000 m/menit, laju pemakanan sumbu Z: 10.000 m/menit, kecepatan spindel (maks.): 4.500 rpm, diameter bor: 40 mm, panjang meja: 2.100 mm, lebar meja: 1.900 mm, CNC Heidenhain iTNC 640 AXES OF MOVEMENT Maximum drilling depth in a single operation, V axis: 1,600 mm Table travel, horizontal movement X axis: 3,000 mm Vertical movement Y axis: 2,100 mm Column approach movement (milling), Z axis: 1,500 mm Tilting of drilling slide (resolution 0.001°), A axis: +30°/-15° Table rotation (resolution 0.001°), B axis: 360° Maximum axis feed rate: 10,000 mm/min DEEP HOLE DRILLING SPINDLE ISO 50 AND MILLING Solid drilling section: 5 - 25 mm Maximum drill bit diameter: 40 mm AXES OF MOVEMENT Maximum drilling depth in a single operation, V axis: 1,600 mm Table travel, horizontal movement X axis: 3,000 mm Vertical movement Y axis: 2,100 mm Column approach movement (milling), Z axis: 1,500 mm Tilting of drilling slide (resolution 0.001°), A axis: +30°/-15° Table rotation (resolution 0.001°), B axis: 360° Maximum axis feed rate: 10,000 mm/min DEEP HOLE DRILLING SPINDLE ISO 50 AND MILLING Solid drilling section: 5 - 25 mm Maximum drill bit diameter: 40 mm Spindle speed (adjustable): 1 – 4,500 rpm Spindle power S1: 17 kW Spindle torque: 324 Nm Standard attachment for drilling tools: Ø 25 x 70 mm Maximum internal spindle pressure: 120 bar Taper type: ISO 50 DIN 69871/A Coolant: YES ROTARY TABLE Rotary table dimensions: 1,900 x 2,100 mm Rotary table resolution (0.001°), B axis: 360° Table load capacity in rotation: 20,000 kg T-slots: 22 mm OIL SYSTEM Hydraulic pump motor power: 4 – 7.5 kW Self-regulating oil pressure: 15 – 120 bar Self-regulating oil flow rate: 5 - 80 l/min Oil tank capacity: 800 – 1,000 L Cooled oil temperature: 25 – 32 °C Filtration degree: 16 micron MACHINE DIMENSIONS & WEIGHT: Width x Length x Height: 7,000 x 7,900 x 4,700 mm Machine weight: 50,000 kg WORKING CHARACTERISTICS FOR GUN DRILLING Maximum depth: 1,600 mm Maximum rotation speed: 4,500 rpm Minimum drilling diameter: 6 mm Nkodpfjywnr Njx Abvsw Maximum drilling diameter: 40 mm THREADING HEAD “IMSASISTEM” WORKING CHARACTERISTICS Max rotation speed: 4,500 rpm Maximum threading on C40 steel: M 36 Machine equipped with: • Remote Heidenhain electronic handwheel • ISO 50 tool changer magazine with 40 positions • 4,000 m³/h fume extraction system • Air/oil supply through spindle center • M24 threads on table side • Various tools and work equipment • Tool rack with various drill bits • Operation and maintenance manual, CE declaration of conformity

Kondisi: bekas, Tahun pembuatan: 2011, Technical details: X-axis travel: 8,500 mm Nkodeytrw Topfx Abvsw y-axis travel: 2,000 mm z-axis travel: 1,500 mm Rapid traverse x/y/z: 25 m/min Table size: 10,000 x 1,350 mm Table load capacity: max. 5 t/m² Universal milling head: orthogonal, 1° x 1° Tool holder: SK 50 Spindle speed range: 4,000 rpm Drive power: 37 kW Spindle torque: 900 Nm Internal coolant supply: 15 bar CNC control: HEIDENHAIN iTNC 530 Tool changer: 60 positions Total connected load: 75 kW Space requirements (LxWxH): approx. 12.7 x 5.2 x 4.6 m Machine weight: approx. 35 t Universal travelling column machining center, with orthogonal milling head, water-cooled, 1° indexing in 2 axes (360 positions in the rear and 270 positions in the front plane), 3D wireless probe M&H 20.41, partition wall for parallel operation/setup, internal air blast, internal coolant supply 15 bar, adapter for high-speed milling spindles with torque support, operator platform travels with machine, chip conveyor, electronic handwheel HR 410, monitored safety fences. Various accessories (angle milling heads, clamps, etc.) available as options. Approx. 39,000 power-on hours, approx. 16,000 spindle hours. Still under power and available for viewing at the current location.

Kondisi: bekas, Tahun pembuatan: 2016, 1 Njdpjytrw Hofx Abvekw

Kondisi: bekas, Tahun pembuatan: 1998, en-230607-technical-data-universal-grinding-machine Nkodpfsxvy Hgjx Abvew

Kondisi: baik (bekas), Tahun pembuatan: 2021, jarak pergerakan sumbu X: 950 mm, jarak lintasan sumbu Y: 850 mm, jarak gerak sumbu Z: 650 mm, We offer you: Universal CNC machining center Manufacturer: DMG MORI Model: DMU 95 monoBlock Year of manufacture: 2021 Control: Celos with Siemens 840D sl Operate Travel distances: - X-axis travel: 950 mm - Y-axis travel: 850 mm - Z-axis travel: 650 mm - C-axis: 360° - A-axis: +/- 120° Main spindle: - Speed: 20,000 rpm - Drive power (40/100%): 25 / 35 kW - Torque: 130 / 86 Nm - Tool interface: HSK-63A Nkodpfxsx Ekt Ee Abvsw Worktable: - Rigid table with integrated rotary table - Table diameter: C-axis 850 x 750 mm integrated in rigid table 1,000 mm x 750 mm - Max. table load: 1,000 kg - Max. workpiece dimensions: Ø 1,040 mm (clampable) / Ø 850 mm (machinable), height 590 mm Tool changer: - Number of tool pockets: 60 positions - Tool-change time (chip-to-chip): 5.9 s - Max. tool diameter: 80 / 160 mm - Max. tool length: 420 mm - Max. tool weight: 8 kg Rapid traverse: - Rapid traverse speed (x/y/z): 40 m/min - Max. feedrate (x/y/z): 40,000 mm/min - Total power-on hours: approx. 25,300 h - Operating hours: approx. 7,200 h Features and accessories: - Double-gripper tool changer - MPC – Machine Protection Control - Economic Production Package (GER / EU) - Production package: Scraper flight chip conveyor with coolant unit 600 l / 160 gallons Paper band filter Internal coolant supply, 40 bar / 23 l/min, through spindle center (AD) External coolant supply, 4 bar – 40 l/min (theoretical pump capacity) Chip flushing at cabin door (not standard coolant system) - Spray gun for chip cleaning - Air-blast cooling through spindle center, selectable via M function - Chip flushing at cabin door: 1.5 bar / 60 l/min (theoretical pump capacity, recommended for heavy chip loads) - Coolant ring nozzle for vertical head: 16 water jets, 7 air jets - Mechanical and electrical interface for oil & emulsion mist extractor - Infrared probe, type Renishaw PP60 optical (OMP 60) - Tool measurement in working area, Blum Laser DIGILOG - 3D quickSET preparation - SGS – Spindle Growth Sensor - Increased accuracy - Electronic hand wheel - ATC (Application Tuning Cycle), programmable feed parameter selection for machining tasks: accuracy / surface / speed - DECKEL MAHO MDynamics package - IoTconnector - Machine Data Connector (MDC) - NETservice - SERVICEcamera - 3D data model in STEP format for CAD system integration Clamping devices shown are not included in the scope of supply. Accessories and depicted tools are only included with delivery if specified in the additional information. Changes and errors in technical specifications and details as well as prior sale are reserved!

Kondisi: bekas, Tahun pembuatan: 2017, We offer you: CNC Bed Milling Machine Manufacturer: DMG MORI Type: DMF 260-11 linear Year of manufacture: 2017 Control: Celos with Siemens 840D sl Operate Main spindle renewed Technical specifications: Travel paths: - X-axis travel: 2,600 mm - Y-axis travel: 1,100 mm - Z-axis travel: 900 mm Nkedpfxewtd A Nj Abvow Main spindle: - Speed range: 20 - 15,000 rpm - Drive power (40/100%): 46 / 30 kW - Torque (40/100%): 200 / 130 Nm - Tool holder: SK 40 Worktable: - Fixed table with integrated rotary table - Clamping area: 3,200 x 1,100 mm - Rotary table diameter: 1,050 mm - Max. table load: 1,200 kg Tool changer: - Number of tool stations: 60 positions - Chip-to-chip time: 7.5 s - Power-on hours: approx. 21,000 h - Operating hours: approx. 9,200 h Special features: - ICS 40 bar (internal coolant supply) - Spray gun for chip extraction - Rotating inspection window - Tropical kit - Dynamic package Accessories: - Paper band filter 600 l - Chip conveyor - Heidenhain TS 649 DMG touch probe - 3D quickSET - 2x oil and emulsion mist separators - 4-color signal lamp - Electronic handwheel Accessories, depicted tools, and clamping devices are only included in the delivery if specified in the additional information. Technical data and specifications are subject to change and errors. Prior sale reserved!

Kondisi: bekas, Tahun pembuatan: 2021, Fungsionalitas: berfungsi sepenuhnya, tegangan masuk: 400 V, arus masuk: 10 A, frekuensi input: 50 Hz, jenis arus masuk: tiga fasa, berat keseluruhan: 280 kg, tekanan kerja: 6 batang, sambungan udara terkompresi: 6 batang, sambungan pneumatik: 6 batang, tekanan: 6 batang, We offer this used BI-MATIC Prima Plus 7.3-r.a. Edge Banding Machine Partnership Edition, year of manufacture 2021. Units: Jointing unit including AIGNER diamond jointing cutter heads with DIA replaceable knife system Konstantin, and controlled edge air nozzle behind the second jointing cutter head. End trimming saw unit with extraction device, including pneumatically tiltable saw blades, adjustable and programmable from the control panel. Radius milling unit. Corner rounding unit (copy milling unit) with insert bottom function and 2-position turret. The entire unit can be pneumatically engaged and disengaged. Radius scraper unit, engageable and disengageable, including extraction device with chip collection box for scraper chips. Nedpfjya I Ubsx Abvekw Flat scraper unit with 4-times usable scraper knife. The entire unit can be engaged/disengaged. Removed glue residues are extracted. Buffing unit with 2 fabric buffing wheels arranged at an angle. Features: - High gloss package: roller scanning for radius milling unit, radius scraper unit and flat scraper unit - Large visibility, noise, and safety enclosure for all units and the glue pot - Interior lighting - Control panel with 12'' touchscreen and intuitive operator guidance - USB port for data backup and transfer - Network connection for online support - Controlled pneumatic cylinder for workpiece distance control - Teflon-coated glue pot with quick-change system and energy-saving standby mode - Glue roller with feed screw for long and high workpieces (especially for PUR adhesive) - Pressure zone with motor-driven first pressure roller - Heavy-duty guillotine shears for edges 54 x 3 mm - Infeed fence adjustable by handwheel (jointing thickness setting) with digital display - Upper pressure beam with digital workpiece thickness display and handwheel adjustment - Pressure zone with digital display and handwheel adjustment - Manual 2-position turret for radius milling unit - Manual 2-position turret for corner rounding unit - Manual 2-position turret for radius scraper unit Technical Data: Edge thickness: 0.4 - 3 mm Min. panel width (without corner rounding unit): 80 mm Min. panel width (with corner rounding unit): 130 mm Min. panel length (without corner rounding unit): 100 mm Min. panel length (with corner rounding unit): 300 mm Min. panel thickness: 10 mm Max. panel thickness: 50 mm Feed speed: 9 m/min Extraction port: 2 x 150 mm Connection: 9 kW - 400 V Compressed air: 6 bar Order no.: BIMA0650 If you have any questions or require further information, please do not hesitate to send us a message or give us a call.

Kondisi: bekas, Tahun pembuatan: 2010, Fungsionalitas: berfungsi sepenuhnya, Pengoperasian pertama: Maret 2010 Nedpfxoytf H Ie Abvokw Kontrol: Fidia dengan handwheel HPX21 Sumbu X: sekitar 11.500 mm Sumbu Y: sekitar 1.550 mm Sumbu Z: sekitar 2.550 mm Sumbu B: ± 210° Sumbu C: ± 104° Kecepatan spindle: maks. 16.000 rpm Tipe holder alat: HSK 50A Penggerak sumbu linier Kecepatan feeding sumbu X, Y, dan Z: 16 m/menit

Kondisi: siap digunakan (bekas), Tahun pembuatan: 1991, agro-ind-mach_bandsaw_2024 Nkjdpfx Absxab R Uevsw

Kondisi: diremaj di bengkel (bekas), Tahun pembuatan: 2017, Fungsionalitas: berfungsi sepenuhnya, diameter pembubutan: 150 mm, kecepatan spindel (maks.): 6.000 rpm, jarak pergerakan sumbu X: 100 mm, jarak gerak sumbu Z: 220 mm, gerak cepat sumbu X: 30 m/menit, pergerakan cepat sumbu Z: 30 m/menit, jenis arus masuk: tiga fasa, berat keseluruhan: 5.700 kg, hidung spindel: JIS A2-5, Jumlah stasiun alat bermotor di turret alat 1: 10, Jumlah stasiun alat bertenaga di turret alat 2: 10, de Nedpfx Aeytrnlobvjkw

Tahun pembuatan: 2018, Kondisi: siap digunakan (bekas), - BEKAS - MESIN BUBUT CNC 2-SUMBU DIAMETER PUTAR MAKS: 420 mm PANJANG PEMBUBUTAN MAKS: 291 mm DIAMETER PEMBUBUTAN MAKS: 320 mm SPINDEL: 3200 rpm; 7,5-11 kW JARAK GERAK SUMBU X: 190 mm JARAK GERAK SUMBU Z: 350 mm GERAK CEPAT X-Z: 24 - 30 m/menit KEPALA MENARA: 12 POSISI UNIT KONTROL: FANUC 0i-TF BERAT: 3500 Kg Nodpfx Absyry R Eovjkw DIMENSI TOTAL: 2214 x 2220 x 2713 mm AKSESORIS: KONVEYOR SERBUK LOGAM; HANDWHEEL PORTABEL CATATAN: DENGAN SISTEM LOADING TIPE GANTRY 16 POSISI

Tahun pembuatan: 2001, Kondisi: siap digunakan (bekas), - BEKAS - MESIN GERINDA LUAR CNC TINGGI PUSAT: 180 mm JARAK ANTAR PUSAT: 1600 mm PANJANG GERINDA MAKS: 1100 mm MAKS BEBAN YANG DIIZINKAN: 150 kg DIAMETER GERINDA: 300 mm Nsdpfx Abjyry Rxjvokw PERGERAKAN SUMBU X: 350 mm PERGERAKAN SUMBU Z: 1250 mm UKURAN BATU GERINDA: 610 x 120 x 203,2 mm DAYA MOTOR: 11 kW UNIT KONTROL: FANUC 18i0 TA BERAT: 8.400 kg DIMENSI KESELURUHAN: 3380 x 2200 x 1800 mm AKSESORIS: FILTER KERTAS; HANDWHEEL PORTABEL CATATAN: PENYEIMBANG DINAMIS OTOMATIS BATU GERINDA; PENOPANG SENDI UNTUK PENGGANTIAN BATU GERINDA; SISTEM PEMBENTUK BATU GERINDA; ALAT PEMOTONG DI UDARA; KEPALA DIAMETER DAN AKSIAL MARPOSS UNIMAR.

Kondisi: bekas, Tahun pembuatan: 2006, Travel X-axis: 1,000 mm Travel Y-axis: 1,000 mm Travel Z-axis: 1,200 mm C-axis: 360° x 0.001° A-axis: ° Control: SINUMERIK 840D Powerline SIEMENS Table size: 900 x 700 mm Milling spindle taper: HSK-A100 Spindle speeds - stepless: 12,000 rpm Tool magazine: Chain type, 180 positions Total power requirement: 85 kW Machine weight approx. 20.5 t Space requirements approx. 6.5 x 6.1 x 3.5 m 5-axis machining center with horizontal milling spindle arrangement Nkjdpfxsw E Nnnj Abvew Control: SIEMENS SINUMERIK 840D Powerline electronic handwheel NC rotary-swivel table Rotoclear window Probe interface prepared Blum laser tool measurement Vibration sensor Tool taper cleaning Operating mode 4 IKZ (internal coolant supply) with 2 pumps, 40 bar and 80 bar Chip conveyor Belt filter system Mist and smoke separator Cooling / heating unit

Kondisi: baru, - Infinitely variable, tiltable sanding unit (0–90°) for vertical and horizontal sanding - Oscillating sanding belt for improved sanding results and extended belt service life - Fast and easy sanding belt changes via quick-release system - Graphite-coated sanding plate as standard for increased belt durability - Worktable made of cast iron, adjustable via handwheel, with T-slot - Includes lateral sanding drum attachment for sanding curves and radii - Two extraction ports, Ø 100 mm Nkjdevxkv Ujpfx Abvew - 1x sanding belt 2750 x 150 mm grit 80 - 1x sanding drum Ø38 mm grit 80 - 1x sanding drum Ø50 mm grit 80 - 1x sanding drum Ø75 mm grit 80 Dimensions and weights: - Length (product) approx.: 1515 mm - Width/depth (product) approx.: 550 mm - Height (product) approx.: 1150 mm - Weight (net) approx.: 207 kg Extraction connection: - Extraction port diameter: 100 mm Worktable(s): - Worktable length: 900 mm - Worktable width: 305 mm - Worktable height adjustment: 120 mm Electrical data: - Connection voltage: 400 V - Mains frequency: 50 Hz Sanding unit: - Belt length: 2750 mm - Belt width: 150 mm - Belt speed: 16 m/s - Oscillation stroke: 15 mm - Sanding area length: 1010 mm - Sanding area width: 190 mm - Max. sanding height: 170 mm - Sanding unit swivel: 0–90° Workpiece: - Max. workpiece width: 1010 mm - Max. workpiece height: 150 mm - New demonstration machine -

Kondisi: bekas, Tahun pembuatan: 2005, 1 Njdsyrhr Dspfx Abvjkw

Kondisi: baru, Tahun pembuatan: 2026, Z-MaT U320 5-Axis Simultaneous Machining Center Control System: ZMATROL 5-Axis Simultaneous, 15" LCD Screen (Optional Siemens ONE, 15" LCD Screen) (Siemens/Fanuc 4+1) Travel (X/Y/Z): 500/500/400 mm Rapid traverse (X/Y/Z): 48/48/48 m/min Cutting feed rate: 1-10,000 mm/min Spindle Spindle speed: 24,000 rpm, built-in Spindle taper: BT30 Spindle motor: 3.7/5.5 kW Through-spindle air blast Spindle air curtain Spindle oil cooler Tool changer: 21-tool disk Max. tool length: 200 mm Max. tool Ø: 60/100 mm Table Table diameter: Ø 320 mm Max. workpiece Ø: 320 mm Max. table load: 80 kg T-slot (width x qty x pitch): 14H8 x 8 x 45° Distance spindle center to table surface: 100-500 mm Nksdpfx Absyv A Trevew A-axis travel (tilting): ± 115° C-axis rotation: 360° Max. rapid traverse A/C axes: 100/130 rpm A/C-axis encoders Standard Accessories End-of-operation lamp, 3-color status light Electronic handwheel (MPG) Work area lighting Roller linear guides Automatic lubrication system (grease) 3-axis glass scales, air-purged (XYZ) Automatic tool changer Air gun Coolant gun Coolant tank Coolant flushing system (chip flushing) Full splash guard Transformer: 400V, 50Hz Cabinet heat exchanger Automatic shutdown Leveling bolts and blocks Toolbox CE compliance Hinged belt chip conveyor Machine Size and Weight Dimensions (L x W x H): 1800 x 3270 x 2510 mm Machine weight: approx. 4,300 kg Subject to prior sale and errors excepted. Extensive automation options available.

Kondisi: baru, Tahun pembuatan: 2026, en-Z-Mat TBX63S ZMATROL 15", 5-axis simultaneous (Siemens/Fanuc opt.) Turning/milling center with B-axis ±120°, 12,000 rpm 6" sub-spindle, Y-axis 150 mm Max. swing diameter: 450 mm Max. turning diameter: 250 mm Max. turning length: 750 mm Linear roller guides on all axes Main spindle Chuck diameter: 203 mm Spindle nose: A2-6 Max. bar diameter: 52 mm Spindle bore diameter: 66 mm Drive power, DDS: 18.5 kW Max. speed: 4000 rpm Sub-spindle Chuck diameter: 152 mm Spindle nose standard: A2-5 Max. bar diameter: 46 mm Spindle bore diameter: 56 mm Drive power, DDS: 11 kW Max. speed: 5000 rpm Milling spindle Spindle interface: HSK-T63 Max. speed: 12,000 rpm Drive power: 30 kW Max. torque: 95 Nm Axis travels X-axis travel, with Heidenhain glass scale: 790 mm Y-axis travel: ±75 mm Z-axis travel: 750 mm W-axis travel: 1,000 mm B-axis swivel range: ±120° Rapid traverse X/Y/Z/W axis: 24 m/min Tool magazine Double arm, 30 tools Max. diameter/length/weight: 78 mm / 250 mm / 8 kg Dimensions (LxWxH): 4.45 x 2.76 x 2.85 m Weight: 9.8 t Standard accessories 30 bar ICS (internal coolant supply) Ergonomic control panel with handwheel USB port, Ethernet, memory card Full enclosure Door safety switch Coolant system Nkedpfx Asyv A Naebvsw Electrical cabinet cooling Three-color warning light Work area illumination Central lubrication Tools and toolbox CE conformity Operating manual A variety of automation systems, such as bar feeders and loading robots, are available.

Kondisi: bekas, Tahun pembuatan: 2003, x-travel 1,600 mm y-travel 1,250 mm z-travel 1,000 mm Pallet size 1,000 x 1,250 mm Control system: SIN840D Drive power (40% duty cycle) 38.00 kW Spindle speed - stepless 20 - 10,000 rpm Drive power (100% duty cycle) 25.00 kW Torque at 40% / 100% duty cycle 288 / 187 Nm Tool holder SK50 Feed rate X/Y/Z axis 20 - 15,000 mm/min Rapid traverse X/Y/Z 60.00 m/min B-axis -150° / +80° x 0.001° B-axis feed rate 3,600° / min C-axis 360 x 0.001° C-axis rapid traverse 1 - 3,600 rpm Table load capacity 3,000 kg Tool magazine with 240 stations Nkodpfx Abjydflrjvsw Tool diameter 110 mm Tool diameter with 2 adjacent empty pockets 250 mm Max. tool length 650 mm Max. tool weight 15.00 kg Total power requirement 75.00 kW Machine weight approx. 55.00 t Required floor space approx. 12.50 x 8.00 x 4.20 m 5-axis machining center with SIEMENS Sinumerik 840D control Electronic handwheel Operation mode 4 240-position tool magazine 4-station pallet storage system Measuring probe TS641 BLUM laser Coolant system Through-spindle coolant supply Chip conveyor Coolant chiller

Kondisi: baru, Tahun pembuatan: 2025, jam operasional: 100 h, Fungsionalitas: berfungsi sepenuhnya, jarak pergerakan sumbu X: 800 mm, jarak lintasan sumbu Y: 550 mm, jarak gerak sumbu Z: 550 mm, gerak cepat sumbu X: 42 m/menit, pergeseran cepat sumbu Y: 42 m/menit, pergerakan cepat sumbu Z: 42 m/menit, daya nominal (semu): 25 kVA, torsi: 135 Nm, produsen pengendali: Siemens, model controller: 828D, berat benda kerja (maks.): 600 kg, tinggi total: 3.000 mm, panjang total: 2.600 mm, lebar total: 2.310 mm, lebar meja: 1.000 mm, panjang meja: 550 mm, beban meja: 600 kg, berat keseluruhan: 5.000 kg, kecepatan spindel (min.): 1 rpm, kecepatan spindel (maks.): 12.000 rpm, jam operasional spindle: 10 h, pasokan pendingin: 30 batang, daya motor spindle: 19.000 W, hidung spindel: HSK63A, jumlah spindel: 1, jumlah slot dalam magazin alat: 30, tegangan masuk: 400 V, jenis arus masuk: AC (pendingin udara), Perlengkapan: dokumentasi / manual, kecepatan rotasi dapat diubah tanpa batas, konveyor serpihan, Vertical Machining Center VM800 - Showroom Machine - Technical specifications: Control: Siemens 828D Milling spindle 12,000 rpm, HSK63 Through-spindle coolant (IKZ) 30 bar Bed flushing system Renishaw OMP60 probe (Heidenhain available on request) Tool measurement Renishaw TS27R (Heidenhain or BLUM available on request) Direct measuring systems from Heidenhain in X, Y, Z axes Rotating viewing window SPINVISTA (Black Edition) Automatic door Robot interface Automatic power-off function Automatic tool changer (30 positions HSK63) Centralized automatic lubrication system Telescopic guideway covers Electronic handwheel for manual operation Signal tower Operating manual Pneumatic air gun Nksdpfx Aboyr A T Aevow Water gun Air gun Chip conveyor Coolant tank 286L This and other machines from GEWA Werkzeugmaschinen GmbH can be viewed at our premises (Eifel) by appointment.
