Beli Tekan Bingkai bekas (5.352)

Kondisi: bekas, Working width 4000 mm Working height 2600 mm Number of pressing cylinders 6 pcs. Dimensions (length/width/height) 5300 x 1250 x 3330 mm S&S Frame Press Type RP 2000, ----- CE version Robust frame-welded construction made of thick-walled special hollow profiles, sliding carriages and pressure beams with 50 mm hole grid. Continuous left-side abutment for width pressing, lower abutment on two levels. Vertical pressing cylinders on special pressure beams with single-handed quick adjustment with weight balance, height-adjustable in 50 mm hole grid, long sliding carriages ensure the permanent absorption of high pressing forces. Fast and smooth width adjustment via ball-bearing mounted carriage with central locking, fixation in 50 mm hole grid. Bdedpfx Aleu Uvaloajb Upper horizontal pressing cylinder infinitely height adjustable and fitted with weight compensation. Lower horizontal pressing cylinder with centering bores for the two abutment levels, with weight compensation. Abutment and pressure plate depth: 100 mm Pressure plate and support width: 130 mm Machine is electro-hydraulically controlled, equipped with 2 vertical pressing cylinders d = 50 mm, stroke 120 mm, double-acting, with weight compensation and single-handed quick adjustment, 2 horizontal pressing cylinders d = 40 mm, stroke 120 mm (double acting), with weight compensation; 2 manual control valves, pressure gauge, 1 pressure control valve from 20 to 125 bar corresponding to 400 to 2400 kg pressing pressure vertical, with 3 kW three-phase motor for 400 Volt, 50 Hz mains voltage. Complete with electrical connection. Paint finish: RAL 7035 light grey with RAL 7016 anthracite grey Working size: 4000 mm x 2600 mm (length x height) Space requirement: 5300 x 1250 x 3330 mm (L x W x H) Machine including the following options: ----- Article ,00 pcs Central pressure beam with pressing cylinder double-acting, weight compensation, pressure hose and shut-off valve up to 2600 mm high Article ,00 pcs Individual pressure regulation for central pressure beam, pressure regulation range up to max. 100 bar (for pressing of cross-bar windows) Article ,00 pcs Cross pressure device complete with pressing cylinder double-acting, weight compensation, pressure hose and shut-off valve Weight compensation on lower horizontal cylinder omitted Article ,00 pcs Individual pressure regulation for cross pressure device, pressure regulation range up to max. 100 bar (for pressing of cross-bar windows) Article ,00 pcs Shut-off valve for 3rd vertical cylinder Article ,00 pcs Shut-off valve for upper horizontal cylinder Article ,00 pcs Width compensation pad for pressing small frames to bridge the 1st pressure beam, including shut-off valve on 1st vertical cylinder Article ,00 pcs Basic equipment for counter profiles The required height increases by 100 mm Article All pressure plates and abutments covered with plastic Article ,00 pcs Triangle studio window pressing device consisting of: locking device for vertical pressure beams and 3 attachable, side-guided swing pressure plates Article ,00 pcs Double swing pressure plate for pointed (triangle) windows ----- Total price as specified above ex works: On request! -----

Kondisi: baru, en-GB Bdodpsd Ih H Sefx Alajb

Kondisi: baru, Working width: 3500 mm Working height: 2300 mm Number of pressure cylinders: 4 pcs. S&S Frame Press Type T 35 – CE Version ----- Options: Working widths from 3,000 mm to 5,000 mm Working heights from 2,000 mm to 3,000 mm Bodsd Ih H Nepfx Alaedb Optional equipment available with intermediate pressure beams, angled window device, counter profiles for single-piece production, and much more! Request our complete price list! Description: Robust frame welded construction made of thick-walled special hollow profiles, sliding carriages and pressure beams with 50 mm grid hole spacing. Continuous left-side counter-bearing for wide surface pressing, lower counter-bearing on 2 levels. Vertical pressing cylinders mounted on special pressure beams with single-hand quick adjustment and weight compensation, height adjustable in 50 mm grid holes. Long sliding carriages ensure permanently high pressing force absorption. Quick, smooth width adjustment by ball-bearing carriage with central locking; fixing in 50 mm raster. Upper horizontal pressing cylinder continuously height adjustable and equipped with weight compensation. Lower horizontal pressing cylinder with centering bores for the two counter-bearing levels, without weight compensation. Counter-bearing and pressure plate depth: 100 mm Pressure plate and support width: 130 mm. Machine is electro-hydraulically controlled, with 2 vertical pressing cylinders d = 60 mm, stroke 120 mm, double-acting, with weight compensation and single-hand quick setting; 2 horizontal pressing cylinders d = 40 mm, stroke 120 mm, double-acting, with weight compensation; 2 manual control valves, manometer, 1 pressure control valve from 20 to 130 bar, equivalent to 550 to 3500 kg pressing force vertically. Equipped with 3 kW three-phase motor for 400 Volt, 50 Hz operating voltage. Complete with electrical connection. Paint finish RAL 7035 light grey with RAL 7016 anthracite grey. (Technical data according to manufacturer's information, errors excepted. Image may show optional equipment!)

Kondisi: bekas, Working width: 3600 mm Working height: 2600 mm Number of pressing cylinders: 5 units Loading dimensions (L x W x H): 4400 x 1150 x 2970 mm Weight: 3000 kg Schafberger + Sprödhuber Frame Press Bavaria ----- Machine will be overhauled by us prior to delivery With automatic pressing cycle + manual control For corner joints with mortise and tenon CE version Base machine in heavy-duty welded frame construction, with thick-walled special hollow sections. Guide rails for the pressure beams at the press corners manufactured for low wear. Bsdpfx Aljw T Un Ueaodb Quick and smooth manual width adjustment via ball bearing carriage, locking in detent system. Height adjustment and pressing via long-stroke cylinders in a single work cycle. Right-side press corners with integrated horizontal cylinders, thus no vertical positioning of the horizontal pressing cylinders necessary, which avoids cylinder collisions. The lower abutments can be set at multiple positions to the most favorable insertion height in each case. 3 vertical pressing cylinders, double-acting, stroke adapted to working height, 2 horizontal pressing cylinders, double-acting Abutment and pressure plate depth: 80 mm Working size: Length x Height = approx. 3,600 mm x 2,600 mm Required space/loading dimensions: approx. 4,400 mm x 1,150 mm x 2,970 mm (Length x Width x Height) Option: ALWA pressing aids for angled windows (Technical data according to manufacturer's specifications – subject to change! Images may differ from original, prices net, plus VAT (domestic))

Kondisi: baik (bekas), 21-26 - Hydraulische Presse KALLESOE (gebraucht) Werkstücklänge: 2.200 mm Werkstückhöhe: 1.400 mm Vertikalzylinder Ø70 mm Bedpfxjuctlnj Alasdb Motorleistung: 1,5 kW Hergestellt in Dänemark Transportmaße: 2.900 x 2.500 x 900 mm Gewicht: 500 kg Preis: 1.250 EUR (EXW Jonava, Litauen)

Kondisi: bekas, lt:Geros būklės Darbinis stalas: 2450x1000 mm Presuojamų dalių skaičius: 3 Presuojamos dalies plotas: 800x1000 mm Maksimalus darbinis aukštis: 500 mm Transportavimo matmenys: 2700x1000x1800 mm Svoris: 1055 kg Bjdpfxjq Tn Nuj Alasdb Kaina: 1100 Eur (EXW Jonava, Lietuva)

Kondisi: bekas, Tahun pembuatan: 1992, 1 Bedpfx Aswwxywjlajdb

Kondisi: sangat baik (bekas), Tahun pembuatan: 1992, 4.5 kW motor Working height: 245 cm Maximum working width: 365 cm Bjdpfx Alotq S H Aeaedb

Kondisi: baik (bekas), 0119 Brand: KOLMAG - ITALIA Modello: PGP 600 F Pressa idraulica per stampi, telai, elementi per mobili, porte in legno massiccio, materiali plastici, materiali compositi e vari. Struttura modulare della pressa realizzata con piastre pesanti di grosso spessore, senza saldature e lavorate a macchina utensile. Impianto oleodinamico dotato di sistema di prefilling dei pistoni per consentire una rapida apertura e chiusura dei piani. Dimensioni piani in acciaio massiccio: mm 1600 x 500 - Spessore mm 60, con resistenze elettriche - Temperatura massima 260°. N° 3 pistoni, diametro mm 240 Pressione kg/cm2 56 Spinta tonnellate 450 Barriere fotoelettriche di sicurezza Centralina idraulica Kw 7,5 Assorbimento potenza piani riscaldanti 31 Kw Quadro di comando con manometro controllo pressione - Timer di apertura piani - Teletermometro per regolazione temperatura piano superiore - Teletermometro per regolazione temperatura piano inferiore - Selettori apertura/chiusura piani - Pulsante di emergenza Ingombro totale mm 2250 x 1700 x 3300 h Peso kg 9000 Bodpfx Aewk Ntzelaodb

Kondisi: bekas, Tahun pembuatan: 1982, Pressing force 40 t Upright clearance 695 / 215 mm Stroke 100 mm Table clamping surface 650 x 440 mm Bdodjtqqq Rspfx Alaeb Ram surface 580 x 285 mm Installation height 400 mm Total power requirement 15 kW Machine weight approx. t Machine dimensions (L x W x H) 1.63 x 1.05 x 2.61 m - with draw cushion - with SICK light curtain

Kondisi: sangat baik (bekas), Tahun pembuatan: 2007, Window mounting press Bodpfet T Srpsx Alasdb

Kondisi: sangat baik (bekas), Tahun pembuatan: 1990, I am selling a Maweg Hildebrand Euro-Auto press for glulam bonding. Material size: 2800 x 2000 x 120 mm 2 pcs vertical hydraulic cylinders 2 pcs lateral hydraulic cylinders Bsdpfx Alog Dvu Teaedb Very good condition. Available immediately.

Kondisi: bekas, Tahun pembuatan: 1994, Frame press Schafberger & Sprödhuber Bodpsilurnefx Alajdb Model Super 4 kW 3 m x 6 m

Kondisi: baru, Tahun pembuatan: 2025, Fungsionalitas: berfungsi sepenuhnya, Aktions-M-Rahmenpresse Presse für alle Arten von Fenstersystemen: Fenster, Lamellenläden, Fensterläden und Massivholztüren. Bodpfx Alewh T Dleasdb Maximale Arbeitsabmessungen L x H: 3500 x 2500 mm Minimale Arbeitsabmessungen L x H: 250 x 375 mm Maximale vertikale/horizontale Presskraft: 7,4 / 2 t Arbeitshöhe: 480 / 1050 mm Hydraulikpumpenleistung: 2,1 kW MASCHINENZUSAMMENSETZUNG: - Aktions-M Rahmenpresse Stk. 1 - 109831 CE-Norm entsprechend SM 1 - R00494 Aktions M 35-25 1 - 930731 Spannung 400 V EU 1 - 931201 Frequenz 50 Hz 1 - 530074 Arbeitsflächen aus PVC-beschichteten Trägern 1 - 530075 Manuelle Zwischentraverse komplett mit Kolben und Gegenanschlag 1 - 530076 Hydraulikanlage für Niederdruckbetrieb 1 - 530077 Vorrichtung für trapezförmige Produkte mit schwenkbarem Kopf zur Anpassung an verschiedene Fenstereckausbildungen 1

Kondisi: baik (bekas), Tahun pembuatan: 2007, Frame press GOMA PHA 3500 Door Press Hydraulic Location Gorzów Wlkp. Delivery terms Bdsdpsdntc Nofx Alajb Self-collection Shipping cost Negotiable Commissioning type Negotiable Description Notes Working area: 3500 x 2300 mm, pressure: 1000 kg (daN), hydraulic unit motor: 2.2 kW, length: 3500 mm, height: 2300 mm, weight: 2000 kg, hydraulic unit included.

Kondisi: baru, Technical Data • System: for frame assembly • Minimum external frame dimensions (mm): 120 x 120 • Maximum external frame dimensions (mm): 700 x 2200 • System length (mm): 2750 • System width (mm): 1250 • System height (mm): 900 • Custom sizes: available Machine Features • Precise alignment of frame rails prevents displacement of mitre surfaces relative to each other • Manual alignment of frame rails is unnecessary • Cost-effective frame production through automation • No fixture-dependent limitation of frame dimensions Bsdjfiqllepfx Alasdb • Popular techniques for joining frame mitres are supported • Compact design ensures a small footprint • Simultaneous bonding of centre layer possible • Complete front panels can be bonded in a single operation

Kondisi: bekas, Tahun pembuatan: 2000, For fully automatic assembly of frame parts. Frame external dimensions: min. 120 x 120 mm, max. 1050 x 2,500 mm. 2 heating rails. Bdjdpfx Alod H Irfoaeb

Kondisi: bekas, Tahun pembuatan: 1986, - 2 pneumatic pressure cylinders for longitudinal axis - 2 pneumatic pressure cylinders for transverse axis - 2 pneumatic workpiece hold-down devices - Feed belt width: approx. 680 mm - Feed belt length: approx. 3,400 mm - Clamping area: 680 x 1,400 mm - Control panel Machine dimensions: - Length: approx. 3,400 mm Bjdpfxjiim Rno Alaodb - Width: approx. 1,700 mm - Height: approx. 1,400 mm - Weight: approx. 800 kg

Kondisi: baru, Tahun pembuatan: 2024, Frame and Edge Press with Manual Hydraulic Press Units, single-sided, stationary > Sturdy welded frame construction > Frame press device with continuous left-hand abutment > 1 sliding carriage for width adjustment with locking in 50 mm hole grid system, with central locking drive bolt Bdodpoyuxkofx Alaob > 2 horizontally and infinitely adjustable manual hydraulic press units, each with 20,000 N pressing force and 60 mm stroke > 5 roller-bearing, vertical pressure beams made of heavy-duty profile tube, electro-galvanized, with manual hydraulic press units, each with 20,000 N pressing force and 60 mm stroke. Press units adjustable in 50 mm hole grid. Abutment adjustable in 6 steps with anti-drop protection. Abutment and pressure plate 140 mm long, 80 mm deep. > 1 hold-down clamp, galvanized, for manual suspension with spindle pressure > Paint finish: grey white RAL 9002, pressure plate and abutment gentian blue RAL 5010. > Overall dimensions (W x H x D): 3340 x 2350 x 730 mm (long version: 3690 x 2350 x 730 mm) > Optionally available with a different number of vertical pressure beams (see accessories list) Usable dimensions (W x H in mm) as frame press: 2700 x 1800 Usable dimensions (W x H in mm) as edge press: 3000 x 1800 Price plus packaging: €92 net Special solutions on request!!

Kondisi: siap digunakan (bekas), Tahun pembuatan: 1993, nomor mesin/kendaraan: 9306005, Fungsionalitas: berfungsi sepenuhnya, Motorquickomat Z Automatic width and height adjustments Bdedpfx Alewa Sxxsajb Wood scanning Pressing time controlled

Kondisi: baru, Bending tools/punches for Trumpf press brake Bdodeiimz Repfx Alaeb H256mm, L500mm, L550mm in segments

Kondisi: baru, Press brake tools/punches for Bystronic press brake P5 RFA style, 30 degrees, H250mm, R1.0mm Flexible lengths: L500mm/508mm/515mm; L550mm in segmented sections Bsdpeiim Dwsfx Alaodb

Kondisi: baru, Press brake punch for Amada/Promecam 30-degree, radius 0.6 mm, height 104 mm, length 835 mm, length 835 mm, sectioned Bdsdpfx Alsin I Dtsasb

Kondisi: baru, 85 degree press brake punch for Amada/Promecam R2.0mm, H145mm, L835mm, L835mm sectioned Bdjdpfx Ajin I E Helaob

Kondisi: baru, Sonder-Umformwerkzeug Bdodpjiq Di Hofx Alaeb
