Beli Mesin Milling Universal bekas (76.792)

Kondisi: bekas, NC universal tool milling machine MAHO type MH 700 P with HEIDENHAIN TNC 121 contouring control . 71247 Circuit diagram no. ET 226 Year of manufacture: 1979 Travel X: 600 mm, Y: 400 mm, Z: 400 mm Table size: 900 x 500 mm Spindle taper: ISO 40 Spindle speed: 40-2000 rpm, 18 steps Feed rate X, Z axes: 1 - 600 mm/min, stepless Feed rate Y: 1 - 300 mm/min, stepless Rapid traverse X, Z axes: 1.5 m/min Rapid traverse Y axis: 0.75 m/min Quill movement vertical: 80 mm Quill movement horizontal: 80 mm Spindle drive: 4 kW Power supply: 380 Volt, 50 Hz, 10 kW - NC contouring control HEIDENHAIN TNC 121 - Vertical milling head with automatic quill feed - Hydro-mechanical tool clamping - Coolant system integrated in machine base Bcsdpfx Ajwd Szbehwjw - Universal rotary table, tiltable and inclinable via leadscrews +/- 30° - Universal rotary table with manual cross adjustment, 200 mm - Universal rotary table, 360° rotation with hydraulic clamping - Rotary table with direct indexing 72 x 5° and indirect indexing via index plate 1:120 = 1 revolution = 3° - Swivelling control panel - Central lubrication - Electrical diagram Space requirement (L x W x H): 2000 x 1650 x 2250 mm Weight: approx. 2800 kg Good condition

Tahun pembuatan: 2003, Kondisi: bekas, 1 used, very well-maintained universal milling machine with 3-axis FAGOR digital readout, infinitely variable feed and overhead support drive Manufacturer: ARSENAL, Bulgaria Model: FUV 321 M Year of manufacture: 2003 Technical data: Spindles: Spindle mounting vertical + horizontal: ISO 50 Speed range, vertical, stepless: 30 – 2000 rpm Speed range, horizontal, stepless: 30 – 2000 rpm Table: Clamping surface: 1350 x 320 mm X-axis, manual / mechanical: 1100 / 1080 mm Y-axis, manual / mechanical: 360 / 340 mm Z-axis, manual / mechanical: 460 / 440 mm Overarm adjustment: approx. 600 mm Table swivelling range: ± 45° Max. distance from table surface to horizontal spindle centre: 490 mm Max. distance from table surface to vertical spindle nose: 630 mm Table movement: Longitudinal and cross feeds, stepless: 12.5 – 630 mm/min Vertical feed, stepless: 5 – 262 mm/min Rapid traverse, longitudinal and cross: 2.5 m/min Rapid traverse, vertical: 1.04 m/min Drive Motor power: 7.5 kW Dimensions and weight Overall dimensions (L x W x H): 2000 x 2500 x 2050 mm Weight: 3200 kg Accessories / Special features: • 3-axis Digital readout, manufacturer FAGOR, model NV 300 M • Universal milling head, "HURON" system, manually adjustable across 2 planes • Infinitely variable feed via joystick and potentiometer on all 3 axes • Stepless speed control for vertical + horizontal via potentiometer with 2 servo drives by TELEMECANIQUE, model Altivar 28 • Stepless feed and stepless speed, each with digital display • Overarm with motorized drive for the universal milling head • Increased speed range up to 2000 rpm • Automatic machining cycle for the X-axis • Horizontal milling device with 2 counter-supports • Coolant system • Central lubrication system • Chip tray • Machine feet • Machine lamp Bcjdpebpmursfx Ahwsw • Operating manual • Electrical equipment CE • CE conform Original new price: €65,800.00 net The machine can be inspected and demonstrated under power at our warehouse at any time by prior appointment. Siegfried Volz Werkzeugmaschinen Ruüschebrinkstr. 151-153 D - 44143 Dortmund-Wambel

Tahun pembuatan: 1994, Kondisi: siap digunakan (bekas), A Hermle CNC universal milling and drilling machine is available. Travel X/Y/Z: 700mm/550mm/500mm, quill stroke: 95mm, spindle power: 12kW, spindle speed: 4,200 rpm, spindle swivel: +/-75°, tool holder: SK40, clamping force: 12kN, feed rate: 10m/min, rapid traverse: 10m/min. Machine dimensions (X/Y/Z): approx. 4,400mm/4,250mm/2,300mm, weight: approx. 4,500kg, control: Heidenhain TNC 425. Documentation available. Inspection on site is possible. Bcsdpfjw D Evlex Ahwjw

Kondisi: bekas, Tahun pembuatan: 2001, x-travel 2000 mm y-travel 920 mm z-travel 900 mm Clamping table area 2200 x 750 mm Table load capacity 3 t Number of T-slots 6 T-slot width 18 mm T-slot spacing 120 mm Spindle taper ISO 50 DIN 69871-B Max. spindle speed 3000 rpm Number of gear stages 1 Stepless speed range 1: 60 - 3000 rpm Machine weight approx. 21.6 t Feed rates - longitudinal/cross/vertical: 0 - 5000 mm/min Rapid traverse 15000 mm/min Total power requirement 38 kW Machine weight approx. 11 t Pull stud DIN 69872-B | ICS Operating hours: Bcsdpfx Aeg E Utxjhwew Control on: 43,036 hrs Machine on: 41,311 hrs Program run: 13,894 hrs The machine has already been dismantled.

Kondisi: baik (bekas), Tahun pembuatan: 1981, Table size 1300 x 400 mm Tool holder DIN 2080 ISO 40 Travel distances X-axis, automatic/manual 1000 / 1020 mm Y-axis, automatic/manual 350 / 370 mm Z-axis, automatic/manual 430 / 450 mm Spindle speed range, 2 steps 32 – 1400 rpm Quill in vertical milling head Yes Milling head, swiveling ± 90° Feed range X/Y axis, stepless 10 – 1000 mm/min Feed range Z axis, stepless 4 – 400 mm/min Rapid traverse X/Y axis 5 m/min Rapid traverse Z axis 1.8 m/min Drive power, vertical + horizontal 3.2/4 kW Floor space required (L x W x H) 3200 x 2700 x 2200 mm Weight 2400 kg Accessories / Special Features: • NC point-to-point control HEIDENHAIN TNC 131 S • RS 232 interface • Stepless (infinitely variable) feed Bcjdpfjd D Tf Hox Ahwsw • Automatic and/or manual operation possible • Safety devices / queries for securing the handwheel when moving the X, Y, and Z axes manually as well as for manual tool clamping • Vertical and horizontal milling spindle • Quill in vertical milling head • Hydraulic axis clamping • Central lubrication • Coolant system Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 D - 44143 Dortmund - Wambel

Kondisi: bekas, CNC Universal Tool Milling Machine HERMLE Type UWF 900 E Machine No. 10829 Year of manufacture: 1995 CNC contouring control Heidenhain TNC 415 B NC software 280540 PLC software 277677 06 Travels X: 600 mm, Y: 400 mm, Z: 400 mm Table size 900 x 458 mm Spindle taper ISO 40 Distance table – spindle nose 40 to 440 mm Spindle speed 20 – 4000 rpm, infinitely variable Feed rate 1 to 3000 mm/min. Rapid traverse X and Y = 7 m/min, Z = 6 m/min Spindle drive 7 kW Quill stroke (vertical head) 60 mm Bcodpfx Ahjwaaqiowjw - Spindle speed via 2 gearbox stages and stepless control via frequency inverter - Hydro-mechanical tool clamping, vertical and horizontal - Thread cutting without compensation chuck - Electronic handwheel - 3D probe RENISHAW - Coolant unit (adjacent), capacity approx. 130 liters - Automatic central lubrication - Fixed angle table - Full safety enclosure - 32,279 recorded spindle hours - Swiveling control panel - Operating manual and electrical diagram Required space (L x W x H): 2700 x 3500 x 2100 mm Weight: 3 tons.

Tahun pembuatan: 1980, Kondisi: bekas, nomor mesin/kendaraan: 5103811, Table clamping surface: 440 x 1200 mm Table travel X: 950 mm Bcsdpfx Aeda U Dgjhwjw Table travel Y: 250 mm Table travel Z: 475 mm Spindle taper: ISA 40 Spindle speeds: 40 - 1800 rpm Feedrates longitudinal & cross: 16 - 630 mm/min Feedrates vertical: 5.6 - 224 mm/min Electrical connection: 380 V, 7.5 kVA Space requirement: 2150 x 2000 x 2100 mm Weight: 2400 kg

Tahun pembuatan: 1998, Kondisi: bekas, nomor mesin/kendaraan: 23 800 029, Table clamping surface: 500 x 1600 mm Bcsdpfxe Ici Uo Ahwsw Table travel X: 1220 mm Table travel Y: 500 mm Table travel Z: 500 mm Spindle taper: SK 50 Spindle speeds: 56 - 2800 rpm Feed rates longitudinal and cross: approx. 10 - 1800 mm/min Feed rates vertical: 2.5 - 450 mm/min Electrical connection: 400 V, 16 kVA Required space: 2000 x 2250 x 2150 mm Weight: 4500 kg

Tahun pembuatan: 1967, Kondisi: baik (bekas), nomor mesin/kendaraan: 7011/C, Table clamping surface: 310 x 1400 mm Table travel x-axis: approx. 950 mm Table travel y-axis: 325/345 mm Bsdpfx Ajd Rxw Hehwocw Table travel z-axis: approx. 500 mm Spindle speeds: 20 - 1500 rpm Feeds longitudinal & cross: 18 - 620 mm/min Feeds vertical: 18 - 620 mm/min Electrical connection: 380 V kW Space requirement: 1900 x 1600 x 1750 mm Weight: approx. 1500 kg

Kondisi: siap digunakan (bekas), nomor mesin/kendaraan: 5722, Table clamping surface: 190 x 710 mm Bcjdpfxjflrg Ts Ahwjw Table travel X-axis: 390/360 mm Table travel Y-axis: 150 mm Table travel Z-axis: 280 mm Spindle taper: SK 40 Spindle speeds: 100 – 3100 rpm Longitudinal feed: 0 – 600 mm/min Electrical connection: 380 V, approx. 1.5 kW Required space: 1400 x 1200 x 1500 mm Weight: approx. 680 kg

Kondisi: siap digunakan (bekas), Tahun pembuatan: 1978, nomor mesin/kendaraan: 32392, Table clamping surface: 560 x 240 mm X-axis travel: 300 mm Y-axis travel: 275 mm Z-axis travel: 200 mm Spindle taper: ISO 40 Spindle speeds: 40 - 2000 rpm Operating voltage: 380 V Bcodpfx Ahod Tfciewew Total power requirement: 1.1 kW Space requirement: 1200 x 1100 x 1700 mm Weight: approx. 750 kg

Kondisi: baik (bekas), Working travels X / Y / Z: 475 / 330 / 280 mm Table size (W x D): 650 x 250 mm Bcedpfx Ahed Dgdyjwsw Quill stroke: 60 mm Spindle speed: 63 - 2,800 rpm / 12 steps Spindle taper: ISO 30 / DIN 2080, ISO 40 / DIN 2080 Weight: approx. 950 kg Machine dimensions (W x D x H): approx. 1100 x 1400 x 1600 mm Spindle bore: 17.8 mm (24.8 mm) Range of movement: Longitudinal travel: Table: 330 mm* 1 handwheel revolution: 5 mm Vertical travel: Knee: 475 mm* 1 handwheel revolution: 2 mm Cross travel: Milling spindle carriage head: 400 mm 1 handwheel revolution: 5 mm * These two axes are fitted with automatic feed and can be controlled by programs. Minimum cycle time: 15 seconds or 4 program cycles per minute. Scale drum readout accuracy: 0.02 mm Main motor: Milling head: 2 speed settings Motor: 1.1 / 1.5 kW, 1500 / 3000 rpm Automatic feeds: Rapid traverse motor: 0.55 kW, 1000 rpm Rapid traverse, longitudinal: 2500 mm/min Rapid traverse, vertical: 1000 mm/min Feed drive motor: max. 0.2 kW Adjustment range, longitudinal: 4 - 500 mm/min Adjustment range, vertical: 1.6 - 200 mm/min Coolant system: Motor: 0.15 kW, 3000 rpm Coolant pump flow rate: 20 l/min Coolant tank capacity: 30 l

Kondisi: baik (bekas), A lot of accessories included; only sold as a complete package! Axis travel X / Y / Z: 300 / 300 / 135 mm Table size (W x D): 700 x 190 mm Spindle speed: 95 - 6000 rpm / 11 steps Tool holder: W 20 Weight: approx. 450 kg Machine dimensions (W x D x H): approx. 900 x 900 x 1500 mm Accessories: Swivel table Rotary table, Ø 200 mm Bcsdpfed Erqbsx Ahwew 6 holders Various collets and clamping tools Horizontal milling attachment Work lamp Coolant system Machine vice

Kondisi: baik (bekas), Tahun pembuatan: 1968, Stock number: 2908 Manufacturer: CUGIR Romania Bedpsvc D Apofx Ahwecw Year of manufacture: 1968 Machine number: 3266 Type / Model: FU-1 Travel x-y-z: 700 - 370 - 250 mm Table size: 1,250 x 320 mm Speed range: Spindle taper: SK 50 Feeds: Rapid traverse: Connection: 7.5 kW Accessories/Equipment: Condition: good Weight: approx. 2.5 t Dimensions: 2,000 x 2,000 x 1,700 mm

Kondisi: bekas, Tahun pembuatan: 1967, x-travel: 1100 mm y-travel: 700 mm z-travel: 500 mm Spindle-to-table distance: 9–509 mm Spindle head swiveling: 360° Spindle taper: ISO 40 (SK 40) Spindle speeds: 30–2066 rpm Number of speed ranges: 27 Feed rate: 1.6–820 mm/min Number of feed rates: 27 Clamping surface: 1435 x 460 mm Rapid traverse X and Y axes: 2.8 m/min Rapid traverse Z axis: 1.4 m/min Total power requirement: 10 HP Bjdscxxyzopfx Ahwecw Machine weight approx.: 3.1 t Space requirement approx.: 2.36 x 1.65 x 1.45 m (W x H x D) Universal tool milling machine with 3-dimensional adjustable original Huron universal milling head; head also adjustable for horizontal milling; handwheels and feeds for X, Y and Z working area; main safety machine switch; adjustable work light; coolant system; Heidenhain digital readout.

Kondisi: bekas, Tahun pembuatan: 1980, x-travel: 1600 mm y-travel: 800 mm z-travel: 630 mm Bedpjcxxrnefx Ahwjcw Spindle taper: SK 50 Feed rate: 10–6000 mm/min Rapid traverse: 6 m/min Infinitely variable speed range: 20–2000 rpm Max. table load: 5000 kg Dimensions of control cabinet: 1800 x 530 x 2000 mm Total power requirement: 18 kW Machine weight approx.: 11 t Space requirement approx.: 4.6 x 2.9 x 2.62 m Universal bed milling machine with 4-axis PHILIPS NC 6664 control system with program memory, additional NC-controlled rotary table (diameter 630 mm), hydraulic tool clamping, coolant system, chip conveyor, horizontal and vertical milling spindle (SK 50), separate control cabinet, emergency stop safety function.

Kondisi: bekas, Tahun pembuatan: 1970, x-travel: 900 mm y-travel: 250 mm z-travel: 370 mm Bodpfjcxxqrox Ahwocw Table clamping surface: 1525 x 325 mm Total power requirement: 9.85 kW Machine weight approx.: 3.1 t Space requirement approx.: 2.0 x 2.5 x 1.7 m

Kondisi: siap digunakan (bekas), Tahun pembuatan: 1990, Fungsionalitas: berfungsi sepenuhnya, jarak pergerakan sumbu X: 2.800 mm, jarak lintasan sumbu Y: 1.000 mm, jarak gerak sumbu Z: 1.200 mm, kecepatan spindel (maks.): 2.000 rpm, kecepatan spindel (min.): 50 rpm, en Bcodsyl U Thopfx Ahwew

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2007, Fungsionalitas: berfungsi sepenuhnya, de Bcsdpfewvra Ijx Ahwew

Kondisi: siap digunakan (bekas), Tahun pembuatan: 2011, VF - 2YT Tahun 2010 & 2011 Perjalanan S.A.E METRIK Sumbu X: 30,00 inci (762 mm) Sumbu Y: 20,00 inci (508 mm) Sumbu Z: 20,00 inci (508 mm) Jarak Hidung Spindel ke Meja (~maks): 24,0 inci (610 mm) Jarak Hidung Spindel ke Meja (~min): 4,0 inci (102 mm) Spindel S.A.E METRIK Daya Maksimal: 30,0 hp (22,4 kW) Kecepatan Maksimal: 10.000 rpm Kopling: BT40 ATC 24 posisi Pelumasan Bantalan: Injeksi Udara/Oli Pendinginan: Pendingin Cairan Dilengkapi Meja Putar RT-160 dan RT-160-2 Dilengkapi sistem pengukur alat Bjdex Hc Uqspfx Ahwecw 2 unit

Kondisi: hampir baru (bekas), Tahun pembuatan: 2003, Fungsionalitas: berfungsi sepenuhnya, jarak pergerakan sumbu X: 510 mm, jarak lintasan sumbu Y: 510 mm, jarak gerak sumbu Z: 460 mm, produsen pengendali: MAZATROL 640M 5X, model controller: MAZATROL 640M 5X, tinggi benda kerja (maks.): 405 mm, diameter benda kerja (maks.): 500 mm, berat benda kerja (maks.): 300 kg, lebar meja: 400 mm, panjang meja: 500 mm, kecepatan spindel (maks.): 12.000 rpm, daya motor spindle: 22.000 W, hidung spindel: CAT40, jumlah slot dalam magazin alat: 40, tegangan masuk: 400 V, jenis arus masuk: AC (pendingin udara), Perlengkapan: dokumentasi / manual, kecepatan rotasi dapat diubah tanpa batas, *MAZAK VARIAXIS 500-5X 5-AXIS TWIN PALLET VMC* Kategori: Pusat Pemesinan Vertikal (VMC) Bcodpfx Ahex Adn Uswjw No. Referensi: 3877 Kapasitas: 510 x 510 x 460 mm Tahun Pembuatan: 2003 Spesifikasi Teknis: SPINDEL Taper Spindel: CAT40 Kecepatan Spindel: 12.000 RPM Daya Motor Spindel: 30 HP KAPASITAS KERJA Ukuran Palet: 500 x 400 mm Perjalanan (XYZ): 510 x 510 x 460 mm Sumbu A: -120 / +30 Derajat Sumbu C: 0,001 Derajat Ukuran Maks. Benda Kerja: Ø500 x 405 mm (Tinggi) Bobot Maks. Benda Kerja: 300 kg ATC Kapasitas Ganti Alat: 40 Tool (CAT40) CNC Kontrol: MAZATROL 640M 5X PC-FUSION-CNC Detail Tambahan: Twin Pallet

Kondisi: bekas, Tahun pembuatan: 2004, de-hu-001 Bcsdpowirmnofx Ahwjw

Kondisi: bekas, dehu Bjdpfow Rktbsx Ahwecw

Kondisi: bekas, Tahun pembuatan: 2009, 01 Bodpfx Ahoypv Tdjwjcw

Kondisi: bekas, Tahun pembuatan: 2017, x-Weg 1.100 mm y-Weg 610 mm z-Weg 610 mm Steuerung Heidenhain Tischabmessungen 1.100 x 610 mm Anzahl der Werkzeugplätze 40 Pos. Werkzeugaufnahme SK 40 Die Maschine befindet sich unserer Einschätzung nach in einem guten gebrauchten Zustand und kann nach Terminvereinbarung unter Strom besichtigt werden. Bsdpfsyn R Ndox Ahwocw Zubehör, abgebildete Werkzeuge und Spannmittel gehören nur zum Lieferumfang wenn dies in den Zusatzinformationen vermerkt ist. Aenderungen und Irrtuemer in den technischen Daten und Angaben sowie Zwischenverkauf vorbehalten!
