Beli Pengeboran Pusat bekas (6.388)

Kondisi: sangat baik (bekas), Meja trunnion HAAS TR160H Trunnion dua sumbu (Miring & Berputar) Plug-and-play untuk mesin Haas Aplikasi: Ideal untuk pemesinan kompleks 3+2 dan full 5-axis. Diameter meja putar penjepit: 160 mm Dcedpfxsy Nchij Ag Dsg

Kondisi: bekas, nomor mesin/kendaraan: 008526, arbeitsbereich_achsex_4m Dsdpfx Agey Nx Ulj Djcg

Kondisi: bekas, nomor mesin/kendaraan: 008527, de-1 Dcjdpfsy Nx Ufjx Ag Deg

Kondisi: bekas, Tahun pembuatan: 2008, Fungsionalitas: berfungsi sepenuhnya, Pusat Putar/Milling dengan Spindel Lawan Dengan 10 sumbu CNC (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Kontrol: FANUC 31:iA Spindel Utama Daya spindel: 15/11 kW Diameter batang: 51 mm Putaran spindel: 5000 rpm Spindel Lawan Daya spindel: 11/7,5 kW Diameter batang: 51 mm Putaran spindel: 50000 rpm Spindel Putar/Milling Djdpfx Aoy N Sw Teg Docg Daya: 7,5/3,7 kW Putaran: 12000 rpm Panjang putar maks revolver bawah: 1005 mm Perjalanan sled X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 / 1090 / 1005 / 1008 mm Perjalanan sled Y1/ Y2: + - 70 / + - 50 mm Rentang putar sumbu B1: + - 95 ° Majalah rak linear termasuk robot pendukung Steady rest CNC Sistem filter siklon cairan pendingin termasuk 2 pompa cairan pendingin Pendingin oli spindel

Kondisi: bekas, Tahun pembuatan: 1971, Fungsionalitas: berfungsi sepenuhnya, drehdurchmesser_900mm_bett Dcedpfjy N Sw Hex Ag Deg

Kondisi: diremajakan ulang (bekas), Tahun pembuatan: 2022, Fungsionalitas: berfungsi sepenuhnya, Drehdurchmesser-ueber-Bett-540-mm Dcsdpfx Aoy N Swyjg Dog

Kondisi: baik (bekas), live centre, revolving centre, live Morse taper, live centre point, live lathe centre, centre cone - Live centre point: shaft-mounted - Taper: MT3 - Dimensions: Ø 60 x 155 mm Dcjdpem U A Exefx Ag Deg - Weight: 1.2 kg

Kondisi: sangat baik (bekas), Tahun pembuatan: 2018, Fungsionalitas: berfungsi sepenuhnya, Kontrol: Siemens SL Tempat alat: 160 Tipe dudukan alat: HSK 63 Kecepatan spindel: 10.000 rpm / 242N Ukuran palet: 630×500 mm Jumlah palet: 2 Sumbu X: 800 mm Dodpfxoy N Unhs Ag Dscg Sumbu Y: 800 mm Sumbu Z: 1000 mm Kapasitas beban meja maksimal: 1000 kg

Kondisi: sangat baik (bekas), Tahun pembuatan: 2020, Pusat pembubutan multi-fungsi CNC dengan 9 sumbu Spindel balik, sumbu Y, spindle milling, dan revolver dengan alat potong bertenaga Spindle milling: X: 630 mm Y: 230 mm Dcedpfx Aoy N T Dujg Dog Z: 1585 mm Sumbu putar: 240° 40 posisi alat Capto C6 Pompa pendingin 20 bar Revolver (bawah): X2: 220 mm Z2: 1515 mm 12 alat potong bertenaga Pompa pendingin 10 bar Jarak gerak spindel balik: 1550 mm Spindel utama: Chuck 10" Lubang batang: 75 mm Spindel balik: Chuck 10" Lubang batang: 73 mm Kontrol: FANUC F3B5 dengan layar 15" Perlengkapan: beragam aksesoris skimmer minyak lengan pengukur alat lepas-pasang AC kabinet kontrol aik AICC II (600 blok) Konveyor serbuk LNS, tipe sabuk engsel kanan

Kondisi: hampir baru (bekas), Tahun pembuatan: 2020, jam operasional: 16.785 h, Fungsionalitas: berfungsi sepenuhnya, jarak pergerakan sumbu X: 800 mm, jarak lintasan sumbu Y: 500 mm, jarak gerak sumbu Z: 610 mm, CNC machining center Make: Fehlmann Type: Picomax 95 Year: 2020 Technical Data: Manufacturer: Fehlmann Dcedpfx Aoy Ny A Djg Djg Type: Picomax 95 Year of manufacture: 2020 Operating hours: 16,785 / 7,181 spindle hours Spindle speed: 50 - 18,000 rpm Spindle power: 25.2 kW Max. torque: 120 Nm at 50-2010 rpm Control: Heidenhain TNC 640 X-axis: 800 mm Y-axis: 500 mm Z-axis: 610 mm Machine table: 1600 x 550 mm with 10 slots 12H8 at 50mm intervals Positioning accuracy XYZ: as per ISO 230-2: A = 0.005 mm / R = 0.003 mm Electrical connection: 400 V 3P+N+E / 50 Hz / 63 A (T) Standard Equipment: - Standard feed range: 1 - 30,000 mm/min - Automatic tool changer, operator-side accessible and can be loaded in parallel to main time, including extended Fehlmann tool management on TNC 640 - Direct path measuring system with pneumatic support in XYZ - Compressed air cleaning through activated carbon filter - Coolant system with chip drawer and fine chip filter insert, coolant spray gun, chip flushing, machine shut-off via M-function - Cooled motor spindle and Y-axis drive - Compensation of spindle and thermal expansion - Graphical machine diagnostics system via softkey - Drawer block bottom-right - Interfaces: RJ45, USB, RS232 - 48-position chain magazine HSK-A63, tool changer with double gripper. Magazine operator-side accessible and can be loaded in parallel to main time - Electronic handwheel HR 510 for TNC 640 - Active recooler for spindle and Y-axis drive cooling - Enclosure of machining area with polycarbonate safety windows, powder-coated, with wide-opening stainless steel sliding door at front and top for crane loading - Left side door with lockable polycarbonate window - Chip flushing through machine bed - FEHLMANN cycle package Special Equipment: - Automatic length compensation of the milling spindle via direct measuring system - Tool clamping system HSK-A63 - Leakage sensor for monitoring coolant supply through the spindle - Automatic right enclosure door for PICOMAX 95 - Profi-Net robot interface for PICOMAX per Fehlmann interface description, for customer-specific robotic solutions - Coolant unit 700 | BF/HD80, with spindle cooling at 80 bar and chip conveyor - Emulsion and oil mist extraction system, program-controlled via M-function: on, off, intermittent - 3D probe system Blum TC52LF incl. spindle holder HSK-A63 - LaserControl Blum LC50-DIGILOG for measuring and monitoring tools from Ø 0.02 to 120 mm - Reference tool HSK-A63, Ø 8 mm - FEHLMANN 5-axis cycle package Automatic indexing and swiveling unit ATS 200 D - with Schunk TANDEM center vise KSP100 Automation - Unirobot pro Unirobot M-20iA-10P pro Robot: Fanuc 6-axis industrial robot - Manipulator: FANUC M-20iA - Max. payload: 20 kg - Programming hand unit Safety fence system uniprotect Drawer system incl. ALB workpiece carrier - 10 pneumatic drawer workpiece carriers (400 x 600 mm) FMB quick-change head Workpiece detection via light barrier Profinet interface Robot cell including program creation - Two-jaw double gripper system pro Gripper modules SCHUNK JGP 100-1 Max. workpiece weight: 3.3 kg All information without guarantee. A demonstration is possible at any time in our exhibition hall.

Kondisi: bekas, Tahun pembuatan: 1998, Fungsionalitas: berfungsi sepenuhnya, Perjalanan sumbu X/Y/Z: 1800mm/850mm/750mm Rentang jarak spindle ke meja: 200mm-950mm Jarak tengah spindle ke kolom: 920mm Dedoy N Suxspfx Ag Decg Dimensi meja X/Y: 2000mm/800mm Beban maksimum meja: 2200kg Tipe pemasangan alat: NT50 Kecepatan putar: 6000rpm Feedrate: 5m/menit Rapid traverse: 12m/menit Dimensi mesin X/Y/Z: sekitar 5700mm/3850mm/3350mm Berat: sekitar 16500kg Kontrol: Heidenhain Jam operasional: sekitar 51000 jam Jam spindle: sekitar 26000 jam Dokumentasi tersedia Inspeksi di lokasi dimungkinkan.

Kondisi: sangat baik (bekas), Tahun pembuatan: 2008, Used CNC Machining Center Manufacturer: IMA Model: BIMA 300 125/430 Year of manufacture: 2008 4-axis CNC machining center with console table 8 manually movable supports in X direction, 3 vacuum cups per console, vacuum pump 90 m³/h vacuum connector for templates LED display for vacuum cup position indication Working area X: 200 – 4300 mm Working area Y: 0 – 1400 mm (milling/drilling), Working area Z: 12 – 125 mm (clearance 150 mm) Additional central stop rail 14 vertical drilling spindles + 6 horizontal Horizontal drilling and grooving saw unit, swivels 90° Milling spindle 7.5 kW up to 18,000 rpm with C-axis, 360° interpolation, liquid circulation cooling – 18-position tool changer on y-support, traversing Edgebanding unit VT 100, 4-sided/all-round – swiveling range 740 degrees with dual-roll magazine, automatic granulate feed Adapter units: – Saw, fixed at 90° Dcedpfx Agey Nzw Ns Dsg – 4-spindle crosshead Control: ICOS open 231 with 17″ TFT UPS ImaWop 10.0 incl. MDE and production list software Safety fence on right side and front pressure-sensitive mats; rear: wall installation or separate safeguarding required

Kondisi: sangat baik (bekas), Tahun pembuatan: 2021, Fungsionalitas: berfungsi sepenuhnya, used 5-axis CNC machining center Manufacturer: Homag Model: Centateq 110 (5-axis) Year of manufacture: 2021 Last manufacturer service: 18.05.2026 Console table with LED suction cup position indicator, 6 manually adjustable consoles (length 1360 mm) each with 3 vacuum cups, 4 support rails Workpiece clamping via vacuum pump 63 m³/h LED system for vacuum fixtures, Dcjdpfxey Nzc Ss Ag Dsg X-axis working range: 3100 mm Y-axis working range: up to 1250 mm with front stop; up to 1405 mm at rear with 25 mm tool diameter Z-axis working range: 260 mm / 160 mm with standard suction cups Drilling head: 12 vertical spindles; 6 (4+2) horizontal drilling spindles, Grooving saw at 90°, tiltable, max. 125 mm dia. Main spindle: DRIVE Future 10 kW, liquid cooled, 1500 – 24,000 rpm 14-position tool changer (carousel) at rear and 10-position fixed linear tool changer at side Aggregate carrier for 2 Z-axes (main spindle + drilling unit) Chip conveyor, program-controlled extraction hood Power-Control PC 86 POWERTOUCH with Woodwop (incl. Lamello CLAMEX-P component), WoodWop also for AV workstation (Office Professional version; DXF-Import Basic) UPS for PC; Tapio Ready compatible Basic barcode reading system Documentation: German Pictured tools, HSK tool holders, drills, etc. are not included in the scope of delivery! Machine available from end of May 2026 The attached PDF file for the machine description refers to the machine’s original delivery status from the manufacturer in 2021 and is not binding for the current delivery status as a used machine.

Kondisi: bekas, CNC vertical machining center FEHLMANN type PICOMAX 60 CNC control HEIDENHAIN TNC 426 Serial No. 14599641 Year of manufacture: 1999 Travel ranges X: 500 mm, Y: 350 mm, Z: 610 mm Feed rate 1 - 20,000 mm/min Rapid traverse 20 m/min Feed force: 12,000 N Clamping surface of the table 920 x 380 mm T-slots 7 pcs, 12-H8 mm Max. table load 250 kg Table height 1,004 mm Distance spindle nose - table 94 - 704 mm Spindle overhang - column 405 mm Spindle speed 50 - 18,000 rpm, stepless Spindle drive 10.2 kW (60% duty cycle) Max. torque 70 Nm (up to 1,240 rpm) Spindle taper SK 30 / DIN 69871A Dcsdoy N Du Dspfx Ag Djg Pull stud DIN 69872 Drilling capacity in steel 25 mm Milling capacity in steel / aluminium 100 / 700 cm³/min Tapping capacity in steel / aluminium M20 / M24 Tool changer 24 positions Tool change time approx. 6 sec. Chip-to-chip time approx. 8 sec. Control Heidenhain TNC 426 Power supply 400 Volt, 50 Hz Connected load 20 kW - Electronic handwheel Heidenhain HR410 - 3D probe Renishaw MP12 - Tool measurement system - TFT display - Direct path measuring system - Coolant system 200 liters, external - Spindle cooling unit, external - Central lubrication Vogel - Pneumatic supply 6 bar, 40 - 200 l/min - Oil mist extraction - Operating hours: - Control on 97,000 h - Machine on 80,000 h - Program run 42,000 h Space required L x W x H 2,000 x 1,700 x 3,000 mm Weight approx. 3.2 tons Good condition

Kondisi: baik (bekas), Tahun pembuatan: 2001, Fungsionalitas: belum diuji, jarak pergerakan sumbu X: 350 mm, jarak lintasan sumbu Y: 240 mm, jarak gerak sumbu Z: 340 mm, gerak cepat sumbu X: 20 m/menit, model controller: Siemens Sinumerik 840 D, tinggi total: 2.100 mm, panjang total: 3.800 mm, lebar total: 3.600 mm, beban meja: 100 kg, kecepatan rotasi (maks.): 15.000 rpm, berat keseluruhan: 1.600 kg, For sale is a 5-axis machining center from DMG, model DMU 35 M, equipped with two manual axes. The machine is in good condition. Technical Data: DMU 35 M Djdpfx Agjy Nz Nrs Dscg Year of manufacture: 2001 X-axis: 350 mm Y-axis: 240 mm Z-axis: 340 mm Spindle speed: 15,000 rpm Feed rate: infinitely variable up to 5,000 mm/min Rapid traverse: 20 m/min Clamping surface: Ø 400 x 280 mm Swivel range: 360° (mechanical) Table clamping range: +105° / -150° (mechanical) Max. table load: 100 kg Tool holder: SK 40 Tool clamping: pneumatic/mechanical Space requirement: 3,800 x 3,600 x 2,100 mm Transport dimensions: approx. 2,000 x 1,700 x 2,100 mm Weight: 1,600 kg Transport and loading can be organised Europe-wide for an additional charge, if required. Prices are subject to VAT. Viewings are possible by appointment. Contact us—our team looks forward to assisting you. Trade-in or exchange possible! Machinery purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MORE. Do you need a high-quality yet affordable metalworking machine for your production? Or would you like to sell yours? For further information or to get in touch, please visit our website.

Kondisi: sangat baik (bekas), Tahun pembuatan: 2007, Kontrol Mitsubishi 64S Perjalanan sumbu X/Y/Z: 600 x 400 x 460 mm Ukuran meja: 700 x 410 mm Kapasitas beban meja: 250 kg Kecepatan spindle: 12.000 rpm Majalah alat untuk 24 alat, BT 40 IKZ 20 bar Unit penyedot debu Dcsdpfx Agjy N D Hgo Dsg Konveyor serpihan

Kondisi: sangat baik (bekas), Tahun pembuatan: 2025, machinery-details-2024-01 Dsdpfoy N D Rxjx Ag Decg

Kondisi: sangat baik (bekas), CNC flexible line for drilling, milling, and dowel insertion BECKHOFF control (Windows-based software) Workpiece length min/max: 260 mm / 2500 mm Workpiece width min/max: 96 mm (*) / 1200 mm Workpiece thickness min/max: 13 mm / 25 mm (*) Minimum panel width for dowel insertion at the 3rd BAT: 120 mm A) Platen feeder "Igel" for loading, with transverse infeed roller conveyor B) 1st pass CNC Mod. BAT-DTW - 2 drilling units, each with 21 spindles (2 x 2.2 kW) - 1 grooving saw (2.2 kW) - 2 grooving saws for back panel grooves (2 x 0.37 kW) - 2 drilling units, each with 12 spindles (2 x 2.2 kW) - 1 router for transverse shutter groove (4.4 kW) Dodpey N Ucfsfx Ag Decg C) 2nd pass CNC Mod. BAT-DTW - 4 drilling units, each with 9 spindles (4 x 1.6 kW) - 2 angular drilling units, each with 3 spindles (2 x 1.6 kW) - 1 router (4.4 kW) - 2 drilling units, each with 5 spindles (2 x 1.6 kW) D) 3rd pass CNC Mod. BAT-DTW - 1 horizontal glue application device (with glue pump and 13-way air glue distributor) - 1 dowel insertion unit - Milling unit with 8-position tool changer (5 collets) - Drilling unit with 12 individually controlled twin spindles

Tahun pembuatan: 2007, Kondisi: bekas, de-20240611-01 Dcedpfxsy N Da Te Ag Dsg

Kondisi: bekas, Tahun pembuatan: 2006, x-weg-450-mm-de-source Djdpfx Agjy Nn Ets Docg

Kondisi: sangat baik (bekas), Dijual meja putar CNC merek ternama Fadal Engineering (USA), model VH65. Sumbu ke-4 profesional untuk pusat pemesinan, khususnya Fadal VMC, namun juga dapat diintegrasikan dengan mesin CNC lain menggunakan kontroler yang sesuai. Spesifikasi teknis: • Model: VH65 • Diameter piringan: 165 mm (6,5”) • Rasio transmisi: 90:1 • Rem pneumatik (M60 ON / M61 OFF) • Konektor industri multipin • No. seri: 4630298 Kondisi: bekas, berfungsi secara mekanis, menunjukkan tanda-tanda pemakaian normal. Konstruksi kuat dan berat – ideal untuk pemesinan presisi 4-sumbu. Dedjw R St Njpfx Ag Docg

Kondisi: sangat baik (bekas), For sale: robust WEMAS column milling machine, model FM23. Rigid cast iron construction — ideal for toolrooms and maintenance workshops. Machine is fitted with a 3-axis DRO D60-3V digital readout system and Rascher Nürnberg–München linear scales. Table with longitudinal T-slots, coolant system with separate tank and pump. Vertical spindle with precision collet and adjustable feed. Power supply 3×400 V. Complete machine, after current maintenance inspection, runs smoothly, ready for power-on tests. Normal signs of use; no excessive play or defects. Included in price: 3-axis DRO display, linear scales on X/Y/Z axes, coolant tank and pump, cables, power roller, work light. Additional details from photos: "WEMAS" and "FM23" nameplates, spindle adjustment correction plate, DRO panel with mm/inch, ABS/INC, calculator functions. Working parameters, spindle taper, and speed ranges to be confirmed on site – I can measure table dimensions and X/Y/Z travels upon request. Forklift loading available. Assistance with transport logistics provided. Dcsdpfx Agsw I Hzpe Djg

Kondisi: sangat baik (bekas), Tahun pembuatan: 1989, For sale: Mazak QuickTurn 20N CNC lathe. The machine is in very good condition. Equipment includes: MAZATROL T-2, MAZATROL CAM-T-2 control system. Djdpfx Agsu U R E Ao Dscg

Kondisi: sangat baik (bekas), Tahun pembuatan: 2006, Heller MCH 250 4 sumbu Tahun pembuatan: 2006 Kontrol: Siemens 840 D Kecepatan spindle: 12.500 rpm Dedpfx Agey Nycko Djcg Perjalanan sumbu X: 800 mm Y: 800 mm Z: 800 mm Ukuran palet: 630 x 630 mm Panjang alat maksimal: 600 mm

Kondisi: sangat baik (bekas), Tahun pembuatan: 2006, Heller MCH 280 C 5 sumbu Tahun Pembuatan: 2006 Kontrol: Siemens 840 D Kecepatan spindel: 8000 rpm Djdpfxsy Nybge Ag Dscg Perjalanan: X: 1000 mm Y: 1200 mm Z: 1100 mm Ukuran palet: 630 x 630 mm Meja putar: 360.000° x 0,001° Posisi alat di majalah: 400 Perkakas penahan: HSK 100
